Briggs & Stratton 20272 Setup guide

Model No. 020272 (2200 PSI (151.7 BARS) Pressure Washer) Manual No. 206227B Revision - (03/10/2008)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Call: Pressure Washer Helpline
1-800-743-4115 M-F 8-5 CT
Illustrated Parts List

2BRIGGSandSTRATTON.COM
Exploded View and Parts list — Main Unit
Item Part # Description
1 202791GS BASE, w/Mounts
2 Y199110GS HANDLE
3 202792GS KIT, Billboard Assy w/Decal & Clips
195964GS Clips, Tree
30809GS Grommet
4 206383GS ASSY, Pump
5 189971GS Kit, Chemical Hose
6 23139GS Key
7 194298GS Valve, Thermal Relief
8 200279GS Kit, Chemical Injection
9 B2384GS Filter, Inlet
10 200278GS Kit, Water Inlet
11 202483GS KIT, Wheel
203872GS Axle
200520GS Cap, Hub
192050GS E-Ring
12 202017GS HOSE
13 202181GS KIT, Nozzles
198841GS Nozzle, Soap
201580AEGS Nozzle, QC, Project Pro, Red
201580XGS Nozzle, QC, Project Pro, Orange
201580RGS Nozzle, QC, Project Pro, Yellow
Item Part # Description
14 192310GS KIT, Vibration Mount
15 204627GS GUN
16 200595GS EXTENSION, QC
17 192649GS KIT, Pump Mounting Hardware
18 B2203GS KIT, Handle Connector
900 § ENGINE
Items Not Illustrated:
206227GS MANUAL, Operator’s
194256GS KIT, Tag/Warning Service
BB3061BGS OIL BOTTLE
793973 ASSY, Shroud/Label
794693 LABEL, Warning
202442GS DECAL, Shroud
87815GS GOGGLES
Optional Accessories
6048 KIT, O-Ring Maintenance
6039 PUMP SAVER
§ - Contact Engine Manufacturer
