Owner’s Manual
Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (the leaet “USING THE UNIT SAFELY”and the
Owner’s Manual (p. 23)). After reading, keep the document(s) where it will be available for immediate reference.
© 2019 Roland Corporation
* The power to this unit will be turned o automatically after a predetermined
amount of time has passed since it was last used for playing music, or its
buttons or controls were operated (AUTO OFF function).
If you do not want the power to be turned o automatically, disengage the AUTO
OFF function (p. 5).
5Unsaved data is lost when the power turns o. Before turning the power o,
save the data that you want to keep.
5To restore power, turn the power on again.

2
Panel Descriptions
Top Panel
1 2
5 6
9 10
3
4
7 8
1 Display
Shows the number of the current phrase memory, and
various other information.
2 [VALUE] knob
Selects the parameter that’s shown in the display, or
edits the value.
3 [MENU] button
Accesses various parameters.
MEMO
By pressing the [MENU] button and [EXIT] button simultaneously,
you can save the phrase (p. 17).
4 [EXIT] button
Used to navigate through the menu shown in the
display.
5 LOOP indicator
The indicators around the edge light according to the
status of recording, overdubbing, or playback.
The center of the indicator shows the division (TRK 1,
TRK 2) of the loop that’s playing.

Panel Descriptions
3
6 [LEVEL] (LOOP) knob
Adjusts the volume of the phrase loop.
7 [LEVEL] (RHYTHM) knob
Adjusts the volume of the rhythm.
8 RHYTHM indicator
The indicators around the edge light according to the
rhythm playback status.
The center of the indicator shows the division (INTRO,
PTN 1, PTN 2, ENDING) of the rhythm that’s playing.
9 [LOOP] switch
Switches between recording, overdubbing, and
playback.
For an empty phrase
Recording -> Overdubbing -> Playback
For a phrase that contains data
Playback -> Overdubbing
During playback or overdubbing
Hold down the switch for two seconds or longer to
Undo (cancel the recording or the last overdub).
Hold down the switch once again for two seconds or
longer to Redo (cancel the Undo).
While stopped
Hold down the switch for two seconds or longer to clear
the phrase.
10 [RHYTHM] switch
While the rhythm is stopped
Press the switch to play the rhythm.
Hold down the switch for two seconds or longer to turn
SYNC on/o (p. 10).
While the rhythm is playing
Press the switch to add a ll-in.
Hold down the switch for two seconds or longer to
switch the division (PTN 1/PTN 2).
Press the switch twice in succession to stop playback.

Panel Descriptions
4
Rear Panel (Connecting Your Equipment)
A B C D
A INPUT (A/MONO, B) jacks
Connect your guitar, bass, or eect unit here.
Use the A and B jacks if connecting an eect unit that
has stereo output. Use only the A jack if using this unit
in mono.
B OUTPUT (A/MONO, B) jacks
Connect this jack to your amp or monitor speakers.
Use only the OUTPUT A jack if using this unit in mono.
Even sound that is input in stereo is output in mono.
Turning On/O the Power
* Once everything is properly connected, be sure to
follow the procedure below to turn on their power. If
you turn on equipment in the wrong order, you risk
causing malfunction or equipment failure.
The DC IN jack also operates as the power switch. The
power turns on when you insert a plug into the DC IN
jack. The power turns o when you remove the plug.
When powering up
Power-up equipment such as your guitar amp last.
When powering down
Power-down equipment such as your guitar amp rst.
Caution when turning o the power
* Never turn o the power in the following states (don’t
remove the plug from the DC IN jack). You risk losing all of
the saved data.
5While the LOOP indicator is rotating (during recording,
overdubbing, or playback)
5While the display indicates“LOADING…” or“EXECUTING…”
(while switching, saving, deleting, or loading phrase
memory)

Panel Descriptions
5
* Before turning the unit on/o, always be sure to turn
the volume down. Even with the volume turned down,
you might hear some sound when switching the unit
on/o. However, this is normal and does not indicate a
malfunction.
AUTO OFF Settings
If you don’t need the power to turn o automatically,
set “AUTO OFF” to “OFF.”
1. From the Menu screen 0“SYSTEM” 0select “AUTO OFF”
and press the [VALUE] knob to conrm.
2. Turn the [VALUE] knob to change the value.
OFF The power will not turn o automatically.
ON The power will automatically turn o when 10 hours have
passed since you last played or operated the RC-10R.
3. Press the [EXIT] button several times to return to the top
screen.
C CTL 1, 2/EXP jacks
You can connect a footswitch (sold separately: FS-5U,
FS-6, FS-7) and use it to control various functions.
&For details, refer to“Parameter Guide (English)”
(PDF).
* Use only the specied expression pedal. By connecting
any other expression pedals, you risk causing
malfunction and/or damage to the unit.
D DC IN jack
Connect the included AC adaptor to this jack.
* Use only the included AC adaptor. Using any other
adaptor may result in malfunctions or electric shock.
* To prevent malfunction and equipment failure, always turn
down the volume, and turn o all the units before making
any connections.

Panel Descriptions
6
Side Panel (Connecting Your Equipment)
E F
E MIDI jacks
Connect an external MIDI device here. You can
synchronize an external MIDI device with this unit.
To make this connection, use a TRS/MIDI connecting
cable (sold separately: BMIDI-5-35).
NOTE
Do not connect an audio device here. Doing so will
cause malfunctions.
F USB port
Connect your computer using a commercially available
USB cable that supports USB 2.0.
You can use your computer to read or write the RC-10R’s
phrases, and synchronize an external USB MIDI device
with the RC-10R.
&For details, refer to“Parameter Guide (English)”
(PDF).
* Do not use a micro USB cable that is designed only for
charging a device. Charge-only cables cannot transmit
data.

7
Phrase Memory
A combination of a track with a rhythm pattern is called a
“phrase memory.”You can store up to 99 dierent phrase
memories.
Rhythm
The rhythm consists of four divisions: INTRO, PTN 1, PTN 2,
and ENDING. Additionally, the PTN 1 and the PTN 2 each have
their own ll-in.
Looper
The looper consists of two divisions: TRK 1 and TRK 2. You can
use this to record and play back the sound of your guitar or
bass.
SYSTEM
This contains overall settings for the entire RC-10R.
&For details, refer to “Parameter Guide (English)”(PDF).
How the RC-10R Is Organized
“Recording” and “Overdubbing”
In this manual, “recording”refers to the rst recording that
you make on an empty track, and “overdubbing”refers
to the second and subsequent recordings that you layer
onto the rst recording.
Phrase Memory 99
RC-10R
Phrase Memory 1
Looper
Rhythm
SYSTEM
PTN 2
TRK 2
INTRO
ENDING
PTN 1
TRK 1

8
Basic Operation
Workow
The RC-10R lets you use“rhythm playback,”“loop recording,” and “rhythm playback + loop recording.”
INTROINTRO
Automatic
(to PTN 1)
Rhythm
([RHYTHM] switch)
Looper
([LOOP] switch)
Press
(switch)
Two
seconds
Press
(ll in)
Once
PTN 1PTN 1
TRK 1TRK 1
SYNC = ONSYNC = ON
SYNC = ONSYNC = ON
“Looper operation” (p. 10)
Press
(record/play TRK 1)
Once
Press
(to INTRO)
Once

Basic Operation
9
Workow INTRO
A short intro suitable for the pattern will play.
PTN 1
This is the basic rhythm pattern.
PTN 2
This rhythm pattern is more amboyant than the PTN 1.
Fill in
You can insert a ll-in at any time while the PTN 1 or PTN
2 are playing. The ll-in is also inserted when you switch
between PTN 1 and PTN 2.
The PTN 1 and the PTN 2 each play a dierent ll-in.
ENDING
After a ll-in, the ending plays and then the rhythm
stops.
Looper (TRK 1, TRK 2)
Use this to record and play back the sound of your guitar
or bass.
When you switch between PTN 1 and PTN 2 in the
Rhythm section, these tracks also switch automatically
for the looper section.
PTN 2PTN 2
TRK 2TRK 2
ENDINGENDING
Press
(ll in)
Once
Press
(to ENDING)
Twice
Press
(stop)
Twice

Basic Operation
10
Synchronizing the looper and rhythm (p. 15)
You can specify whether the looper and rhythm operate simultaneously (SYNC ON) or separately (SYNC OFF).
To turn SYNC on/o, hold down the [RHYTHM] switch for two seconds or longer while the looper and rhythm are stopped.
When SYNC is on, the RHYTHM indicator changes color.
SYNC OFF: red and green
SYNC ON: red and light blue
Looper operationLooper operation
OVER-
DUBBING
OVER-
DUBBING
REC
(record)
REC
(record)
* If there is no recorded data, you’ll start with recording.
PLAY
(loop playback)
PLAY
(loop playback)
Press
(undo/redo)
Two
seconds
Press
(loop playback)
Once
Press
(overdubbing)
Once
* If there is no recorded
data, you’ll start with
recording.

Basic Operation
11
Basic Rhythm Operation
Selecting a Rhythm Pattern
The RC-10R contains more than 250 dierent rhythm
patterns.
1. Press the [VALUE] knob to move the cursor to
the genre.
* If the screen is dierent than shown above, press the
[EXIT] button several times to access the top screen.
2. Turn the [VALUE] knob to select the genre.
3. Press the [VALUE] knob to move the cursor to
the rhythm pattern.
4. Turn the [VALUE] knob to select the rhythm
pattern.
MEMO
5 For details on the internal rhythm patterns, refer to
“Parameter Guide”(PDF). To obtain the PDF manual,
refer to p. 21.
5 You can’t change the time signature of the rhythm
patterns. Select a rhythm pattern of the time signature
that you want to play.

Basic Operation
12
Playing the Rhythm
1. Press the [RHYTHM] switch.
The rhythm plays.
The RHYTHM indicator rotates at the timing of the
rhythm.
Switching Between PTN 1 and PTN 2
1. While the rhythm is playing, hold the
[RHYTHM] switch for two seconds.
A ll-in is inserted, and then the division that plays
is switched.
Stopping the Rhythm
1. While the rhythm is playing, press the
[RHYTHM] switch twice in succession.
A ll-in is inserted, the ending plays, and then the
rhythm stops.
5You can also start the rhythm without playing the intro.
5You can also stop the rhythm without playing the ending.
&For details, refer to“Parameter Guide (English)”(PDF).
Inserting a Fill-In
1. While the PTN 1 or PTN 2 are playing, press the
[RHYTHM] switch once.
A ll-in appropriate to the rhythm pattern is
inserted.
MEMO
5 A ll-in is also inserted when you switch between PTN
1 and PTN 2.

Basic Operation
13
Adjusting the Rhythm Volume
1. Turn the [LEVEL] (RHYTHM) knob.
Adjusting the Tempo
1. Press the [VALUE] knob to move the cursor to
the tempo.
2. Turn the [VALUE] knob to adjust the tempo.
Basic Looper Operation
Selecting a Phrase Memory
1. Press the [VALUE] knob to move the cursor to
the phrase number.
2. Turn the [VALUE] knob to select a phrase
memory (1–99).
LOOP indicator Explanation
Unlit
No recorded data
Press the [LOOP] switch to start
recording
Lit Green
Recorded data exists
Press the [LOOP] switch to start loop
playback

Basic Operation
14
Record
Select a phrase memory that does not contain recorded
data, and press the [LOOP] switch to start recording.
Track status and LOOP indicator color
Green: When stopped, data exists; otherwise,
playing
Red: Recording
Orange: Overdubbing
Light blue: When using Undo or Redo
Overdub
By pressing the [LOOP] switch during recording or loop
playback, you can record another layer (overdub) onto
the currently-playing phrase.
5 If you press the [LOOP] switch during overdubbing,
you’ll switch to loop playback.
5 You can perform Undo and Redo operations.
&“Cancelling an Overdub (Undo/Redo/Track
Clear)” (p. 15)
Loop Playback
During overdubbing, or if a phrase memory containing
recorded data is selected, you can press the [LOOP]
switch to start loop playback.
5 If you press the [LOOP] switch during loop playback,
you’ll switch to overdubbing.
5 During phrase playback, if you move the cursor to
the phrase number and turn the [VALUE] knob, the
phrase memory number blinks, allowing you to
select the next phrase (memory shift).
5 You can also perform memory shift operations
using an external footswitch connected to the CTL
1, 2 jacks.
&For details, refer to “Parameter Guide (English)”
(PDF).
Stopping
To stop, press the [LOOP] switch twice in succession.

Basic Operation
15
Cancelling an Overdub (Undo/Redo/Track Clear)
You can Undo/Redo by holding down the [LOOP] switch
for two seconds or longer during phrase playback or
overdubbing.
You can clear the phrase by holding down the [LOOP]
switch for two seconds or longer while the phrase is
stopped.
Operation Explanation
Undo
You can cancel the recording or the most recent overdub
by holding down the [LOOP] switch for two seconds or
longer during playback or overdubbing.
Redo
If you want to bring back the cancelled sound, once
again hold down the [LOOP] switch for two seconds
or longer during playback. Redo is possible only for
overdubbing.
Clear
While phrase playback is stopped, you can hold down
the [LOOP] switch for two seconds or longer to clear the
phrase (this Clear operation is temporary; the phrase
saved in phrase memory is not lost).
Using Rhythm and Looper
Together
For even more variety in your performance, you can use
the rhythm together with the looper.
Using the Looper to Record a Backing with
Rhythm
1. Make sure that the rhythm and the looper are
stopped.
2. Hold down the [RHYTHM] switch for two
seconds or longer.
SYNC turns on, so that the rhythm and looper will
operate simultaneously.
When SYNC is on, the RHYTHM indicator changes
color.
SYNC OFF: red and green
SYNC ON: red and light blue

Basic Operation
16
3. Press the [RHYTHM] switch.
After the intro plays, the rhythm’s PTN 1 plays. At the
same time, the looper’s TRK 1 starts being recorded.
4. Press the [LOOP] switch.
The length of the TRK 1 is determined, and the
looper switches to the overdubbing state.
* The length of the track is automatically adjusted (loop
quantized) according to the tempo and the time
signature of the rhythm.
Start Stop
Even if the timing is slightly inaccurate, the
phrase length will automatically be adjusted to
the precise measure interval.
5. Press the [LOOP] switch.
The looper switches to the loop playback state.
You can perform freely while playing back the
backing track that you created using the rhythm
and looper.
* The rhythm is not recorded on the looper.
* Even during loop recording, overdubbing, or playback,
you can freely insert a rhythm ll-in by pressing the
[RHYTHM] switch.

Basic Operation
17
Recording a TRK 2
Just as you can switch the rhythm between the PTN 1
and the PTN 2, you can also switch between the looper’s
TRK 1 and TRK 2 during recording or playback. This lets
you create a backing track that contains dierent chord
progressions appropriate for the song’s playback parts.
1. During TRK 1 recording, overdubbing, or
playback, hold down the [RHYTHM] switch for
two seconds or longer.
The rhythm switches to playing the PTN 2, and at
the same time the looper switches to recording the
TRK 2.
In the same way as when recording the TRK 1, you
can also switch the TRK 2 between overdubbing and
playback.
MEMO
5 The rhythm part that is playing and the looper track
that is recording, overdubbing, or playing are shown in
the center of each indicator.
&“5 LOOP indicator” (p. 2)
&“8 RHYTHM indicator”(p. 3)
Stopping Playback
1. Press the [RHYTHM] switch twice in succession.
Playback continues to the end of the measure, the
ending plays, and then playback stops.
Phrase Memories (Write/Delete)
Saving a phrase
If you record or overdub, or make rhythm settings, and
then select another phrase memory or turn o the
power, your phrase settings will be lost.
If you want to keep your phrase, you must write it into
memory.
1. While stopped, hold down the [MENU] button
and press the [EXIT] button.
The MENU screen appears.

Basic Operation
18
2. Turn the [VALUE] knob to select “WRITE,” then
press the [VALUE] knob to conrm.
3. Turn the [VALUE] knob to select the write-
destination phrase memory.
If you decide to cancel, press the [EXIT] button.
MEMO
5 The maximum recording time is a total of approximately
six hours for all phrases (including an unsaved phrase).
If there’s not enough memory to save the phrase, the
display indicates“MEMORY FULL!”In this case, delete
unneeded phrases (p. 18) and then try the operation
again.
4. Press the [VALUE] knob.
The phrase is saved.
NOTE
5 Never turn o the power while“EXECUTING...” is shown.
Doing so might cause all saved data to be lost.
5 When repairing the unit, we take great care to save the
contents of memory, but it might not be possible to
recover the contents of memory in cases such as when
the memory section has malfunctioned.
5 Roland accepts no responsibility, nancial or otherwise,
for recovering any contents lost from this unit’s
memory.
Deleting a phrase
Here’s how to delete a phrase.
1. While stopped, hold down the [MENU] button
and press the [EXIT] button.
The MENU screen appears.
2. Turn the [VALUE] knob to select “CLEAR,” and
then press the [VALUE] knob to conrm.

Basic Operation
19
3. Turn the [VALUE] knob to select the phrase
memory that you want to delete, and then
press the [VALUE] knob to conrm.
If you decide to cancel, press the [EXIT] button.
4. Turn the [VALUE] knob to select “YES,” and then
press the [VALUE] knob.
The phrase is deleted.
NOTE
5 Never turn o the power while“EXECUTING...” is shown.
Doing so might cause all saved data to be lost.

20
Appendix
Returning to the Factory Settings
(Factory Reset)
Restoring the RC-10R’s settings to their original factory
default settings is referred to as “Factory Reset.”
Factory reset lets you return the system settings to their
factory-set state or initialize all phrase memories. When
you initialize the phrase memories, the phrases are
deleted.
1. Hold down the [MENU] button and press the
[EXIT] button.
The MENU screen appears.
2. Turn the [VALUE] knob to select “FACTORY
RESET,” and then press the [VALUE] knob to
conrm.
You see a screen where you can specify the range of
the factory reset.
3. Specify the range of the factory reset.
To advance the cursor Press the [VALUE] knob.
To return the cursor Press the [EXIT] button.
To edit the value Turn the [VALUE] knob.
Parameter Value Explanation
FROM
TO
SYS System and MIDI parameter
settings
1–99 The contents of phrase
memories 1–99
