Bresser ClimaTrend Life H User manual

Weather Station · Wetterstation ·
ClimaTrend Life H
EN Instruction manual
DE Bedienungsanleitung

DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or the
available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit product
of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare il
nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7008000000000
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or the
available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit product
of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare il
nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7008000000000
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA

3 / 56
1 Imprint
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
For any warranty claims or service inquiries, please refer to
the information on "Warranty" and "Service" in this docu-
mentation. We ask for your understanding that unsolicited
returns cannot be processed.
Errors and technical changes excepted.
© 2022 Bresser GmbH
All rights reserved.
The reproduction of this documentation - even in extracts -
in any form (e.g. photocopy, print, etc.) as well as the use
and distribution by means of electronic systems (e.g. image
file, website, etc.) without the prior written permission of the
manufacturer is prohibited.
The designations and brand names of the respective com-
panies used in this documentation are generally protected
by trade, trademark and/or patent law in Germany, the
European Union and/or other countries.
2 Validity note
This documentation is valid for the products with the follow-
ing article numbers:
7008000000000
Manual version: 0222

4 / 56
Manual designation:
Manual_7008000000000_ClimaTrend-Life-H_en-
de_BRESSER_v022022a
Always provide information when requesting service.
3 About this Instruction Manual
NOTICE
These operating instructions are to be considered a
component of the device.
Read the safety instructions and the operating manual care-
fully before using this device.
Keep this instruction manual in a safe place for future refer-
ence. When the device is sold or given to someone else,
the instruction manual must be provided to the new owner/
user of the product.
4 General safety instructions
DANGER
Risk of an electric shock!
This device contains electronic parts that are powered by a
power source (AC adapter and/or batteries). Improper use
of this product may result in electric shock. Electric shock
can cause serious or fatal injuries. It is therefore imperative
that you observe the following safety information.
• Never leave children unattended when handling the
device! Follow the instructions carefully and do not at-
tempt to power this device with anything other than

5 / 56
power sources recommended in this instruction
manual, otherwise there is a danger of an electric
shock!
• Disconnect the power supply by pulling the mains plug
when the appliance is not in use, in case of a longer in-
terruption of operation and before any maintenance
and cleaning work.
• Place your device so that it can be disconnected from
the power supply at any time. The power outlet should
always be near your appliance and should be easily ac-
cessible, as the plug of the power cord serves as a dis-
connect device from the mains supply.
• To disconnect the unit from the mains, always pull the
mains plug and never pull the cable!
• Check this device, cables and connections for damage
before use.
• Never attempt to operate a damaged device, or a
device with damaged electrical parts! Damaged parts
must be replaced immediately by an authorized service
agent.
• Operate the device only in a completely dry environ-
ment and do not touch the device with wet or damp
body parts.
DANGER
Danger of suffocation!
Improper use of this product may result in suffocation, espe-
cially for children. It is therefore imperative that you observe
the following safety information.
• Keep packaging materials (plastic bags, rubber bands,
etc.) away from children! There is a danger of choking!

6 / 56
• This product contains small parts that can be swal-
lowed by children! Choking hazard!
DANGER
Explosion hazard!
Improper use of this product may result in fire. It is essential
that you observe the following safety information in order to
avoid fires.
• Do not expose the device to high temperatures. Use
only the supplied AC adapter or the recommended bat-
teries. Do not short-circuit the device or batteries or dis-
pose of in fire! Excessive heat and improper handling
can cause short circuits, fires and even explosions!
NOTICE
Danger of material damage!
Improper handling may result in damage to the unit and/or
accessories. Therefore, use the device only in accordance
with the following safety information.
• Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Ser-
vice Center and can arrange the return of this device
for repair if necessary.
• Do not expose the device to high temperatures and
protect it from water and high humidity.
• Do not immerse the unit in water!
• Do not subject the device to excessive vibrations.
• Only use accessories and spare parts for this device
that comply with the technical specifications.

7 / 56
• Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dif-
ferent brands or types or with different capacities. Re-
move batteries from the device if it is not to be used for
a longer period of time!
• Do not use rechargeable AA batteries, as these will not
give out the correct voltage for use.
NOTICE
Danger of voltage damage!
The manufacturer accepts no liability for voltage damage as
a result of incorrectly inserted batteries, or the use of an un-
suitable mains adapter!

8 / 56
5 Parts overview and scope of
delivery
12/24
1
2
3
4
5
6
26
27
20
910 11
812
13 18
A
B
C
16 17
14
15
19
23
24
25
22
7
21
Illustration1: Parts overview for base station and remote sensor
1 ALARM/SNOOZE button
(snooze function)
2 LCD Display

9 / 56
3 Colour loop - humidity (Press
button again to stop at cur-
rent colour).
4 Colour loop - temperature
(Press button again to stop
at current colour).
5 Automatic colour change
when temperature or humidity
changes.
6 DC connection socket for
coaxial/barrel connector
7 Battery compartment (Base
station) (Backup)
8 TIME SET button
9 ALARM button 10 ALERT button
11 CH button (Channel selec-
tion) and UP button (+)
12 MEM button (switch between
maximum/minimum weather
data records) and DOWN
button (-)
13 HISTORY button (retrieve
measurements for the past
24 hours)
14 RESET button (reset all set-
tings)
15 °C/°F switch (display change
between °C or °F)
16 SENSOR button (initializing
sensor data reception)
17 12/24 hours time mode 18 INDEX button (display
change between current tem-
perature and heat index)
19 HI/LO/OFF button (Backlight
brightness)
20 Function indicator
21 RCC button (initialize time
signal reception)
22 RESET button (reset all set-
tings)
23 Wall mount 24 Channel selector switch
25 Battery compartment (Re-
mote sensor)
26 DC power adapter with EU
mains plug.
27 DC coaxial/barrel connector
Scope of delivery
Base station (A), remote sensor (B), power adapter (C)

10 / 56
Also required (not included):
2 pcs. Mignon batteries (1.5V, AA type), 1 pcs. CR2032 but-
ton cell (as backup)

11 / 56
6 Screen display
1
9
7
6
10
8
3
4
5
2
23
22
17
18
19
20
12
14
13
15
11
16
21
Illustration2: Parts overview for base station
1 Graphical weather trend dis-
play
2 Remote sensor signal
strength

12 / 56
3 Indoor area and outdoor
channel 1-8 Symbol
4 Automatic Channel loop
5 Battery level indicator (re-
mote sensor)
6 AM/PM information in 12-
hour time mode
7 Current time 8 Alarm symbol (bell)
9 Symbol for active daylight
saving time (DST)
10 Time signal transmission
symbol
11 Date 12 Humidity value
13 Mould alert symbol (will be
displayed when upper limit
value is exceeded)
14 Humidity trend arrow indic-
ator
15 Humidity Level 16 Alarm symbol for high
(HIGH) or low (LOW) humid-
ity
17 Heat alert 18 Ice alert
19 Temperature Level 20 Temperature trend arrow in-
dicator
21 Heat index 22 Temperature value
23 Alarm symbol for high
(HIGH) or low (LOW) tem-
perature (indoor)
7 Before commissioning
NOTICE
Avoid connection faults!
In order to avoid connection problems between the devices,
the following points must be observed during commission-
ing.
1. Place the base unit (receiver) and sensor (transmitter)
as close together as possible.

13 / 56
2. Connect the power supply to the base unit and wait un-
til the indoor temperature is displayed.
3. Establish power supply for the sensor.
4. Set up/operate the base unit and sensor within the ef-
fective transmission range.
5. Make sure that the base unit and the radio sensor are
set to the same channel.
When changing the batteries, always remove the batteries
in both the base unit and the sensor and reinsert them in
the correct order so that the radio connection can be re-es-
tablished. If one of the two devices is operated via a mains
power connection, the power connection for this device
must also be disconnected briefly when changing the bat-
tery. If, for example, only the batteries in the sensor are re-
placed, the signal cannot be received or can no longer be
received correctly.
Note that the actual range depends on the building materi-
als used in the building and the position of the base unit and
outdoor sensor. External influences (various radio transmit-
ters and other sources of interference) can greatly reduce
the possible range. In such cases, we recommend finding
other locations for both the base unit and the outdoor
sensor. Sometimes a shift of just a few centimetres is
enough!
Though the remote unit is weather proof, it should be placed
away from direct sunlight, rain or snow.
8 Setting up power supply
Base device
1. Insert the DC connector into the connection socket of
the base station.
2. Insert the mains plug into the power outlet.

14 / 56
3. The device is energized directly.
4. Wait until the indoor temperature is displayed on the
base station.
NOTICE!For permanent operation, mains power
supply is recommended. Alternatively a power sup-
ply with batteries is also possible, to keep the time
setting in case of power failure. Proceed as follows:
5. Remove the battery compartment cover.
6. Insert the batteries into the battery compartment. En-
sure that the battery polarity (+/-) is correct.
7. Replace the battery compartment cover.
8. Wait until the indoor temperature is displayed on the
base station.
NOTICE!When switching from mains power supply
to battery power supply or vice versa, the power
supply is being disabled for a short moment for
technical reasons. Exception: permanent battery op-
eration.
Remote sensor
9. Remove the battery compartment cover.
10. Insert the batteries into the battery compartment. En-
sure that the battery polarity (+/-) is correct.
11. Set the channel selector switch to the desired channel.
NOTICE!This weather station can be operated with
one or more remote sensors. Each remote sensor
being connected must be operated on a different
channel. If only one remote sensor is connected, it
should be operated on channel 1.
12. Replace the battery compartment cover.

15 / 56
9 Automatic time setting
After the powering it on, the unit automatically searches for
the radio signal. It takes about 3-8 minutes to complete this
process.
If the radio signal is received correctly, the date and time
are set automatically and the reception symbol is displayed.
If no radio signal is received, proceed as follows:
1. Press the RCC button for approx. 2 seconds to initiate
the reception of the radio signal again.
2. If no radio signal is still received, the time must be set
manually.
10 Manual time setting
1. Press and hold TIME SET button for approx. 3 seconds
to change to time setting mode.
2. Digits to be set are flashing.
3. Press +/CHANNEL or -/MEM button to change the
value.
4. Press TIME SET button to confirm and continue to the
next setting.
5. Settings order: 12/24-hours mode > Hours > Minutes >
Year > Month (M) and Day (D) / Day (D) and Month (M)
> Month > Day > Time offset > Time signal reception
(RCC) ON/OFF > DST (Daylight Saving Time) AUTO/
OFF > Weather forecast animation ON/OFF
6. Finally press the TIME SET button to save the settings
and exit the setting mode.

16 / 56
11 Alarm setting
1. Press and hold ALARM button for approx. 3 seconds to
enter the alarm time setting mode.
2. Digits to be set are flashing.
3. Press CH/+ (UP) or MEM/- (DOWN) button to change
the value.
4. Press ALARM button to confirm and continue to the
next setting.
5. Settings order: Hours > Minutes
6. Finally press the ALARM button to save the settings
and exit the setting mode. Alarm will be activated auto-
matically. The symbol will be displayed.
7. Press ALARM button in normal display mode to display
the alarm time.
8. Press ALARM button during the alarm time display to
disable the alarm.
12 Snooze function
1. When the alarm sound starts, press the ALARM/
SNOOZE button to activate the Snooze function. The
Alarm will sound again after 5 minutes.
2. When the alarm sound starts, press the ALARM button
or press and hold the ALARM/SNOOZE button for ap-
prox. 3 seconds, to stop the alarm.
3. The alarm will be turned off automatically if no button is
pressed within 2 minutes.

17 / 56
13 Receiving measurements
automatically
Once the power supply is enabled, the base station will dis-
play the measurement readings. Readings from the remote
sensor will be displayed within 3 minutes after powering it
on.
Read the detailed manual for more information about read-
ings (see download information on page 2).
14 Manual measurement display
1. Press MEM button several times to display the saved
values one after another.
2. Display order: MAX (highest value) temperature > MIN
(lowest value) temperature > MAX (highest value) hu-
midity > MIN (lowest value) humidity
3. Press MEM button for approx. 3 seconds during
highest or lowest value display to irrevocable delete all
saved values.
15 HI/LO Alert
HI/LO alert are used to alert you of certain weather con-
ditions. Once activated, an alarm sound is trigger and the
alert icon flashes as soon as a set value is reached.Suppor-
ted areas and alarm types:
Area Type of alert available
Indoor temperature HI AL / LO AL
Outdoor temperature HI AL / LO AL
Indoor humidity HI AL / LO AL

18 / 56
Outdoor humidity HI AL / LO AL
HI AL = High alert / LO AL = Low alert
HI/LO alert setting
1. Press the ALERT button for approx. 2 seconds and the
current channel symbol starts flashing.
2. Press the +/CH- or -/MEM button to select IN (indoor)
or CHANNEL 1-8.
3. Press ALERT button to confirm and continue to the
next setting.
4. Settings order: Channel > HI temperature > LO temper-
ature > HI humidity > LO humidity
5. Press the +/CH or -/MEM button to modify the value by
0.1 °C/°F for temperature or 1% for humidity. Press and
hold to quick adjust the value.
6. Press the ALARM button to activate or deactivate the
Alarm for the currently selected HI/LO Alert.
7. Then finished, press the ALERT button for approx. 2
seconds to return to normal mode.
Silence the alarm
8. When alert is triggered, press the ALARM/SNOOZE,
ALARM or ALERT button to stop the alert.
9. If you ignore the alarm, it will stop after 2 minutes by it-
self.

19 / 56
16 Weather trend
The weather station will calculate a weather trend for the
next 12 hours on basis of the measured values.
12345
1 Sunny 2 Partly cloudy
3 Cloudy 4 Rain
5 Snow
17 Trend arrow indicators
123
1 Rising 2 Steady
3 Falling
The temperature and humidity trend indicator shows the
trends of changes in the forthcoming few minutes. Arrows
indicate a rising, steady or falling trend.

20 / 56
18 Mould alert
The mould icon is an indication which is based on in-
door and outdoor air temperature and humidity in an at-
tempt to determine risk of mould. It allows you to monitor
some key areas in the home, that can lead to mould, dust
mites and bacteria.
Note:
The mould indication is just a reference for you to monitor
your living environment and remind you of the risk of mould.
19 Ice pre-alert
1. When the outdoor temperature hits the range of -2 ° C
to 3 ° C (28 ° F to 37 ° F) the ice pre-alert symbol
will appear on the display, flashing continuously.
2. The ice pre-alert symbol will disappear as soon as
the outdoor temperature leaves this range again.
20 Heat index
Press the INDEX button to display the Heat index
Heat index Warning Meaning
Above 46.1°C Extreme danger Strong risk of de-
hydration / sun
stroke
39.5°C ~ 46.1°C Danger Heat exhaustion
likely
