Broadata Communications LBC-SPH4-1H3B-IR User manual

LBC-SPH4-1H3B-IR
BCI reserves the right to make changes to the products described herein without
prior notice or consent. No liability is assumed as a result of their use or
application. All rights reserved.
©2017 Broadata Communications, Inc.
Link Bridge HD BaseT
3x Transmission System
TM

SAFETY INSTRUCTIONS AND
COMPLIANCE DECLARATIONS
PLEASE OBSERVE THE FOLLOWING SAFETY
PRECAUTIONS
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may
be damaged by electrical spikes, surges, electric shock, lightning
strikes, etc. Use of surge protection systems is highly recommended
in order to protect and extend the life of your equipment.
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
Broadata Technical Support, [e-mail] 3
TM

TABLE OF CONTENTS
1.0 PRODUCT DESCRIPTION............................................................... 5
2.0 OPERATION CONTROLS AND FUNCTIONS................................... 6
2.1 FRONT PANEL.................................................................................. 6
2.2 REAR PANEL .......................................................................... 8
3.0 IR CABLE PIN ASSIGNMENT ........................................................... 9
4.0 MAINTENANCE AND TROUBLESHOOTING ................................. 10
4.1 MAINTENANCE .............................................................................. 10
4.2 TROUBLESHOOTING .................................................................... 11
5.0 SPECIFICATIONS ...........................................................................12
8.0 SERVICE PROCEDURE....................................................................13
8.1 REPLACEMENT POLICY ................................................................13
8.2 RETURN & REPAIR SERVICE............................................................13
9.0 LIMITED WARRANTY.......................................................................14
Broadata Technical Support, [e-mail] 4
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

FEATURES
• Extend HDMI Signals up to 100 meters Over One
CAT 5e/6 Cable
• Supports 4K2K & Full HDTV Video Resolutions up
to 720p/1080i/1080p@60 Hz
• Fully Uncompressed Video & Audio Provides Zero
Loss of Quality
• Supports True DDC/EDID/HDCP Transmission Over
One Ethernet Cable
• Video/Audio+IR+LAN, Over 1 CAT 5e/6 Cable
• Supports PoC (Power over Cable) with compatible
receivers
• Provides 3x HDBaseT output transmission ports
• Supports network rates up to 100Mbps and IR
Control Data
1.0 PRODUCT DESCRIPTION
Broadata Technical Support, [e-mail] 5
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

1. HDMI IN: Connect to HDMI equipped source equipment such
as a DVD/Blu-ray player or games console.
2. SYNC LED: This LED will illuminate when the HDMI input is
connected to a HDMI source and receiving a signal.
3. HDMI OUT: Connect to a HDMI display for local monitoring
of the HDMI signal or cascade to another Splitter.
4. HDMI LINK LED: This LED will illuminate when HDMI output is
connected to TV or display monitor and receiving a signal.
5. EDID STD/TV: The default setting is TV, when in this mode,
the unit will detect the EDID settings of the display device
connected to the CAT 5e/6/7 Output 1. If it detects a 4K×2K
capable EDID setting it will transmit the signal in that format to
the output port. If no 4K×2K capable EDID is detected then the
unit will detect the EDID settings and send out the signal that all
outputs can accept.
This device has a last memory function and will retain the EDID
settings of the last device connected via the CAT5e/6/7 output
port when it is not connected to a display after power cycling.
Switch to the STD setting to use the unit’s built-in EDID if there
are display problems. In this mode, the video output will be set
to 1080p@60Hz and the audio at LPCM 2CH Stereo.
2.0 OPERATION CONTROLS AND FUNCTIONS
2.1 Front Panel
Broadata Technical Support, [e-mail] 6
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

6. SERVICE: Reserved for manufacture use only.
7. POWER LED: The LED will illuminate when connected to an
active power supply.
8. DC 24V: Connect the 24V DC power supply to the unit and plug
the adaptor into an AC outlet.
Broadata Technical Support, [e-mail] 7
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] 8
1. IR IN: Connect the supplied IR Receiver cable for IR signal
reception. Ensure that remote being used is within the direct
line-of-sight of the IR Extender.
2. IR OUT: Connect the supplied IR Blaster cable for IR signal
transmission. Place the IR Blaster in direct line-of-sight of the
equipment to be controlled.
3. CAT5e/6/7 OUT 1~3: Connect to CAT5e/6/7 to HDMI Receivers
with a single CAT5e/6/7 cable each to extend the HDMI signal
up to 100 m.
MODE LED: This LED will illuminate when the power is connected.
LINK LED: This LED will illuminate when connected to a Receiver
unit that is connected with a TV/monitor that is displaying the
signal.
2.2 Rear Panel
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

3.0 IR CABLE PIN ASSIGNMENT
Broadata Technical Support, [e-mail] 9
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] 10
4.0 MAINTENANCE AND TROUBLESHOOTING
4.1 Maintenance
There is no operator maintenance other then keeping the
units clean. However, observe the following light indicators
to make sure that the unit is working properly:
4.2 Troubleshooting
If the LBC-SPH4-1H3B-IR units do not operate properly after
installation, check for possible cable breaks, loose connections,
and incorrect cable connections. If problems persist that may
be ber related, contact BCI at 1-800-214-0222 for further
assistance.
For electrical problems, perform the following troubleshooting
procedures:
1. If the POWER indicator is OFF, check for the following:
a. The line cord is plugged into the unit and your outlet
has power.
2. If the POWER indicator is ON, but the Link indicator is
OFF, check for the following:
a. Make sure the appropriate cables are being used.
b. Cable and cable connectors are not broken.
c. For each unit, the transmit (TX) cable is connected to the
other unit’s receiver (RX).
3. If the POWER indicator and Link indicator are ON, but
the channels are not operating, then:
a. Check to see that the attached user equipment is turned on.
b. Both ends of the link are connected to the corresponding
equipment and to the same corresponding channel port.
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] Technical Support, [e-mail] 11
c. Cable connections at both channels are securely fastened
to each connector. Turn the power o, then back on to reset
the link.
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] 12
4.0 SPECIFICATIONS
Video/ Audio Specications
HDMI Version 1.4 with 3D, 4K×2K support
Video Resolution 4K2K & up to 1080p@60Hz or
1920x1200@60Hz
Protocol DDC/EDID/HDCP Capable
Video Bandwidth 340MHz / 10.2Gbps
Audio Operating Mode Stereo Audio
Audio Formats Supports up to 7.1CH & Dolby
TrueHD, DTS-HD Master Audio
Audio Sampling Rate 32KHz to 192KHz
HDMI/Audio Connector HDMI Female plug
Data
IR Control Infrared
Data Rate 30 - 50KHz
In/Out Connectors 3.5mm Stereo
Physical
Dimensions
Standalone 5.71” (W) x 7.83” (D) x 1.18” (H)
Power Consumption +24VDC @ 2.7 Amps (Max.)
Operating Temperature 0 to +40oC
Humidity 20 to 90% RH, Non-Condensing
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] Technical Support, [e-mail] 13
5.0 SERVICE PROCEDURE
5.1 REPLACEMENT POLICY
Standard products found defective on arrival (DOA) will be
replaced, based on availability, within 24 to 48 hours anywhere in
the U.S. Please call Customer Service at 800-214-0222 for
information.
5.2 RETURN/REPAIR SERVICE
The LBC-SPH8-1H7B-IR System contains no user serviceable
components. If you have a problem with your unit, please
contact the Customer Service Department. To facilitate our
return/ repair processing please contact Broadata
Communications, Inc. to obtain a Return Material Authorization
(RMA). Please include the following information:
• Product model number
• Serial Number
• Complete description of problem
• Hardware installation description
Broadata Communications, Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone] (Facsimile)
e-mail: [email protected]
Website: www.broadatacom.com
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Communications, Inc. (BCI) warrants, for a period of one
year from date of shipment, each product sold shall be free from
defects in material and workmanship. BCI will correct, either by
repair, or at BCI’s election, by replacement, any said products that
in our sole discretion prove to be defective and are returned to the
manufacturing location within 30 days after such defect is ascertained.
All warranties are limited to defects arising under normal use and
do not include malfunctions or failure resulting from misuse, abuse,
neglect, alterations, electrical power problems, usage not in accordance
with product instructions, improper installation, or damage determined
by BCI to have been caused by the Buyer or repair made by a third
party. Limited warranties granted onproducts are to the initial customer
end-user and are not transferable.
OUR LIABILITY UNDER THIS WARRANTY SHALL IN ANY CASE BE
LIMITED TO THE INVOICE VALUE OF THE PRODUCT SOLD AND
BCI SHALL NOT BE LIABLE TO ANYONE FOR CONSEQUENTIAL
OR INCIDENTAL DAMAGES ARISING FROM THE USE OF ITS
PRODUCTS OR THE SALE THEREOF. We make NO WARRANTY
AS TO THE MERCHANTABILITY OF ANY GOODS, OR THAT THEY
ARE FIT FOR ANY PARTICULAR PURPOSE OR END APPLICATION
NOR DO WE MAKE ANY WARRANTY, EXPRESSED OR IMPLIED
OTHER THAN AS STATED ABOVE.
Broadata Technical Support, [e-mail] 14
8.0 LIMITED WARRANTY
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Technical Support, [e-mail] 15
LBC-SPH4-1H3B-IR User’s Manual
Link Bridge HD BaseT 3x Transmission System
TM

Broadata Communications, Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone] (Facsimile)
e-mail: [email protected]
Website: www.broadatacom.com
LBC-SPH4-1H3B-IR
