Broan 353SOBK User manual

MODEL 353SOBK
Page 1
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer.
If you have questions, contact the manufacturer at the address
or telephone number listed in the warranty.
2. Before servicing or cleaning unit, disable the ventilator by cover-
ing the solar panel with cardboard or disconnecting the wires
from the motor terminals (note wire locations when disconnect-
ing).
3. Installation work must be done by a qualified person(s) in ac-
cordance with all applicable codes and standards, including
fire-rated construction codes and standards.
4. If removing an existing 120 VAC powered attic ventilator, use
only a qualified person(s) to remove any electrical wiring in
accordance with all applicable codes and standards.
5. Sufficient air is needed for proper combustion and exhausting
of gases through the flue (chimney) of fuel burning equipment
to prevent backdrafting. Follow the heating equipment manufac-
turer's guidelines and safety standards such as those published
by the National Fire Protection Association (NFPA), and the
American Society for Heating, Refrigeration and Air Condition-
ing Engineers (ASHRAE), and the local code authorities.
6. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
CAUTION
1. F o r general ventilating use only. Do not use to exhaust hazard-
ous or explosive materials and vapors.
2 . To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power
unit.
3. This unit has an unguarded impeller. Do not use in locations
readily accessible to people or animals.
4. This ventilator operates when the solar panel is exposed to
sun light. To reduce risk of injury while installing, servicing or
cleaning unit, cover the solar panel with cardboard or discon-
nect the wires from the motor terminals (note wire locations
when disconnecting).
5. The recommended open air inlet for this ventilator is 4.25
square feet. The best location for these air intake vents are
under the eaves with direct access to the attic. Failure to pro-
vide these intakes could cause natural-draft gas appliances to
backdraft.
6. Your attic fan installation will create a screened opening into
your attic space. During a heavy rain storm there could be a
light spray of rain into this attic space. This is a normal condi-
tion with all attic ventilators and will not cause any damage to
the structure. We recommend that you do not store any valu-
able articles directly under the fan opening in the roof.
7
. This ventilator is intended for gable (side wall) installation.
Broan Models 349, 350, 355, & 356 Roof Mount Ventilators
are available for roof applications.
8. This ventilator is suitable for use with Broan Model 433 Auto-
matic Shutter (purchase separately).
9. The plastic ventilator dome and base may be painted with
high quality paint. Follow the paint manufacturer's recommen-
dations for acrylic and ABS plastic as appropriate. Ta k e care
to avoid getting paint on the solar panel.
10. Please read specification label on product for further informa-
tion and requirements.
11. The installation instructions contained in this document are
only a recommendation and individual professionals may
have their own methods of installation.
GABLE-MOUNT
SOLAR POWERED
ATTIC VENTILATOR
READ AND SAVE THESE INSTRUCTIONS
r
Slotted Screwdriver
r
Drill
r
1/4" Drill Bit
r
Sabre Saw or Keyhole Saw
r
Saw
r
Hammer
r
Ruler / Tape Measure
r
Pencil, Marker or Scribe
r
Utility Knife
r
Silicone or Roofing Cement
r
Galvanized Roofing Nails (1¾" min.)
TOOLS AND MATERIALS REQUIRED
Register your product online at:
www.broan.com/register

MODEL 353SOBK
Page 2
VENTILATOR INSTALLATION
Note: This ventilator is capable of replacing an existing
120 volt powered attic ventilator. Only a qualified per-
son should remove any electrical wiring in accordance
with local codes and standards.
1. The ventilator is designed to mount behind existing
louvers. Louvers should be mounted in the center of
the gable as high as possible. For maximum efficiency,
the open area of the louver should be greater than the
outlet area of the ventilator. If no louver exists, one must
be installed. Follow the manufacture’s recommendation
for installing the louver.
CAUTION! When installing louvers or ventilator, do
not remove any existing structural members without
providing alternate support members.
2. Locate the remote solar panel on your roof where the
sun’s exposure is best barring shade (trees, other
buildings etc) at 4:00pm in the hottest month of the year.
The solar panel comes from the factory with 15 feet of
wire. If the desired location of the solar panel is greater
than 15 feet away from the ventilator, an additional 50
ft of 14 AWG (minimum) UL listed or recognized copper
wire may be used.
3. Prior to installation, we recommend setting up the
ventilator and solar panel to verify operation. Ta k e
the fan and solar panel to a location exposed to sun.
Connect the red solar panel wire to the black (negative)
motor terminal and the black solar panel wire to the
red (positive) motor terminal. Removing the cardboard
cover from the solar panel should cause the ventilator to
operate. Place cardboard over solar panel (for safety),
disconnect wire from motor terminals and proceed to
installation instructions outlined below
4. The ventilator can be installed between studs or placed
over a curb manufactured from 2” x 4” or 2” x 6” wood
(refer to illustration above for curb dimensions). Nail
or screw the ventilator to the wall studs or curb around
perimeter of base every 6 inches.
5. Make sure the outlet of the ventilator is properly sealed to
the exterior wall to maximize the amount of air exhausted
by the ventilator. When installing the ventilator behind
louvers, seal off any louver area not covered by the
ventilator base to prevent air leakage and recirculation.
19-1/4”
16-1/8”
2”
MIN.

MODEL 353SOBK
Page 3
6. Working from inside the attic, find the center of the
selected solar panel location identified in step 2, drill a
small hole in the roof decking large enough for the solar
panel wire to fit through.
7. Feed the solar panel wire through the hole into the attic.
8. Run a bead of silicone or roof cement around the
perimeter of the underside of the solar panel and secure
to the roof using nails or screws. Nail or screw all corners
and perimeter of base every 6 inches. Seal the fastener
heads with silicone or roof cement.
9. From inside the attic, apply silicone around the wire
where it enters the roof.
10. Connect the red wire to the positive motor terminal and
the black wire to the negative motor terminal. Tape or
tie extra wire to prevent contact with the fan blade.
11. Remove cardboard from the solar panel and verify that
the ventilator operates.
REMOTE SOLAR PANEL
INSTALLATION
Model
Key 355RSOBK
No. (Black) Description
1 S99527255 Solar Panel Assembly
2 S99527261 Fan Blade w/ Set Screw
3 S99527257 Motor, DC
4 S99527250 Roof Sheet Panel
1
2
3
4
SERVICE PARTS
Replacement parts
can now be ordered
on our website.
Please visit us at
www.Broan.com

MODEL 353SOBK
Page 4
WARRANTY
BROAN-NUTONE LLC
– Exclusive Limited Warranty –
The Exclusive Limited Warranty Agreement (the “Warranty”) is entered into by and between Customer and Broan-NuTone LLC
(“Broan”). Customer has carefully reviewed this Warranty and agrees that Broan’s performance of its obligations hereunder will
provide Customer with an adequate remedy which will serve the essential purpose of the parties’ agreement relating to the products
manufactured by Broan and identified on the reverse side hereof (the “Products”). Customer acknowledges and agrees that he/she is
purchasing the Products for residential purposes (and not for industrial or commercial purposes) after careful inspection of the same.
Customer’s rights and benefits hereunder inure solely to Customer, as the original purchaser of the Products, and are non-assignable
and non-transferable. No other party or entity, including, without limitation, subsequent purchasers or owners of the Products shall
have or be entitled to assert any rights or benefits hereunder.
EXCLUSIVE LIMITED WARRANTY; LIMITATION OF REMEDIES. Broan hereby warrants the Customer that the Products’ motors
are and will remain for a period of two (2) years from the date of delivery to Customer; and the Products are and will remain for a
period of six (6) years from the date of delivery to Customer (collectively, the “Warranty Period”), free of defects in materials and
workmanship, provided that such Products are used for their intended purpose and are properly serviced in accordance with the
User’s Manual provided to Customer. Subject to the foregoing, if at any time during the Warranty Period any Product fails to conform
to the foregoing warranty by reason of defects in materials or workmanship, Customer shall properly notify Broan in writing and shall
include with such notice a sales receipt or proof of purchase of the defective Product, and Broan at its option shall repair or replace
the defective Product or component part without charge to Customer, except for: (A) costs incurred in transporting the Products or
component parts to and from Broan’s designated dealer or its manufacturing plant in Hartford, Wisconsin; and (B) charges for labor
or other costs incidental to the removal or remounting of component parts repaired or replaced under this Warranty, both of which
shall be borne by Customer. Notwithstanding any provision herein to the contrary, this Warranty shall not extend or obligate Broan
to take any action with respect to: (A) Products which have been modified, altered, installed, used or operated in a manner which is
not recommended by Broan, including any Products in which parts not manufactured or approved by Broan have been installed; (B)
Products which have not been regularly or properly serviced in accordance with the User’s Manual or which have otherwise been
neglected; and (C) ordinary wear and tear, service and maintenance and replacement items. THIS WARRANTY APPLIES ONLY
TO MACHINERY, EQUIPMENT AND COMPONENT PARTS MANUFACTURED BY BROAN. THIS WARRANTY DOES NOT APPLY
OR EXTEND TO: (A) PARTS PURCHASED SEPARATELY FROM SUCH MACHINERY AND EQUIPMENT, WHICH ARE COVERED
BY A SEPARATE WRITTEN WARRANTY; OR (B) ITEMS OF EQUIPMENT OR ACCESSORIES MANUFACTURED BY PARTIES
OTHER THAN BROAN.
EXCEPT AS SPECIFICALLY STATED IN THE PARAGRAPH IMMEDIATELY ABOVE, BROAN MAKES NO WARRANTY OR REP-
RESENTATION, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THE WARRANTY SET FORTH IN THE PRECEDING PARAGRAPH AND THE OB-
LIGATIONS AND LIABILITIES OF BROAN THEREUNDER REPRESENT CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES
AND ARE EXPRESSLY MADE IN LIEU OF ANY AND ALL OTHER REMEDIES, WARRANTIES, GUARANTIES OR LIABILITIES,
EXPRESS OR IMPLIED, ALL OF WHICH ARE HEREBY EXPRESSLY WAIVED BY CUSTOMER. THERE ARE NO WARRANTIES
WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT SHALL BROAN’S LIABILITY HERE-
UNDER EXCEED THE PURCHASE PRICE FOR THE PRODUCTS. ADDITIONALLY, BROAN SHALL NOT BE LIABLE FOR ANY
SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
Broan reserves the right to modify, alter or improve any products or equipment manufactured by Broan without incurring any duty or
obligation to modify, alter, improve or replace any of the Products covered hereby.
THIS WARRANTY SETS FORTH THE PARTIES’ FINAL, COMPLETE AND EXCLUSIVE AGREEMENT CONCERNING THE
PRODUCTS AND BROAN’S WARRANTY OBLIGATIONS. NO AFFIRMATION OF FACT, PROMISE, DESCRIPTION, DEMON-
STRATION, SAMPLE OR MODEL CONSTITUTES A WARRANTY OR OTHERWISE MODIFIES, EXTENDS OR ALTERS THIS
WARRANTY UNLESS IN A WRITTEN INSTRUMENT SIGNED BY AN AUTHORIZED BROAN OFFICER.
This Warranty shall be governed by and construed in accordance with the laws of the State of Wisconsin. The venue for any action
arising out of or related to this Warranty shall be in Washington County, Wisconsin.
99527271B
