Breville Mini Wizz LFP150 User manual

the Mini Wizz™ Quad Blade
Instruction Book – LFP150

2
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
•Carefully read all
instructions before
operating the chopper for
the first time and save for
future reference.
•Remove and safely
discard any packaging
material and promotional
labels before using the
chopper for the first time.
•To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover fitted
to the power plug of the
chopper.
•Do not place the chopper
near the edge of a bench
or table during operation.
Ensure the surface is level,
clean and free of water
and other substances.
Contents
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition, we ask
that you exercise a degree
of care and adhere to the
following precautions.
2 Breville recommends safety first
7 Components
8 Assembly
9 Functions
10 Hints
10 Recommended foods,
quantities and function table
11 Care, cleaning & storage
12 Troubleshooting

3
•Do not use the chopper on
a sink drain board.
•Do not place the chopper
on or near a hot gas or
electric burner, or where
it could touch a heated
oven.
•Handle the chopper and
attachments with care.
•Remember the blades are
sharp and should be kept
out of reach of children
•Always ensure the
chopper is completely
assembled before
operating. The food
chopper will not
operate unless properly
assembled and the
processing bowl cover
is correctly locked into
place.
•Ensure the chopper is
switched off at the power
outlet and the power
cord is unplugged before
attaching the blades.
•Ensure the processing
bowl cover is securely
locked in place before
attempting to operate.
•Do not attempt to open
the processing bowl cover
when chopping.
•Keep fingers, hands,
knives and other utensils
away from moving blades.
•Do not place hands
or fingers into the
processing bowl unless
the blades have come to
a complete stop and the
power cord is unplugged.
•Ensure the blades have
completely stopped before
disassembling. Ensure
the chopper is switched
off and unplugged from
the power outlet before
attempting to move the
chopper, when not in use,
if left unattended and
before disassembling,
cleaning and storing.
•Do not use attachments
other than those provided
with the chopper.
•Do not attempt to operate
the chopper by any
method other than those
described in this book.

4
•Do not chop a dry, thick
or heavy mixture for
more than 10 seconds
without turning the
chopper off and stirring
the ingredients before
continuing.
•If the chopper is operated
continuously for too long,
it should be allowed to
rest for 25-30 minutes
before recommencing.
•Do not chop hot or boiling
liquids – allow liquids to
cool before placing into
the processing bowl.
•Do not move the chopper
while in operation.
•Do not leave the chopper
unattended when in use.
•Do not place any part
of the chopper in a
microwave oven.
•Do not chop thin liquids
such as water, milk, stock,
juice etc, above the MAX
level marked on the
processing bowl as this
could result in overflow.
To reduce the risk of
overflow, always add drier
or thicker ingredients to
the processing bowl prior
to adding fluids.
•Do not place anything on
top of the chopper when
the cover is on, when in
use and when stored.
•Keep the chopper clean.
Follow the Care, Cleaning
& Storage instructions
provided in this book.
IMPORTANT
SAFEGUARDS
FOR ALL
ELECTRICAL
APPLIANCES
•Fully unwind the power
cord before use.
•Connect only to a 230V
or 240V power outlet.
•Do not let the power cord
hang over the edge of
a bench or table, touch
hot surfaces or become
knotted.

5
•To protect against electric
shock, do not immerse
the power cord, power
plug or appliance in water
or any other liquid or
allow moisture to come
in contact with the part,
unless it is recommended
in the cleaning
instructions.
•The appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their
safety.
•Children should be
supervised to ensure that
they do not play with the
appliance.
•It is recommended to
regularly inspect the
appliance. To avoid a
hazard, do not use the
appliance if power cord,
power plug or appliance
becomes damaged in any
way. Return the entire
appliance to the nearest
authorized Breville service
centre for examination
and / or repair.
•Any maintenance other
than cleaning should
be performed at an
authorised Breville
Service Centre
•This appliance is for
household use only. Do
not use this appliance
for anything other than
its intended use. Do not
use in moving vehicles
or boats. Do not use
outdoors. Misuse may
cause injury.

6
•The installation of
a residual current
device (safety switch)
is recommended to
provide additional safety
protection when using
electrical appliances.
It is advisable that a
safety switch with a rated
residual operating current
not exceeding 30mA be
installed in the electrical
circuit supplying the
appliance. See your
electrician for professional
advice.
•During electrical storms,
the appliance should be
disconnected from the
power source at the wall
socked to prevent any
electrical surges that may
arise during the storm and
which may inadvertently
cause damage to the
appliance and its
electronic componentry.
•Always turn the appliance
to the OFF position, switch
off at the power outlet and
unplug at the power outlet
when the appliance is not
in use.
•Before cleaning, always
turn the appliance to the
OFF position, switch off at
the power outlet, unplug
at the power outlet and
remove the power cord,
if detachable, from the
appliance and allow all
parts to cool.
•Do not place this appliance
on or near a heat source,
such as hot plate, oven or
heaters.
•Position the appliance at
a minimum distance of
20cm away from walls,
curtains and other heat or
steam sensitive materials
and provide adequate
space above and on all
sides for air circulation.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

7
Components
A
B
C
D
E
F
D2
D1
A. POWER button
Press and hold to operate
continuously or press and release
in succession to PULSE.
B. Motor body
C. Processing bowl cover
D. Dual & quad blade
D1 - Removable spindle
with stainless steel lower
dual blade
Can be used on its own when dual
blade performance is required, or
assembled with the stainless steel
top blade (D2) to create the quad
blade chopping action.
D2 - Stainless steel top blade
Becomes quad blade when
assembled.
E. 600ml processing bowl
F. Processing bowl spindle shaft
Not shown
Power cord and plug
Anti-slip feet
NOTE
This chopper is designed with a safety
switch. If the processing bowl cover
or motor are not fitted correctly, the
blades will not operate.

8
ASSEMBLING THE BLADES
This chopper is designed with 2 (dual) or 4
(quad) blade operation. The dual blades come
connected to the lower spindle and can be used
on its own or assembled with the top blade for
quad blade action, depending on the chopping
requirement.
1. Place the removable spindle with lower
blades upright on the bench. Carefully
insert the removable top blades onto the
spindle ensuring the LOCK and UNLOCK
markings remain upward.
2. Carefully turn the top blades anti-clockwise
to secure and complete the quad blade
assembly.
WARNING
The blades must be handled carefully as they
are sharp!
NOTE
Refer to the RECOMMENDED FOODS,
QUANTITIES AND FUNCTION table in this
book for suggestions on using the dual blades
or the quad blades for specific results.
BEFORE FIRST USE
Before first use, remove and safely discard
of any promotional labels. Ensure that you
have all parts and accessories listed in
the components list before discarding the
packaging.
Wash the processing bowl, processing bowl
cover & stainless steel blades in warm, soapy
water. Dry thoroughly. Wipe the motor body
with a damp cloth and dry thoroughly.
WARNING
Blades are sharp! Handle with care.
WARNING
Do not immerse the motor body in any liquids.
NOTE
Carefully remove the plastic covers from the
blades before first use.
Assembly

9
NOTE
The chopper will not operate unless properly
assembled and the motor body is correctly in
place.
6. Insert the power plug into a 230V or 240V
power outlet. Switch the power on at the
power outlet.
7. Use one hand to hold the processing bowl.
With the other hand, press and hold down
the POWER button on the top of the motor
body to begin processing. Release the
POWER button to stop processing.
8. For pulsing, press and release in short spurts
on the POWER button until the desired
results have been achieved.
9. Once processing has finished, turn the
power off at the power outlet.
10. Remove the motor body, then turn the
processing bowl cover clockwise to unlock
and remove.
11. Carefully remove the spindle with blades
from the processing bowl.
WARNING
The blades must be handled carefully as they
are sharp!
12. Remove the processed food.
USING YOUR CHOPPER
1. Place the processing bowl on a flat, dry
surface such as a bench top. Ensure the
chopper is turned off at the power outlet
and the power cord is unplugged.
2. Once the blades are assembled, fit them
onto the processing bowl spindle shaft.
3. Add the food to the processing bowl.
4. Place the processing bowl cover onto the
processing bowl, ensuring the round tab on
the cover is parallel with the groove on the
processing bowl. Turn in an anti-clockwise
direction until the round tab aligns with
the to secure.
5. Align the tabs on the motor body with the
grooves on the processing bowl cover to
place the motor body on top. The motor
body will be seated on the processing bowl
cover ready for operation.
Functions

10
• Do not overload the chopper by putting
in too much food at one time. Chop in
batches for a better result (Refer to table for
quantities).
• Do not operate continuously for more than
one minute.
• Always remove the blades before removing
food.
• Chop larger quantities in batches; do not
exceed recommended maximum quantities.
• To ensure even chopping results, cut food
into pieces of similar size, up to 2cm square,
before placing into the chopper bowl.
Hints
• When chopping herbs, ensure they are as dry
as possible.
• To avoid damage to the processing blades,
do not process or grind hard items such as
frozen foods, ice, cereals, rice, spices and
coffee.
• Do not process thin liquids such as water or
milk.
• Do not process hot liquids.
RECOMMENDED FOODS, QUANTITIES AND FUNCTION
TYPE OF FOOD PREPERATION MAX. AMOUT
AT ONE TIME
PRESS OR
PULSE
NUMBER OF
BLADES
APPROXIMATE
TIME
Lean meat 2cm dice 50-200g Pulse 45 - 10 secs
Fish 2cm dice 50g – 200g Pulse 45 - 10 secs
Onions Cut into ¼’s 50g - 200g Pulse 45 - 10 secs
Nuts Shelled 50g – 100g Pulse 2 or 4 10 - 30 secs
Garlic Cloves only, raw or
cooked 20g – 150g Press 2 or 4 5 - 10 secs
Apple Cooked, tinned 50g – 130g Press 2 or 4 20 – 30 secs
Peanuts Shelled 50g – 200g Press 2 or 4 20 secs – 1 min
Bread 2cm dice 20g – 80g Press 430 secs – 1 min
Mayonnaise 250ml Press 2 or 4 30 secs – 2 mins
Vegetable puree,
soup
Soft, cooked and
COOLED 50ml – 300ml Press 2 or 4 30 secs – 2 mins
Herbs Dried or Fresh 10g – 30g Press 2 or 4 10 – 30 secs
WARNING! DO NOT ADD HOT FOODS TO THE PROCESSOR
as hot food may pop the cover if pressure builds

11
Before disassembling and cleaning, switch the
chopper off at the power outlet and remove the
power plug from the power outlet.
CLEANING THE PROCESSING BOWL
AND ACCESSORIES
1. Wash the processing bowl, processing
bowl cover and stainless steel blades in
warm soapy water after each use. Rinse
thoroughly and dry.
2. Wipe the motor body with a damp cloth.
Dry with a lint free cloth.
NOTE
The blades, processing bowl and processing
bowl cover can also be cleaned in a dishwasher.
WARNING
Do not wash or soak the motor body in water
or any other liquid. Do not allow water or any
other liquid to enter the gear system as this
may result in damage.
STORAGE
1. Re-assemble the quad blade assembly into
the processing bowl.
WARNING
The blades must be handled carefully as they
are sharp!
2. Place the processing bowl cover on the
processing bowl and turn in an anti-
clockwise direction to lock, then place the
motor body onto the processing bowl cover.
3. Store the chopper upright in a cool, dry
place.
Care, Cleaning
& Storage

12
Possible Problem Easy Solution
Motor doesn’t start or blades do not rotate • Check that the processing bowl, processing bowl
cover and motor body are securely locked into place.
• Check that the power plug is securely inserted into
the power outlet and the outlet is switched on.
Food is unevenly chopped • Either too much food is being chopped at one
time or the pieces are not small enough. Cut food
into smaller pieces of even size and chop a smaller
amount per batch.
• For best results, the food should be pre-cut into
pieces no larger than 2cm.
Food is chopped too fine or is watery • The food is over-processed. Use brief pulses or chop
for a shorter time.
Food collects on processing bowl cover or side
of bowl • Too much food. Turn the chopper off. Scrape the
bowl and processing bowl cover with a spatula.
Reduce the quantity of food and continue chopping.
Food sticks to the blades • Too much food. Turn the chopper off. Carefully
remove the blades. Remove the food from the
blades with a spatula. Reduce quantity of food and
continue chopping.
Troubleshooting

13
Notes

Notes

Notes

Breville, the Breville logo, Master Every Moment, and Mini Wizz
are trademarks of Breville Pty. Ltd. A.B.N. 98 000 092 928.
Copyright Breville Pty. Ltd. 2020.
Due to continued product improvement, the products illustrated/photographed
in this brochure may vary slightly from the actual product.
LFP150 ANZ – A20
Web: www.breville.comWeb: www.breville.com
Australian Customers
Phone: [phone]
New Zealand Customers
Phone: [phone]
Breville Customer Service Centre
