Broan ULTRA SILENT QTXE150 User manual

REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
SPECIFICATION SHEET
QTXE SERIES FANS
models QTXe050, QTXe080,
QTXe110, QTXe150
TYPICAL SPECIFICATION
Ceiling Ventilator shall be Broan Model QTXE050 (QTXE080)
(QTXE110) (QTXE150).
Ceiling Ventilator shall have corrosion resistant galvanized
steel housing with four-point mounting capability. It shall be
ducted to a roof or wall cap using 6” round ductwork.
Blower assembly shall be removable, have a centrifugal-type
blower wheel and a permanently lubricated motor designed
for continuous operation.
Non-metallic damper/duct connector shall be included.
Air delivery shall be no less than 50 (80) (110) (150) CFM
and sound level no greater than <0.3 (0.3) (0.7) (1.4) Sones.



Ceiling Ventilator shall be U.L. Listed for use over bathtubs
and showers when connected to a GFCI protected branch
circuit.
90D 99044085B
Ultra-quiet, high performance bath fan with a
modern-styled grille.
FEATURES
BLOWER:
• Plug-in, permanently lubricated motor - engineered for
continuous operation
• Dynamically balanced centrifugal blower wheel for

• Maintains a high percentage of rated CFM in less than
ideal installations
• Low RPM for quiet operation
• Resilient anti-vibration motor mounts (QTXE150 only)

• Rugged, 26 gauge, galvanized steel construction
• 6” round ducting for superior performance
• Polymeric duct connector with tapered sleeve and no
metallic clatter
• 7-5/8” height allows for 2” x 8” (nominal) joist
installations
• Sturdy, easy, four-point mounting directly to joist
• Includes unique spacer (patent pending) for mounting
to engineered “I” joists
• Includes hanger bars to position housing anywhere
between 16” to 24”-on-center joists
 
installation with bottom or top of drywall
• Can be mounted in ceilings up to 12/12 pitch
GRILLE:
• Polymeric construction
• Innovative design - the result of extensive research with
designers and consumers
CONTROLS (Purchase separately):
• Model 69VL (Ivory) / 69WL (White) - One rocker switch
with “on” indicator light
• Other controls available from Broan-NuTone
U.L. Listed for use over bathtubs and showers when
connected to a GFCI protected branch circuit (ceiling
mount only).
3-Year Warranty



PERFORMANCE RATINGS
QTXE SERIES FANS
AMPS
Model Amps
QTXE050 0.2
QTXE080 0.2
QTXE110 0.3
QTXE150 0.5
WEIGHT
Model Shipping
Weight
QTXE050 12.4 lbs.
QTXE080 12.4 lbs.
QTXE110 13.0 lbs.
QTXE150 13.6 lbs
AIR FLOW PERFORMANCE
MODEL QTXE050
MODEL QTXE080
MODEL QTXE110
MODEL QTXE150
0.0
0.1
0.2
0.3
0.4
0.5
0 10 20 30 40 50 60 70
Air flo w ( cf m )
Ps (in . w .g .)
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
010 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Airflow (cfm)
Ps (in. w.g.)
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0 10 20 30 40 50 60 70 80 90 100 110
Air flo w (c f m )
Ps (in . w .g .)
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0 10 20 30 40 50 60 70 80 90 100 110 120 130
Airflow (cfm )
P s (in . w .g. )
   comply with new
testing technologies and procedures prescribed
      
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in a state-of-the-art test laboratory.
Sones are a measure of humanly-perceived loudness,
based on laboratory measurements.
HVI PERFORMANCE
Static
Model Pressure (Ps) CFM Sones Watts
QTXE050 0.10 50 < 0.3 19.7
0.25 39
QTXE080 0.10 80 0.3 23.3
0.25 55
QTXE110 0.10 110 0.7 33.5
0.25 90
QTXE150 0.10 150 1.4 51.3
0.25 137
