Bretford MSP-W5 User manual

SUPPORT WALL INFEED
MODEL:
AssemblyInstructions
PARTS LIST
Qty Description
x Wall Plate
LIQUID™WORKSPACE
CAUTION:
Turn off all power prior to connecting or disconnecting
the liquid electrical components.
MSP-W5
MSP-W7
MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN

TopCover
Support
Fig. 1
Step 1
RemoveTop Cover bypulling it up andsave to reassemble.

Fig. 2
Step 2
DisassembleTop Plate and Data Traybyunfasteningthetwo
Data Plate Bolts. Save parts for reassembly.
Data Plate Bolt
TopPlate
DataTray

Pin Pin
Channel
Support
Fig. 3
Step 3
InstallChannelonSupportbyaligningpinswithcurvedslotsin
Support.Do not clamp.

Fig. 4
Step 4
Remove theDataCoversby twisting and pulling andBelly
Pan by pulling down (Fig. 3). Save parts for reassembly.
Data Cover
Data Cover
BellyPan

Fig. 5
Step 5
PlaceWallInfeedCoverPlate into Middle PlateofSupport by
aligningpinswith curved slots inMiddle Plate (Fig. 5).
WallInfeed
CoverPlate
Curvedslot
Middle Plate
Support
Pins

Infeed
Plug Distribution
Harness
Wall
monument
Infeed
open
end
Support
Partsremoved
forclarity
Channel
Infeed
Fig. 6
STEP 6
Hardwiretheend of the Infeedto the WallMonument (this has to be installed by a certi-
fied electrician).Threadtheother end of the Infeed through the WallInfeed Cover Plate
andtheChanneland connect it to the DistributionHarness(Fig.6).
Channel
Support
WallInfeed
CoverPlate Channelconnector
assembly

Fig.7
STEP 7
ReassembleDataTray,TopPlate, Data Covers andBellyPan(may have to liftChannelto
reinstallBelly Pan).
Part#031-6527
Rev. 07.15.03 IM
Bretford Bretford Ltd.
11000 Seymour Avenue Technology House
Franklin Park, IL 60131 7 Lake End Court, Taplow
TEL: [phone] Bucks SL6 0JQ England
800.521.9614 TEL: [phone]
FAX: [phone] FAX: [phone]
800.343.1779
www.bretford.com
Fig.8
STEP 8
WhenChannelis in desired position andsupportedon both ends clampChannelbyflip-
pingcam lever 180° overand replace Top Cover.
CamLever
