B+K precision 2560B Series User manual

2
Safety Summary
The following safety precautions apply to both operating and maintenance personnel and must be followed during all
phases of operation, service, and repair of this instrument.
Before applying power to this instrument:
• Read and understand the safety and operational information in this manual.
• Apply all the listed safety precautions.
• Verify that the voltage selector at the line power cord input is set to the correct line voltage. Operating the instrument
at an incorrect line voltage will void the warranty.
• Make all connections to the instrument before applying power.
• Do not operate the instrument in ways not specified by this manual or by B&K Precision.
Failure to comply with these precautions or with warnings elsewhere in this manual violates the safety standards of design,
manufacture, and intended use of the instrument. B&K Precision assumes no liability for a customer’s failure to comply
with these requirements.
Category rating
The IEC 61010 standard defines safety category ratings that specify the amount of electrical energy available and the
voltage impulses that may occur on electrical conductors associated with these category ratings. The category rating is
a Roman numeral of I, II, III, or IV. This rating is also accompanied by a maximum voltage of the circuit to be tested,
which defines the voltage impulses expected and required insulation clearances. These categories are:
Category I (CAT I): Measurement instruments whose measurement inputs are not intended to be connected to the
mains supply. The voltages in the environment are typically derived from a limited-energy trans-
former or a battery.
Category II (CAT II): Measurement instruments whose measurement inputs are meant to be connected to the mains
supply at a standard wall outlet or similar sources. Example measurement environments are portable
tools and household appliances.
Category III (CAT III): Measurement instruments whose measurement inputs are meant to be connected to the mains
installation of a building. Examples are measurements inside a building’s circuit breaker panel
or the wiring of permanently-installed motors.
Category IV (CAT IV): Measurement instruments whose measurement inputs are meant to be connected to the primary
power entering a building or other outdoor wiring.
Do not use this instrument in an electrical environment with a higher category rating than what is specified in this manual
for this instrument.
You must ensure that each accessory you use with this instrument has a category rating equal to or higher than the
instrument’s category rating to maintain the instrument’s category rating. Failure to do so will lower the category rating
of the measuring system.

3
Electrical Power
This instrument is intended to be powered from a CATEGORY II mains power environment. The mains power should be
115 V RMS or 230 V RMS. Use only the power cord supplied with the instrument and ensure it is appropriate for your
country of use.
Ground the Instrument
To minimize shock hazard, the instrument chassis and cabinet must be connected to an electrical safety ground. This
instrument is grounded through the ground conductor of the supplied, three-conductor AC line power cable. The power
cable must be plugged into an approved three-conductor electrical outlet. The power jack and mating plug of the power
cable meet IEC safety standards.
Do not alter or defeat the ground connection. Without the safety ground connection, all accessible conductive parts
(including control knobs) may provide an electric shock. Failure to use a properly-grounded approved outlet and the
recommended three-conductor AC line power cable may result in injury or death.
Unless otherwise stated, a ground connection on the instrument’s front or rear panel is for a reference of potential only
and is not to be used as a safety ground. Do not operate in an explosive or flammable atmosphere.
Do not operate the instrument in the presence of flammable gases or vapors, fumes, or finely-divided particulates.
The instrument is designed to be used in office-type indoor environments. Do not operate the instrument
• In the presence of noxious, corrosive, or flammable fumes, gases, vapors, chemicals, or finely-divided particulates.
• In relative humidity conditions outside the instrument’s specifications.
• In environments where there is a danger of any liquid being spilled on the instrument or where any liquid can condense
on the instrument.
• In air temperatures exceeding the specified operating temperatures.
• In atmospheric pressures outside the specified altitude limits or where the surrounding gas is not air.
• In environments with restricted cooling air flow, even if the air temperatures are within specifications.
• In direct sunlight.
This instrument is intended to be used in an indoor pollution degree 2 environment. The operating temperature range is
0
∘
C to 40
∘
C and 20% to 80% relative humidity, with no condensation allowed. Measurements made by this instrument
may be outside specifications if the instrument is used in non-office-type environments. Such environments may include
rapid temperature or humidity changes, sunlight, vibration and/or mechanical shocks, acoustic noise, electrical noise,
strong electric fields, or strong magnetic fields.

4
Do not operate instrument if damaged
If the instrument is damaged, appears to be damaged, or if any liquid, chemical, or other material gets on or inside the
instrument, remove the instrument’s power cord, remove the instrument from service, label it as not to be operated,
and return the instrument to B&K Precision for repair. Notify B&K Precision of the nature of any contamination of the
instrument.
Clean the instrument only as instructed
Do not clean the instrument, its switches, or its terminals with contact cleaners, abrasives, lubricants, solvents, acids/bases,
or other such chemicals. Clean the instrument only with a clean dry lint-free cloth or as instructed in this manual. Not
for critical applications
This instrument is not authorized for use in contact with the human body or for use as a component in a life-support
device or system.
Do not touch live circuits
Instrument covers must not be removed by operating personnel. Component replacement and internal adjustments must
be made by qualified service-trained maintenance personnel who are aware of the hazards involved when the instrument’s
covers and shields are removed. Under certain conditions, even with the power cord removed, dangerous voltages may
exist when the covers are removed. To avoid injuries, always disconnect the power cord from the instrument, disconnect
all other connections (for example, test leads, computer interface cables, etc.), discharge all circuits, and verify there
are no hazardous voltages present on any conductors by measurements with a properly-operating voltage-sensing device
before touching any internal parts. Verify the voltage-sensing device is working properly before and after making the
measurements by testing with known-operating voltage sources and test for both DC and AC voltages. Do not attempt
any service or adjustment unless another person capable of rendering first aid and resuscitation is present.
Do not insert any object into an instrument’s ventilation openings or other openings.
Hazardous voltages may be present in unexpected locations in circuitry being tested when a fault condition in the circuit
exists.
Fuse replacement must be done by qualified service-trained maintenance personnel who are aware of the instrument’s fuse
requirements and safe replacement procedures. Disconnect the instrument from the power line before replacing fuses.
Replace fuses only with new fuses of the fuse types, voltage ratings, and current ratings specified in this manual or on
the back of the instrument. Failure to do so may damage the instrument, lead to a safety hazard, or cause a fire. Failure
to use the specified fuses will void the warranty.

5
Note:
Note:
Servicing
Do not substitute parts that are not approved by B&K Precision or modify this instrument. Return the instrument to
B&K Precision for service and repair to ensure that safety and performance features are maintained.
For continued safe use of the instrument
• Do not place heavy objects on the instrument.
• Do not obstruct cooling air flow to the instrument.
• Do not place a hot soldering iron on the instrument.
• Do not pull the instrument with the power cord, connected probe, or connected test lead.
• Do not move the instrument when a probe is connected to a circuit being tested.
Working Environment
Environment
This instrument is intended for indoor use and should be operated in a clean, dry environment.
Temperature
Operating: 0℃ to +40℃
Non-operation:-20℃ to +60℃
Direct sunlight, radiators, and other heat sources should be taken into account when assessing the ambient temperature.
Humidity
Operating: 85% RH, 40 ℃, 24 hours
Non-operating: 85% RH, 65 ℃, 24 hours
Altitude
Operating: less than 3 Km
Non-operation: less than 15 Km
Installation (overvoltage) Category
This product is powered by mains conforming to installation (overvoltage) category II.
Degree of Pollution
The oscilloscopes may be operated in environments of Pollution Degree II.
Degree of Pollution II refers to a working environment which is dry and non-conductive pollution occurs. Occasional
temporary conductivity caused by condensation is expected.
IP Rating
IP20 (as defined in IEC 60529).

6
Compliance Statements
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European
countries with separate collection systems)
This product is subject to Directive 2002/96/EC of the European Parliament
and the Council of the European Union on waste electrical and electronic equipment
(WEEE), and in jurisdictions adopting that Directive, is marked as being put on the
market after August 13, 2005, and should not be disposed of as unsorted municipal
waste. Please utilize your local WEEE collection facilities in the disposition of this
product and otherwise observe all applicable requirements.
Safety Symbols
Symbol
Description
indicates a hazardous situation which, if not avoided, will result in death or serious injury.
indicates a hazardous situation which, if not avoided, could result in death or serious injury
indicates a hazardous situation which, if not avoided, will result in minor or moderate injury
Refer to the text near the symbol.
Electric Shock hazard
Alternating current (AC)
Chassis ground
Earth ground
This is the In position of the power switch when instrument is ON.
This is the Out position of the power switch when instrument is OFF.
is used to address practices not related to physical injury.

Contents
1 General Information 13
1.1 Product Overview 13
1.2 Features 14
1.3 Contents 15
1.4 Dimensions 15
1.5 Front Panel Overview 16
1.6 Rear Panel Overview 17
1.7 Touch Screen Overview 18
2 Getting Started 19
2.1 Input Power Requirements 19
2.2 Fuse Requirements and Replacement 20
2.3 Preliminary Check 21
2.3.1 Verify AC Input Voltage 21
2.3.2 Connect Power 21
2.3.3 Self-Test 21
2.3.4 Self-Cal 21
2.3.5 Check Model and Firmware Version 21
2.3.6 Function Check 22
2.4 Probe Safety 23
3 Control Panel 25
3.1 Vertical Control 25
3.2 Horizontal Control 26
3.3 Trigger Control 26
3.4 Run/Stop Key 27
3.5 Auto Setup Key 27
3.6 Analysis Keys 27
3.7 Universal Knob 28
3.8 Menu Keys 28
3.9 Other Keys 29
4 Acquisition 30
4.1 Changing Acquisition Mode 30
4.2 Sequence 32
5 History 33
6 Horizontal Control 34
6.1 Adjusting the Horizontal Scale (time/div) 34
6.2 Adjusting the Horizontal Delay (position) 35
6.3 Panning and Zooming Single or Stopped Acquisitions 36
6.4 Horizontal Scale (Coarse/Fine) 36
6.5 Zoom 37
6.6 Roll 38

8
7 Vertical Control 39
7.1 Enabling Channels 39
7.1.1 Channel Enable/Disable From the Touch Screen 39
7.2 Vertical Scale 40
7.2.1 Coarse/Fine Adjustment 40
7.3 Vertical Position 40
7.4 Channel Setup 41
7.4.1
Channel Coupling
41
7.4.2
Bandwidth Limit
42
7.4.3
Probe Attenuation
42
7.4.4
Label
43
7.4.5
Apply To
43
7.4.6
Impedance
44
7.4.7
Unit
44
7.4.8
Deskew
44
7.4.9
Invert
45
7.4.10
Trace
45
8 Digital Channels 46
8.1 LP2560 Probe 46
8.2 Connecting the Digital Probes 47
8.3 Acquiring Digital Waveforms 47
8.4 Displaying Digital Channels 48
8.5 Turning Individual Channels On or Off 49
8.6 Logic Threshold for Digital Channels 50
8.7 Displaying Digital Channels as a Bus 50
9 Trigger 52
9.1 Trigger Source 53
9.2 Trigger Types 54
9.2.1 Edge Trigger 54
9.2.2 Slope Trigger 55
9.2.3 Pulse Trigger 57
9.2.4 Video Trigger 59
9.2.5 Window Trigger 62
9.2.6 Interval Trigger 64
9.2.7 Dropout Trigger 65
9.2.8 Runt Trigger 67
9.2.9 Pattern Trigger 68
9.3 Trigger Mode 70
9.4 Trigger Level 71
9.5 Trigger Coupling 72
9.6 Trigger Holdoff 73
9.6.1 Holdoff by Time 73
9.6.2 Holdoff by Event 73
9.6.3 Start Holdoff On 74
9.7 Noise Reject 75
9.8 Zone Trigger 76
9.8.1 Creating and Moving Zones 76
10 Serial Trigger and Decode 79
10.1 I2C Trigger and Serial Decode 79
10.1.1 Setup for I2C Signals 79
10.1.2 I2C Trigger 81
10.1.3 I2C Serial Decode 84
10.2 SPI Trigger and Serial Decode 85
10.2.1 Setup for SPI Signals 85
10.2.2 SPI Trigger 88

9
10.2.3 SPI Serial Decode 89
10.3 UART Trigger and Serial Decode 90
10.3.1 Setup for UART Signals 90
10.3.2 UART Trigger 91
10.3.3 UART Serial Decode 92
10.4 CAN Trigger and Serial Decode 94
10.4.1 Setup for CAN Signals 94
10.4.2 CAN Trigger 94
10.4.1 CAN Serial Decode 95
10.5 LIN Trigger and Serial Decode 97
10.5.1 Setup for LIN Signals 97
10.5.2 LIN Trigger 97
10.5.1 Interpreting LIN Decode 99
10.6 FlexRay Trigger and Serial Decode 100
10.6.1 FlexRay Signal Configuration 100
10.6.2 FlexRay Trigger 101
10.6.3 FlexRay Serial Decode 102
10.7 CAN FD Trigger and Serial Decode 104
10.7.1 CAN FD Signal Configuration 104
10.7.2 CAN FD Trigger 106
10.7.3 CAN FD Serial Decode 106
10.8 I2S Trigger and Serial Decode 108
10.8.1 I2S Signal Configuration 108
10.8.2 I2S Trigger 111
10.8.3 I2S Serial Decode 112
10.9 MIL-STD-1553B Trigger and Serial Decode 113
10.9.1 MIL-STD-1553B Signal Configuration 113
10.9.2 MIL-STD-1553B Serial Decode 114
10.10 SENT Trigger and Serial Decode 116
10.10.1 SENT Signal Configuration 116
10.10.2 SENT Trigger 118
10.10.3 SENT Serial Decode 121
10.11 Manchester Trigger and Serial Decode 124
10.11.1 Manchester Signal Configuration 124
10.11.2 Manchester Serial Decode 126
11 Cursors 128
11.1 X Cursors 129
11.2 Y Cursors 130
11.3 Display Style 132
11.4 Make Cursor Measurements 133
11.5 Cursors Reference 134
12 Measure 136
12.1 Measurement Modes 136
12.2 Set Measurement Types 138
12.3 Type of Measurement 139
12.3.1 Vertical Measurements 139
12.3.2 Horizontal Measurements 141
12.3.3 Miscellaneous Measurements 142
12.3.4 Delay Measurements 143
12.4 Trend 144
12.5 Simple Measurements 145
12.6 Measurement Statistics 145
12.7 Statistics Histogram 146
12.8 Gate 146
12.9 Amplitude Strategy 147
12.10 Threshold 148

10
13 Math 149
13.1 Units for Math Waveforms 150
13.2 Arithmetic 151
13.2.1 Subtraction Example 151
13.2.2 Average 152
13.2.3 ERES 153
13.3 Algebra 154
13.3.1
Differentiate
154
13.3.2
Integrate
155
13.3.3
Square Root
156
13.3.4
Absolute
157
13.3.5
Sign
157
13.3.6
Exp/Exp10
158
13.3.7
Ln/Lg
159
13.3.8
Interpolate
159
13.4 Frequency Analysis (FFT Operation) 160
13.4.1 Setting FFT Parameters 160
13.4.2 Parameter Display Area 162
13.4.3 Vertical 162
13.4.4 Horizontal 163
13.5 FFT Tools 163
13.5.1 Peaks Tool 163
13.5.2 Markers Tool 164
13.5.3 Measure the FFT Waveform 165
13.6 Formula Editor 166
14 Reference Waveform 167
14.1 Save REF Waveform to Internal Memory 167
14.2 Display REF Waveforms 167
15 Search 169
16 Navigate 171
16.1 Navigate by Time 171
16.2 Navigate by Search Event 172
16.3 Navigate by History Frame 173
17 Mask Test 174
17.1 Mask Setup 175
17.1.1 Create Mask 175
17.1.2 Mask Editor 176
17.2 Operation 178
17.3 Pass/Fail Rule 178
18 Counter 179
18.1 Counter Configuration 179
18.2 Mode 180
19 Power Analysis 181
19.1 Power Quality 182
19.1.1 Type 182
19.1.2 Input Setup 183
19.2 Current Harmonics 184
19.2.1 Configuration 184
19.2.2 Standard 184
19.2.3 Parameter Description 185
15.1
Setting
169
15.2
Copy
169
15.3
Results
169

11
19.2.4 Input Setup 185
19.3 Inrush Current 186
19.3.1 Input Setup 186
19.4 Switching Loss 187
19.4.1 Deskew Calibration 187
19.4.2 Switching Loss Configuration 188
19.4.3 Conduction Type 188
19.4.4 Input Setup 189
19.5 Slew Rate 190
19.5.1 Connection Guide 190
19.6 Modulation 191
19.6.1 Input Modulation 191
19.7 Output Ripple 192
19.7.1 Output Ripple Input Setup 192
19.8 Turn on/Turn Off 193
19.8.1 Turn On/Turn Off Input Setup 193
19.8.2 Testing Conditions 194
19.9 Transient Response 195
19.9.1 Transient Response Input Setup 195
19.9.2 Transient Response Configuration 196
19.10 PSRR 197
19.10.1 PSRR Configuration 197
19.10.2 PSRR Amplitude 197
19.11 Power Efficiency 198
19.11.1 Power Efficiency Input Setup 198
20 Bode Plot 199
20.1 Bode Plot Configuration 200
20.1.1 Connection 200
20.1.2 Sweep 201
20.1.3 Simple Sweep 201
20.1.4 Editor 203
21 Arbitrary Waveform Generator 204
21.1 AWG Configuration 204
21.1.1 Other Settings 205
22 Save/Recall 206
22.1 Save Type 206
22.2 Internal/External Save and Recall 207
22.3 File Manager 209
23 Utility Menu 211
23.1 System Setting 211
23.1.1 View System Status 211
23.1.2 Sound 211
23.2 Language 211
23.3 Screen Saver 212
23.4 IO Set 212
23.4.1 LAN 212
23.4.2 USB Device 213
23.4.3 Date/Time 213
23.5 Options 214
23.6 Reference Position 214
23.7 Do Self-Test 215
23.7.1 Screen Test 215
23.7.2 Keyboard Test 216
23.7.3 LED Test 217

12
23.8 Start Self Cal 218
23.9 Power On Line 218
24 Remote Control 219
24.1 Web Browser 219
24.2 Other Connectivity 220
25 Troubleshooting 221
26 Service Information 223
27 LIMITED THREE-YEAR WARRANTY 224

General Information
1.1 Product Overview
Figure 1.1 2560B
The 2560B Digital Storage (DSO) and Mixed Signal Oscilloscope (MSO) Series delivers advanced features and debug
capabilities for a wide range of applications. With increasing bandwidths to 350 MHz in a 4-channel configuration, each
model offers a maximum sample rate of 2 GSa/s and a maximum memory depth of 200 Mpts. Equipped with a 10.1”
(1024 x 600) capacitive touchscreen and high waveform update rate of 120,000 wfms/s, these oscilloscopes can capture
infrequent glitches with excellent signal fidelity.

General Information 14
1.2 Features
• 4 Analog channels
• Maximum sampling rate of 2 GSa/s
• 200 Mpts. memory depth
• Maximum waveform update rates of 120,000 (normal mode) and 500,000 (sequence mode)
• History and sequence mode store a maximum of 90,000 frames
• Large 10.1” TFT-LCD capacitive touchscreen, 1024 x 600 resolution
• 10-bit mode increases vertical resolution
• Advance triggers with trigger zone support
• 50 MHz DDS waveform generator supports Bode plots
• Power analysis includes 11 analyzing tools
• Automatic measurements with statistics and histogram
• Math function supports 2 traces and a formula editor
• 2 Mpts FFT provides high resolution of frequency spectrum
• Additional16 digital channels standard in MSO models (option available for DSO)
• Serial bus decoder supports I2C, SPI, UART, CAN and LIN protocol
• LAN and USBTMC-compliant USB device port for remote PC control
• USB Host (x2), Pass/Fail Out and EXT Trig
• Support SCPI remote control commands

Note:
General Information 15
1.3 Contents
• 1 x 2560B Digital Storage Oscilloscope (DSO) or Mixed Signal Oscilloscope (MSO)
• AC Power Cord
• USB type A to type B cable.
• Certificate of Calibration
• Test Report
• 4 oscilloscope probes
Model
2565B
2565B-MSO
2567B
2567B-MSO
2569B
2569B-MSO
Probe
PR150B
PR250B
PR500B
Bandwidth
150 MHz
250 MHz
500 MHz
Attenuation Value
X1, X10
X10
X10
Table 1.1 Probes
• 1 x LP2560 (MSO models)
Ensure the presence of all the items above. Contact the distributor if any items are missing.
1.4 Dimensions
The 2560B series oscilloscope’s dimensions are approximately: 352 mm (13.9 in) x 224.00 mm (8.8 in) x 101 mm (4 in)
(W x H x D).
Figure 1.2 Front View Dimension

General Information
16
1.5 Front Panel Overview
The front panel interface allows for control of the unit.
Figure 1.3 Front Panel
Item
Name
Description
Visual presentation of the device function and measurements.
See section Touch Screen Display for more details.
2 Control Panel Includes control knobs and keys. See section Control Panel
3 WaveGen Built-in waveform generator output.
4 Probe Compensation Supplies a 0-3.3 V, 1 kHz square wave for compensating the probes.
5 USB Host Port USB port used to connect flash drives. (Type A)
6 Digital Input Connector Receives digital signals from the LP2560 digital probe.
7 Analog Input Channels Input channels (Default: 1 M Ω )
8 Power Button Power the unit ON or OFF.
Table 1.2 Front Panel
1 Touch Screen

General Information
17
ger types.
1.6 Rear Panel Overview
Figure 1.4 Rear Panel Overview
Item
Name
Description
Outputs the trigger indicator. When Pass / Fail is enabled, outputs the
pass / fail signal.
2 External Trigger Input The external trigger input can be used as a source in several of the trig-
3
USB Interface Connect a USB type B to type A to remotely control the unit.
4
LAN Connect an ethernet cable to remotely control the unit over the network.
lock the instrument to a fixed location using the security lock via the lock
hole. Lock is not included.
AC Power Input
& Fuse Box
Houses the fuse as well as the AC input .
7 Handle Handle for easy carrying of the instrument.
Table 1.3 Rear Panel
1 Auxiliary Out
5 Safety Lock Hole
6

General Information
18
1.7 Touch Screen Overview
Use your fingers to touch, drag, pinch, spread, or draw a selection box.
Figure 1.5 Touch Screen Overview
Item
Name
Description
1 Menu Bar Displays the available options in the selected menu.
Trigger Delay
Indicator
Displays the trigger status.
3 Trigger Status Displays the trigger status.
USB Host
Port Indicator
Indicates that a USB is connected to the instrument.
5 LAN Port Indicator Indicates the status of the LAN connection.
6 Menu Bar Displays the available options in the selected menu.
Table 1.4 Touch Screen Overview
2
4

SHOCK HAZARD:
Getting Started
Before connecting and powering up the instrument, review the instructions in this section.
2.1 Input Power Requirements
The oscilloscope has a universal AC input that accepts line voltage and frequency input within:
Line
Voltage Range
100-120 V
100-240 V
Frequency
400 Hz
50/60 Hz
Power
80W Max
Table 2.1
Before connecting to an AC outlet or external power source, be sure that the power switch is in the OFF position and
verify that the AC power cord, including the extension line, is compatible with the rated voltage/current and that there
is sufficient circuit capacity for the power supply. Once verified, connect the cable firmly.
The included AC power cord is safety certified for this instrument operating in rated range. To
change a cable or add an extension cable, be sure that it can meet the required power
ratings for this instrument. Any misuse with wrong or unsafe cables will void the warranty.
The power cord provides a chassis ground through a third conductor. Verify that your power
outlet is of the three-conductor type with the correct pin connected to earth ground.

Getting Started
20
2.2 Fuse Requirements and Replacement
For continued fire protection at all line voltages replace only with a 2.00 A / 250 V "T" RATED, 5 x 20 mm
fuse.
For safety, no power should be applied to the instrument while changing line voltage
operation. Disconnect all cables connected to the instrument before proceeding.
Check and/or Change Fuse
– Locate the fuse box next to the AC input connector in the rear panel. (See figure 1.4 )
– Insert a small flathead screwdriver into the fuse box slit to pull and slide out the fuse box as indicated below.
– Check and replace fuse if necessary. (See figure 2.1 )
Figure 2.1 Fuse Removal
Any disassembling of the case or changing the fuse not performed by an
authorized service technician will void the warranty of the instrument
