USER’S MANUAL
MODEL: VTK501HD
5 IN 1 CAMERA SYSTEM
1. BILL OF MATERIAL
2. SPECIFICATIONS
1/3” HD Color CMOS Image Sensor (1058)
976 (H) x 592 (V) Resolution
700 TV Lines
0.1 LUX Minimum Illumination
170 Degree Viewing Angle (D)
6 VDC ~ 32 VDC Power Source
IP68 Waterproof Rating
Selectable Reverse or Non-Rerverse Image
Selectable On/Off Fixed Parking Guidelines
Ball Mount Camera with 6ft (1.8m) Camera Cable
Metal Square Bracket Mount
Metal Flush Mount
Metal Angle Mount
Rubber Angle Mount
Concealed License Plate Mount
24ft (7.2m) RCA Video Cable with trigger wire
0.984” (25mm) Hole Saw for Flush Mount
3M Brand Mounting Tape for Mounts
HD CAMERA VIDEO/POWER CABLE 24ft RCA VIDEO CABLE SQUARE BRACKET MOUNT
FLUSH MOUNT METAL ANGLE MOUNT RUBBER ANGLE MOUNT LICENSE PLATE MOUNT
3M MOUNTING TAPE MOUNTING HARDWARE HOLE SAW FOR FLUSH MOUNT CAMERA ADJUST TOOLS
1
WWW.VISIONTECHAMERICA.COM 2
8
3. METAL SQUARE BRACKET MOUNT ASSEMBLY
4. METAL FLUSH MOUNT ASSEMBLY
6. RUBBER ANGLE MOUNT ASSEMBLY
USER’S MANUAL
MODEL: VTK501HD
5 IN 1 CAMERA SYSTEM
7. LICENSE PLATE MOUNT ASSEMBLY
CAMERA
CAMERA
CAMERA
CAMERA
LICENSE PLATE MOUNT
RUBBER ANGLE MOUNT
METAL ANGLE MOUNT
SQUARE MOUNT
5. METAL ANGLE MOUNT ASSEMBLY
METAL SQUARE MOUNT
METAL FLUSH MOUNT
*NOTE: INSTALL THE CAMERA FROM THE FRONT HOLE OF THE RUBBER ANGLE MOUNT. USE THE CAMERA ADJUST TOOL TO SET THE CAMERA TO THE DESIRED POSITION.
*NOTE: THE CAMERA CABLE CAN EXIT THE METAL ANGLE MOUNT FROM THE TOP HOLE OR FROM THE BACK OF THE MOUNT.
*NOTE: THE LICENSE PLATE MOUNT HAS TWO POSITIONS TO INSTALL THE CAMERA SQUARE MOUNT TO ALLOW CLEARANCE FOR A LICENSE PLATE FRAME OR ALLOW MORE ANGLE ADJUSTMENT.
*NOTE: TO PREVENT WATER LEAK, APPLY A SMALL BEAD OF CLEAR SILICONE SEALENT AROUND THE FLUSH MOUNT BEFORE INSTALLING IT INTO THE PRE-DRILLED 25mm HOLE
SMALL O RING LARGE O RING
WWW.VISIONTECHAMERICA.COM
8
8. WIRING (POWER AND RCA CONNECTORS)
A) RED WIRE CONNECTS TO (+) POWER SOURCE (Example - Reverse Light Wire + when in reverse gear, Ignition On Switch +)
B) BLACK/RED WIRE CONNECTS TO CHASSIS GROUND (NOT the other wire at reverse light)
C) YELLOW RCA VIDEO CABLE CONNECTOR PLUGS INTO CAMERA CABLE YELLOW RCA CONNECTOR AT THE CAMERA SIDE
D) (OPTIONAL) 4” RED WIRE ON YELLOW RCA CABLE CONNECTS TO REVERSE LIGHT WIRE + (CAMERA SIDE)
E) (OPTIONAL) 4” RED WIRE ON YELLOW RCA CABLE CONNECTS TO REVERSE TRIGGER INPUT (MONITOR SIDE)
F) YELLOW RCA VIDEO CABLE CONNECTOR PLUGS INTO CAMERA INPUT AT THE MONITOR SIDE
USER’S MANUAL
MODEL: VTK501HD
5 IN 1 CAMERA SYSTEM
9. WIRE LOOPS (BLUE AND WHITE)
A) BLUE LOOP CUT = NO PARKING GUIDELINES
B) BLUE LOOP NOT CUT = PARKING GUIDELINES
C) WHITE LOOP CUT = NON-REVERSE IMAGE
D) WHITE LOOP NOT CUT = REVERSE IMAGE
D & E
A & B C & F
3
RED WIRE
(+ )REVERSE LIGHT WIRE
OR (+) IGNITION SWITCH
BLACK/RED WIRE
(-) VEHICLE CHASSIS GROUND
CONNECT THE
RCA EXTENSION CABLE
TO CAMERA
RCA/POWER CABLE
(OPTIONAL CONNECTION)
RCA EXTENSION CABLE RED WIRES
RED WIRE ON CAMERA SIDE
*CONNECT TO (+) REVERSE LIGHT WIRE
RED WIRE ON MONITOR/RADIO SIDE
*CONNECTS TO REVERSE INPUT WIRE
OF MONITOR OR RADIO
*FOR REVERSE CAMERA INSTALLATION
CAMERA VIDEO OUT
CAMERA POWER WIRES
