BRAYER BR4120 User manual

Instruction manual
Инструкция по эксплуатации
Handle garment steamer BR4120
Ручной отпариватель BR4120
brayer.pro

3EN
СОДЕРЖАНИЕ
EN......................................................................................................................................3
DE....................................................................................................................................10
RU ...................................................................................................................................18
KZ....................................................................................................................................26
HANDLE GARMENT STEAMER
BR4120
The garment steamer is intended for careful
smoothing of folds on clothes or furniture.
DESCRIPTION
1. Removable water tank
2. Water inlet lid
3. Steam supply button lock
4. Steam supply on button
5. Operating surface with steam release openings
6. On/o󰀨 indicator
7. ON/OFF-button « »
8. Handle
9. Power cord
10. Base
11. Brush attachment
EN
ATTENTION!
For additional protection it is reasonable to install a
residual current device (RCD) with nominal operation
current not exceeding 30 mA, to install RCD, contact
a specialist.
1
56
7
8
9
10
11
4
3
2

4 5EN EN
SAFETY MEASURES AND OPERATION
RECOMMENDATIONS
Read the operation instructions carefully before
using the garment steamer, after reading keep them
for future reference.
• Use the unit for its intended purpose only, as it is
stated in this manual.
• Mishandling the unit can lead to its breakage and
cause harm to the user or damage to the user’s
property, which is not covered by warranty.
• Make sure that the operating voltage of the unit
indicated on the label corresponds to your home
mains voltage.
• The power cord is equipped with a «euro-plug»;
insert it into a socket that has a reliable grounding
connection.
• To avoid re, do not use adapters for connecting the
unit to the mains.
• Do not touch the unit body, the power cord and the
power plug with wet hands.
• Do not switch the garment steamer on if the water
tank is empty. Switch the unit o󰀨 and unplug it when
the water tank becomes empty.
• Never leave the unit connected to the mains
unattended.
• Do not use the unit outdoors or in bathrooms.
• It is not recommended to use the unit during lightning
storms.
• Protect the unit from impacts, falling, vibrations and
other mechanical stress.
• Do not use the unit near heating appliances, heat
sources or open ame.
• Do not use the unit in proximity to the kitchen sink, in
bathrooms, near swimming pools or other containers
lled with water.
• If the unit is dropped into water, unplug it
immediately, and only then you can take the unit out
of water. Apply to the authorized service center for
testing or repairing the unit.
• Do not use the unit in places where aerosols
are used or sprayed, and in proximity to highly
inammable liquids, do not use the unit in the places
where such liquids are stored.
• Place the garment steamer vertically on a at dry
moisture- and heat-resistant surface, do not place it
horizontally and do not turn it over.
• Use only the attachment supplied with the unit.
• Before using the unit, make sure that the attachment
is set and xed properly.
• During the operation hold the garment steamer
vertically, do not turn it over.
• Fill the tank with water additionally cleaned with a
domestic lter. Do not use carbonated water or any
perfume additives.
• Ensure that water level is not above the maximal
mark «MAX». If the water level exceeds the maximal
mark, water may splash out of the garment steamer.
• Do not block and do not insert any foreign objects
into the steam release openings.
• During the operation the upper part of the garment
steamer body becomes hot. To avoid getting burns,
hold the garment steamer by the handle on the same
level with the steam supply on button.
• Avoid getting burns by hot steam.
• Never steam clothes on a person, always use a
hanger.
• Never direct operating steamer onto people,
animals and plants as well as onto furniture, electric
appliances, books and any other objects that can be
damaged by hot steam. The garment steamer should
be at least 20 cm away from any interior objects.
• Do not use the power cord as a handle for carrying
the garment steamer, carry it by the handle.
• Unplug the unit after usage or before cleaning.
• Switch the garment steamer o󰀨 and unplug the power
cord plug from the mains socket.
• When unplugging the unit, hold the power plug and
carefully remove it from the mains socket, do not pull
the power cord, as this can lead to its damage and
cause a short circuit.
• For children safety reasons do not leave polyethylene
bags used as a packaging unattended.
• The unit is not intended for usage by children.
• Do not leave children unattended to prevent using
the unit as a toy.
• Do not allow children to touch the operating surface,
the unit body, the power cord or the power plug
during operation of the unit.
• Be especially careful if children or disabled persons
are near the operating unit.
• During the unit operation and breaks between
operation cycles, place the unit out of reach of
children.
• The unit is not intended for usage by physically or
mentally disabled persons (including children) or by
persons lacking experience or knowledge if they are
not under supervision of a person who is responsible
for their safety or if they are not instructed by this
person on the usage of the unit.
• From time to time check the power cord integrity.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or
similar qualied personnel to avoid danger.
• Do not repair the unit by yourself. Do not
disassemble the unit by yourself, if any malfunction
is detected, and after the unit was dropped, unplug it
and apply to the service center.
• To avoid damages, transport the unit in the original
package.
• Keep the unit in a dry cool place out of reach of
children and disabled persons.
Attention! Do not allow children to play with
polyethylene bags or packaging lm. Danger of
su󰀨ocation!

6 7EN EN
THE UNIT IS INTENDED FOR HOUSEHOLD USE
ONLY, DO NOT USE THE UNIT FOR COMMERCIAL
OR LABORATORY PURPOSES.
BEFORE THE FIRST USE
After the unit’s transportation or storage at negative
temperature, unpack it and wait for at least 3 hours
before using it.
• Unpack the unit and remove all the packaging
materials.
• If there is a protective lm on the operating surface
(5), remove it.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the unit for damages, in case of damage do
not plug it into the mains.
• Make sure that specied specications of power
supply voltage of the unit correspond to the
specications of your mains. When using the unit in
the mains with 60 Hz frequency, the unit does not
need any additional settings.
• Wipe the garment steamer body with a slightly damp
cloth and then wipe it dry.
GARMENT STEAMER PURPOSE
- The garment steamer can be used for careful
smoothing of folds on clothes or furniture.
- If you have doubts about steaming any certain
kind of fabric or clothes, you should follow the
recommendations on the product label.
- If no such information is available, try to steam the
fabric on the reverse side.
- When steaming such fabrics as silk or corduroy, keep
the garment steamer at some distance from the fabric.
- Use the brush attachment (11) to remove lint or
threads from the fabric.
STEAMER OPERATION
WATER SELECTION
• Fill the water tank (1) with tap water. If tap water is
hard, we recommend mixing it with distilled water
in proportion 1:1. If tap water is too hard, mix it with
distilled water in proportion 1:2 or use distilled water
only.
ATTENTION!
Before detaching the water tank (1), make sure that
the power plug (9) is not inserted into the mains
socket.
• Take the water tank by both sides and remove it.
• Open the water inlet lid (2). Fill the water tank (1) with
water non exceeding the MAX mark and close the
water inlet lid (2) tightly.
• Do not ll the tank (1) with carbonated water,
perfume additives, vinegar, chemical agents, etc.
• Install the water tank (1) back to its place and make
sure that the tank (1) is xed properly.
ATTENTION!
Do not plug the garment steamer in if the water tank
(1) is empty.
• Place the garment steamer on the base (10) on a at
and steady surface.
• Connect the power plug (9) to the mains socket,
press the ON/OFF button (7) « », the indicator
(6) will light up and start ashing. When the set
temperature is reached, the indicator (6) will glow
constantly.
• Take the garment steamer by the handle (8) on the
same level with the steam supply on button (4).
• To switch the steam supply on, press and hold down
the button (4).
• To switch the steam supply o󰀨 release the button (4).
• For continuous steam supply, move the lock (3)
downwards, to switch the continuous steam supply
on, move the lock (3) upwards.
• Before general use of the garment steamer clean the
steam chamber. To do this, direct the outgoing steam
to a piece of cloth, for instance, try to smooth out a
kitchen towel.
• If during the operation the water tank (1) becomes
empty, switch the garment steamer o󰀨 before
removing the tank (1) and relling it with water, press
and hold the ON/OFF button (7) « », disconnect
the power plug (9) from the mains socket. To do this,
disconnect the power plug (9) from the mains socket.
• After the unit operation switch the garment steamer o󰀨,
remove the power plug (9) from the mains socket and let
the garment steamer cool down.
Note: when switching the unit on for the rst time, foreign
smell can appear. It is normal.
ATTENTION!
If the garment steamer is switched on and does not operate
for 8 minutes, the heating element will switch o󰀨 and the
indicator (6) will be ashing. To switch the garment steamer
on, press the steam supply button (4) or the ON/OFF button
(7) « », the garment steamer will switch on; wait until the
indicator (6) glows constantly and continue the operation.
USING THE BRUSH ATTACHMENT
ATTENTION!
Before installing the brush attachment (11) and
removing the tank (1), make sure that the power plug
(9) is not inserted into the mains socket.
• Install the brush attachment (11) on the garment
steamer.
• Remove the water tank (1).
• Open the water inlet lid (2). Fill the water tank (1) with
water non exceeding the MAX mark and close the water
inlet lid (2) tightly.
• Do not ll the tank (1) with carbonated water, perfume
additives, vinegar, chemical agents, etc.

8 9EN EN
• Install the water tank (1) back to its place and make
sure that the tank (1) is xed properly.
• Place the garment steamer on the base (10) on a at
and steady surface.
• Connect the power plug (9) to the mains, press the
ON/OFF button (7) « », the indicator (6) will light
up and start ashing. When the unit reaches the set
temperature, the indicator (6) will glow constantly.
• Take the garment steamer by the handle (8) on the
same level with the steam supply on button (4).
• Hang the clothes on a hanger.
Note: never steam clothes on a person as the outgoing
steam temperature is very high, use a hanger only.
• To switch the steam supply on, press and hold down
the button (4).
• To switch the steam supply o󰀨 release the button (4).
• For continuous steam supply, move the lock (3)
downwards, to switch the continuous steam supply
on, move the lock (3) upwards.
• Slowly move the brush attachment (11) along the
fabric, smooth out the fabric with your free hand.
Notes:
- during operation, hold the garment steamer vertically
and do not turn it over;
- during the garment steamer operation the upper
part of the body becomes very hot. Be careful and do
not touch hot parts of the unit body and the operating
surface (3);
- after steaming the clothes may need some time to dry,
leave them on the hanger.
• After the unit operation, press and hold the ON/OFF
button (7) « », remove the power plug (9) from the
mains socket and let the garment steamer cool down.
• Detach the brush attachment.
• Remove the water tank (1), open the lid (2) and pour out
the remaining water, install the water tank (1) back to its
place.
OVERHEATING PROTECTION
• If you accidentally switch the garment steamer on without
water or the water level appears to be below the minimal
mark, the automatic thermal switch will be on and the
garment steamer will be switched o󰀨 and the indicator (6)
will go out.
• In this case disconnect the power plug (9) from the mains
sockets and let the garment steamer cool down for 15-20
minutes. Then ll the water tank (1) with water and insert
the power plug (9) to the mains socket, the garment
steamer will operate in normal mode.
CLEANING AND CARE
• Disconnect the power plug (9) from the mains socket and
wait until the garment steamer cools down completely.
• Remove the water tank (1), open the lid (2) and pour out
the remaining water, install the water tank (1) back to its
place.
• Clean the garment steamer body (7) and the operating
surface with the steam release openings (5) with a
slightly damp cloth, and then wipe dry.
• You can remove the mineral deposit from the
operating surface (5) with a cloth soaked in vinegar-
water solution.
• Remove the brush attachment (11) and wash it under
a water jet.
• Do not use abrasive cleaners and solvents to clean
the garment steamer.
• Do not immerse the garment steamer, the power cord
(9) and the power plug (9) into water or any other
liquids.
STORAGE
• Unplug the garment steamer and wait till it cools
down completely.
• Clean the garment steamer.
• Keep the unit in a dry cool place out of reach of
children and disabled persons.
Troubles and troubleshooting
DELIVERY SET
1. Garment steamer – 1 pc.
2. Brush attachment – 1 pc.
3. Manual – 1 pc.
TECHNICAL SPECIFICATIONS
• Power supply: 220-240 V, ~ 50/60 Hz
• Rated input power: 1400 W
• Water tank capacity: 220 ml
• Steam release: 25 g/min
RECYCLING
To prevent possible damage to the
environment or harm to the health of
people by uncontrolled waste disposal,
after expiration of the service life of the
unit or the batteries (if included), do not
discard them with usual household waste,
take the unit and the batteries to specialized stations for
further recycling.
The waste generated during the disposal of products
is subject to mandatory collection and consequent
disposal in the prescribed manner.
For further information about recycling of this product
apply to a local municipal administration, a household
waste disposal service or to the shop where you
purchased this product.
The manufacturer reserves the right to change the
design, structure and specications not a󰀨ecting
general principles of the unit operation, without prior
notice.
The unit operating life is 3 years
The manufacturing date is specied in the serial
number.
In case of any malfunctions, it is necessary to apply
promptly to the authorized service center.
