Brooks FluidX Aperio Series User manual




FluidX Aperio
Semi-Automated Screw Cap Decapper
User Manual
Part Number 319427 Rev. B
ThisistheOriginalinstructionfortheFluidXAperio.

FluidX
Part Number: 319427 Rev. B
Brooks Automation, Inc.

Informationprovidedwithinthisdocumentissubjecttochangewithoutnotice,andalthoughbelievedtobe
accurate,BrooksAutomation,Inc.assumesnoresponsibilityforanyerrors,omissions,orinaccuracies.
ABF™,AcuLigner™,AdvanTag™,Align™,AquaTran™,AutoTeach™,ATR™,AXM™,BasicBlue™,
BioStore™,BiSymmetrik™,CenterSmart™,CoolSolutions™,CratetoOperate™,CrossingConnect™,
Cryotiger™,DARTS™,Enerta™,e-RMA™,e-Spares™,e-Volution™,Falcon™,FastRegen™,FIXLOAD™,
FrogLeg™,IndependentTwinLinearExchange™,InCooler™,InLigner™,Interface™,Isoport™,ITLX™,
Jet™,JetEngine™,LEAP™,LowProfile™,M2Nano™,PASIV™,PowerPak™,PerformanceBlue™,Plate
Auditor™,PowerPak™,PowerTools™,QuadraFly™,Radius™,Radient™,RadientExpress™,
RapidThaw™,Reliance™,RelianceATR™,RetroEase™,SCARA™,SmartPM™,SPOTLevel™,Sprint™,
Synetics™,TheNewPathwaytoProductivity™,TimeOptimizedTrajectory™,TimeOptimalTrajectory™,
TimeOptimizedPath™,TopCooler™,TopLigner™,TubeAuditor™,UltimateBlue™,VAC-407™,
VacuTran™,VersaPort™,andWaferEngine™aretrademarksofBrooksAutomation,Inc.
AcuTran®,AquaTrap®,Asyst®,theCoolSolutionslogo,CrossingAutomation®,Cryodyne®,Cryo-Torr®,
Fusion®,GOLDLink®,Guardian®,GUTS®,Helix®,Leapfrog®,MagnaTran®,MapTrak®,Marathon®,
Marathon2®,MarathonExpress®,On-Board®,Polycold®,Razor®,REMP®,Spartan®,TrueBlue®,
TurboPlus®,Vision®,Xpeel®,XTape®,Zaris®,theBrookslogo,andtheBrooksLifeScienceslogoare
registeredU.S.trademarksofBrooksAutomation,Inc.
Allothertrademarksarepropertiesoftheirrespectiveowners.
©2020BrooksAutomation,Inc.Allrightsreserved.Theinformationincludedinthismanualisproprietary
informationofBrooksAutomation,Inc.andisprovidedfortheuseofBrookscustomersonlyandcannotbe
usedfordistribution,reproduction,orsalewithouttheexpresswrittenpermissionofBrooksAutomation,Inc.
ThistechnologyissubjecttoUnitedStatesexportAdministrationRegulationsandauthorizedtothe
destinationonly;diversioncontrarytoU.S.lawisprohibited.
OriginalmanualprintedinEnglish.







ii Copyright © 2020, Brooks Automation, Inc.

Brooks Automation
Part Number: 319427 Rev. B


Corporate Headquarters
15ElizabethDrive
Chelmsford,MA01824U.S.A.

ForTechnicalSupport:
Location Contact Number Website
North America [phone](TollFree)
[phone](Local) http://www.brooks.com/
Europe +498000009347(TollFreeGermany)
+4936417699996(HasToll) http://www.brooks.com/
Japan +81120-255-390(TollFree)
+8145-330-9005(Local) http://jp.brooks.com/
China +864006276657 http://cn.brooks.com/
Taiwan +886080-003-5556(TollFree)
+8863-5525258(Local) http://tw.brooks.com/
Korea 1800-5116(TollFree) http://kr.brooks.com/
Singapore +651-800-4-276657(TollFree)
+6563090701(Local) http://www.brooks.com/
ContactTechnicalPublicationsdirectly:[e-mail]




AcceleratingInnovation
Copyright © 2020, Brooks Automation, Inc. iii

FluidX
Part Number: 319427 Rev. B

Brooks Automation,
Inc.
15ElizabethDrive
Chelmsford,MA
01824-2400
Tel:+1978-262-2400
Fax:+1978-262-2500
www.brooks.com
BrooksLocationsWorldwide:
Brooks Automation Inc.
46702BaysideParkway
Fremont,CA94538
Tel:[phone]
Fax:[phone]
Brooks Life Sciences
BioStorageTechnologies
2910FortuneCircleWest,
SuiteE
Indianapolis,IN46241
Tel:+1317-268-5500
Fax:+1317-390-1868

Brooks Automation, Inc.
AIMServicios
Administrativos
SdeRLdeCV
CarreteraHuinalákm2.8
ParqueIndustrialLas
Américas66640Apodaca,NL
Mexico
Tel:+52818863-6363

Brooks Automation
(Germany) GmbH
Ernst-Ruska-Ring11
07745Jena,Germany
Tel:+4936414821100
Fax:+49364148214100

Brooks Automation
(Germany) GmbH
imWiesengrund17
78315Radolfzell,Germany
Tel:[phone]
Fax:[phone]

Brooks Automation
(Germany) GmbH
Karl-Marx-Strasse23
D-01109Dresden,Germany
Tel:+49351885930
Fax:+493518859322




Brooks Automation, Inc.
9601DessauRoad,Suite301

Austin,TX78754
Tel:+1512-912-2840
Toll-Free:+1800-367-4887

Brooks Life Sciences
BioStorageTechnologies
GmbH
ImLeuschnerpark1B
64347Griesheim,Germany
Tel:+4961558981011

Brooks Automation
(Israel) Ltd.
MevoYerach5
Kiryat-Gat82000
Israel
Tel:+97286722988
Fax:+97286722966

Brooks Life Sciences
BrooksAutomationAG
Bernstrasse134
CH-3613Steffisburg
Switzerland
Tel:+41(0)317707070

Brooks Life Sciences
Northbank,Irlam
ManchesterM445AY
UnitedKingdom
Tel:+44(0)1617772000
Fax:+44(0)1617772002

Brooks Technology
(Shanghai) Limited
2ndFloor,No.72,
887ZuchongzhiRoad
ZhangjiangHi-Tech
ParkPudong,Shanghai
China201203
Tel:[phone]
Fax:[phone]





Brooks Japan K.K.
HEADQUARTERS
NissoBldg.No16,9F
3-8-8ShinYokohama,
Kohoku-ku
Yokohama,Kanagawa222-
0033
Tel:[phone]
Fax:[phone]

Brooks Japan K.K.
YOKOHAMATECHNICAL
CENTER
852-1Kawamuko-cho,
Tsuzuki-ku
Yokohama,Kanagawa224-
0044
Tel:[phone]
Fax:[phone]

Brooks Japan K.K.
YOKKAICHISERVICE
CENTER
HikariShokaiYokkaichiBldg.
2-26Shinshinmachi
Yokkaichi,Mie510-0094
Tel:[phone]
Fax:[phone]

Brooks Japan K.K.
KUMAMOTOSERVICE
OFFICE
202MiraiOfficeII
312-1TatsudamachiYuge
Tatsuda,Kumamoto861-
8002
Tel:[phone]
Fax:[phone]

Brooks CCS Japan K.K.
CONTAMINATION
CONTROLSOLUTIONS
NissoBldg.No16,9F
3-8-8ShinYokohama,
Kohoku-ku
Yokohama,Kanagawa222-
0033
Tel:[phone]
Fax:[phone]




Brooks Automation Ltd.
TAIWANHEADQUARTERS
5F-5,No.32,Tai-YuenStreet
Chu-PeiCity
HsinchuCounty302,Taiwan,
R.O.C.
Tel:+886-3-5525258
Fax(G&A):+886-3-5525255
Fax(Sales):+886-3-5525200

Brooks Automation Korea,
Inc.
#35Giheungdanji-Ro
121Beon-Gil
Giheung-Gu,Yongin-Si
Gyeonggi-Do,17086
Korea
Tel:[phone]
Fax:[phone]
Brooks Automation (S) Pte
Ltd
51-18-C1MenaraBHL,
57JalanAhmadShah,
10050,Penang,
Malaysia
Tel:+6043701012
Fax:+6043701015

Brooks Automation
(Singapore) Pte Ltd
Blk5008AngMoKioAvenue
5
#05-08,TechplaceII
Singapore569874
Tel:[phone]
Fax:[phone]

Brooks Automation Ltd.
TAINANOFFICE
3F.,No.11,Nanke3rdRd.,
XinshiDist.
TainanSciencePark
TainanCity74147,Taiwan
(R.O.C.)
TEL:[phone]
FAX:[phone]


iv Copyright © 2020, Brooks Automation, Inc.

Brooks Automation
Part Number: 319427 Rev. B
Revision History
PartNumber:319427
FluidXAperioUserManual
Revision ECO Number Date Explanation of Changes Author
Revision A EC108865 1/22/2019 BrooksRe-Brandingandapplicationof
BrooksTemplates. A.Kleen
Revision B EC119928 6/01/2020
FixedtheDecapandRecapproceduresin
theOperationchapter.
AddedtheWEEEstatementtothe
appendix.
G.Russell
Copyright © 2020, Brooks Automation, Inc. v

FluidX
Part Number: 319427 Rev. B

Table of Contents
1.Overview 7
2.SpecificationsandSiteRequirements 8
ElectricalRequirements 8
UnitDimensions 8
FluidXAperio4 9
FluidXAperio6 9
FluidXAperio8 10
3.Installation 11
Unpacking 11
Setup 11
Alignment 12
ToolsNeeded 12
PortraitAdjustment 12
LandscapeAdjustment 14
4.Operation 16
Decap 18
RecapFromStore 19
5.PreventativeMaintenance 20
Overview 20
SchedulesandProcedures 20
6.Troubleshooting 21
7.Appendices 22
AppendixA:DeclarationofCEConformity 23
AppendixB:ReplaceableParts 24
AppendixC:WEEEStatement(EuropeanUnion) 25
vi Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 1. Overview
Part Number: 319427 Rev. B
1. Overview
TheFluidXAperiosemi-automatedsystemiscompactandidealforuseonabenchtop.The
systemisdesignedforefficienttubecappinginlabswithmediumtohighthroughput.FluidX
Aperioofferstheconsistencyofanautomateddecappingsystematlowerpricepoint.Usinga
semi-automatedhandlever,theFluidXAperiosystemhastheabilitytocapasinglecolumnof
tubesfromacapcarrierinunder10seconds,andtocap,ordecap,acompleterackof96tubesin
under2minutes.
FluidXAperioissuitableforusewith24,48or96-formatSBSrackedtubes.FluidXAperiois
compatiblewithFluidXsamplestoragetubesaswellasthosemanufacturedbyThermo-Matrix®,
Thermo-Nunc™,Micronic,andLVL.
FluidXAperioprovidestheconsistencyofanautomatedsystem,withallcapstightenedtothe
sametorquedeliveringaneffectiveandsecuresealandpeaceofmind.
Designedforefficienttubecappinganddecapping,FluidXAperio’ssetdownpositionallowsthe
simpleinsertionofscrewcapsusingaFluidXCapCarrier.
Equallysuitedforusewithbothinternalthreadandexternalthreadsamplestoragetubes.
Copyright © 2020, Brooks Automation, Inc. 7

2. Specifications and Site Requirements FluidX
Electrical Requirements Part Number: 319427 Rev. B
2. Specifications and
Site Requirements
Electrical Requirements
Thesystemmustonlyoperatewiththepowersupplyandfrequencyspecifiedonthesystem
identificationstickersmountedonthesideofthedevice.Operatingthesystemwithanyother
powersupplyorfrequencycanresultindamagetotheequipment.
Parameter Specification
SupplyVoltage 100-240VAC50/60Hz
Table 2-1: Electrical Requirements
Unit Dimensions
Parameter Specification
Width ~345mm
Depth ~310mm
Height ~370mm
Weight ~6kg
Table 2-2: Unit Dimension

8Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 2. Specifications and Site Requirements
Part Number: 319427 Rev. B Unit Dimensions
FluidX Aperio 4
Figure 2-1: FluidX Aperio4 Dimension
FluidX Aperio 6
Figure 2-2: FluidX Aperio 6 Dimensions
Copyright © 2020, Brooks Automation, Inc. 9

2. Specifications and Site Requirements FluidX
Unit Dimensions Part Number: 319427 Rev. B
FluidX Aperio 8
Figure 2-3: FluidX Aperio 8 Dimensions
10 Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 3. Installation
Part Number: 319427 Rev. B Unpacking
3. Installation
Unpacking
Step Action
1. Checktheintegrityoftheboxforexternallydamage.
2. Placetheboxonaflatfirmsurfaceandopenthebox.
3. Removethetopfoaminsert.
4. RemovethesmallboxcontainingtheFluidXAperio’sassociateditems.
5.
LifttheFluidXAperiooutoftheboxbythehandleontopofunitandplaceonaclean,dryflat
workbench.
NOTE: Do NOT use the black control lever to lift the unit.
6. Removetheadditional(2)foaminsertssupportingtheheadoftheunit.
Setup
TheFluidXAperiocomessuppliedwithitownexternalpowersupply,andpowercablesformost
regions.
Step Action
1. Removethetiesaroundthepowersupplyandstraightenthelead.
2. PlugthepowersupplyintotherearoftheFluidXAperio.
3. Plugthesuppliedpowercableintotheotherendofthepowersupply,thenintoawallsocket.
4. Switchthepoweronatthewallsocket.
Copyright © 2020, Brooks Automation, Inc. 11

3. Installation FluidX
Alignment Part Number: 319427 Rev. B
Alignment
Tools Needed
lFluidXAperio8andFluidXAperio6(operateswithrackscounting96and48positions
correspondingly)
ItemNº170-01-301
Spacing=9mmand13.50mm
lFluidXAperio4(operateswithrackscounting24positions)
ItemNº170-01-302
Spacing=18mmand19.50mm
l3mmhexwrench
Portrait Adjustment
Step Action
1.
Placecalibrationtoolonthetrayandcheckthattheejectionpinsarecenteredintheholes.
12 Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 3. Installation
Part Number: 319427 Rev. B Alignment
Step Action
2.
Iftheejectpinsarenotcentered,usea3mmhexheadwrenchtoloosenthe(2)screws.
3.
Movetrayinthedirectionofthearrowsuntiltheejectpinsarecentered.
4.
Usea3mmhexheadwrenchtotightenthe(2)screws.
Copyright © 2020, Brooks Automation, Inc. 13

3. Installation FluidX
Alignment Part Number: 319427 Rev. B
Landscape Adjustment
Step Action
1.
Placecalibrationtoolonthetrayandcheckthattheejectionpinsarecenteredintheholes.
2.
Iftheejectpinsarenotcentered,usea3mmhexheadwrenchtoloosenthe(2)screws.
14 Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 3. Installation
Part Number: 319427 Rev. B Alignment
Step Action
3.
Movetrayinthedirectionofthearrowsuntiltheejectpinsarecentered.
4.
Usea3mmhexheadwrenchtotightenthe(2)screws.
Copyright © 2020, Brooks Automation, Inc. 15

4. Operation FluidX
Part Number: 319427 Rev. B
4. Operation
Step Action
1. Placearackofcappedtubesinthelefttrayposition.
2. Usethelevertolowertheheadontothecaps.
3.
PressandholdtheDecapbutton.

4. Oncethecapsareunscrewedandthereisaclickingsoundindicatingthatthecapsareskipping
ontopofthetubes,slowlyandgentlylifttheleverup.
5. Oncecapsareclearedofthetubes,releasetheDecapbutton.
16 Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 4. Operation
Part Number: 319427 Rev. B
Step Action
6.
Torecap,pressandholdtherightcontrolbuttononthelever.
Lowertheheadgentlyontothecap.
7.
Toeject,twistthejoystickhandlekeepingtheheadinthedownposition.
Copyright © 2020, Brooks Automation, Inc. 17

4. Operation FluidX
Decap Part Number: 319427 Rev. B
Decap
Step Action
1. Placearackofcappedtubesinthelefttrayposition.
Tostorecapsonacapcarrier,placeanemptycapcarrierintherighttrayposition.
2. Usethelevertolowertheheadontothecaps.
3.
PressandholdtheDecapbutton.

4. Oncethecapsareunscrewedandthereisaclickingsoundindicatingthecapsskippingontopof
thetubes,slowlyandgentlylifttheleverup.
5. OncecapsareclearedofthetubesletgooftheDecapbutton.
6. Ifstoringcaps,slidethetrayrackintothesecondtrayposition(originally,ontherightofthe
device).
7.
Usethelevertolowertheheadontotheemptycapcarrier,thentwisttheleverclockwiseto
releasethecaps.

18 Copyright © 2020, Brooks Automation, Inc.

Brooks Automation 4. Operation
Part Number: 319427 Rev. B Recap From Store
Recap From Store
Step Action
1. Placeafullcapcarriertrayinthelefttrayposition
2. Placeafulltrayofuncappedtubesinthesecondtrayposition.
3.
PressandholdtheRecapbuttonsothedriversbeginturning.
4. Usethelevertogentlylowertheheadontothecaps.Oncethecapsareengagedonthehead,let
gooftheRecapbuttonandusethelevertoraisethehead.
5. Slidethetrayracktothesecondtrayposition.
6. Usethelevertolowertheheadontothefullrackofuncappedtubes.
7. PressandholdtheRecapbuttonsothedriversbeginturning.
8.
Oncethecapsareinstalledonthetubes,letgooftheRecapbuttonandtwisttheleverclockwise
toejectthecaps,thenusethelevertoraisethehead.

Copyright © 2020, Brooks Automation, Inc. 19

5. Preventative Maintenance FluidX
Overview Part Number: 319427 Rev. B
5. Preventative Maintenance
Overview
TheFluidXAperioneedsonlyminimummaintenancetooperate.
Schedules and Procedures
Periodic
Cleaning
Cleantrayusingalcoholwipes,non-bleachdisinfectingwipes,orgermicidaldisposable
wipes.
Tray Ensurethetrayismovingfreelyandiscleanofdustanddebris.
Springs TheFluidXAperiohasindividuallysprungloadedcapdrivers.Gentlypusheachcapdriver
uptoensuretheyspringback.
20 Copyright © 2020, Brooks Automation, Inc.
