Bretford CUBE Micro Statio User manual

031-11214 Rev. 1 05/2022 1 of 9
User Guide

031-11214 Rev. 1 05/2022 2 of 9
About Your Product
Product Overview
The CUBE Micro Station® Charging Station
Adapter storage
below the module tray
Removable Modules
accommodate up to
14 in devices
9 Foot Power Cable
Lift Handles
Programmable
combo padlock
Courtesy
Outlet
Power Switch
TVS10
TVS16

031-11214 Rev. 1 05/2022 3 of 9
About Your Product
Technical Specifications
CUBE Micro Station®
Model
TVS10PAC CUBE Micro Station® 10
TVS10USBC CUBE Micro Station® 10 Pre-Wired
TVS16PAC CUBE Micro Station® 16
TVS16USBC CUBE Micro Station® 16 Pre-Wired
Outer Dimensions
(W x D x H)
(TVS10) 18.25 x 17 x 16.5 in / 46.4 x 43.2 x 41.9cm
(TVS16) 27 x 17.75 x 17.63 in / 68.6 x 45.3 x 45cm
Slot Dimensions
(W x D x H)
1.25 x 14 x 9.9 in.
3.2 x 35.6 x 25.1 cm.
Capacity 10 or 16 AC outlets
Weight
TVS10PAC 40 lbs/ 18.1 kg
TVS10USBC 48 lbs/ 21.8 kg
TVS16PAC 54 lbs / 24.5 kg
TVS16USBC 64 lbs/ 29.0 kg
Rating
125V, 12A. 60Hz
Charging
Supports device power adapters up to 65W each, or 1,440W total
Warranty
7- Year
Certifications
ETL Listed to UL 62368

031-11214 Rev. 1 05/2022 4 of 9
Using Your Product
CUBE Micro Station®
Setting the Combination Lock
Your new CUBE Micro Station® comes equipped with a resettable
Combination Padlock. You can program the lock with your own
combination. The lock starts with 0-0-0-0. Follow the directions with the
look for changing the combination. Remember to depress the shackle
before disengaging it from the lock.
Wiring your CUBE Micro Station® (Pre-Wired models can skip section)
1. Shutdown the CUBE Micro Station® using the power switch and
unplug the unit from the wall.
2. Unlock and open the CUBE Micro Station® door.
3. Remove device modules from the unit and set them to the side.
4. Remove the module tray by lifting up from the center cut out.

031-11214 Rev. 1 05/2022 5 of 9
Using Your Product
CUBE Micro Station®
Wiring your CUBE Micro Station® Cont…
5. One-by-one, plug each AC adapter into one of the AC outlets.
6. Route each power cable through the front, corresponding holes on the
lower portion of the unit.
7. Replace the module tray, making sure to wrap it over the front, back
and side edges. Look for imprinted “R” on the tray. “R” goes in first,
towards the back.
8. Replace the device modules in the unit.Left to right: slots 5, 6, 5
9. Insert devices into the slot dividers, connecting each into a
corresponding AC power adapter.
Note
: Middle divider between device
modules is not intended for storage.
10. Connect the main CUBE Micro Station power cord into the wall
11. Toggle the power switch to ON (“RESET”)

031-11214 Rev. 1 05/2022 6 of 9
Using Your Product
CUBE Micro Station®
Placing your CUBE Micro Station®
Your CUBE Micro Station® can be placed on a cabinet, stacked, daisy-
chained (TVS10 only) or wall mounted. Stacking and wall mounting kits are
available upon request.
Stacking
1. Carefully place two CUBE Micro Station®’s on top of each other to avoid
scratching or denting either station.
2. Locate the stacking brace plate and attach to the back of the units with
the four (4) Torx T-25 screws
Daisy-Chaining (TVS10 only)
Daisy-chaining allows for two CUBE Micro Station® 10 unit to be run off one
outlet.Daisy-chaining feature is not applicable to wall mounted units. The
remaining courtesy outlet can power an additional auxiliary device not to
exceed 100W.

031-11214 Rev. 1 05/2022 7 of 9
Using Your Product
CUBE Micro Station®
Daisy-Chaining Cont…
1. Shutdown both CUBE Micro Stations using the power switch and unplug
each unit from the wall.
2. With two units securely placed in adjacent positions, take the AC power
cord from one CUBE Micro Station® and plug into the rear courtesy outlet
of the adjacent CUBE Micro Station®.
3. Connect the AC power cord from the second CUBE Micro Station® into
the wall.
4. Toggle each CUBE Micro Station® power switch to ON (“RESET”)

031-11214 Rev. 1 05/2022 8 of 9
Important Information
Safety Notice
•
Product for indoor use only
•Do not plug the unit in if the switch or power cord has been damaged.
•For safety purposes, make sure all electrical components do not exceed
the maximum load rating of 12 amps.
•Do not sit on, stand on, or place unreasonably heavy objects on the unit.
•Unplug unit from te wall before moving to a different location.
•Only transport device to a different location if door is securely locked.
•Product must be plugged into a socket with an earthing connection.

031-11214 Rev. 1 05/2022 9 of 9
Additional Resources
Contact Support
Technical support is available by contacting Bretford Customer Care via
phone, email or the web:
Hours of Operation: M-F, 7:30am - 4:30pm CST
Telephone: [phone]
Email: [email protected]om
Website: www.bretford.com/contact
Bretford, CUBE, and CUBE Micro Station®are trademarks or registered marks of Bretford Manufacturing,
Inc. Patents pending. © 2022 Bretford Manufacturing, Inc. All rights reserved.
