Brother MFC-J615W Assembly instructions

ADVANCED
USER’S GUIDE
MFC-J615W
MFC-J630W
Version 0
USA/CAN

i
User's Guides and where do I find it?
Which manual? What's in it? Where is it?
Safety and Legal Please read the Safety Instructions before you
set up your machine.
Printed / In the box
Quick Setup Guide Read this Guide first. Follow the instructions for
setting up your machine and installing the
drivers and software for the operating system
and connection type you are using.
Printed / In the box
Basic User's Guide Learn the basic Fax, Copy, Scan and
PhotoCapture Center®operations and how to
replace consumables. See troubleshooting tips.
Printed / In the box
Advanced User's Guide Learn more advanced operations: Fax, Copy,
security features, and printing reports. Perform
routine maintenance.
PDF file /
Documentation
CD-ROM
Software User's Guide Follow these instructions for Printing, Scanning,
Network Scanning, PhotoCapture Center®,
Remote Setup, PC-Fax, and using the Brother
ControlCenter utility.
PDF file /
Documentation
CD-ROM
Network User's Guide This Guide provides more advanced
information for configuring the Ethernet and
Wireless network connections. In addition, find
information about network utilities, network
printing, troubleshooting tips and supported
network specifications.
PDF file /
Documentation
CD-ROM

ii
Table of Contents
1 General setup 1
Memory storage..................................................................................................... 1
Volume Settings.....................................................................................................1
Ring Volume .................................................................................................... 1
Beeper Volume................................................................................................2
Speaker Volume ..............................................................................................2
Automatic Daylight Saving Time............................................................................3
Sleep Mode ........................................................................................................... 3
LCD screen............................................................................................................4
Setting the backlight brightness....................................................................... 4
Setting the Dim Timer for the backlight ...........................................................4
Setting the Wallpaper ......................................................................................4
Mode Timer............................................................................................................5
2 Security features 6
TX Lock .................................................................................................................6
Setting and changing the TX Lock password ..................................................6
Turning TX Lock on/off ....................................................................................7
3 Sending a fax 8
Additional sending options.....................................................................................8
Sending faxes using multiple settings .............................................................8
Contrast ...........................................................................................................8
Changing fax resolution...................................................................................9
Setting your changes as the new default.........................................................9
Restoring fax settings to the factory settings...................................................9
Additional sending operations.............................................................................. 10
Sending a fax manually .................................................................................10
Sending a fax at the end of a conversation ...................................................10
Dual Access (Black & White only) .................................................................10
Broadcasting (Black & White only) ................................................................10
Real Time Transmission................................................................................ 12
Overseas Mode .............................................................................................12
Delayed Faxing (Black & White only) ............................................................12
Delayed Batch Transmission (Black & White only) .......................................13
Checking and canceling waiting jobs............................................................. 13
Polling overview................................................................................................... 14
Polled Transmit (Black & White only) ............................................................14

iii
4 Receiving a fax 15
Memory Receive (Black & White only) ................................................................15
Receiving faxes into memory when paper tray is empty ...............................15
Fax Forwarding..............................................................................................15
Paging ...........................................................................................................16
Fax Storage ...................................................................................................16
Printing a fax from the memory .....................................................................17
PC-Fax Receive (Windows®only).................................................................17
Turning off Memory Receive operations........................................................19
Changing Memory Receive operations .........................................................19
Remote Retrieval .................................................................................................20
Setting a Remote Access Code..................................................................... 20
Using your Remote Access Code..................................................................20
Remote Fax commands ................................................................................21
Retrieving fax messages ...............................................................................22
Changing your Fax Forwarding number ........................................................22
Additional receiving operations............................................................................23
Printing a reduced incoming fax ....................................................................23
Receiving a fax at the end of a conversation.................................................23
Polling overview................................................................................................... 24
Polling receive ...............................................................................................24
5 Dialing and storing numbers 25
Voice operations ..................................................................................................25
Tone or Pulse (Canada only).........................................................................25
Fax/Tel mode.................................................................................................25
Caller ID.........................................................................................................25
Special line considerations ............................................................................26
Additional dialing operations................................................................................28
Outgoing Call ................................................................................................28
Caller ID history .............................................................................................28
Dialing access codes and credit card numbers .............................................29
Additional ways to store numbers ........................................................................30
Storing Speed Dial numbers from Outgoing Calls.........................................30
Storing Speed Dial numbers from the Caller ID history.................................30
Setting up groups for broadcasting................................................................31
6Printingreports 33
Fax reports...........................................................................................................33
Transmission Verification Report...................................................................33
Fax Journal (activity report) ...........................................................................33
Reports ................................................................................................................34
How to print a report ......................................................................................34

iv
7 Making copies 35
Copy settings ....................................................................................................... 35
Stop copying.................................................................................................. 35
Changing copy quality ...................................................................................35
Enlarging or reducing the copied image........................................................35
Making N in 1 copies or a poster (Page Layout) ........................................... 37
Sorting copies using the ADF ........................................................................ 38
Adjusting Density ........................................................................................... 38
Ink Save Mode...............................................................................................38
Book Copy ..................................................................................................... 39
Watermark Copy............................................................................................ 40
Setting your changes as the new default.......................................................41
Restoring all settings to the factory settings .................................................. 41
8 PhotoCapture Center®: Printing photos from a memory card or
USB Flash memory drive 42
PhotoCapture Center®operations.......................................................................42
Memory cards, USB Flash memory drive and folder structures .................... 42
Movie printing ................................................................................................ 43
Print Images......................................................................................................... 43
Print Index (Thumbnails) ...............................................................................43
Printing Photos .............................................................................................. 44
Print All Photos .............................................................................................. 45
Enhance Photos ............................................................................................ 45
Search by Date .............................................................................................. 48
Slide Show..................................................................................................... 48
Trimming........................................................................................................49
DPOF printing ................................................................................................ 49
PhotoCapture Center®print settings ...................................................................50
Print Quality ................................................................................................... 50
Paper options ................................................................................................ 50
Adjusting Brightness, Contrast and Color...................................................... 51
Cropping ........................................................................................................52
Borderless printing......................................................................................... 52
Print Date....................................................................................................... 52
Setting your changes as the new default.......................................................52
Restoring all settings to the factory settings .................................................. 53
Scan to a memory card or USB Flash memory drive .......................................... 53
Auto Crop ...................................................................................................... 53
How to set a new default ...............................................................................54
How to reset to the factory settings ............................................................... 54

v
9 Printing photos from a camera 55
Printing photos directly from a PictBridge camera...............................................55
PictBridge requirements ................................................................................55
Setting your digital camera ............................................................................55
Printing Images..............................................................................................56
DPOF printing ................................................................................................56
Printing photos directly from a digital camera (without PictBridge)......................57
Printing Images..............................................................................................57
A Routine maintenance 58
Cleaning and checking the machine....................................................................58
Cleaning the outside of the machine .............................................................58
Cleaning the scanner.....................................................................................59
Cleaning the machine’s printer platen ...........................................................59
Cleaning the paper pick-up rollers................................................................. 60
Cleaning the print head .................................................................................60
Checking the print quality ..............................................................................61
Checking the print alignment .........................................................................62
Checking the ink volume ...............................................................................62
Packing and shipping the machine ......................................................................63
B Glossary 66
C Index 70

1
1
1
Memory storage 1
Even if there is a power failure, you will not
lose the settings you have chosen using the
Menu key because they are stored
permanently. Also, you will not lose your
settings in the FAX, COPY and
PHOTO CAPTURE mode key menus if you
have chosen Set New Default. You may
have to reset the date and time.
Volume Settings 1
Ring Volume 1
You can choose a range of ring volume
levels, from High to Off.
While the machine is idle, press dor c
to adjust the volume level. The LCD shows
the current setting, and each key press will
change the volume to the next level. The
machine will keep the new setting until you
change it.
You can also change the volume through the
menu, by following the instructions below:
Setting the Ring Volume from the
menu 1
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Ring.
ePress dor cto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
General setup 1

Chapter 1
2
Beeper Volume 1
When the beeper is on, the machine will beep
when you press a key, make a mistake, or
after you send or receive a fax.
You can choose a range of beeper volume
levels, from High to Off.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Beeper.
ePress dor cto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
Speaker Volume 1
You can choose a range of speaker volume
levels, from High to Off.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Speaker.
ePress dor cto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
You can also adjust the speaker volume by
pressing Hook.
aPress Hook.
bPress aor bto choose Speaker.
Press OK.
cPress dor cto choose Low, Med, High
or Off.
dPress Hook.

General setup
3
1
Automatic Daylight
Saving Time 1
You can set the machine to change
automatically for daylight saving time. It will
reset itself forward one hour in the Spring and
backward one hour in the Fall. Make sure you
have set the correct date and time in the
Date&Time setting.
The factory setting is Off, so you will have to
turn on Automatic Daylight Saving Time as
follows.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose
Auto Daylight.
dPress dor cto choose On (or Off).
Press OK.
ePress Stop/Exit.
Sleep Mode 1
You can choose how long the machine must
be idle (from 1 to 60 minutes) before it goes
into sleep mode. The timer will restart if any
operation is carried out on the machine.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Sleep Mode.
dPress dor cto choose 1Min, 2Mins,
3Mins, 5Mins, 10Mins, 30Mins or
60Mins.
Press OK.
ePress Stop/Exit.

Chapter 1
4
LCD screen 1
Setting the backlight
brightness 1
You can adjust the brightness of the LCD
backlight. If you are having difficulty reading
the LCD, try changing the brightness setting.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose Backlight.
ePress dor cto choose Light, Med or
Dark.
Press OK.
fPress Stop/Exit.
Setting the Dim Timer for the
backlight 1
You can set how long the LCD backlight stays
on after you go back to the Ready screen.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose Dim Timer.
ePress dor cto choose 10Secs,
20Secs, 30Secs or Off.
Press OK.
fPress Stop/Exit.
Setting the Wallpaper 1
You can change the wallpaper.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose Wallpaper.
Press OK.
ePress aor bto choose your wallpaper
from the four available designs.
Press OK.
fPress Stop/Exit.

General setup
5
1
Mode Timer 1
The machine has four temporary mode keys
on the control panel: FAX, SCAN, COPY and
PHOTO CAPTURE. You can change the
amount of time the machine takes after the
last Scan, Copy or PhotoCapture operation
before it returns to Fax mode. If you choose
Off, the machine stays in the mode you used
last.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Mode Timer.
dPress dor cto choose 0Sec, 30Secs,
1Min, 2Mins, 5Mins or Off.
Press OK.
ePress Stop/Exit.

6
2
TX Lock 2
TX Lock lets you prevent unauthorized
access to the machine. You will not be able to
continue to schedule Delayed Faxes or
Polling jobs. However, any pre-scheduled
Delayed Faxes will be sent even if you turn on
TX Lock, so they will not be lost.
While TX Lock is On, the following operations
are available:
Receiving faxes
Fax Forwarding
(If Fax Forwarding was already On)
Paging
(If Paging was already On)
Remote retrieval
(If Fax Storage was already On)
PC-Fax Receive
(If PC-Fax Receive was already On)
While TX Lock is On, the following operations
are NOT available:
Sending faxes
Copying
PC printing
Scanning
PhotoCapture
Operation from the Control panel
Note
If you forget the TX Lock password,
please call Brother Customer Service.
(See Brother numbers on page i in the
Basic User’s Guide.)
Setting and changing the
TX Lock password 2
Note
If you have already set the password, you
will not need to set it again.
Setting the password 2
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
eEnter a 4-digit number for the password.
Press OK.
fWhen the LCD shows Verify:,
re-enter the password.
Press OK.
gPress Stop/Exit.
Security features 2

Security features
7
2
Changing the password 2
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
ePress aor bto choose Set Password.
Press OK.
fEnter a 4-digit number for the current
password.
Press OK.
gEnter a 4-digit number for a new
password.
Press OK.
hWhen the LCD shows Verify:,
re-enter the password.
Press OK.
iPress Stop/Exit.
Turning TX Lock on/off 2
Turning TX Lock on 2
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
ePress aor bto choose Set TX Lock.
Press OK.
fEnter the registered 4-digit password.
Press OK.
The machine goes offline and the LCD
shows TX Lock Mode.
Turning TX Lock off 2
aPress Menu.
bEnter the registered 4-digit password.
Press OK.
TX Lock is automatically turned off.
Note
If you enter the wrong password, the LCD
shows Wrong Password and stays
offline. The machine will stay in TX Lock
mode until the registered password is
entered.

8
3
Additional sending
options 3
Sending faxes using multiple
settings 3
When you send a fax you can choose any
combination of these settings: resolution,
contrast, scan size, etc.
aPress (FAX).
The LCD shows:
bPress aor bto choose a setting you
want to change.
cPress dor cto choose an option.
Press OK.
dRepeat steps bto cto change more
settings.
Note
• Most settings are temporary and the
machine returns to its default settings after
you send a fax.
• You can save some of the settings you
use most often by setting them as default.
These settings will stay until you change
them again. (See Setting your changes as
the new default on page 9.)
Contrast 3
If your document is very light or very dark, you
may want to change the contrast. For most
documents the factory setting Auto can be
used. It automatically chooses the suitable
contrast for your document.
Choose Light when sending a light
document. Choose Dark when sending a
dark document.
aPress (FAX).
bPress aor bto choose Contrast.
cPress dor cto choose Auto, Light or
Dark.
Press OK.
Note
Even if you choose Light or Dark, the
machine will send the fax using the Auto
setting in any of the following conditions:
• When you send a color fax.
• When you choose Photo as the Fax
Resolution.
Sending a fax 3
FAX
FAX
Fax Press Start
Enter Number
Fax Resolution Standard
Contrast Auto
Speed Dial

Sending a fax
9
3
Changing fax resolution 3
The quality of a fax can be improved by
changing the fax resolution.
aPress (FAX).
bPress aor bto choose
Fax Resolution.
cPress dor cto choose the resolution
you want.
Press OK.
Note
You can choose four different resolution
settings for black & white faxes and two for
color faxes.
If you choose S.Fine or Photo and then
use the Color Start key to send a fax, the
machine will send the fax using the Fine
setting.
Setting your changes as the
new default 3
You can save the fax settings for
Fax Resolution, Contrast,
Real Time TX and Glass ScanSize you
use most often by setting them as default.
These settings will stay until you change
them again.
aPress (FAX).
bPress aor bto choose the setting you
want to change, and then press dor cto
choose your new option.
Press OK.
Repeat this step for each setting you
want to change.
cAfter changing the last setting, press
aor bto choose Set New Default.
Press OK.
dPress 1to choose Yes.
ePress Stop/Exit.
Restoring fax settings to the
factory settings 3
You can restore the fax settings
Fax Resolution, Contrast,
Real Time TX, and Glass ScanSize,
that you have changed, to the factory
settings.
aPress (FAX).
bPress aor bto choose
Factory Reset.
Press OK.
cPress 1to choose Yes.
dPress Stop/Exit.
Black & White
Standard Suitable for most typed
documents.
Fine Good for small print and
transmits a little slower than
Standard resolution.
S.Fine Good for small print or artwork
and transmits slower than Fine
resolution.
Photo Use when the document has
varying shades of gray or is a
photograph. Photo has the
slowest transmission.
Color
Standard Suitable for most typed
documents.
Fine Use when the document is a
photograph. The transmission
time is slower than Standard
resolution.

Chapter 3
10
Additional sending
operations 3
Sending a fax manually 3
Manual transmission lets you hear the
dialing, ringing and fax-receiving tones while
sending a fax.
Note
To send a multiple page fax, use the ADF.
aPress (FAX).
bLoad your document.
cTo listen for a dial tone press Hook or
pick up the handset of the external
telephone.
dDial the fax number.
eWhen you hear the fax tone, press
Black Start or Color Start.
If you are using the scanner glass
press 1on the machine to send a fax.
fIf you picked up the handset of the
external telephone, replace it.
Sending a fax at the end of a
conversation 3
At the end of a conversation you can send a
fax to the other party before you both hang
up.
aAsk the other party to wait for fax tones
(beeps) and then to press the Start or
Send key before hanging up.
bPress (FAX).
cLoad your document.
dPress Black Start or Color Start.
If you are using the scanner glass,
press 1to send a fax.
eReplace the handset of the external
phone.
Dual Access
(Black & White only) 3
You can dial a number and start scanning the
fax into memory—even when the machine is
sending from memory, receiving faxes or
printing PC data. The LCD shows the new job
number and available memory.
The number of pages you can scan into the
memory will vary depending on the data that
is printed on them.
Note
If the Out of Memory message appears
while scanning a document, press
Stop/Exit to cancel or Black Start to send
the scanned pages.
Broadcasting
(Black & White only) 3
Broadcasting is when the same fax message
is automatically sent to more than one fax
number. You can include Groups, Speed Dial
numbers, and up to 50 manually dialed
numbers in the same broadcast.
After the broadcast is finished, a Broadcast
Report will be printed.
aPress (FAX).
bLoad your document.
cPress aor bto choose Broadcasting.
Press OK.

Sending a fax
11
3
dYou can add numbers to the broadcast
in the following ways:
Press aor bto choose Add Number
and enter a number using the dial
pad.
Press OK.
Press aor bto choose Speed Dial
and OK. Press aor bto choose
Alphabetic Order or
Numeric Order and OK.
Press aor bto select a number and
OK.
eAfter you have entered all the fax
numbers by repeating step d, press
aor bto choose Complete.
Press OK.
fPress Black Start.
Note
• If you did not use up any of the numbers
for Groups, you can broadcast faxes to as
many as 250 different numbers.
• The machine’s available memory will vary
depending on the types of jobs in the
memory and the number of locations used
for broadcasting. If you broadcast to the
maximum number available, you will not
be able to use dual access and delayed
fax.
• If the Out of Memory message
appears, press Stop/Exit to stop the job.
If more than one page has been scanned,
press Black Start to send the portion that
is in the machine’s memory.
Canceling a Broadcast in progress 3
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Remaining Jobs.
Press OK.
The LCD will show the fax number being
dialed and the Broadcast job number.
dPress OK.
The LCD will ask you the following
question:
Cancel Job?
Yes iPress 1
No iPress 2
ePress 1to cancel the fax number being
dialed.
The LCD will then show the Broadcast
job number.
fPress OK.
The LCD will ask you the following
question:
Cancel Job?
Yes iPress 1
No iPress 2
gTo cancel the Broadcast, press 1.
hPress Stop/Exit.

Chapter 3
12
Real Time Transmission 3
When you are sending a fax, the machine will
scan the document into the memory before
sending it. Then, as soon as the telephone
line is free, the machine will start dialing and
sending.
Sometimes, you may want to send an
important document immediately, without
waiting for memory transmission. You can do
this by turning on Real Time TX.
aPress (FAX).
bPress aor bto choose Real Time TX.
cPress dor cto choose On (or Off).
Press OK.
Note
• If the memory is full and you are sending a
black & white fax from the ADF, the
machine will send the document in real
time (even if Real Time TX is set to
Off). Faxes from the scanner glass
cannot be sent until you clear some of the
memory.
• In Real Time Transmission, the automatic
redial feature does not work when you are
using the scanner glass.
Overseas Mode 3
If you are having difficulty sending a fax
overseas due to possible interference on the
telephone line, we recommend that you turn
on the Overseas mode. After you send a fax
using this feature, the feature will turn itself
off.
aPress (FAX).
bLoad your document.
cPress aor bto choose
Overseas Mode.
dPress dor cto choose On (or Off).
Press OK.
Delayed Faxing
(Black & White only) 3
You can store up to 50 faxes in the memory
to be sent within 24 hours. These faxes will
be sent at the time of day you enter in step e.
aPress (FAX).
bLoad your document.
cPress aor bto choose Delayed Fax.
dPress dor cto choose On.
Press OK.
eEnter the time you want the fax to be
sent (in 24-hour format).
(For example, enter 19:45 for 7:45 PM.)
Press OK.
Note
• When you set 12h Clock in the
Date&Time setting, enter the time in
12-hour format.
• The number of pages you can scan into
the memory depends on the amount of
data that is printed on each page.

Sending a fax
13
3
Delayed Batch Transmission
(Black & White only) 3
Before sending the delayed faxes, your
machine will help you economize by sorting
all the faxes in the memory by destination and
scheduled time. All delayed faxes that are
scheduled to be sent at the same time to the
same fax number will be sent as one fax to
save transmission time.
aPress (FAX).
bPress aor bto choose Batch TX.
cPress dor cto choose On.
Press OK.
dPress Stop/Exit.
Checking and canceling
waiting jobs 3
You can check which jobs are still waiting in
the memory to be sent and cancel a job.
(If there are no jobs, the LCD shows
No Jobs Waiting.)
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Remaining Jobs.
Press OK.
Any waiting jobs appear on the LCD.
dPress aor bto scroll through the jobs
and choose the job you want to cancel.
Press OK.
eDo one of the following:
To cancel, press 1to choose Yes.
If you want to cancel another job go
to step d.
To exit without canceling, press 2to
choose No.
fRepeat steps dand efor each job you
want to cancel.
gWhen you are finished, press Stop/Exit.

Chapter 3
14
Polling overview 3
Polling lets you set up your machine so other
people can receive faxes from you, but they
pay for the call. It also lets you call somebody
else’s fax machine and receive a fax from it,
so you pay for the call. The polling feature
needs to be set up on both machines for this
to work. Not all fax machines support polling.
Polled Transmit
(Black & White only) 3
Polled transmit lets you set up your machine
to wait with a document so another fax
machine can call and retrieve it.
The document will be stored and can be
retrieved by any other fax machine until you
delete it from the memory. (See Checking
and canceling waiting jobs on page 13.)
Setup for polled transmit 3
aPress (FAX).
bLoad your document.
cPress aor bto choose Polled TX.
dPress dor cto choose On (or Off).
Press OK.
ePress aor bto choose any settings you
want to change.
Press OK.
After each setting is accepted, you can
continue to change more settings.
fPress Black Start.
gIf you are using the scanner glass, the
LCD will prompt you to choose one of
the options.
Press 1to send another page.
Go to step h.
Press 2or Black Start to send the
document.
hPlace the next page on the scanner
glass.
Press OK.
Repeat steps gand hfor each
additional page.
Your machine will automatically send
the fax.
