BRONKHORST BRIGHT User manual

instruction manual
BRIGHT
Local colour TFT readout
and control module
Doc nr.: 9.17.048H Date: 15-03-2017
ATTENTION:
Before installing and operating the instrument it is recommended to read the Short-form user manual or this
instruction manual. Not following the guidelines could result in personal injury and/or damage to the equipment.

BRONKHORST®
9.17.048
Page 2
Disclaimer
Even though care has been taken in the preparation and publication of the contents of this manual, we do not assume
legal or other liability for any inaccuracy, mistake, misstatement or any other error of whatsoever nature contained
herein. The material in this manual is for information purposes only, and is subject to change without notice.
Symbols
!
Important information. Discarding this information could cause injuries to people
or damage to the Instrument or installation.
Helpful information. This information will facilitate the use of this instrument.
Additional info available on the internet or from your local sales representative.
Receipt of equipment
Check the outside packing box for damage incurred during shipment. Should the packing box be damaged, then the
local carrier must be notified at once regarding his liability, if so required. At the same time a report should be
submitted to your distributor.
Carefully remove the equipment from the packing box. Verify that the equipment was not damaged during shipment.
Should the equipment be damaged, then the local carrier must be notified at once regarding his liability, if so
required. At the same time a report should be submitted to your distributor.
Equipment storage
The equipment should be stored in its original packing in a cupboard warehouse or similar. Care should be taken not
to subject the equipment to excessive temperatures or humidity.
Warranty
The products of Bronkhorst® are warranted against defects in material and workmanship for a period of three years
from the date of shipment, provided they are used in accordance with the ordering specifications and the instructions
in this manual and that they are not subjected to abuse, physical damage or contamination. Products that do not
operate properly during this period may be repaired or replaced at no charge. Repairs are normally warranted for one
year or the balance of the original warranty, whichever is longer.
See also paragraph 9 of the Conditions of sales:
http://www.bronkhorst.com/files/corporate_headquarters/sales_conditions/en_general_terms_of_sales.pdf
•The warranty includes all initial and latent defects, random failures, and indeterminable internal causes.
•It excludes failures and damage caused by the customer, such as contamination, improper electrical hook-up,
dropping etc.
•Re-conditioning of products primarily returned for warranty service that is partly or wholly judged non-
warranty may be charged for.
•Bronkhorst High-Tech B.V. prepays outgoing freight charges when any part of the service is performed under
warranty, unless otherwise agreed upon beforehand. However, if the product has been returned collect to
Bronkhorst High-Tech B.V., these costs are added to the repair invoice. Import and/or export charges, foreign
shipping methods/carriers are paid for by the customer.

BRONKHORST®
9.17.048
Page 3
Table of content
1SCOPE OF THIS MANUAL...............................................................................................................................4
1.1 Introduction......................................................................................................................................................... 4
2UNPACKING .................................................................................................................................................. 5
3MOUNTING................................................................................................................................................... 7
4CONNECTING ................................................................................................................................................8
5USER INTERFACE ...........................................................................................................................................9
5.1 Buttons ................................................................................................................................................................ 9
5.2 Power-up ............................................................................................................................................................. 9
5.3 Display ................................................................................................................................................................. 9
5.4 Measure readout............................................................................................................................................... 10
5.5 Custom readout 1.............................................................................................................................................. 10
5.6 Custom readout 2.............................................................................................................................................. 10
5.7 Top line.............................................................................................................................................................. 11
5.8 Edit Setpoint...................................................................................................................................................... 11
5.9 Reset Counter.................................................................................................................................................... 12
5.10 Reset Alarm ....................................................................................................................................................... 13
5.11 Select Instrument .............................................................................................................................................. 14
6SETTINGS MENU ......................................................................................................................................... 16
6.1 Readout screen.................................................................................................................................................. 17
6.2 readout format.................................................................................................................................................. 17
6.3 fluidset selection ............................................................................................................................................... 17
6.4 fluid capacity ..................................................................................................................................................... 18
6.5 Controller settings screen ................................................................................................................................. 19
6.6 Setpoint slope.................................................................................................................................................... 19
6.7 Controller mode ................................................................................................................................................ 19
6.8 Master slave settings......................................................................................................................................... 20
6.9PID controller settings ....................................................................................................................................... 21
6.10 Controller response settings ............................................................................................................................. 22
6.11 Counter settings screen..................................................................................................................................... 23
6.12 Set counter mode .............................................................................................................................................. 24
6.13 Set counter parameters..................................................................................................................................... 24
6.14 Set setpoint at counter limit.............................................................................................................................. 25
6.15 Alarm settings screen ........................................................................................................................................ 26
6.16 Set alarm mode ................................................................................................................................................. 27
6.17 Set alarm mode parameters.............................................................................................................................. 27
6.18 Set setpoint at alarm ......................................................................................................................................... 28
6.19 Setup menu ....................................................................................................................................................... 29
6.20 Get instrument information .............................................................................................................................. 29
6.21 Change usertag.................................................................................................................................................. 30
6.22 Customize display info....................................................................................................................................... 30
6.23 Display appearance ........................................................................................................................................... 30
6.24 Bus settings ....................................................................................................................................................... 31
6.25 Advanced menu................................................................................................................................................. 31
6.26 Sensor filter settings.......................................................................................................................................... 31
6.27 Sensor auto zero................................................................................................................................................ 31
6.28 Restore instrument settings .............................................................................................................................. 32
7SECURITY SETTINGS .................................................................................................................................... 33
7.1 Security modes .................................................................................................................................................. 33
7.2 Enter the security settings screen ..................................................................................................................... 33
7.3 Security items .................................................................................................................................................... 33
7.4 Change Password .............................................................................................................................................. 34
7.5 Reset Password ................................................................................................................................................. 35
8TROUBLESHOOTING.................................................................................................................................... 36
9TECHNICAL DATA ........................................................................................................................................ 37
10 SERVICE....................................................................................................................................................... 38

BRONKHORST®
9.17.048
Page 4
1 Scope of this manual
1.1 Introduction
The BRIGHT is a readout and operator module for Bronkhorst® digital Mass Flow and Pressure Meters/Controllers. The
module not only allows reading of actual and total flow, simultaneously, but also features local operation, i.e. change
of setpoint, counter reset, setting of engineering units, fluid name and tag number, etc. Four push-buttons at the right
side of the device give access to a user-friendly menu. The bright 1.8” color display is clearly visible over a wide angle,
due to state-of-the-art TFT-technology. The weatherproof (IP65) housing makes the module suitable for use in
industrial areas and the module can be mounted on the instrument or, using the mounting kit, on an adjacent wall or
panel and on the pipework.
Note
Because the BRIGHT uses the RS232 port of these instruments for communication, other RS232 communication is not
possible. When the instrument is connected with a bus-system like PROFIBUS DP or DeviceNet, communication with
this bus-system will not be effected. Measure, setpoints and other parameters can be “read-and-write” by the BRIGHT
or via the bus-system.

2 | UNPACKING
9.17.048
Page 5
2 Unpacking
B1
B2
B3
B4




BRIGHT module




Mounting set


--
IP40 T-part
- -


IP65 T-part




Short 0.3m cable
-

-

Extended mounting set
-

-

Long cable for distance
mounting up to 1.0m




Short-form manual

2 | UNPACKING
9.17.048
Page 6
Check the outside packing box for damage incurred during shipment. Should the packing box be damaged,
then the local carrier must be notified at once regarding his liability, if so required. At the same time a report
should be submitted to:
BRONKHORST HIGH-TECH B.V.
RUURLO HOLLAND
Do not discard spare or replacement parts with the packing material and inspect the contents for damaged
or missing parts.
When returning material, always describe the problem and if possible the work to be done, in a covering
letter.
Take proper care of packing, if possible use the original packing box
Important: Clearly note, on top of the package, the customer clearance number of
Bronkhorst High-Tech B.V., namely:
NL801989978B01
!
!
!

3 | MOUNTING
9.17.048
Page 7
3 Mounting
!
Take attention to tighten, don’t over tight.
!
The BRIGHT comes with 4 different bolts. Please check the instruction above which bolt should be used.
The design makes it possible to place the BRIGHT in other positions as shown above. The clip and the BRIGHT
can be turned in angles of 90°. The BRIGHT can also be placed on the backside of the T-part.
The external mounting-part can also be used for mounting the BRIGHT on a wall.
Dimensional drawings are available at the download section of our website: http://www.bronkhorst.com

4 | CONNECTING
9.17.048
Page 8
4 Connecting
!
Do not apply pressure until electrical connections are made.
!
When providing your own power supply, be sure that voltage and current rating are according to the
specifications of the instrument(s). Cable wire diameters should be sufficient to carry the supply current and
voltage losses must be kept as low as possible.
!
Bronkhorst® recommends using their standard cables. These cables have the right connectors and if loose ends
are used, these will be marked to prevent wrong connection.
The hook-up diagrams are available at the download section of our website: http://www.bronkhorst.com
!
Before switching on power check if all connections have been made according to the hook-up diagram which
belongs to the instrument.
!
Turn on power and allow at least 30 minutes to warm up and stabilize the connected instrument.
!
When the T-part is connected, other RS232 communication is disabled.

5 | USER INTERFACE
9.17.048
Page 9
5 User Interface
5.1 Buttons
The buttons have the following functions:
- Enter selected menu
- Enter edit mode
- Confirm selection/changes
- Menu selection up
- Select information field
- Next character in edit mode
- Up in table
- Menu selection down
- Select information field
- Previous character in edit mode
- Down in table
- Return to previous screen
- Undo and Exit edit mode
- Change information in right user-field
Display
Measure readout
Custom readout 1
Custom readout 2
Top line
Buttons
Button
Button
Button
Button
5.2 Power-up
When power-up, the BRIGHT shows consecutive:
Firmware version
Bronkhorst logo
Readout screen.
5.3 Display
The display is divided into 4 areas, ‘measure readout’,
‘custom readout 1’, ‘custom readout2’ and the top line.
The information in these areas can be configured by the
user.
If an area contains a parameter which can be set or reset
by the operator, you can press or to select this
parameter. Press to enter the edit mode or press
to return to ‘measure readout’.
If ‘custom readout1’ is disabled. You can
only switch between ‘measure’ and ‘custom
readout 2’
SET
CANCEL
A
B
C
D
1
SET
2
3
4
CANCEL
1
2
3
SET
CANCEL
!

5 | USER INTERFACE
9.17.048
Page 10
5.4 Measure readout
This area shows the actual flow. The following parameters
will affect the format of this readout:
oactual or percentage readout
onumber of digits
5.5 Custom readout 1
This area can be enabled or disabled by the operator.
When enabled, the operator can choose one of the
following parameters to be shown:
parameter
editable
setpoint
yes
valve
no
temperature
no
density
no
The available parameters of this area are
determined by the connected instrument.
See chapter Customize display info on page 30 to select one
of the above parameters.
5.6 Custom readout 2
The ‘Custom readout 2’ area is always visible. The user can
choose one of following parameters to be shown:
parameter
editable
counter
yes
setpoint
yes
actual or percentage reading
no
valve
no
alarm
yes
capacity
no
temperature
no
density
no
select instr.
yes
The available parameters of this area are
determined by the connected instrument.
From the ‘measure readout’ press to change the
readout parameter of ‘custom readout 2’.Press
again te select the next available parameter.
!
!
CANCEL
CANCEL

5 | USER INTERFACE
9.17.048
Page 11
5.7 Top line
The top line will show the USERTAG or the serial number of
the connected instrument.
5.8 Edit Setpoint
Setpoint can only be edited when the setpoint parameter is
displayed in custom readout 1 or 2.
Security settings can be set to avoid unauthorised access to
the setpoint parameter.
To edit the setpoint press to select the readout area in
which this parameter is displayed. Press to enter the
edit mode, the first digit will lighten.
Security settings can be set to avoid
unauthorised access to the setpoint.
For changing security settings see chapter
“Security Settings” on page 33.
Use or to change the digits, press to confirm
and select the next digit.
You can change the setpoint edit mode into
‘step’. This enables you to change the setpoint
using fixed steps. See chapter Customize
display info page 30.
After the last digit is confirmed, the setpoint will be sent to
the instrument.
If the entered setpoint is ignored, check
controller mode. See chapter Controller mode
on page 19.
SET
!
SET
!

5 | USER INTERFACE
9.17.048
Page 12
The button can be used to exit the edit mode and
cancel the changes.
5.9 Reset Counter
The Counter can only be reset when the counter
parameter is displayed in custom readout 2. Security
settings can be set to avoid unauthorised access to the
counter parameter.
Check chapter “Custom readout 2” on page 10 how to
change the shown parameter.
To reset the counter press 2x to select the readout area
in which this parameter is displayed. Press to enter
the edit mode.
Press or to select ‘yes’ and press to confirm.
The counter will be reset to 0.
The button can be used to exit the edit mode and
cancel the changes.
CANCEL
SET
SET
CANCEL

5 | USER INTERFACE
9.17.048
Page 13
5.10 Reset Alarm
Alarm messages will be shown in the topline of the display
and custom readout 2 will be selected automatically.
Enter the edit mode by pressing . Use or to
select ‘yes’ and press again to confirm.
An alarm message will be occurring as long as
the cause has not been removed/repaired.
Security settings can be set to avoid
unauthorised access to this option.
For changing security settings see chapter
“Security Settings” on page 33.
SET
SET
!
!

5 | USER INTERFACE
9.17.048
Page 14
The button can be used to exit the edit mode and
cancel the changes.
If you are not intending to reset the alarm, you can press
to deactivate ‘Custom readout 2’. Check chapter
“Custom readout 2” on page 10 how to select another
parameter in this readout.
Actual alarm messages will always been shown in the
topline.
5.11 Select Instrument
When the instrument is connected to a FLOWBUS system,
it is possible to select another instrument on this bus to
operate. Check chapter “Custom readout 2” on page 10
how to select the option “select instr.” in “Custom readout
2”.
To enter the “select instrument” mode, press 2x . Press
to enter.
Security settings can be set to avoid
unauthorized access to this option.
For changing security settings see chapter
“Security Settings” on page 33.
CANCEL
CANCEL
SET
!

5 | USER INTERFACE
9.17.048
Page 15
The instrument directly connected with the BRIGHT will be
indicated as ‘local’. Other instruments will be indicated
with their node address.
Press or to search another instrument on the bus.
While the message “search” is displayed, the BRIGHT is
searching for a valid node address and it will not show any
specific instrument info till an active node is found.
When an active node address is found, the BRIGHT will
show the corresponding USERTAG or Serial Number in the
topline. It will also show the actual measure and, if applied,
the actual set point.
Press to select this instrument to be operated by the
BRIGHT or press to return to the previous selected
instrument.
SET
CANCEL

6 | SETTINGS MENU
9.17.048
Page 16
6 Settings menu
From the readout screen press to enter the settings
menu. Press to return to the readout screen.
Security settings can be set to avoid
unauthorised access to this menu.
For changing security settings see chapter
“Security Settings” on page 33.
The available menu options are determined by
the instrument you are operating.
In the following explanation, all possible options are
shown.
The or signs in the upper right corner indicates that
you can scroll this menu using the and buttons to
select more items. Press to enter the selected menu
item.
SET
CANCEL
!
!
SET

6 | SETTINGS MENU
9.17.048
Page 17
6.1 Readout screen
From the readout screen you can edit the following
settings:
oreadout format, actual or percentage
ofluidset selection
ocapacity
6.2 readout format
Enter the readout settings screen and press to enter
the edit mode of the readout option. Use or to
select either ‘actual’ or ‘percentage’.
Press to exit the edit mode without changing or
press to confirm your selection.
Press to return to the settings menu. Press
again to return from the settings menu to the
readout screen.
6.3 fluidset selection
From the readout screen press to select ‘fluid
selection’ and press to enter the fluid selection.
SET
CANCEL
SET
CANCEL
CANCEL
SET

6 | SETTINGS MENU
9.17.048
Page 18
Press again to enter the edit mode of the fluid field.
Use or to select one of the available fluidsets. Press
to confirm.
Press 3x to return to the readout screen.
6.4 fluid capacity
From the readout screen, press to select ‘fluid
selection’ and press to enter. In the fluid selection
screen press to select capacity and press to enter
the edit mode.
Now the fluid capacity can be changed between the
minimal and maximal capacity of the selected fluid of the
operating instrument.
When the last character is confirmed, the value will be
activated. Pressing before confirming the final
character will undo changes.
Use the button to return to the measure screen.
SET
SET
CANCEL
SET
SET
CANCEL
CANCEL

6 | SETTINGS MENU
9.17.048
Page 19
6.5 Controller settings screen
From the controller settings screen you can edit the
following settings:
osetpoint slope time
ocontroller mode
omaster address.
oPID settings
oresponse settings
To enter the controller settings screen, select the
controller option from the settings menu and press .
Take care when changing the controller
settings. Wrong controller settings can cause
unpredictable instrument behavior.
6.6 Setpoint slope
When entering the controller settings screen, the setpoint
slope parameter is already selected. Press to enter
the edit mode.
Now you can change the slope time. Use and to
select a character and press to select the next
character. Press to exit the edit mode without
changes.
Pressing after changing the final character will
confirm your input, the value will be sent to the
instrument.
Use the button to return to the readout screen.
6.7 Controller mode
Enter the controller settings screen from the settings
menu. Use to select the controller mode parameter
and press to enter the edit mode.
SET
!
SET
SET
CANCEL
SET
CANCEL
SET

6 | SETTINGS MENU
9.17.048
Page 20
The following controller modes can be selected:
selection
description
analog input
Setpoint via analog input
bus/rs232
Setpoint via bus or RS232 (BRIGHT)
rs232
Setpoint via RS232 only (BRIGHT)
fb ana slave
Setpoint is factor of measure of
master on the bus, factor is set by
analog input.
analog slave
Setpoint is factor of analog input
fb slave
Setpoint is factor of measure of
master on the bus
valve open
Setpoint neglected, valve fully open
valve close
Setpoint neglected, valve closed
controller idle
Setpoint neglected, valve stays in
actual position
setpoint 100%
Setpoint is 100 perc.
setpoint 0%
Setpoint is 0 perc.
Use or to select one of these control modes. Press
to cancel selection and exit the edit mode
without changes
When the required control mode is selected, press to
confirm.
6.8 Master slave settings
When you select one of the three slave modes the ‘master
slave’ option will be added to the controller settings
screen.
CANCEL
SET
