Bose OE2i User manual

BOSE®OE2iAUDIO
HEADPHONES
| | |
©2011 Bose Corporation, The Mountain,
Framingham, MA 01701-9168 USA
AM346800 Rev.00
BOSE®OE2iAUDIO HEADPHONES
Cover 3.9x3.7 with spine 17L_OE2i.fm Page 1 Tuesday, May 3, 2011 10:58 AM

2
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Safety Information
Please read this owner’s guide
Please take the time to follow the instructions in this owner’s guide
carefully. It will help you set up and properly use your new
headphones. Please save this owner’s guide for future reference.
CAUTIONS:
• Long-term exposure to loud music may cause hearing damage. Please avoid
extreme volume when using headphones, especially for extended periods.
• Do not use headphones when operating a motor vehicle or anywhere the
inability to hear outside sounds may present a danger to you or others.
Check and follow local laws regarding headphone use.
• Sounds that you rely on as reminders or warnings may have an unfamiliar
character when using headphones. Be aware of how these sounds may
vary in character so you can recognize them as needed.
• Do not drop, sit on, or allow the headphones to be immersed in water.
This product conforms to all applicable EMC Directive
requirements. The complete Declaration of Conformity can
be found at www.Bose.com/compliance.
WARNING: DO NOT use mobile phone adapters to connect head-
phones to airplane seat jacks, as this could result in personal injury
such as burns or property damage due to overheating. Remove and
disconnect immediately if you experience warming sensation or loss
of audio.
OE2i Headphones_ENG.fm Page 2 Friday, July 1, 2011 12:25 PM

3
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
Introduction
Thank you for purchasing the Bose®OE2i audio headphones.
Enjoy your music with smooth, full range sound, a comfortable
on-ear fit and a contoured design that folds up for easy portability.
An in-line remote and microphone provide convenient control of
select Apple products.
For use with:
The remote and microphone are supported only by iPod nano
(4th generation and later), iPod classic (120GB, 160GB),
iPod touch (2nd generation and later), iPhone 3GS, iPhone 4,
iPad, iPad 2 and 2009 models or later of MacBook and
MacBook Pro. The remote is supported by iPod shuffle (3rd
generation and later). Audio is supported by all iPod models.
OE2i Headphones_ENG.fm Page 3 Friday, July 1, 2011 12:25 PM

4
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Components
L
Carry case
Adjustable
headband
Earcup
cushions L mark
Remote and
microphone
Volume up
Answer/End
Volume down
Audio cable
2.5mm
3.5mm
R mark
OE2i Headphones_ENG.fm Page 4 Friday, July 1, 2011 12:25 PM

5
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
Storing your headphones
❶❷❸
Note: Do not try to exceed the limits of the pivots or over-rotate the
earcups.
OE2i Headphones_ENG.fm Page 5 Friday, July 1, 2011 12:25 PM

6
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Using your headphones
Wearing the headphones
After removing the headphones from the case and unfolding them
(see page 5), put on the headphones using the markings that
identify the left (L) and right (R) earcups. Adjust the headband so it
rests gently on top of your head and the earcup cushions fit
comfortably on your ears.
Cleaning the headphones
The Bose®OE2iaudio headphones do not require scheduled
cleaning. Should cleaning be necessary, simply wipe the outside
surfaces with a soft cloth. Be sure the earcup ports are kept clear,
and that no moisture is allowed to get inside the earcup.
Connecting to your Apple device
Ensure that the 2.5mm plug is securely inserted into the left earcup.
Plug the other end of the cable (3.5mm plug) securely into the audio
output jack of the Apple audio device.
OE2i Headphones_ENG.fm Page 6 Friday, July 1, 2011 12:25 PM

7
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
Using the headphones with your Apple device
The Bose OE2iheadphones come with a small in-line remote with an
integrated microphone for convenient control of select Apple products.
Easily control volume, track selection and voice applications, plus
switch between your calls and music.
Note: Full controls may not be available for some Apple products.
Basic functions
Call-related functions
Increase volume Press and release the +button.
Decrease volume Press and release the –button.
Answer a call When you receive an incoming call, press
and release the Answer/End button to
answer.
End a call Press and release the Answer/End
button.
Decline an incoming
call Press and hold the Answer/End button for about two seconds, then release.
Switch to an incoming
or on-hold call and
put the current call on
hold
While on a call, press and release the
Answer/End button once. Press and
release again to switch back to the first
call.
OE2i Headphones_ENG.fm Page 7 Friday, July 1, 2011 12:25 PM

8
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Media playback functions
Replacement parts and accessories
Replacement parts and accessories such as the carry case,
earcup cushion, and the audio cable can be ordered through
Bose®Customer Service. See the contact information for your
area included in this guide.
Switch to an incoming
or on-hold call and
end the current call
While on a call, press and hold the
Answer/End button for about two
seconds, then release.
Use Voice Control Press and hold the Answer/End button.
See iPhone User Guide for compatibility
and usage information about this feature.
Play or pause a song
or video Press and release the Answer/End button.
Skip to the next
song or chapter Press and release the Answer/End button twice quickly.
Fast-forward Press and release the Answer/End button
twice quickly and hold the second press.
Go to the previous
song or chapter Press and release the Answer/End button three times quickly.
Rewind Press and release the Answer/End button
three times quickly and hold the third press.
OE2i Headphones_ENG.fm Page 8 Friday, July 1, 2011 12:25 PM

9
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
Troubleshooting
If you experience any trouble using your headphones, try the
following troubleshooting instructions
If any problem persists, contact Bose®Customer Service. See the
phone number for your area, included in this guide.
Problem What to do
No audio or
audio in one
earcup only
• Ensure both ends of the audio cable are
securely connected.
• Try a different audio device.
Distorted bass • Ensure both earcup cushions are firmly secured.
Misshaped
earcup cushion • The high-density earcup cushion foam will regain its shape after a few minutes in a neutral position.
Microphone is
not picking up
sound
• Make sure the headphone plug is securely
connected to the headphone jack.
• Make sure the microphone is not being blocked
or covered.
The microphone is located on the back of the
Answer/End button.
Phone is not
responding to
button presses
• Make sure that the headphone plug is securely
connected to the headphone jack.
• For multi-press functions: vary speed of presses.
Apple product is
not responding
to remote
• Full controls may not be available for some Apple
products.
OE2i Headphones_ENG.fm Page 9 Friday, July 1, 2011 12:25 PM

10
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Replacing earcup cushions
Remove earcup cushion:
1. Grasp the earcup cushion securely.
2. Pull up and out to remove the earcup cushion.
Re-attach earcup cushion:
1. Place the edge of the earcup cushion skirt into the slot behind
the earcup flange.
2. Work the remainder of the skirt into the slot all the way around
the earcup.
Re-attachRemove
OE2i Headphones_ENG.fm Page 10 Friday, July 1, 2011 12:25 PM

11
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
Limited Warranty
Your Bose®headphones are covered by a limited warranty. Details
of the limited warranty are provided on the product registration
card that is included in the carton. Please refer to the card for
instructions on how to register. Failure to register will not affect
your limited warranty rights.
What you must do to obtain Limited Warranty Service:
Return product, with proof of purchase from an authorized Bose
dealer, using the following procedures:
1. Contact the Bose organization in your country/region (visit
Global.Bose.com/register for Bose contact information in your
country/region) for specific return and shipping instructions;
2. Label and ship the product, freight prepaid, to the address
provided by the Bose organization in your country; and
3. Place any necessary return authorization number prominently
on the outside of the carton. Cartons not bearing a return
authorization number, where required, will be refused.
Note: The serial number is located on the warranty card included in
the carton.
OE2i Headphones_ENG.fm Page 11 Friday, July 1, 2011 12:25 PM

12
English
Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14
Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part
Name
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
(CR(VI))
Polybrominated
Biphenyl (PBB)
Polybrominated
diphenylether (PBDE)
PCBs X0 0 0 0 0
Metal
parts X0 0 0 0 0
Plastic
parts 00 0 0 0 0
Speakers X0 0 0 0 0
Cables X0 0 0 0 0
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous
materials for this part is below the limit requirement in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement in SJ/T
11363-2006.
OE2i Headphones_ENG.fm Page 12 Friday, July 1, 2011 12:25 PM

13
English Tab 6, 12 Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11
©2011 Bose Corporation. No part of this work may be reproduced,
modified, distributed, or otherwise used without prior written
permission.
Apple, iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle,
iPod touch and MacBook are trademarks of Apple Inc., registered
in the U.S. and other countries.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean
that an electronic accessory has been designed to connect
specifically to iPod, iPhone, or iPad, respectively, and has been
certified by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that
the use of this accessory with iPod, iPhone, or iPad may affect
wireless performance.
OE2i Headphones_ENG.fm Page 13 Friday, July 1, 2011 12:25 PM

BOSE CORPORATION
USA
The Mountain,
Framingham, MA, 01701
888 757 9943
owners.Bose.com
Canada
9133 Leslie Street,
Suite 120, L4B 4N1
800 905 2177
www.Bose.ca
Australia
Unit 3/2 Holker
St.Newington NSW, 2127
1 800 061 046
www.Bose.com.au
Belgique/Belgie
B-3700 Tongeren
012 390 800
www.Bosebelgium.be
China
2203-2305 22F, West Gate
Tower/1038 West Nanjing
Road-MeiLongzhen Plaza,
Shanghai, 200041
86 400 880 2266
www.Bose.cn
Denmark
2605 Brondby
4343 7777
www.Bose.dk
Deutschland
D-61381 Friedrichsdorf
0 6172 71040
www.Bose.de
France
78100 Saint Germain en
Laye
01 30 61 67 39
www.Bosefrance.fr
India
Shriram Bhartiya Kala
Kendra, 1 Copernicus
Marg, New Delhi, 100-001
1 800 11 2673
www.Boseindia.com
Ireland
Castlebury Road,
Carrickmacross, Co
Monaghan
42 967 1500
www.Bose.ie
Italia
Via della Magliana 876
Roma, 00148
800 832 277
www.Bose.it
Japan
Mexico
PaseodelasPalmas#405,
11000
001 866 693 2673
www.Bose.com.mx
Nederland
1135 GE Edam
0299 390290
www.Bose.nl
New Zealand
0800 501 511
www.Bose.co.nz
"OSE++
3HIBUYA94"UILDING
-ARUYAMACHO
3HIBUYAKU4OKYO

WWW"OSECOJP

Norge
N-2213 Kongsvinger
62 82 15 60
www.Bose.no
Österreich
Wienerbergstrasse 7
(10.OG)
01 6040 4340
www.Bose.at
Schweiz
Hauptsrasse 134
061 975 77 33
www.Bose.ch
Sverige
S-43153 Mölndal
031 878850
www.Bose.se
United Kingdom
1 Ambley Green,
Gillingham Business Park,
Gillingham, Kent, ME8 ONJ
0844 209 2630
[email protected]
Hong Kong
Suite 1203, Midas Plaza, 1
Tai Yau Street, San Po
Kong, Kowloon, Hong
Kong
852 2123 9000
[e-mail]
Finland
Kornetintie 6b Helsinki, 380
010 778 6900
www.Bose.fi
Poland
ul. Woloska 12
Warszawa, 02-675
[phone]
www.Bose.pl
World Wide Web
www.Bose.com
www.Boseeurope.com

BOSE®OE2iAUDIO
HEADPHONES
| | |
©2011 Bose Corporation, The Mountain,
Framingham, MA 01701-9168 USA
AM346800 Rev.0
BOSE®OE2iAUDIO HEADPHONES
Cover 3.9x3.7 with spine 17L_OE2i.fm Page 1 Tuesday, May 3, 2011 10:58 AM
