Start Here MFC-J6920DW
Quick Setup Guide
CEE-ENG Version 0
Please read the Product Safety Guide first before you set up your machine. Then, read this Quick Setup Guide for
the correct setup and installation.
1
Unpack the machine
aUpper tray
bLower tray
WARNING
Plastic bags are used in the packing of your machine. To avoid the danger of suffocation, keep these
plastic bags away from babies and children. Plastic bags are not toys.
CAUTION
To prevent injuries when moving or lifting this machine, make sure to use at
least two people. Be careful not to pinch your fingers when you set the
machine back down.
aRemove the protective tape and film covering the machine, and also from the
Touchscreen.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injuries.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injuries.
IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in
damage to property or loss of product functionality.
NOTE Notes tell you how to respond to a situation that may arise or give tips about how the operation
works with other features.
NOTE
If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your
computer operating system, or you want to download manuals and utilities, visit your model’s home page at
http://solutions.brother.com/.
1
2

2
2
Connect the power cord
and telephone line
WARNING
• The machine must be fitted with an earthed
plug.
• Since the machine is grounded through the
power outlet, you can protect yourself from
potentially hazardous electrical conditions on
the telephone network by keeping the power
cord connected to your machine when you
connect it to a telephone line. Similarly, you
can protect yourself when you want to move
your machine by disconnecting the telephone
line first and then the power cord.
aConnect the power cord.
bLift the scanner cover until it locks securely into
the open position.
cConnect the telephone line cord.
Connect one end of the telephone line cord to
the socket marked LINE on the machine.
Carefully guide the telephone line cord into the
cable channel and out the back of the machine.
Connect the other end to a modular wall
socket.
dGently close the scanner cover using the finger
holds on each side.
CAUTION
Be careful not to pinch your fingers when you
close the scanner cover.
Always use the finger holds provided on each side
of the scanner cover when opening and closing it.
NOTE
DO NOT connect the USB cable yet (if you are
using a USB cable).
NOTE
• If you do not plan to use the fax feature on this
machine, go to step 3on page 3.
• To prolong the life of the print head, provide the
best ink cartridge economy and maintain print
quality, we do not recommend unplugging the
machine frequently and/or leaving the machine
unplugged for extended periods of time. Each
time you plug the machine in, it automatically
cleans the print head, which uses some of your
ink.
We recommend using to power down the
machine. Using allows minimal power to
the machine, resulting in periodic, but less
frequent, cleaning of the print head.
IMPORTANT
The telephone line cord MUST be connected to
the socket marked LINE on the machine.

3
3
Install the ink cartridges
CAUTION
If ink gets in your eyes, wash it out with water at
once and call a doctor if you are concerned.
aMake sure that the power is turned on.
bOpen the ink cartridge cover a.
cRemove the orange protective part.
dLift the scanner cover into the open position.
eStore the orange protective part in the holder
inside the machine as shown.
fGently close the scanner cover using the finger
holds on each side.
CAUTION
Be careful not to pinch your fingers when you
close the scanner cover.
Always use the finger holds provided on each side
of the scanner cover when opening and closing it.
NOTE
Make sure you install the Introductory Ink
Cartridges included with your machine first.
NOTE
You can adjust the angle of the control panel by
lifting it. To lower this control panel, push the
release button that is located behind the control
panel, as shown in the illustration.
NOTE
Do not throw away the orange protective part.
You will need it if you transport the machine.
1

4
gUnpack the ink cartridge.
Turn the green release lever on the orange
protective packing acounterclockwise until it
clicks to release the vacuum seal. Then
remove the orange protective packing aas
shown.
hTake care to match the sticker colour with the
cartridge colour.
Install each ink cartridge in the direction of the
arrow on the label.
iGently push the back of the ink cartridge
marked “PUSH” until the cartridge lever lifts.
After all the ink cartridges are installed, close
the ink cartridge cover.
4
Load plain A4 paper
aPull paper tray #1, the upper tray completely
out of the machine.
bGently press and slide the paper side guides a
to fit the paper size. Make sure that the
triangular mark bon the paper side guide a
lines up with the mark for the paper size you
are using.
cOpen the output paper tray cover.
dGently press and slide the paper length
guide ato fit the paper size.
Make sure that the triangular marks bon the
paper length guide alines up with the mark for
the paper size you are using.
eClose the output paper tray cover.
IMPORTANT
• DO NOT shake the ink cartridges. If ink stains
your skin or clothing, wash with soap or
detergent at once.
• DO NOT touch the cartridge in the area
indicated b, as this can cause the machine not
to function with the cartridge.
NOTE
The machine will prepare the ink tube system for
printing. This process will take approximately four
minutes. Do not turn off the machine. We
recommend you perform the next step while
waiting.
1
2
1
2
1
2
1
2

5
fFan the stack of paper well to avoid paper jams
and misfeeds.
gGently put the paper into paper tray #1.
hGently adjust the paper side guides to fit the
paper with both hands. Make sure that the
paper side guides touch the sides of the paper.
iCheck that the paper is flat in the tray and
below the maximum paper mark.
jSlowly push the paper tray completely into the
machine.
kWhile holding the paper tray in place, pull out
the paper support until it clicks, and then unfold
the paper support flap.
5
Check the print quality
aWhen the preparation process has finished, the
Touchscreen shows Load paper and
press [OK].
Press OK.
bCheck the quality of the four colour blocks on
the sheet (black/yellow/cyan/magenta).
cIf all lines are clear and visible, press Yes to
finish the quality check and go to the next step.
If lines are missing, press No and follow the
steps on the Touchscreen.
NOTE
Always make sure that the paper is not curled or
wrinkled.
NOTE
For printing and copying on special print media,
open the manual feed slot aon the back of the
machine. Feed only one sheet at a time.
NOTE
If your machine has two paper trays, make sure
there is paper in tray #1, the upper tray, when
checking the print quality.
1

6
6
Set the date and time
The Touchscreen displays the date and time. You can
also add the current date and time to each fax you
send by setting your Station ID (see step 11).
aEnter the last two digits of the year on the
Touchscreen, and then press OK.
bRepeat for month and day.
cEnter the time on the Touchscreen in 24-hour
format.
dPress OK.
7
Set the paper settings
For your machine to produce the best print quality and
to feed the correct paper size, the paper type and size
must be set to match the paper in the tray.
aWhen Tray Setting appears on the
Touchscreen, press Tray Setting to set the
paper size and paper type.
bPress Tray #1 to set paper size and paper
type for tray #1, or press Tray #2 to set paper
size for tray #2.
cPress the size and type of paper you are using.
dPress OK.
8
Review Touchscreen
display
The Touchscreen displays information about screen
operation and manual feed slot use. Review this
information and press OK.
9
Choose your language
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dSwipe up or down, or press aor bto display
Local Language.
Press Local Language.
ePress your language.
fPress .
NOTE
You can change date and time at any time. For
more information uuBasic User’s Guide: Setting
the date and time

7
10
Choose a Receive Mode
There are four possible receive modes: Fax Only,
Fax/Tel, Manual and External TAD.
aPress .
bPress All Settings.
cPress Fax.
dPress Setup Receive.
ePress Receive Mode.
fPress your preferred receive mode.
gPress .
11
Enter personal
information (Station ID)
Set your machine’s Station ID so that the date and
time appear on each fax you send.
If you are not using this machine for faxing, go to the
next step.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dPress Station ID.
ePress Fax.
fEnter your fax number (up to 20 digits) on the
Touchscreen, and then press OK.
gPress Name.
hEnter your name (up to 20 characters) using
the Touchscreen, and then press OK.
iPress .
12
Set Tone or Pulse dialling
mode
Your machine comes set for a Tone dialling service. If
you have a Pulse dialling (rotary) service, you need to
change the dialling mode.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dPress Tone/Pulse.
ePress Pulse (or Tone).
fPress .
No
Yes
Yes
No
No
Yes
Do you want to use the telephone features of your
machine (if available), an external telephone or
external telephone answering device connected on the
same line as the machine?
Do you want the machine to
answer fax and telephone calls
automatically?
Are you using the voice message
function of an external telephone
answering device?
Manual
Fax Only
Fax/Tel
External TAD
You control the telephone
line and must answer every
call yourself.
Your external telephone
answering device (TAD)
automatically answers every
call. Voice messages are
stored on the external TAD.
Fax messages are printed.
Your machine controls the
line and automatically
answers every call. If the
call is not a fax, the
telephone will ring for you
to pick up the call.
Your machine automatically
answers every call as a fax.

8
13
Set the telephone line
type
If you are connecting the machine to a line that
features PBX or ISDN to send and receive faxes, it is
necessary to change the telephone line type
accordingly.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dSwipe up or down, or press aor bto display
Phone Line Set.
Press Phone Line Set.
ePress Normal, PBX or ISDN.
Press the desired telephone line type.
fPress .
14
Set the telephone line
compatibility (VoIP)
If you are connecting the machine to a VoIP service
(over the Internet), you need to change the
compatibility setting.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dSwipe up or down, or press aor bto display
Compatibility.
Press Compatibility.
ePress Basic(for VoIP).
fPress .
15
Automatic Daylight
Saving Time
You can set the machine to change automatically for
Daylight Saving Time. It will reset itself forward one
hour in the spring and backward one hour in the
autumn.
aPress .
bPress
(Date and Time).
cPress Auto Daylight.
dPress On (or Off).
ePress .
16
Set the Time Zone
You can set the time zone for your location on the
machine.
aPress .
bPress
(Date and Time).
cPress Time Zone.
dEnter your time zone.
Press OK.
ePress .
NOTE
If you choose PBX the machine will then ask you
to set the Dial Prefix. uuBasic User’s Guide:
Setting the Telephone Line Type
NOTE
If you are using an analogue telephone line, you
can skip this step.
00:00 01.01.2013
00:00 01.01.2013

9
Windows®Macintosh Windows®Macintosh
USB Wired Network Wireless Network
17
Choose your connection type
These installation instructions are for Windows®XP Home, XP Professional, XP Professional x64 Edition,
Windows Vista®, Windows®7, Windows®8, and Mac OS X v10.6.8, 10.7.x, 10.8.x.
NOTE
If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your
computer operating system, or you want to download manuals and utilities, visit your model’s home page at
http://solutions.brother.com/. Some software applications included on the CD-ROM may not be available as a
download.
For USB interface cable
Windows
®
, go to page 10
Macintosh, go to page 13
For Wired Network
Windows
®
, go to page 15
Macintosh, go to page 18
For Wireless Network
Windows
®
, Macintosh and mobile devices
go to page 20

10
Windows®
USB
For Windows
®
USB interface users
(Windows®XP Home/XP Professional/Windows Vista®/Windows®7/Windows®8)
18
Before you install
Make sure that your computer is ON and you are
logged on with Administrator rights.
19
Install MFL-Pro Suite
aPut the CD-ROM into your CD-ROM drive. If
the model name screen appears, choose your
machine. If the language screen appears,
choose your language.
bClick Install MFL-Pro Suite and click Yes if
you accept the license agreements.
Follow the on-screen instructions.
cChoose Local Connection (USB), and then
click Next.
dFollow the on-screen instructions until the Plug
in the USB cable screen appears.
20
Connect the USB cable
a
b
NOTE
If the Brother screen does not appear
automatically, go to Computer (My Computer).
(For Windows®8: click the (File Explorer)
icon on the taskbar, and then go to Computer.)
Double-click the CD-ROM icon, and then
double-click start.exe.
