Bretford CORE 10S User manual

1
USER GUIDE STORE & CHARGE | CHGCAB10-CK
CORE™10S CABINET
TECHNICAL SPECIFICATIONS
CAPACITY
10 Devices
COMPATIBILITY
Chromebook screen sizes up to 13.3” (thickness less than 1”)
Tablet screen sizes up to 13.3” (thickness less than 1” with case)
UNIT DIMENSIONS
20.5”W x 17”D x 18”H
SLOT DIMENSIONS
0.875”W x 12”D x 9.25”H
WEIGHT WITHOUT DEVICES
48 lbs.
WARRANTY
12-years, 1-year on electrical
CONSTRUCTION
Steel constructed case with plastic molded slots.
SHIPPING
Ships fully assembled.
CAUTION
• Productisforindooruseonly
• Usercanonlyconnect10devicesatonetime
• Turnpowerswitchoffbeforepluggingindevices
• Turnpowerswitchoffbeforeunpluggingthecabinet
• Donotplugthecabinetiniftheswitchorpower
 cordhasbeendamaged

2
GENERAL USE
POWER SWITCH
Locatedontherighthandsideofthecabinet.
AC OUTLET ACCESS - ADAPTER STORAGE
PlugadaptersintoACoutletsasneeded.Usevelcrostrapstotiedownbricktypepoweradapters.
DEVICE STORAGE
ThreadassociatedpowercablesthroughslotsinACaccessdoorandthenclose.
ACOutletAccess-AdapterStorage DeviceStorage
PowerSwitch
USER GUIDE | CORE™10S CABINET STORE & CHARGE | CHGCAB10-CK
UsingtheHandle InsertingtheShackle LockProgramming
HANDLE & LOCK INSTRUCTIONS
USING THE HANDLE
The Flywheel Handle/Lock serves as a handle to open and close the cabinet when the shackle is not inserted.
INSERTING THE SHACKLE
Holdthelockshackleonaslightanglewheninsertingintotheshackleopeningandpushrmly.Oncetheshackleisinsertedthecam
isnolongerengagedandtheFlywheelHandle/Lockwillspinwithoutengagingthelockingcam,preventingthedoorfromopening.
LOCK PROGRAMMING
Toprogramtheuserprogrammablecombinationpadlockincluded:
1. Openthepadlockusingcombination“0000.”
2. Inserttheprogrammingkeyandturn90degrees.
3. Set the combination you would like to use.
4. Removetheprogrammingkey.

3
ATTACH TO DESKTOP/COUNTERTOP
1. Usingthetwointernalholesinthebottomfrontofthe
 cabinetasguides,(see orange arrows) drill two pilot
 holesintothemountingsurface.
2. Usingappropriatelengthscrews(customersupplied),
with washers if necessary, fasten the screws into the
 mountingsurface.DO NOT OVER TIGHTEN.
(For mounting to optional carrier, see separate instructions
included with CTUCAR-CK.)
USER GUIDE | CORE™10S CABINET STORE & CHARGE | CHGCAB10-CK
MOUNTING TO WALL
1.Attachthecabinetmountingplatetothewallusingsuitable
 hardwareforyourchosenmountingsurface.Themounting
 methodmustbeabletosupportupto220lbs.(100kg.).
2.Oncethemountingplateissecurelymountedtothewall,
 lifttheplateintoplaceandslidethematchingplate
located on the rear of the cabinet into the lip of the
wall-mounted plate. (See pictures above.)
3.Topreventthecabinetfrombeingliftedoffoftheplate,
 secureitbyinsertingthe2screwsprovidedthroughthe
holes in the back of the cabinet (see picture) and fasten
 securely.Oncethefrontdoorislockedthesescrewswill
 beinaccessible,preventingthecabinetfrombeing
removed from the wall.
CAUTION
• For added safety and ease of installation, use a
 qualiedprofessionaltoproperlyinstallthecorrect
 mountinghardware.Failure to secure the cabinet
properly will void the warranty.
• Thewallmountingplateisintendedtosupportthe
 cabinetandtenmobiledevices(maximumweightof
devices not to exceed 40 lbs.).
• Donotplaceanythingontopofthecabinet.
• Useonlythemountingplateprovidedwith
this product.
• Bretford will not be liable for the improper use
installation of its products.
Part#031-10018
Rev. 01 03.11.14 RCG
