SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
MODEL QTXE110S
VENTILATOR
21F 99044986A
A modern-styled, high performance fan, with
sensingcircuitry,that“knows”whentoventilate
the room.
FEATURES
BLOWER:
• Plug-in,permanentlylubricatedmotor-engineered
forcontinuousoperation
• Dynamicallybalancedcentrifugalblowerwheelfor
quiet,efcientperformance
• MaintainsahighpercentageofratedCFMinless
thanidealinstallations
• LowRPMforquietoperation
HOUSING:
• Rugged,26gauge,galvanizedsteelconstruction
• 6”roundductingforsuperiorperformance
• Polymericductconnectorwithtaperedsleeveandno
metallicclatter
• 7-5/8”heightallowsfor2”x8”(nominal)joist
installations
• Sturdy,easy,four-pointmountingdirectlytojoist
• Includesuniquespacer(patentpending)formounting
toengineered“I”joists
• Includeshangerbarstopositionhousinganywhere
between16”to24”-on-centerjoists
• Twosetsofmountingholesforhangerbarsallow
ushinstallationwithbottomortopofdrywall
GRILLE:
• Integratedhumiditysensor
• Polymericconstruction
• Innovativedesign-theresultofextensiveresearch
withdesignersandconsumers
Broan-NuToneLLCHartford,Wisconsinwww.broan.com800-558-1711
AUTOMATICCONTROL:
• HumiditycontrolautomaticallyturnsfanONwheneitherof
theseconditionsisdetected:
-arapidtomoderate(useradjustable)increaseofhumidity
-humidityaboveuser-adjustableset-point(50%-80%RH)
• Twowiremanualoperationforodorcontrol-TurnsfanON
whenpowerlinethroughwallswitchiscycledON,OFFand
backON
• RemainsONforauser-adjustable5to60minutesafter
humidityhasstabilizedandisbelowset-pointorafter
manuallyinitiatedthroughpowerlinecycling
• Savesenergybecauseunitrunsonlyforthetimerequired.
AunitcontrolledwithawalltimermaykeepfanONlonger
thanrequiredorturnitOFFbeforeroomissufciently
ventilated
ACCESSORYCONTROL(Purchaseseparately):
DesignedbyBroanforusewiththisproduct(purchase
separately)
• Model68V,P68V(Ivory)/68W(White)2-FunctionWall
Control
U.L.Listedforuseoverbathtubsandshowerswhenconnected
toaGFCIprotectedbranchcircuit(ceilingmountonly).
3-YearWarranty

Broan-NuToneLLCHartford,Wisconsinwww.broan.com800-558-1711
PERFORMANCE RATINGS
MODEL QTXE110S
VENTILATOR
AMPS
Model Amps*
 QTXE110S 0.3
WEIGHT
HVI-2100CERTIFIEDRATINGScomplywithnew
testingtechnologiesandproceduresprescribed
by the Home Ventilating Institute, for off-the-shelf
products,astheyareavailabletoconsumers.
Productperformanceisratedat0.1in.static
pressure,based ontests conductedin astate-of-
the-art test laboratory. Sones are a measure of
humanly-perceivedloudness,basedonlaboratory
measurements.
HVI PERFORMANCE
Model Shipping
Weight
 QTXE110S 12.2lbs.
*Total connected load
AIR FLOW PERFORMANCE
MODEL QTXE110S
TYPICAL SPECIFICATION
CeilingVentilatorshallbeBroanModelQTXE110S.
TheunitwillhaveacontrolthatwillautomaticallyturnfanON
whenhumidityincreaseisrapidtomoderate(useradjustable),or
whenhumidityishigherthanuser-adjustableset-point(50%-80%
RelativeHumidity),orwhensupplypoweriscycledfromON(for
morethanasecond)toOFF(forlessthanasecond)andback
ON.Itshallbeuser-adjustabletoturnOFF5to60minutesafter
humidityhasstabilizedandisbelowuser-adjustableset-point,
oraftermanuallyinitiatedbysupplypowercycling.
CeilingVentilatorshallhavecorrosionresistantgalvanizedsteel
housingwithfour-pointmountingcapability.Itshallbeductedto
arooforwallcapusing6”roundductwork.
Blowerassemblyshallberemovable,haveacentrifugal-typeblower
wheelandapermanentlylubricatedmotordesignedforcontinuous
operation.
Non-metallicdamper/ductconnectorshallbeincluded.
Airdeliveryshallbenolessthan110CFMandsoundlevelnogreater
than0.7Sones.AllairandsoundratingsshallbecertiedbyHVI.
CeilingVentilatorshallbeEnergyStar®qualiedandhaveanenergy
efcientpermanentsplitcapacitormotor.
CeilingVentilatorshallbeU.L.Listedforuseoverbathtubsand
showerswhenconnectedtoaGFCIprotectedbranchcircuit.
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0 10 20 30 40 50 60 70 80 90 100 110 120 130
Airflow (cfm)
Ps (in. w.g.)
Static Fan
Model Pressure (Ps) CFM Sones Watts
QTXE110S 0.10 110 0.7 33.5
0.25 90
