Brother HL-1110 User manual

User’s Guide
Brother Laser Printer
HL-1110
HL-1111
For visually-impaired users
You can read this manual with Screen Reader ‘text-to-speech’ software.
You must set up the hardware and install the driver before you can use the machine.
Please use the Quick Setup Guide to set up the machine. You can find a printed copy in the box.
Please read this User’s Guide thoroughly before you use the machine.
Please visit us at http://solutions.brother.com/ where you can get product support, the latest driver updates and utilities,
and answers to frequently asked questions (FAQs) and technical questions.
Note: Not all models are available in all countries.
Version 0
ARL/ASA/SAF/GLF

i
Brother numbers
IMPORTANT
For technical and operational help, you must call the country where you bought the machine. Calls must
be made from within that country.
Register your product
Please complete the Brother Warranty Registration or, for your convenience and most efficient way to register
your new product, register on-line at
http://www.brother.com/registration/
Frequently asked questions (FAQs)
The Brother Solutions Center is our one-stop resource for all your machine needs. You can download the
latest drivers, software and utilities, read FAQs and troubleshooting tips to learn how to get the most from
your Brother product.
http://solutions.brother.com/
You can check here for Brother driver updates.
Customer Service
Visit http://www.brother.com/ for contact information on your local Brother office.
Internet Addresses
Brother Global Web Site: http://www.brother.com/
For Frequently Asked Questions (FAQs), Product Support and Technical Questions, and Driver Updates and Utilities:
http://solutions.brother.com/

ii
User’s Guides and where to find them?
Which manual? What's in it? Where is it?
Windows users Macintosh users
Product Safety Guide Read this Guide first.
Please read the Safety
Instructions before you set
up your machine. See this
Guide for trademarks and
legal limitations.
http://solutions.brother.com/
Quick Setup Guide Follow the instructions for
setting up your machine
and installing the drivers
and software for the
operating system and
connection type you are
using.
http://solutions.brother.com/
User’s Guide Learn the print operations,
how to replace
consumables, and
performing routine
maintenance. See
troubleshooting tips.
http://solutions.brother.com/
http://solutions.brother.com/

iii
Using the documentation
Thank you for buying a Brother machine! Reading the documentation will help you make the most of your
machine.
Symbols and conventions used in the documentation
The following symbols and conventions are used throughout the documentation.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injuries.
IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided,
may result in damage to property or loss of product functionality.
NOTE Notes tell you how you should respond to a situation that may arise or give tips
about how the operation works with other features.
Prohibition icons indicate actions that must not be performed.
Electrical Hazard icons alert you to possible electrical shock.
Fire Hazard icons alert you to the possibility of fire.
Hot Surface icons warn you not to touch machine parts that are hot.
Bold Bold style identifies keys on the machine control panel or computer screen.
Italics Italicized style emphasizes an important point or refers you to a related topic.
WARNING

iv
Table of Contents
1 Printing Methods 1
About this Machine ....................................................................................................................................1
Machine overview................................................................................................................................1
Acceptable paper.......................................................................................................................................2
Paper capacity of the paper tray..........................................................................................................2
2-sided printing ..........................................................................................................................................3
Guidelines for printing on both sides of the paper ...............................................................................3
Manual 2-sided printing .......................................................................................................................4
2 Driver and Software 5
Printer driver ..............................................................................................................................................5
Printing a document.............................................................................................................................5
Printer driver settings...........................................................................................................................6
Windows®..................................................................................................................................................7
Accessing the printer driver settings....................................................................................................7
Features in the Windows®printer driver..............................................................................................7
Basic tab..............................................................................................................................................8
Advanced tab.....................................................................................................................................13
Print Profiles tab ................................................................................................................................19
Device Settings tab............................................................................................................................21
Support ..............................................................................................................................................22
Uninstalling the printer driver.............................................................................................................23
Status Monitor ...................................................................................................................................24
Macintosh ................................................................................................................................................26
Features in the printer driver (Macintosh)..........................................................................................26
Choosing page setup options ............................................................................................................26
Removing the printer driver ...............................................................................................................33
Status Monitor ...................................................................................................................................34
Software ..................................................................................................................................................35
Remote Printer Console (Windows®only) ........................................................................................35
3 General Information 36
Control panel ...........................................................................................................................................36
LEDs (Light Emitting Diodes) ............................................................................................................36
Service call indications ......................................................................................................................40
Power On/Off key ..............................................................................................................................41
Print a Printer Settings page....................................................................................................................42
Using the Power On/Off key ..............................................................................................................42
Using the printer driver ......................................................................................................................42
Ecology features ......................................................................................................................................43
Toner Save ........................................................................................................................................43
Sleep Time ........................................................................................................................................43
Deep Sleep mode..............................................................................................................................43
Power Off mode.................................................................................................................................44

v
A Troubleshooting and other information 45
Consumable items...................................................................................................................................45
Toner Setting ...........................................................................................................................................46
Identifying your problem ..........................................................................................................................47
Error messages in the Status Monitor .....................................................................................................48
Improving the print quality........................................................................................................................49
Paper jams...............................................................................................................................................53
If you are having difficulty with your machine ..........................................................................................57
Cleaning and Checking the machine .......................................................................................................59
Machine Information ................................................................................................................................60
Default settings..................................................................................................................................60
B Specifications 61
General....................................................................................................................................................61
Print media...............................................................................................................................................63
Important information for choosing your paper ........................................................................................64
Printer ......................................................................................................................................................65
C Index 66

1
1
1
About this Machine 1
Machine overview 1
1 Top cover
2 Control panel
3 Face-down output tray support flap (support flap)
4 Paper tray
5 USB port
NOTE
For details about how the LEDs show the machine’s status, see LEDs (Light Emitting Diodes) on page 36.
For the Power On/Off key functions, see Power On/Off key on page 41.
Printing Methods 1
1
3
5
2
4

Printing Methods
2
1
Acceptable paper 1
Print quality may vary according to the type of paper you are using.
For best results, follow the instructions below:
DO NOT put different types of paper in the paper tray at the same time because it may cause paper jams
or misfeeds.
For correct printing, you must choose the same paper size from your software application as the paper in
the tray.
Avoid touching the printed surface of the paper immediately after printing.
Before you buy a lot of paper, test a small quantity to make sure that the paper is suitable.
Paper capacity of the paper tray 1
1Folio size is 215.9 mm x 330.2 mm.
Paper size Paper types No. of sheets Paper weight
A4, Letter, Legal, Folio 1Plain paper and
Recycled paper
up to 150 sheets (80 g/m2) 65 - 105 g/m2

Printing Methods
3
1
2-sided printing 1
The supplied printer drivers all enable 2-sided printing. For more information about how to choose the
settings, see 2-sided / Booklet on page 10 for Windows®and 2-sided Printing on page 33 for Macintosh.
Guidelines for printing on both sides of the paper 1
If the paper is thin, it may wrinkle.
If paper is curled, straighten it and put it back in the paper tray. If the paper continues to curl, replace the
paper.
If the paper is not feeding correctly, it may be curled. Remove the paper and straighten it. If the paper
continues to curl, replace the paper.
When you use the manual 2-sided function, it is possible that there may be paper jams or poor print quality.
(If there is a paper jam, see Paper jams on page 53. If you have a print quality problem, see Improving the
print quality on page 49.)

Printing Methods
4
1
Manual 2-sided printing 1
If you are using the Macintosh Printer Driver, see Manual 2-sided Printing on page 33.
Manual 2-sided printing with the Windows®printer driver 1
aChoose the following settings from each drop-down list of the printer driver.
Paper Size
You can use all the paper sizes specified for the tray you are using.
Media Type
You can use all the media types that are specified for the tray you are using.
2-sided / Booklet
Choose 2-sided (Manual).
2-sided Type in 2-sided Settings
There are four options for each orientation. (See 2-sided / Booklet on page 10.)
Binding Offset in 2-sided Settings
You can specify the offset for binding. (See 2-sided / Booklet on page 10.)
For any other settings, see Driver and Software in Chapter 2.
bSend the print data to the machine. The machine will print all the even-numbered pages on one side of
the paper first. Then, the Windows®driver instructs you (with a pop-up message) to reinsert the paper
to print the odd-numbered pages.
NOTE
Before reinserting the paper, straighten it well, or you may get a paper jam. Very thin or thick paper is not
recommended.

5
2
2
Printer driver 2
A printer driver is software that translates data from the format used by a computer to the format that a
particular printer needs. Typically, this format is page description language (PDL).
The printer drivers for the supported versions of Windows®is on the CD-ROM we have supplied and for
Macintosh it is on the Brother Solutions Center website at http://solutions.brother.com/. Install the drivers by
following the steps in the Quick Setup Guide. The latest printer drivers for Windows®and Macintosh can be
downloaded from the Brother Solutions Center website at:
http://solutions.brother.com/
For Windows® 2
Windows®printer driver (the most suitable printer driver for this product)
For Macintosh 2
Macintosh printer driver (the most suitable printer driver for this product)
For Linux®12
2
LPR printer driver
CUPS printer driver
1For more information and to download the printer driver for Linux please visit your model page at http://solutions.brother.com/ or use the link on
the CD-ROM we have supplied.
2Depending on Linux distributions, the driver may not be available or it may be released after the initial release of your model.
Printing a document 2
When the machine receives data from your computer, it begins printing by picking up paper from the paper
tray. The paper tray can feed plain paper and recycled paper to the machine. (See Paper capacity of the
paper tray on page 2.)
aFrom your application, choose the Print command.
If any other printer drivers are installed on your computer, choose Brother HL-XXXX series (Where
XXXX is your model name.) as your printer driver from the Print or Print Settings menu in your software
application, and then click OK or Print to begin printing.
bYour computer sends the data to the machine. The Ready LED ( ) will blink.
cWhen the machine finishes printing all the data, the Ready LED ( ) finishes blinking.
NOTE
• You can choose the paper size and orientation in your application software.
Driver and Software 2

Driver and Software
6
2
• If your application software does not support your custom paper size, choose the next largest paper size.
• Then adjust the print area by changing the right and left margins in your application software.
Printer driver settings 2
You can change the following printer settings when you print from your computer:
Paper Size
Orientation
Copies
Media Type
Print Quality
Print Settings
Multiple Page
2-sided / Booklet
Print Preview
Scaling
Reverse Print
Use Watermark
Header-Footer Print
Toner Save Mode
Administrator
Density Adjustment
Improve Print Output
Skip Blank Page
PrintTextinBlack
Print Profile

Driver and Software
7
2
Windows® 2
Accessing the printer driver settings 2
a(For Windows®XP and Windows Server®2003)
Click Start, and then Printers and Faxes.
(For Windows Vista®and Windows Server®2008)
Click the (Start) button, Control Panel, Hardware and Sound, and then Printers.
(For Windows®7 and Windows Server®2008 R2)
Click the (Start) button, and then click Devices and Printers.
(For Windows®8)
Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings,
and then click Control Panel. In the Hardware and Sound group, click View devices and printers.
(For Windows Server®2012)
Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings,
and then click Control Panel. In the Hardware group, click View devices and printers.
b(For Windows®XP, Windows Server®2003, Windows Vista®and Windows Server®2008)
Right-click the Brother HL-XXXX series icon (where XXXX is your model name) and then select
Properties option. If printer driver options appear, select your printer driver.
(For Windows®7, Windows Server®2008 R2, Windows®8 and Windows Server®2012)
Right-click the Brother HL-XXXX series icon (where XXXX is your model name) and then select
Printer properties option. If printer driver options appear, select your printer driver.
cChoose the General tab and then click Preferences... (Printing Preferences...).
Features in the Windows®printer driver 2
For more information, see the Help text in the printer driver.
NOTE
• The screens in this section are from Windows®7. The screens on your PC will vary depending on your
operating system.
• To access the printer driver settings, see Accessing the printer driver settings on page 7.

Driver and Software
8
2
Basic tab 2
You can also change the Page Layout settings by clicking the illustration on the left side of the Basic tab.
aChoose the Paper Size, Orientation, Copies, Media Type, Print Quality and Print Settings (1).
bChoose Multiple Page and 2-sided / Booklet (2).
cConfirm your current settings in the window (3).
dClick OK to apply your chosen settings.
To return to the default settings, click Default, then OK.
NOTE
If you want to preview your document before printing, check the Print Preview check box (4).
Paper Size 2
From the drop-down list choose the Paper Size you are using.
4
1
2
3

Driver and Software
9
2
Orientation 2
Orientation selects the position of how your document will be printed (Portrait or Landscape).
Copies 2
The copies selection sets the number of copies that will be printed.
Collate
With the Collate check box selected, one complete copy of your document will be printed and then
repeated for the number of copies you selected. If the Collate check box is not selected, then each page
will be printed for all the copies selected before the next page of the document is printed.
Media Type 2
You can use the following types of media in your machine. For the best print quality, select the type of media
that you wish to use.
Plain Paper
Recycled Paper
Print Quality 2
You can choose the print quality as follows.
Draft
Normal
Fine
Portrait (Vertical) Landscape (Horizontal)
Collate checked Collate non-checked

Driver and Software
10
2
Print Settings 2
You can change the print settings as follows:
Graphics
This is the best mode for printing documents that contain graphics.
Text
This is the best mode for printing text documents.
Manual
You can change the settings manually by choosing Manual and clicking the Manual Settings... button.
You can set brightness, contrast and other settings.
Multiple Page 2
The Multiple Page selection can reduce the image size of a page allowing multiple pages to be printed on
one sheet of paper or enlarge the image size for printing one page on multiple sheets of paper.
Page Order
When Nin1option is selected, the page order can be selected from the drop-down list.
Border Line
When printing multiple pages onto one sheet, with the Multiple Page feature, you can choose to have a
solid border, dash border or no border around each page on the sheet.
Print cut-out line
When 1 in NxN Pages option is selected, the Print cut-out line option can be selected. This option allows
you to print a faint cut-out line around the printable area.
2-sided / Booklet 2
When you want to print a booklet or do 2-sided printing, use this function.
None
This disables 2-sided printing.
2-sided (Manual)
When you want to do 2-sided printing, use this option.
•2-sided (Manual)
The machine prints all the even numbered pages first. Then the printer driver will stop and show the
instructions required to re-insert the paper. When you click OK the odd numbered pages will be printed.
When you choose 2-sided (Manual), the 2-sided Settings... button becomes available to choose. You
can set following settings in the 2-sided Settings dialog box.

Driver and Software
11
2
•2-sided Type
There are four types of 2-sided binding directions available for each orientation.
•Binding Offset
When you check Binding Offset, you can also specify the offset for binding in inches or millimetres.
Booklet (Manual)
Use this option to print a document in booklet format using 2-sided printing; it will arrange the document
according to the correct page number and allows you to fold at the centre of the print output without having
to change the order of the page number.
•Booklet (Manual)
The machine prints all the even numbered sides first. Then the printer driver will stop and show the
instructions required to re-install the paper. When you click OK the odd numbered sides will be printed.
When you choose Booklet (Manual), the 2-sided Settings... button becomes available to choose. You
can set the following settings in the 2-sided Settings dialog box.
Portrait
Long Edge (Left)
Long Edge (Right) Short Edge (Top) Short Edge (Bottom)
Landscape
Long Edge (Top)
Long Edge (Bottom) Short Edge (Right) Short Edge (Left)

Driver and Software
12
2
•2-sided Type
There are two types of 2-sided binding directions available for each orientation.
•Booklet Printing Method
When Divide into Sets is selected:
This option allows you to print the whole booklet into smaller individual booklet sets, it still allows you
to fold at the center of the smaller individual booklet sets without having to change the order of the page
number. You can specify the number of sheets in each smaller booklet set, from 1 to 15. This option
can help when folding the printed booklet that has a large number of pages.
•Binding Offset
When you check Binding Offset, you can also specify the offset for binding in inches or millimetres.
Print Preview 2
You can preview a document before it is printed. If you check the Print Preview check box, the Print Preview
Viewer window will open before printing starts.
Portrait Landscape
Left Binding
Right Binding Top Binding Bottom Binding
2
1

Driver and Software
13
2
1 Page List Area
The Page List Area displays the page numbers for the actual pages that will be printed. If you chose a
page in this list, a preview of the print results for the page will be displayed in the Preview Area.
If you do not want to print a page, clear the check mark.
2 Preview Area
The Preview Area displays a preview of the print results for the pages chosen in the Page List Area.
NOTE
If 2-sided (Manual) or Booklet (Manual) was chosen in the Printer driver settings, you cannot use the
Print Preview function.
Advanced tab 2
Change the tab settings by clicking one of the following selections:
Scaling (1)
Reverse Print (2)
Use Watermark (3)
Header-Footer Print (4)
Toner Save Mode (5)
Administrator (6)
Other Print Options (7)
1
2
3
4
5
6
7

Driver and Software
14
2
Scaling 2
You can change the print image scaling.
Reverse Print 2
Check Reverse Print to reverse the data from up to down.
Use Watermark 2
You can put a logo or text into your document as a watermark. You can choose one of the preset Watermarks,
or you can use a bitmap file that you have created. Check Use Watermark and then click the Settings...
button.
Watermark Settings 2
