Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21a
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m a y not be i nc luded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58465
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
To reduce the risk of FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
1. Install only according to these instructions.
Improper installation can create hazards.
2. Avoid electric shock. Keep plugs and receptacles
dry. Use only on GFCI-protected circuits.
3. The Light is not waterproof. Use extreme
caution in any wet location.
4. This product is not suitable for recessed
installation in ceilings or on buildings. Do
not install on radiant heat ceilings.
5. Wear ANSI-approved goggles and heavy-
duty work gloves during installation.
6. Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
7. Do not operate the Light in explosive atmospheres,
such as in the presence of flammable liquids,
gases or dust. The Light generates sparks
which may ignite the dust or fumes.
8. The Light’s plug must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with the Light. Unmodified plugs and
matching outlets will reduce risk of electric shock.
9. Do not abuse the Power Cord. Never use the Cord
for unplugging the Light. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
10. Maintain the Light. Check for breakage of
parts and any other condition that may affect
the Light’s operation. If damaged, have it
repaired before use. Many accidents are
caused by poorly maintained items.
11. Do not pull on the On/Off Pull Chain too hard or
at an angle to prevent the Light from falling.
12. Maintain labels and nameplates on the
Light. These carry important safety
information. If unreadable or missing, contact
Harbor Freight Tools for a replacement.
13. This product is not a toy. Keep it
out of reach of children.
14. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
15. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
SAVE THESE INSTRUCTIONS.

Page 3For technical questions, please call 1-888-866-5797.Item 58465
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING
WIRE CONNECTION:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
Do not modify the power cord plug provided with the Light. Never remove the grounding prong
from the plug. Do not use the Light if the power cord or plug is damaged. If damaged, have it repaired by a
service facility before use. If the plug will not fit the outlet, have a proper outlet installed by a
qualified electrician.
110-120 VAC Double Insulated Lights: Lights with Two Prong Plugs
Outlets for 2-Prong Plug
1. To reduce the risk of electric shock, double
insulated equipment has a polarized plug
(one blade is wider than the other). This plug will fit
in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install
the proper outlet. Do not change the plug in any way.
2. Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration.
(See Outlets for 2-Prong Plug.)
Extension Cords
1. Double Insulated Lights can use either
a two or three wire extension cord.
2. As the distance from the supply outlet increases,
you must use a heavier gauge extension cord.
Using extension cords with inadequately sized wire
causes a serious drop in voltage, resulting in loss of
power and possible tool damage. (See Table A.)
3. The smaller the gauge number of the wire,
the greater the capacity of the cord. For
example, a 14 gauge cord can carry a
higher current than a 16 gauge cord.
4. When using more than one extension cord to
make up the total length, make sure each cord
contains at least the minimum wire size required.
5. If you are using one extension cord for more than
one tool, add the nameplate amperes and use the
sum to determine the required minimum cord size.
6. If you are using an extension cord outdoors, make
sure it is marked with the suffix “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use.
7. Make sure the extension cord is properly wired
and in good electrical condition. Always replace
a damaged extension cord or have it repaired
by a qualified electrician before using it.
8. Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas.
TABLE A: RECOMMENDED
MINIMUM WIRE GAUGE FOR
EXTENSION CORDS* (120 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 16 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop to five volts at
150% of the rated amperes.

Page 4 For technical questions, please call 1-888-866-5797. Item 58465
Symbology
Double Insulated
VAC Volts Alternating Current
AAmperes
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover ventilation ducts.
Keep flammable objects away.
WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.
Specifications
Electrical Rating 
Outlet Rating 120VAC / 60Hz / Max 3A
Bulb Non-replaceable LED
Not suitable for dimmer
Power Cord Length 5 ft
Maximum Shop Lights linked together 4
Installation Instructions
V-Hook and Chain Installation
Note: For motion sensor to work properly, the light
fixture must be 9 feet to 11.5 feet from floor.
1. Select installation location for Shop Light.
Installation surface must be capable of

thick. Verify installation surface has no hidden
utility lines before drilling or driving screws.
2. Install appropriate hardware to mounting surface.
CAUTION! Do not use included hardware
on steel stud/joist wall. If mounting to a steel
wall stud/joist, use appropriate hardware.
a. Drop Ceiling
Have Lights installed by a professional
using appropriate hardware.
b. Wood Joist
• 
size. Use a stud finder (sold separately)
to find joist and mark its location.
• Mark and drill two pilot holes 23 inches apart.
• Screw the two Screw Eye Hooks (4) into
the pilot holes and directly into the joist.
c. Drywall
• Mark and drill two holes, 23 inches
apart, for the two Anchors (5), or use
expansion bolts (sold separately).
• Install the two Anchors/expansion
bolts to mounting surface.
Anchor (5)
3/8"
Mounting Surface
23 inches
• Attach the two Screw Eye
Hooks (4) to the Anchors
Screw Eye Hooks (4)
Mounting Surface

Page 5For technical questions, please call 1-888-866-5797.Item 58465
3. Feed the end of one Chain Link (2)
through each V-Hook (3).
4. Connect the V-Hooks to the outside
holes of the Light Fixture.
5. Attach one Chain Link to each of the two
Screw Eye Hooks on the mounting surface.
Chain Links
V-Hooks
Light Fixture
Power
Cord
Caution: Connect one Chain Link to one
Screw Eye Hook. Do NOT group more than
one Chain Link to a single Screw Eye Hook.
6. Be sure the Light Fixture is level and secure. Use
the Cable Tie (7) to secure the Power Cord.
Power
Cord
Outlet
Cable
Tie
Light Fixture
Mounting Surface
7. Plug the Power Cord into the electrical outlet. If
connecting multiple Lights together, connect the
Power Cord into the Outlet of the previous Light.
Flush Mount Installation
Note: For motion sensor to work properly, the light
fixture must be 9 feet to 11.5 feet from floor.
1. Select installation location for Shop Light.
Installation surface must be capable of

thick. Verify installation surface has no hidden
utility lines before drilling or driving screws.
2. Install appropriate hardware to mounting surface.
CAUTION! Do not use included hardware
on steel stud/joist wall. If mounting to a steel
wall stud/joist, use appropriate hardware.
a. Drop Ceiling
Have Lights installed by a professional
using appropriate hardware.
b. Wood Joist
• 
size. Use a stud finder (sold separately)
to find joist and mark its location.
• Mark and drill two pilot holes 22 inches apart.
• Screw the two Screws (6) into the pilot
holes and directly into the joist.
c. Drywall
• Mark and drill two holes, 22 inches
apart, for the two Anchors (5), or use
expansion bolts (sold separately),
• Install the two Anchors/expansion
bolts to mounting surface.
Anchor (5)
3/8"
Ceiling
22 inches
• Secure one Screw (6) into each Anchor.
Do not screw all the way in. Spacing
between the ceiling and Screw Heads
should be 0.18 - 0.2 inches.
Screw (6)
Ceiling
0.18 - 0.2"
3. Slide the Light Fixture into the Screw
Heads so that Screw Heads fit firmly inside
the Light Fixture holding it in place.
Screw (6)
Ceiling
Power
Cord
Outlet
Light Fixture
4. Be sure the Light Fixture is level and secure.
Use the Cable Tie to secure the Power Cord.
5. Plug the Power Cord into the electrical outlet. If
connecting multiple Lights together, connect the
Power Cord into the outlet of the previous Light.

Page 6 For technical questions, please call 1-888-866-5797. Item 58465
Maintenance
Procedures not specifically explained in this manual must
be performed only by a qualified technician
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Unplug the Light from its electrical outlet before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM LIGHT FAILURE:
Do not use damaged equipment. If damage is noted, have the problem corrected before further use.
1. BEFORE EACH USE, inspect the general
condition of the Shop Light. Check for:
• loose hardware
• misalignment or binding of moving parts
• damaged cord/electrical wiring
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. PERIODICALLY, clean the Shop Light
cover and Sensor with nonabrasive
glass cleaner and a clean cloth.
WARNING! TO PREVENT SERIOUS INJURY: If
the supply cord of this light is damaged, it must be
replaced only by a qualified service technician.
Operation
1. Plug the Shop Light into a grounded,

2. The Shop Light is equipped with a motion sensor.
Set to “0” to turn it OFF and set to “I” to turn it ON.
3. Set the time to turn the light off. Adjust the
time delay (TIME) as desired. The range is
1 to 10 minutes. Turning the TIME counter
clockwise (to –) will decrease time and
turning clockwise (to +) will increase time.
Time
Adjust
Sensor On/Off
I0
-+
TIME
4. The motion sensor should turn the light
on when motion is sensed from 3 feet to
8 feet around the Shop Light. The sensor
should be 9 feet to 11.5 feet from floor.
Top View
3 ft (+/- 1 ft)
from sensor
8 ft (+/- 1 ft)
from sensor
Shop Light
Motion
Sensor
9 feet to
11.5 feet
Floor
Ceiling

Page 7For technical questions, please call 1-888-866-5797.Item 58465
Parts List and Assembly Diagram
Part Description Qty
1 Light Fixture 1
2 Chain Link 2
3 V-Hook 2
4 Screw Eye Hook 2
5 Anchor 4
6 Screw 2
7 Cable Tie 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Do not open the housing, there are no user-
serviceable parts inside. Specify UPC 193175439727 when ordering parts.
1
2
3
456
7
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion
may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
