Bryant Legacy 116B Operation manual

116B
LegacytLine 16 Air Conditioner
with PuronrRefrigerant
1--1/2 to 5 Nominal Tons (Sizes 018--060)
Product Data
the environmentally sound refrigerant
Bryant’s Air Conditioners with Puronrrefrigerant provide a
collection of features unmatched by any other family of
equipment. The 116B has been designed utilizing Bryant’s Puron
refrigerant. The environmentally sound refrigerant allows you to
make a responsible decision in the protection of the earth’s ozone
layer.
As an Energy StarrPartner, Bryant Heating and Cooling has
determined that this product meets the Energy Starrguidelines
for energy efficiency. Refer to the combination ratings in the
Product Data for system combinations that meet Energy Starr
guidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S14 -- 16.5 SEER/11.0-- 13.5 EER
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 76 dBA
SSound level as low as 74 dBA with accessory sound
blanket
Comfort
SSystem supports Thermidistattor standard thermostat
controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
DuraGuardtprotection package:
SSolid, durable sheet metal construction
SDense wire coil guard standard
SBaked--on, complete outer coverage, powder paint
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent
length, up to 200 feet (60.96 m) condenser above
evaporator, or up to 80 ft. (24.38 m) evaporator above
condenser (See Longline Guide for more information.)
SLow ambient (down to --20_F/--28.9_C)) with
accessory kit

2
MODEL NUMBER NOMENCLATURE
12345678910111214
N N N A A/N N N N N A/N A/N N A
116BNA03600 00
Prod-
uct
Family
Tier SEER Major
Series Voltage Grille Variations
Cooling Capacity Open Open Open Series
1=AC
1=
Legacy
RNC
6=16 SEER B=Puron
N=
208--- 230---1
or
208/230--- 1
A=Dense
W=Standard
0=Not
Defined
0=Not
Defined
0=Not
Defined
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star®criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 018 024 030 036 042 048 060
Puron Refrigerant XXXXXXX
Maximum SEER * 16.0 16.0 16.5 16.5 16.0 16.0 16.0
Scroll Compressor XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
Dense Grille XXXXXXX
* With approved combinations
X=Standard
PHYSICAL DATA
UNIT SIZE --- VOLTAGE, SERIES 018 --- B 024 --- A 030 --- A 036 --- A 042 --- A 048 --- A 060--- A
Operating Weight lb (kg) 125
(56.7)
147
(66.5)
153
(69.3)
165
(74.8)
213
(96.4)
231
(104.8)
272
(123.4)
Shipping Weight lb (kg) 154
(69.9)
183
(82.8)
188
(85.2)
204
(92.5)
254
(115.2)
274
(124.3)
310
(140.6)
Compressor Type Scroll
REFRIGERANT Puron®(R---410A)
Control TXV (Puron®Hard Shutoff)
Charge lb (kg) 4.60
(2.09)
6.00
(2.72)
6.81
(3.09)
7.00
(3.18)
8.62
(3.91)
10.50
(4.76)
14.50
(6.58)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1881 2614 2614 3223 3810 4046 4046
Motor HP 1/12 1/10 1/10 1/12 1/5 1/4 1/4
Motor RPM 1100 1100 1100 800 800 800 800
COND COIL
Face Area (Sq ft) 11.50 15.10 17.20 17.60 25.15 20.10 30.15
Fins per In. 25 25 25 25 25 20 20
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 4 6 7 8
VALVECONNECT.(In.ID)
Vapor 3/4 3/4 3/4 7/8 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 3/4 7/8 1 --- 1 / 8
Max Liquid Line {3/8
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
{See Liquid Line Sizing For Cooling Only Systems with Puron Refrigerant tables.
116B

3
REFRIGERANT PIPING LENGTH LIMITATIONS
Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with PuronrRefrigerant:
The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and
outdoor units.
See Table below for liquid line sizing and maximum lengths :
Maximum Total Equivalent Length
Outdoor Unit BELOW Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor
Vertical Separation ft (m)
0 --- 5
(0---1.5)
6 --- 1 0
(1.8---3.0)
11---20
(3.4---6.1)
21---30
(6.4---9.1)
31---40
(9.4---12.2)
41---50
(12.5---15.2)
51---60
(15.5---18.3)
61---70
(18.6---21.3)
71---80
(21.6---24.4)
18000
AC with
Puron
3/8
1/4 150 150 125 100 100 75 --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 225* 150
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 225* 175 125 100
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 175 225* 200 175 125 100 75 --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---
3//8 250* 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8 5/16 125 100 100 75 75 50 --- --- --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 150
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
60000
AC with
Puron
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
Maximum Total Equivalent Length
Outdoor Unit ABOVE Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor
Vertical Separation ft (m)
25
(7.6)
26---50
(7.9---15.2)
51---75
(15.5---22.9)
76---100
(23.2---30.5)
101---125
(30.8---38.1)
126---150
(38.4---45.7)
151---175
(46.0---53.3)
176---200
(53.6---61.0)
18000
AC with
Puron
3/8
1/4 175 250* 250* 250* 250* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
24000
AC with
Puron
3/8
1/4 100 125 175 200 225* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
30000
AC with
Puron
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
36000
AC with
Puron
3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
42000
AC with
Puron
3/8 5/16 175 200 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
48000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
60000
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
116B

4
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size Puron Charge oz/ft
3/8 0.60
(Factory charge for lineset = 9 oz)
5/16 0.40
1/4 0.27
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz. When using other length or diameter
liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line
depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.
For Air Conditioner systems, the chart below shows when an application is considered Long Line.
AC WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 No accessories needed within allowed
lengths
No accessories needed within allowed
lengths 175 (53.3)
5/16 120 (36.6) 50 (15.2) 120 (36.6)
3/8 80 (24.4) 35 (10.7) 80 (24.4)
Note: SeeLongLineGuidelinefordetails
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for AC systems with Puron refrigerant:
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
26 --- 50
(7.9---15.2)
51 --- 80
(15.5---24.4)
81 --- 100
(24.7---30.5)
101 --- 125
(30.8---38.1)
126 --- 150
(38.4---45.7)
151 --- 175
(46.0---53.3)
176 --- 200
(53.6---61.0)
201 --- 225
(61.3---68.6)
226 --- 250
(68.9---76.2)
18000
1Stage
AC with
Puron
3/8
1/2 1 2 3 5 6 7 8 9 11
5/8 0 1 1 1 2 2 2 3 3
3/4 0 0 0 0 1 1 1 1 1
24000
1Stage
AC with
Puron
3/8
5/8 0 1 2 2 3 3 4 5 5
3/4 0 0 1 1 1 1 1 2 2
7/8 0 0 0 0 0 1 1 1 1
30000
1Stage
AC with
Puron
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36000
1Stage
AC with
Puron
3/8
5/8 1 2 4 5 6 8 9 10 12
3/4 0 1 1 2 2 3 3 4 4
7/8 0 0 0 1 1 1 1 2 2
42000
1Stage
AC with
Puron
3/8
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
11/8 0 0 0 0 0 0 0 0 0
48000
1Stage
AC with
Puron
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
11/8 0 0 0 0 0 0 0 1 1
60000
1Stage
AC with
Puron
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
11/8 0 0 0 1 1 1 1 1 1
Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.
116B

5
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE
PKG. DESCRIPTION
T 6 --- P R H 0 1 --- A Programmable Thermidistat
T 6 --- N R H 0 1 --- A Non---programmable Thermidistat
T 6 --- P A C 0 1 Preferred Series Programmable AC Stat
T 6 --- N A C 0 1 Preferred Series Non--- programmable AC Stat
T 2 --- P A C 0 1 Legacy Series Programmable AC Stat
T 2 --- N A C 0 1 Legacy Series Non---programmable AC Stat
T 1 --- P A C 0 1 Legacy RNC Series Programmable AC Stat
T 1 --- N A C 0 1 Legacy RNC Series Non --- programmable AC Stat
TSTATBBSEN01---B Outdoor Air Temperature Sensor
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXNBP01 Backplate for Non --- Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack
ACCESSORIES
KIT NUMBER DESCRIPTION Size --- Voltage & Series
018 --- B 024 --- A 030 --- A 036 --- A 042--- A 048 --- A 060--- A
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X
KSALA0601AAA{MOTORMASTER 230V X X X X X X X
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE240 MOTOR FAN BALL BEARING X X
HC32GE229 MOTOR FAN BALL BEARING X
HC38GE228 MOTOR FAN BALL BEARING X
HC40GE228 MOTOR FAN BALL BEARING X X
KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KAALS0201LLS LIQUID LINE SOLENOID X X X X X X X
KAAWS0101AAA WINTER START X X X X X X X
KAACH1701AAA CRANKCASE HTR X X X X
KAACH1601AAA CRANKCASE HTR X S S
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X X
KSASH0601COP SOUND HOOD X X X X
KSASH2101COP SOUND HOOD X X X
KAALP0401PUR LOW PRESSURE SWITCH X X X X X X X
KAAHI0501PUR HIGH PRESSURE SWITCH X X X X X X X
{Required accessories include ball bearing fan motor, compressor start assist (CAP / Relay), crankcase heater, evaporator freeze stat, hard shut---off TXV.
X = Accessory / S --- Standard
116B

6
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW---AMBI-
ENT COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR LONG
LINE
APPLICATIONS*
(Over 80 ft./24.38 m)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within2miles/3.22km)
Ball Bearing Fan Motor Yes{No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
H a r d S h u t --- O f f T X V Yes Yes Yes
Liquid Line Solenoid Valve No No No
Motor Master®Control or
L o w --- a m b i e n t P r e s s u r e S w i t c h Yes No No
Support Feet Recommended No Recommended
Winter Start Control Yes No No
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Residential Split---System Longline
Application Guideline.
{Required for Low ---Ambient Controller (full modulation feature) MotorMasterrControl.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterris used.
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
(--18_C) when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling operation is
used at outdoor temperatures below 55_F (12.8_C).
8. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
5.5_C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
9. Outdoor Air Temperature Sensor
Designed for use with Bryant Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Bryant thermostats listed in this
publication.
116B

7
Accessory Description and Usage (Listed Alphabetically) (Continued)
10. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces
the sound level by about 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft (4.57 m) to
quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft (3.05 m) apart.
11. Support Feet
Four stick--on plastic feet that raise the unit 4 in. (101.6 mm)
above the mounting pad. This allows sand, dirt, and other debris
to be flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
12. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve ARI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
13. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
ARI Unitary Directory.
14. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
116B

8
ELECTRICAL DATA
UNIT SIZE V/PH
OPER VOLTS* COMPR FAN
MCA
MIN WIRE
SIZE{
60°C
MIN WIRE
SIZE{
75°C
MAX
LENGTH
ft. (m)}
60°C
MAX
LENGTH
ft. (m)}
75°C
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
018 --- B
208/230/1---60 253 197
48.0 9.0 0.50 11.8 14 14 67 (20.4) 64 (19.5) 20
024 --- A 58.3 13.5 0.75 17.7 14 14 46 (14.0) 43 (13..1) 25
030 --- A 64.0 12.8 0.75 16.8 14 14 44 (13.4) 41 (12.5) 25
036 --- A 77.0 14.1 0.50 18.1 12 12 57 (17.4) 54 (16.5) 30
042 --- A 112.0 17.9 1.20 23.6 10 10 85 (25.9) 81 (24.7) 40
048 --- A 109.0 19.9 1.20 26.1 10 10 70 (21.3) 67 (20.4) 40
060 --- A 135.0 21.4 1.20 28.0 810 91 (27.7) 56 (17.1) 40
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non---metallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336---26. If other than uncoated (no---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER LEVEL (dBA)
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
018 --- B 76 52.5 59.0 65.5 70.5 64.5 59.0 54.5
024 --- A 76 57.5 64.0 69.0 71.0 69.0 64.5 60.0
030 --- A 76 55.0 63.5 68.0 69.5 67.0 63.5 58.5
036 --- A 76 50.5 59.5 64.5 70.5 62.0 59.5 54.5
042 --- A 78 52.5 62.0 66.0 73.5 68.0 62.0 55.5
048 --- A 78 58.0 62.0 65.0 66.5 62.5 59.5 56.5
060 --- A 78 55.0 62.5 67.5 70.5 65.0 61.0 53.5
NOTE: Tested in accordance with ARI Standard 270 ---08 (not listed in AHRI).
A--WEIGHTED SOUND POWER LEVEL (dBA) WITH SOUND SHIELD
U n i t S i z e ---
Voltage, Series
Standard
Rating (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA without tone adjustment)
125 250 500 1000 2000 4000 8000
018 --- B 74 55.5 59.0 65.0 68.5 63.5 58.0 52.0
024 --- A 75 58.0 64.0 69.0 70.5 68.5 64.5 59.5
030 --- A 75 55.5 63.0 68.0 69.0 67.0 63.0 58.5
036 --- A 74 51.5 58.5 62.0 65.0 61.0 58.0 52.0
042 --- A 76 53.0 62.0 65.5 72.0 65.0 61.0 54.0
048 --- A 76 60.0 63.5 65.0 65.5 62.0 58.0 52.5
060 --- A 75 56.5 62.5 66.5 68.0 63.0 59.5 51.5
NOTE: Tested in accordance with ARI Standard 270 ---08 (not listed in AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)
018 --- B 10 (5.6)
024 --- A 10 (5.6)
030 --- A 10 (5.6)
036 --- A 10 (5.6)
042 --- A 9 (5.0)
048 --- A 10 (5.6)
060 --- A 9 (5.0)
116B

9
DIMENSIONS -- ENGLISH
B
3"
K
5/16"
L
C
3 1/2"
1 7/8"
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)
SHIPPING
WEIGHT (lbs)
SHIPPING
DIMENSIONS (L x W x H)
116BNA024 A X O O O 31 3/16" 28 5/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 16" 16" 13" 147 183 32 3/8" X 35 1/2" X 32 9/16"
116BNA030 A X O O O 31 3/16" 32 5/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 15 1/2" 16" 14 1/4" 153 188 32 3/8" X 35 1/2" X 35 15/16"
116BNA036 A X O O O 35" 28 5/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16" 16" 13" 165 204 36 1/8" X 39 5/16" X 32 9/16"
116BNA042 A X O O O 35" 39 1/8" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 1/2" 17 1/2" 17 1/2" 213 254 36 1/8" X 39 5/16" X 42 3/4"
116BNA048 A X O O O 35" 32 5/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17" 17 1/2" 14 1/4" 231 274 36 1/8" X 39 5/16" X 35 15/16"
116BNA060 A X O O O 35" 45 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 1/2" 17" 16 1/4" 272 310 36 1/8" X 39 5/16" X 49 9/16"
116BNA018 B X O O O 25 3/4" 28 11/16" 3 3/4" 3/4" 4 7/16" 21 1/4" 7 13/16" 2 13/16" 1/2" 13 5/8" 13 1/2" 12 3/4" 125 154 26 7/8" X 30 1/16" X 32 9/16"
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 26" X 26"
24,30 31 1/2" X 31 1/2"
36 THRU 60 35" X 35"
AIR DISCHARGE
AIR DISCHARGE
SQ.
AIR IN
VAPOR LINE CONN.
D
3/8"
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
3/8" TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY CONN.
7/8" HOLE WITH 1 1/8" KNOCKOUT
X = YES O = NO
NOTES: 1. ALLOW 30" CLEARANCE TO SERVICE SIDE OF UNIT, 48" ABOVE UNIT, 6" ON ONE SIDE, 12" ON REMAINING SIDE, AND 24" BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 55° F, MAX. 125° F. 3. SERIES DESIGNATION IS THE 10TH POSITION OF THE UNIT MODEL NUMBER. 4. CENTER OF GRAVITY . 5. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
116B

10
DIMENSIONS -- SI
B
C
88.9
47.6
P
A
76.2
K
8.0
L
N
M
E
F
G
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs)
SHIPPING
DIMENSIONS (L x W x H)
116BNA024 A X O O O 792.2 719.2 95.2 19.0 166.7 627.1 231.8 71.4 12.7 406.4 406.4 330.2 66.5 82.8 822.3 X 901.7 X 827.1
116BNA030 A X O O O 792.2 820.8 95.2 19.0 166.7 627.1 231.8 71.4 12.7 393.7 406.4 362.0 69.3 85.2 822.3 X 901.7 X 912.8
116BNA036 A X O O O 889.0 719.2 98.4 22.2 166.7 722.3 231.8 74.6 15.9 406.4 406.4 330.2 74.8 92.5 917.6 X 998.6 X 827.1
116BNA042 A X O O O 889.0 993.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 444.5 444.5 96.4 115.2 917.6 X 998.6 X 1085.8
116BNA048 A X O O O 889.0 820.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 431.8 444.5 362.0 104.8 124.3 917.6 X 998.6 X 912.8
116BNA060 A X O O O 889.0 1166.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 431.8 412.8 123.4 140.6 917.6 X 998.6 X 1258.9
116BNA018 B X O O O 654.0 728.7 95.2 19.0 112.7 539.8 198.4 71.4 12.7 346.1 342.9 323.9 56.7 69.9 682.6 X 763.6 X 827.1
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 660.4 X 660.4
24,30 800.1 X 800.1
36 THRU 60 889.0 X 889.0
AIR DISCHARGE
SQ.
AIR DISCHARGE
AIR IN
VAPOR LINE CONN.
D
9.53
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
X = YES O = NO
NOTES: 1. ALLOW 762.0 CLEARANCE TO SERVICE SIDE OF UNIT, 1219.2 ABOVE UNIT, 152.4 ON ONE SIDE, 304.8 ON REMAINING SIDE, AND 609.6 BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 13° C, MAX. 52 ° C. 3. SERIES DESIGNATION IS THE 10TH POSITION OF THE UNIT MODEL NUMBER. 4. CENTER OF GRAVITY . 5. ALL DIMENSIONS ARE IN "MM" UNLESS NOTED.
116B

11
CLEARANCES
Clearances (various examples)
Wall
6”
(152.4)
24”
(609.6)
Service
Wall
Wall
Wall
12”
(304.8)
12”
(304.8)
18”
(457.2)
24”
(609.6)
Service
6”
(152.4)
12”
(304.8)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
Note: Numbers in ( ) = mm
18”
(457.2)
18”
(457.2)
12”
(304.8)
IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
116B

12
COMBINATION RATINGS
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632435 116BNA018****B †CNPV*1917A**+TDR 18,000 12.0 14.5
3632420 116BNA018****B CAP**1814A** 313*AV024045 18,000 13.0 15.5
3632395 116BNA018****B CAP**1814A** 315(A,J)AV036070 18,000 12.5 15.5
3632429 116BNA018****B CAP**1814A**+TDR 18,000 11.5 13.5
3632421 116BNA018****B CAP**2414A** 313*AV024045 18,000 13.0 16.0
3632396 116BNA018****B CAP**2414A** 315(A,J)AV036070 18,000 13.0 16.0
3632430 116BNA018****B CAP**2414A**+TDR 18,000 11.5 14.0
3632422 116BNA018****B CAP**2417A** 313*AV024045 18,000 13.0 16.0
3632397 116BNA018****B CAP**2417A** 315(A,J)AV036070 18,000 13.0 16.0
3632404 116BNA018****B CAP**2417A** 315(A,J)AV048090 18,000 13.0 16.0
3632453 116BNA018****B CAP**2417A** 353(A,B)AV036040 18,000 13.0 16.0
3632458 116BNA018****B CAP**2417A** 353(A,B)AV036060 18,000 13.0 16.0
3663501 116BNA018****B CAP**2417A** 353AAV036040 18,000 13.0 16.0
3632411 116BNA018****B CAP**2417A** 355(A,C)AV042060 18,000 13.0 16.0
3635381 116BNA018****B CAP**2417A** 355BAV042060 18,000 13.0 16.0
3632431 116BNA018****B CAP**2417A**+TDR 18,000 11.5 14.0
3632432 116BNA018****B CNPF*2418A**+TDR 18,000 11.5 14.0
3632423 116BNA018****B CNPH*2417A** 313*AV024045 18,000 13.0 16.0
3632398 116BNA018****B CNPH*2417A** 315(A,J)AV036070 18,000 13.0 16.0
3632405 116BNA018****B CNPH*2417A** 315(A,J)AV048090 18,000 13.0 16.0
3632455 116BNA018****B CNPH*2417A** 353(A,B)AV036040 18,000 13.0 16.0
3632460 116BNA018****B CNPH*2417A** 353(A,B)AV036060 18,000 13.0 16.0
3663503 116BNA018****B CNPH*2417A** 353AAV036040 18,000 13.0 16.0
3632412 116BNA018****B CNPH*2417A** 355(A,C)AV042060 18,000 13.0 16.0
3632416 116BNA018****B CNPH*2417A** 355(A,C)AV042080 18,000 13.0 16.0
3632418 116BNA018****B CNPH*2417A** 355AAV042040 18,000 13.0 16.0
3635382 116BNA018****B CNPH*2417A** 355BAV042060 18,000 13.0 16.0
3635386 116BNA018****B CNPH*2417A** 355BAV042080 18,000 13.0 16.0
3632433 116BNA018****B CNPH*2417A**+TDR 18,000 12.0 14.5
3632424 116BNA018****B CNPV*1814A** 313*AV024045 18,000 13.0 15.5
3632399 116BNA018****B CNPV*1814A** 315(A,J)AV036070 18,000 13.0 15.5
3632434 116BNA018****B CNPV*1814A**+TDR 18,000 11.5 14.0
3632425 116BNA018****B CNPV*1917A** 313*AV024045 18,000 13.0 16.0
3632400 116BNA018****B CNPV*1917A** 315(A,J)AV036070 18,000 13.0 16.0
3632406 116BNA018****B CNPV*1917A** 315(A,J)AV048090 18,000 13.0 16.0
3632452 116BNA018****B CNPV*1917A** 353(A,B)AV036040 18,000 13.0 16.0
3632457 116BNA018****B CNPV*1917A** 353(A,B)AV036060 18,000 13.0 16.0
3663500 116BNA018****B CNPV*1917A** 353AAV036040 18,000 13.0 16.0
3632413 116BNA018****B CNPV*1917A** 355(A,C)AV042060 18,000 13.0 16.0
3635383 116BNA018****B CNPV*1917A** 355BAV042060 18,000 13.0 16.0
3632426 116BNA018****B CNPV*2414A** 313*AV024045 18,000 13.0 16.0
3632401 116BNA018****B CNPV*2414A** 315(A,J)AV036070 18,000 13.0 16.0
3632436 116BNA018****B CNPV*2414A**+TDR 18,000 11.5 14.0
3632427 116BNA018****B CNPV*2417A** 313*AV024045 18,000 13.0 16.0
3632402 116BNA018****B CNPV*2417A** 315(A,J)AV036070 18,000 13.0 16.0
3632407 116BNA018****B CNPV*2417A** 315(A,J)AV048090 18,000 13.0 16.0
3632454 116BNA018****B CNPV*2417A** 353(A,B)AV036040 18,000 13.0 16.0
3632459 116BNA018****B CNPV*2417A** 353(A,B)AV036060 18,000 13.0 16.0
3663502 116BNA018****B CNPV*2417A** 353AAV036040 18,000 13.0 16.0
3632414 116BNA018****B CNPV*2417A** 355(A,C)AV042060 18,000 13.0 16.0
3635384 116BNA018****B CNPV*2417A** 355BAV042060 18,000 13.0 16.0
3632437 116BNA018****B CNPV*2417A**+TDR 18,000 11.5 14.0
3632428 116BNA018****B CSPH*2412A** 313*AV024045 18,000 13.0 16.0
3632403 116BNA018****B CSPH*2412A** 315(A,J)AV036070 18,000 13.0 16.0
3632408 116BNA018****B CSPH*2412A** 315(A,J)AV048090 18,000 13.0 16.0
3632456 116BNA018****B CSPH*2412A** 353(A,B)AV036040 18,000 13.0 16.0
3632461 116BNA018****B CSPH*2412A** 353(A,B)AV036060 18,000 13.0 16.0
3663504 116BNA018****B CSPH*2412A** 353AAV036040 18,000 13.0 16.0
3632415 116BNA018****B CSPH*2412A** 355(A,C)AV042060 18,000 13.0 16.0
3632417 116BNA018****B CSPH*2412A** 355(A,C)AV042080 18,000 13.0 16.0
3632419 116BNA018****B CSPH*2412A** 355AAV042040 18,000 13.0 16.0
3635385 116BNA018****B CSPH*2412A** 355BAV042060 18,000 13.0 16.0
3635387 116BNA018****B CSPH*2412A** 355BAV042080 18,000 13.0 16.0
3632409 116BNA018****B CSPH*2412A** 359BAV036040 18,000 13.0 15.5
3632410 116BNA018****B CSPH*2412A** 359BAV036060 18,000 13.0 15.5
3632438 116BNA018****B CSPH*2412A**+TDR 18,000 12.0 14.0
3632439 116BNA018****B FE4ANF002+UI 18,000 13.0 16.0
3632440 116BNA018****B FF1ENP018 18,000 11.5 14.0
3632441 116BNA018****B FF1ENP019 18,000 12.5 15.5
3632442 116BNA018****B FF1ENP024 18,000 11.5 14.0
3632443 116BNA018****B FF1ENP025 18,000 13.0 16.0
3632444 116BNA018****B FV4BNF002 18,000 13.0 16.0
3632445 116BNA018****B FV4CNF002 18,000 13.0 16.0
See notes on page 37
116B

13
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632446 116BNA018****B FX4CNF018 18,000 13.0 15.5
3632447 116BNA018****B FX4CNF024 18,000 13.0 16.0
3632448 116BNA018****B FX4DNF019 18,000 13.0 16.0
3632449 116BNA018****B FX4DNF025 18,000 13.0 16.0
3632450 116BNA018****B FY4ANF018 18,000 11.5 14.0
3632451 116BNA018****B FY4ANF024 18,000 11.5 13.5
3632611 116BNA024****A †CNPV*3117A**+TDR 23,600 12.0 14.5
3632573 116BNA024****A CAP**2414A** 313*AV024045 23,000 12.5 15.5
3632462 116BNA024****A CAP**2414A** 315(A,J)AV036070 22,800 12.5 15.5
3632592 116BNA024****A CAP**2414A**+TDR 23,000 11.5 14.0
3632670 116BNA024****A CAP**2417A** 353(A,B)AV036080 23,200 13.0 16.0
3632574 116BNA024****A CAP**2417A** 313*AV024045 23,000 12.5 15.5
3632463 116BNA024****A CAP**2417A** 315(A,J)AV036070 22,800 12.5 15.5
3632481 116BNA024****A CAP**2417A** 315(A,J)AV048090 22,800 13.0 16.0
3632639 116BNA024****A CAP**2417A** 353(A,B)AV036040 23,400 13.0 16.0
3632655 116BNA024****A CAP**2417A** 353(A,B)AV036060 23,400 13.0 16.0
3663507 116BNA024****A CAP**2417A** 353AAV036040 23,400 13.0 16.0
3632521 116BNA024****A CAP**2417A** 355(A,C)AV042060 23,200 13.0 16.0
3635389 116BNA024****A CAP**2417A** 355BAV042060 23,200 13.0 16.0
3632593 116BNA024****A CAP**2417A**+TDR 23,000 11.5 14.0
3632575 116BNA024****A CAP**3014A** 313*AV024045 23,200 12.5 15.5
3632464 116BNA024****A CAP**3014A** 315(A,J)AV036070 22,800 13.0 16.0
3632594 116BNA024****A CAP**3014A**+TDR 23,200 11.5 14.0
3632671 116BNA024****A CAP**3017A** 353(A,B)AV036080 23,400 13.0 16.0
3632576 116BNA024****A CAP**3017A** 313*AV024045 23,200 13.0 16.0
3632465 116BNA024****A CAP**3017A** 315(A,J)AV036070 23,000 13.0 16.0
3632482 116BNA024****A CAP**3017A** 315(A,J)AV048090 23,000 13.0 16.0
3632640 116BNA024****A CAP**3017A** 353(A,B)AV036040 23,600 13.0 16.0
3632656 116BNA024****A CAP**3017A** 353(A,B)AV036060 23,600 13.0 16.0
3663508 116BNA024****A CAP**3017A** 353AAV036040 23,600 13.0 16.0
3632522 116BNA024****A CAP**3017A** 355(A,C)AV042060 23,200 13.0 16.0
3635390 116BNA024****A CAP**3017A** 355BAV042060 23,200 13.0 16.0
3632595 116BNA024****A CAP**3017A**+TDR 23,200 11.5 14.0
3632577 116BNA024****A CAP**3614A** 313*AV024045 23,200 13.0 16.0
3632466 116BNA024****A CAP**3614A** 315(A,J)AV036070 23,000 13.0 16.0
3632596 116BNA024****A CAP**3614A**+TDR 23,200 11.5 14.0
3632672 116BNA024****A CAP**3617A** 353(A,B)AV036080 23,600 13.0 16.0
3632578 116BNA024****A CAP**3617A** 313*AV024045 23,400 13.0 16.0
3632467 116BNA024****A CAP**3617A** 315(A,J)AV036070 23,000 13.0 16.0
3632483 116BNA024****A CAP**3617A** 315(A,J)AV048090 23,000 13.0 16.0
3632641 116BNA024****A CAP**3617A** 353(A,B)AV036040 23,600 13.0 16.0
3632657 116BNA024****A CAP**3617A** 353(A,B)AV036060 23,800 13.0 16.0
3663509 116BNA024****A CAP**3617A** 353AAV036040 23,600 13.0 16.0
3632523 116BNA024****A CAP**3617A** 355(A,C)AV042060 23,400 13.0 16.0
3635391 116BNA024****A CAP**3617A** 355BAV042060 23,400 13.0 16.0
3632597 116BNA024****A CAP**3617A**+TDR 23,200 11.5 14.0
3632517 116BNA024****A CAP**3619A** 359BAV036040 23,400 12.5 15.5
3632519 116BNA024****A CAP**3619A** 359BAV036060 23,600 12.5 15.5
3632598 116BNA024****A CAP**3619A**+TDR 23,200 11.5 14.0
3632673 116BNA024****A CAP**3621A** 353(A,B)AV036080 23,600 13.0 16.0
3632484 116BNA024****A CAP**3621A** 315(A,J)AV048090 23,000 13.0 16.0
3632497 116BNA024****A CAP**3621A** 315(A,J)AV060110 23,200 13.0 16.0
3632642 116BNA024****A CAP**3621A** 353(A,B)AV036040 23,800 13.0 16.0
3632658 116BNA024****A CAP**3621A** 353(A,B)AV036060 23,800 13.0 16.0
3663510 116BNA024****A CAP**3621A** 353AAV036040 23,800 13.0 16.0
3632524 116BNA024****A CAP**3621A** 355(A,C)AV042060 23,400 13.0 16.0
3632537 116BNA024****A CAP**3621A** 355(A,C)AV042080 23,000 13.0 16.0
3632545 116BNA024****A CAP**3621A** 355(A,C)AV060080 22,800 13.0 16.0
3632553 116BNA024****A CAP**3621A** 355(A,C)AV060100 23,000 13.0 16.0
3635392 116BNA024****A CAP**3621A** 355BAV042060 23,400 13.0 16.0
3635405 116BNA024****A CAP**3621A** 355BAV042080 23,000 13.0 16.0
3635413 116BNA024****A CAP**3621A** 355BAV060080 22,800 13.0 16.0
3635421 116BNA024****A CAP**3621A** 355BAV060100 23,000 13.0 16.0
3632599 116BNA024****A CAP**3621A**+TDR 23,200 11.5 14.0
3632600 116BNA024****A CNPF*2418A**+TDR 23,000 11.5 14.0
3632601 116BNA024****A CNPF*3618A**+TDR 23,200 11.5 14.0
3632678 116BNA024****A CNPH*2417A** 353(A,B)AV036080 23,000 13.0 16.0
3632579 116BNA024****A CNPH*2417A** 313*AV024045 23,000 12.5 15.5
3632468 116BNA024****A CNPH*2417A** 315(A,J)AV036070 22,800 12.5 15.5
3632485 116BNA024****A CNPH*2417A** 315(A,J)AV048090 22,800 13.0 16.0
3632498 116BNA024****A CNPH*2417A** 315(A,J)AV060110 22,800 12.5 15.5
3632505 116BNA024****A CNPH*2417A** 315(A,J)AV066135 22,800 12.5 15.5
See notes on page 37
116B

14
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632511 116BNA024****A CNPH*2417A** 315(A,J)AV066155 22,800 12.5 15.5
3632647 116BNA024****A CNPH*2417A** 353(A,B)AV036040 23,200 13.0 16.0
3632663 116BNA024****A CNPH*2417A** 353(A,B)AV036060 23,200 13.0 16.0
3663515 116BNA024****A CNPH*2417A** 353AAV036040 23,200 13.0 16.0
3632525 116BNA024****A CNPH*2417A** 355(A,C)AV042060 23,000 12.5 15.5
3632538 116BNA024****A CNPH*2417A** 355(A,C)AV042080 22,800 12.5 15.5
3632546 116BNA024****A CNPH*2417A** 355(A,C)AV060080 22,600 12.5 15.5
3632554 116BNA024****A CNPH*2417A** 355(A,C)AV060100 22,800 12.5 15.5
3632561 116BNA024****A CNPH*2417A** 355(A,C)AV060120 23,000 13.0 16.0
3632567 116BNA024****A CNPH*2417A** 355AAV042040 22,800 12.5 15.5
3635393 116BNA024****A CNPH*2417A** 355BAV042060 23,000 12.5 15.5
3635406 116BNA024****A CNPH*2417A** 355BAV042080 22,800 12.5 15.5
3635414 116BNA024****A CNPH*2417A** 355BAV060080 22,600 12.5 15.5
3635422 116BNA024****A CNPH*2417A** 355BAV060100 22,800 12.5 15.5
3635429 116BNA024****A CNPH*2417A** 355BAV060120 23,000 13.0 16.0
3632602 116BNA024****A CNPH*2417A**+TDR 23,000 11.5 14.0
3632679 116BNA024****A CNPH*3017A** 353(A,B)AV036080 23,400 13.0 16.0
3632580 116BNA024****A CNPH*3017A** 313*AV024045 23,200 13.0 16.0
3632469 116BNA024****A CNPH*3017A** 315(A,J)AV036070 23,000 13.0 16.0
3632486 116BNA024****A CNPH*3017A** 315(A,J)AV048090 23,000 13.0 16.0
3632499 116BNA024****A CNPH*3017A** 315(A,J)AV060110 23,000 13.0 16.0
3632506 116BNA024****A CNPH*3017A** 315(A,J)AV066135 23,000 13.0 16.0
3632512 116BNA024****A CNPH*3017A** 315(A,J)AV066155 23,000 13.0 16.0
3632648 116BNA024****A CNPH*3017A** 353(A,B)AV036040 23,600 13.0 16.0
3632664 116BNA024****A CNPH*3017A** 353(A,B)AV036060 23,600 13.0 16.0
3663516 116BNA024****A CNPH*3017A** 353AAV036040 23,600 13.0 16.0
3632526 116BNA024****A CNPH*3017A** 355(A,C)AV042060 23,200 13.0 16.0
3632539 116BNA024****A CNPH*3017A** 355(A,C)AV042080 23,000 13.0 16.0
3632547 116BNA024****A CNPH*3017A** 355(A,C)AV060080 22,800 13.0 16.0
3632555 116BNA024****A CNPH*3017A** 355(A,C)AV060100 23,000 13.0 16.0
3632562 116BNA024****A CNPH*3017A** 355(A,C)AV060120 23,200 13.0 16.0
3632568 116BNA024****A CNPH*3017A** 355AAV042040 23,000 13.0 16.0
3635394 116BNA024****A CNPH*3017A** 355BAV042060 23,200 13.0 16.0
3635407 116BNA024****A CNPH*3017A** 355BAV042080 23,000 13.0 16.0
3635415 116BNA024****A CNPH*3017A** 355BAV060080 22,800 13.0 16.0
3635423 116BNA024****A CNPH*3017A** 355BAV060100 23,000 13.0 16.0
3635430 116BNA024****A CNPH*3017A** 355BAV060120 23,200 13.0 16.0
3632603 116BNA024****A CNPH*3017A**+TDR 23,200 11.5 14.0
3632680 116BNA024****A CNPH*3117A** 353(A,B)AV036080 24,000 13.0 16.0
3632581 116BNA024****A CNPH*3117A** 313*AV024045 23,800 13.0 16.0
3632470 116BNA024****A CNPH*3117A** 315(A,J)AV036070 23,400 13.0 16.0
3632487 116BNA024****A CNPH*3117A** 315(A,J)AV048090 23,400 13.0 16.0
3632500 116BNA024****A CNPH*3117A** 315(A,J)AV060110 23,400 13.0 16.0
3632507 116BNA024****A CNPH*3117A** 315(A,J)AV066135 23,400 13.0 16.0
3632513 116BNA024****A CNPH*3117A** 315(A,J)AV066155 23,400 13.0 16.0
3632649 116BNA024****A CNPH*3117A** 353(A,B)AV036040 24,000 13.0 16.0
3632665 116BNA024****A CNPH*3117A** 353(A,B)AV036060 24,000 13.0 16.0
3663517 116BNA024****A CNPH*3117A** 353AAV036040 24,000 13.0 16.0
3632527 116BNA024****A CNPH*3117A** 355(A,C)AV042060 23,800 13.0 16.0
3632540 116BNA024****A CNPH*3117A** 355(A,C)AV042080 23,400 13.0 16.0
3632548 116BNA024****A CNPH*3117A** 355(A,C)AV060080 23,200 13.0 16.0
3632556 116BNA024****A CNPH*3117A** 355(A,C)AV060100 23,400 13.0 16.0
3632563 116BNA024****A CNPH*3117A** 355(A,C)AV060120 23,600 13.0 16.0
3632569 116BNA024****A CNPH*3117A** 355AAV042040 23,400 13.0 16.0
3635395 116BNA024****A CNPH*3117A** 355BAV042060 23,800 13.0 16.0
3635408 116BNA024****A CNPH*3117A** 355BAV042080 23,400 13.0 16.0
3635416 116BNA024****A CNPH*3117A** 355BAV060080 23,200 13.0 16.0
3635424 116BNA024****A CNPH*3117A** 355BAV060100 23,400 13.0 16.0
3635431 116BNA024****A CNPH*3117A** 355BAV060120 23,600 13.0 16.0
3632604 116BNA024****A CNPH*3117A**+TDR 23,600 12.0 14.5
3632681 116BNA024****A CNPH*3617A** 353(A,B)AV036080 23,400 13.0 16.0
3632582 116BNA024****A CNPH*3617A** 313*AV024045 23,200 13.0 16.0
3632471 116BNA024****A CNPH*3617A** 315(A,J)AV036070 23,000 13.0 16.0
3632488 116BNA024****A CNPH*3617A** 315(A,J)AV048090 23,000 13.0 16.0
3632501 116BNA024****A CNPH*3617A** 315(A,J)AV060110 23,000 13.0 16.0
3632508 116BNA024****A CNPH*3617A** 315(A,J)AV066135 23,000 13.0 16.0
3632514 116BNA024****A CNPH*3617A** 315(A,J)AV066155 23,000 13.0 16.0
3632650 116BNA024****A CNPH*3617A** 353(A,B)AV036040 23,600 13.0 16.0
3632666 116BNA024****A CNPH*3617A** 353(A,B)AV036060 23,600 13.0 16.0
3663518 116BNA024****A CNPH*3617A** 353AAV036040 23,600 13.0 16.0
3632528 116BNA024****A CNPH*3617A** 355(A,C)AV042060 23,200 13.0 16.0
3632541 116BNA024****A CNPH*3617A** 355(A,C)AV042080 23,000 13.0 16.0
3632549 116BNA024****A CNPH*3617A** 355(A,C)AV060080 22,800 13.0 16.0
See notes on page 37
116B

15
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632557 116BNA024****A CNPH*3617A** 355(A,C)AV060100 23,000 13.0 16.0
3632564 116BNA024****A CNPH*3617A** 355(A,C)AV060120 23,200 13.0 16.0
3632570 116BNA024****A CNPH*3617A** 355AAV042040 23,000 13.0 16.0
3635396 116BNA024****A CNPH*3617A** 355BAV042060 23,200 13.0 16.0
3635409 116BNA024****A CNPH*3617A** 355BAV042080 23,000 13.0 16.0
3635417 116BNA024****A CNPH*3617A** 355BAV060080 22,800 13.0 16.0
3635425 116BNA024****A CNPH*3617A** 355BAV060100 23,000 13.0 16.0
3635432 116BNA024****A CNPH*3617A** 355BAV060120 23,200 13.0 16.0
3632605 116BNA024****A CNPH*3617A**+TDR 23,200 11.5 14.0
3632583 116BNA024****A CNPV*1917A** 313*AV024045 23,200 13.0 16.0
3632472 116BNA024****A CNPV*1917A** 315(A,J)AV036070 23,000 13.0 16.0
3632489 116BNA024****A CNPV*1917A** 315(A,J)AV048090 23,000 13.0 16.0
3632638 116BNA024****A CNPV*1917A** 353(A,B)AV036040 23,600 13.0 16.0
3632654 116BNA024****A CNPV*1917A** 353(A,B)AV036060 23,600 13.0 16.0
3663506 116BNA024****A CNPV*1917A** 353AAV036040 23,600 13.0 16.0
3632529 116BNA024****A CNPV*1917A** 355(A,C)AV042060 23,400 13.0 16.0
3635397 116BNA024****A CNPV*1917A** 355BAV042060 23,400 13.0 16.0
3632606 116BNA024****A CNPV*1917A**+TDR 23,200 11.5 14.0
3632584 116BNA024****A CNPV*2414A** 313*AV024045 23,000 12.5 15.5
3632473 116BNA024****A CNPV*2414A** 315(A,J)AV036070 22,800 12.5 15.5
3632607 116BNA024****A CNPV*2414A**+TDR 23,000 11.5 14.0
3632674 116BNA024****A CNPV*2417A** 353(A,B)AV036080 23,000 13.0 16.0
3632585 116BNA024****A CNPV*2417A** 313*AV024045 23,000 12.5 15.5
3632474 116BNA024****A CNPV*2417A** 315(A,J)AV036070 22,800 12.5 15.5
3632490 116BNA024****A CNPV*2417A** 315(A,J)AV048090 22,800 13.0 16.0
3632643 116BNA024****A CNPV*2417A** 353(A,B)AV036040 23,200 13.0 16.0
3632659 116BNA024****A CNPV*2417A** 353(A,B)AV036060 23,200 13.0 16.0
3663511 116BNA024****A CNPV*2417A** 353AAV036040 23,200 13.0 16.0
3632530 116BNA024****A CNPV*2417A** 355(A,C)AV042060 23,000 12.5 15.5
3635398 116BNA024****A CNPV*2417A** 355BAV042060 23,000 12.5 15.5
3632608 116BNA024****A CNPV*2417A**+TDR 23,000 11.5 14.0
3632586 116BNA024****A CNPV*3014A** 313*AV024045 23,200 12.5 15.5
3632475 116BNA024****A CNPV*3014A** 315(A,J)AV036070 23,000 13.0 16.0
3632609 116BNA024****A CNPV*3014A**+TDR 23,200 11.5 14.0
3632675 116BNA024****A CNPV*3017A** 353(A,B)AV036080 23,400 13.0 16.0
3632587 116BNA024****A CNPV*3017A** 313*AV024045 23,200 13.0 16.0
3632476 116BNA024****A CNPV*3017A** 315(A,J)AV036070 23,000 13.0 16.0
3632491 116BNA024****A CNPV*3017A** 315(A,J)AV048090 23,000 13.0 16.0
3632644 116BNA024****A CNPV*3017A** 353(A,B)AV036040 23,600 13.0 16.0
3632660 116BNA024****A CNPV*3017A** 353(A,B)AV036060 23,600 13.0 16.0
3663512 116BNA024****A CNPV*3017A** 353AAV036040 23,600 13.0 16.0
3632531 116BNA024****A CNPV*3017A** 355(A,C)AV042060 23,200 13.0 16.0
3635399 116BNA024****A CNPV*3017A** 355BAV042060 23,200 13.0 16.0
3632610 116BNA024****A CNPV*3017A**+TDR 23,200 11.5 14.0
3632669 116BNA024****A CNPV*3117A** 353(A,B)AV036080 24,000 13.0 16.0
3632588 116BNA024****A CNPV*3117A** 313*AV024045 23,800 13.0 16.0
3632477 116BNA024****A CNPV*3117A** 315(A,J)AV036070 23,400 13.0 16.0
3632492 116BNA024****A CNPV*3117A** 315(A,J)AV048090 23,400 13.0 16.0
3632637 116BNA024****A CNPV*3117A** 353(A,B)AV036040 24,000 13.0 16.0
3632653 116BNA024****A CNPV*3117A** 353(A,B)AV036060 24,000 13.0 16.0
3663505 116BNA024****A CNPV*3117A** 353AAV036040 24,000 13.0 16.0
3632532 116BNA024****A CNPV*3117A** 355(A,C)AV042060 23,800 13.0 16.0
3635400 116BNA024****A CNPV*3117A** 355BAV042060 23,800 13.0 16.0
3632676 116BNA024****A CNPV*3617A** 353(A,B)AV036080 23,400 13.0 16.0
3632589 116BNA024****A CNPV*3617A** 313*AV024045 23,200 13.0 16.0
3632478 116BNA024****A CNPV*3617A** 315(A,J)AV036070 23,000 13.0 16.0
3632493 116BNA024****A CNPV*3617A** 315(A,J)AV048090 23,000 13.0 16.0
3632645 116BNA024****A CNPV*3617A** 353(A,B)AV036040 23,600 13.0 16.0
3632661 116BNA024****A CNPV*3617A** 353(A,B)AV036060 23,600 13.0 16.0
3663513 116BNA024****A CNPV*3617A** 353AAV036040 23,600 13.0 16.0
3632533 116BNA024****A CNPV*3617A** 355(A,C)AV042060 23,200 13.0 16.0
3635401 116BNA024****A CNPV*3617A** 355BAV042060 23,200 13.0 16.0
3632612 116BNA024****A CNPV*3617A**+TDR 23,200 11.5 14.0
3632677 116BNA024****A CNPV*3621A** 353(A,B)AV036080 23,400 13.0 16.0
3632494 116BNA024****A CNPV*3621A** 315(A,J)AV048090 23,000 13.0 16.0
3632502 116BNA024****A CNPV*3621A** 315(A,J)AV060110 23,000 13.0 16.0
3632646 116BNA024****A CNPV*3621A** 353(A,B)AV036040 23,600 13.0 16.0
3632662 116BNA024****A CNPV*3621A** 353(A,B)AV036060 23,600 13.0 16.0
3663514 116BNA024****A CNPV*3621A** 353AAV036040 23,600 13.0 16.0
3632534 116BNA024****A CNPV*3621A** 355(A,C)AV042060 23,200 13.0 16.0
3632542 116BNA024****A CNPV*3621A** 355(A,C)AV042080 23,000 13.0 16.0
3632550 116BNA024****A CNPV*3621A** 355(A,C)AV060080 22,800 13.0 16.0
3632558 116BNA024****A CNPV*3621A** 355(A,C)AV060100 23,000 13.0 16.0
See notes on page 37
116B

16
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3635402 116BNA024****A CNPV*3621A** 355BAV042060 23,200 13.0 16.0
3635410 116BNA024****A CNPV*3621A** 355BAV042080 23,000 13.0 16.0
3635418 116BNA024****A CNPV*3621A** 355BAV060080 22,800 13.0 16.0
3635426 116BNA024****A CNPV*3621A** 355BAV060100 23,000 13.0 16.0
3632613 116BNA024****A CNPV*3621A**+TDR 23,200 11.5 14.0
3632518 116BNA024****A CSPH*2412A** 359BAV036040 23,200 12.8 15.2
3632520 116BNA024****A CSPH*2412A** 359BAV036060 23,200 12.8 15.2
3632614 116BNA024****A CSPH*2412A**+TDR 23,200 11.5 14.0
3632682 116BNA024****A CSPH*3012A** 353(A,B)AV036080 23,400 13.0 16.0
3632590 116BNA024****A CSPH*3012A** 313*AV024045 23,200 13.0 16.0
3632479 116BNA024****A CSPH*3012A** 315(A,J)AV036070 23,000 13.0 16.0
3632495 116BNA024****A CSPH*3012A** 315(A,J)AV048090 23,200 13.0 16.0
3632503 116BNA024****A CSPH*3012A** 315(A,J)AV060110 23,200 13.0 16.0
3632509 116BNA024****A CSPH*3012A** 315(A,J)AV066135 23,200 13.0 16.0
3632515 116BNA024****A CSPH*3012A** 315(A,J)AV066155 23,200 13.0 16.0
3632651 116BNA024****A CSPH*3012A** 353(A,B)AV036040 23,600 13.0 16.0
3632667 116BNA024****A CSPH*3012A** 353(A,B)AV036060 23,600 13.0 16.0
3663519 116BNA024****A CSPH*3012A** 353AAV036040 23,600 13.0 16.0
3632535 116BNA024****A CSPH*3012A** 355(A,C)AV042060 23,400 13.0 16.0
3632543 116BNA024****A CSPH*3012A** 355(A,C)AV042080 23,000 13.0 16.0
3632551 116BNA024****A CSPH*3012A** 355(A,C)AV060080 22,800 13.0 16.0
3632559 116BNA024****A CSPH*3012A** 355(A,C)AV060100 23,000 13.0 16.0
3632565 116BNA024****A CSPH*3012A** 355(A,C)AV060120 23,200 13.0 16.0
3632571 116BNA024****A CSPH*3012A** 355AAV042040 23,000 13.0 16.0
3635403 116BNA024****A CSPH*3012A** 355BAV042060 23,400 13.0 16.0
3635411 116BNA024****A CSPH*3012A** 355BAV042080 23,000 13.0 16.0
3635419 116BNA024****A CSPH*3012A** 355BAV060080 22,800 13.0 16.0
3635427 116BNA024****A CSPH*3012A** 355BAV060100 23,000 13.0 16.0
3635433 116BNA024****A CSPH*3012A** 355BAV060120 23,200 13.0 16.0
3632615 116BNA024****A CSPH*3012A**+TDR 23,200 11.5 14.0
3632683 116BNA024****A CSPH*3612A** 353(A,B)AV036080 23,800 13.0 16.0
3632591 116BNA024****A CSPH*3612A** 313*AV024045 23,600 13.0 16.0
3632480 116BNA024****A CSPH*3612A** 315(A,J)AV036070 23,400 13.0 16.0
3632496 116BNA024****A CSPH*3612A** 315(A,J)AV048090 23,400 13.0 16.0
3632504 116BNA024****A CSPH*3612A** 315(A,J)AV060110 23,400 13.0 16.0
3632510 116BNA024****A CSPH*3612A** 315(A,J)AV066135 23,400 13.0 16.0
3632516 116BNA024****A CSPH*3612A** 315(A,J)AV066155 23,400 13.0 16.0
3632652 116BNA024****A CSPH*3612A** 353(A,B)AV036040 24,000 13.0 16.0
3632668 116BNA024****A CSPH*3612A** 353(A,B)AV036060 24,000 13.0 16.0
3663520 116BNA024****A CSPH*3612A** 353AAV036040 24,000 13.0 16.0
3632536 116BNA024****A CSPH*3612A** 355(A,C)AV042060 23,800 13.0 16.0
3632544 116BNA024****A CSPH*3612A** 355(A,C)AV042080 23,400 13.0 16.0
3632552 116BNA024****A CSPH*3612A** 355(A,C)AV060080 23,200 13.0 16.0
3632560 116BNA024****A CSPH*3612A** 355(A,C)AV060100 23,400 13.0 16.0
3632566 116BNA024****A CSPH*3612A** 355(A,C)AV060120 23,600 13.0 16.0
3632572 116BNA024****A CSPH*3612A** 355AAV042040 23,400 13.0 16.0
3635404 116BNA024****A CSPH*3612A** 355BAV042060 23,800 13.0 16.0
3635412 116BNA024****A CSPH*3612A** 355BAV042080 23,400 13.0 16.0
3635420 116BNA024****A CSPH*3612A** 355BAV060080 23,200 13.0 16.0
3635428 116BNA024****A CSPH*3612A** 355BAV060100 23,400 13.0 16.0
3635434 116BNA024****A CSPH*3612A** 355BAV060120 23,600 13.0 16.0
3632616 116BNA024****A CSPH*3612A**+TDR 23,600 12.0 14.5
3632617 116BNA024****A FE4AN(B,F)003+UI 23,200 13.0 16.0
3632618 116BNA024****A FE4ANF002+UI 23,200 13.0 16.0
3632619 116BNA024****A FF1ENP024 22,800 11.5 13.5
3632620 116BNA024****A FF1ENP025 23,200 12.5 15.0
3632621 116BNA024****A FF1ENP030 22,800 11.5 13.5
3632622 116BNA024****A FF1ENP031 23,200 12.5 15.0
3632623 116BNA024****A FF1ENP036 23,000 11.0 13.5
3632624 116BNA024****A FF1ENP037 23,400 12.5 15.5
3632625 116BNA024****A FV4BN(B,F)003 23,200 13.0 16.0
3632626 116BNA024****A FV4BNF002 23,200 13.0 16.0
3632627 116BNA024****A FV4CN(B,F)003 23,200 13.0 16.0
3632628 116BNA024****A FV4CNF002 23,200 13.0 16.0
3632629 116BNA024****A FX4CN(B,F)036 23,200 12.0 14.5
3632630 116BNA024****A FX4CNF024 23,200 12.5 15.0
3632631 116BNA024****A FX4CNF030 23,400 13.0 16.0
3632632 116BNA024****A FX4DN(B,F)031 23,600 12.5 15.5
3632633 116BNA024****A FX4DNF025 23,400 13.0 16.0
3632634 116BNA024****A FY4ANF024 22,800 11.5 14.0
3632635 116BNA024****A FY4ANF030 23,000 12.0 14.5
3632636 116BNA024****A FY4ANF036 23,000 11.0 13.5
See notes on page 37
116B

17
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632864 116BNA030****A †CNPV*3117A**+TDR 28,600 12.0 14.5
3632684 116BNA030****A CAP**3014A** 315(A,J)AV036070 27,600 13.0 15.2
3632849 116BNA030****A CAP**3014A**+TDR 28,000 12.0 14.0
3632929 116BNA030****A CAP**3017A** 353(A,B)AV036080 28,000 13.0 16.0
3632946 116BNA030****A CAP**3017A** 353(A,B)AV048080 28,200 13.0 15.5
3632820 116BNA030****A CAP**3017A** 313*AV048070 28,000 12.5 15.0
3632685 116BNA030****A CAP**3017A** 315(A,J)AV036070 27,800 12.5 15.5
3632700 116BNA030****A CAP**3017A** 315(A,J)AV048090 27,800 13.0 16.0
3632895 116BNA030****A CAP**3017A** 353(A,B)AV036040 28,200 13.0 16.0
3632912 116BNA030****A CAP**3017A** 353(A,B)AV036060 28,200 13.0 15.5
3663522 116BNA030****A CAP**3017A** 353AAV036040 28,200 13.0 16.0
3632751 116BNA030****A CAP**3017A** 355(A,C)AV042060 28,000 13.0 15.5
3635437 116BNA030****A CAP**3017A** 355BAV042060 28,000 13.0 15.5
3632850 116BNA030****A CAP**3017A**+TDR 28,000 12.0 14.0
3632686 116BNA030****A CAP**3614A** 315(A,J)AV036070 27,800 12.5 15.5
3632851 116BNA030****A CAP**3614A**+TDR 28,000 12.0 14.0
3632930 116BNA030****A CAP**3617A** 353(A,B)AV036080 28,200 13.0 16.0
3632947 116BNA030****A CAP**3617A** 353(A,B)AV048080 28,400 13.0 16.0
3632821 116BNA030****A CAP**3617A** 313*AV048070 28,000 12.5 15.2
3632687 116BNA030****A CAP**3617A** 315(A,J)AV036070 27,800 12.5 15.5
3632701 116BNA030****A CAP**3617A** 315(A,J)AV048090 27,800 13.0 16.0
3632896 116BNA030****A CAP**3617A** 353(A,B)AV036040 28,200 13.0 16.0
3632913 116BNA030****A CAP**3617A** 353(A,B)AV036060 28,200 13.0 16.0
3663523 116BNA030****A CAP**3617A** 353AAV036040 28,200 13.0 16.0
3632752 116BNA030****A CAP**3617A** 355(A,C)AV042060 28,000 13.0 16.0
3635438 116BNA030****A CAP**3617A** 355BAV042060 28,000 13.0 16.0
3632852 116BNA030****A CAP**3617A**+TDR 28,000 12.0 14.0
3632745 116BNA030****A CAP**3619A** 359BAV036040 28,000 12.5 15.0
3632748 116BNA030****A CAP**3619A** 359BAV036060 28,200 12.5 15.2
3632853 116BNA030****A CAP**3619A**+TDR 28,000 11.5 14.0
3632931 116BNA030****A CAP**3621A** 353(A,B)AV036080 28,200 13.0 16.0
3632948 116BNA030****A CAP**3621A** 353(A,B)AV048080 28,400 13.0 16.0
3632822 116BNA030****A CAP**3621A** 313*AV048070 28,000 13.0 15.2
3632837 116BNA030****A CAP**3621A** 313*AV048090 28,200 13.0 16.0
3632702 116BNA030****A CAP**3621A** 315(A,J)AV048090 27,800 13.0 16.0
3632717 116BNA030****A CAP**3621A** 315(A,J)AV060110 27,800 13.0 16.0
3632897 116BNA030****A CAP**3621A** 353(A,B)AV036040 28,200 13.0 16.0
3632914 116BNA030****A CAP**3621A** 353(A,B)AV036060 28,200 13.0 16.0
3663524 116BNA030****A CAP**3621A** 353AAV036040 28,200 13.0 16.0
3632753 116BNA030****A CAP**3621A** 355(A,C)AV042060 28,200 13.0 16.0
3632768 116BNA030****A CAP**3621A** 355(A,C)AV042080 27,600 13.0 16.0
3632780 116BNA030****A CAP**3621A** 355(A,C)AV060080 27,800 13.0 16.0
3632792 116BNA030****A CAP**3621A** 355(A,C)AV060100 27,600 13.0 15.5
3635439 116BNA030****A CAP**3621A** 355BAV042060 28,200 13.0 16.0
3635454 116BNA030****A CAP**3621A** 355BAV042080 27,600 13.0 16.0
3635466 116BNA030****A CAP**3621A** 355BAV060080 27,800 13.0 16.0
3635478 116BNA030****A CAP**3621A** 355BAV060100 27,600 13.0 15.5
3632854 116BNA030****A CAP**3621A**+TDR 28,000 12.0 14.0
3632932 116BNA030****A CAP**4221A** 353(A,B)AV036080 28,400 13.0 16.0
3632949 116BNA030****A CAP**4221A** 353(A,B)AV048080 28,600 13.0 16.0
3632823 116BNA030****A CAP**4221A** 313*AV048070 28,200 12.5 15.5
3632838 116BNA030****A CAP**4221A** 313*AV048090 28,400 13.0 16.0
3632703 116BNA030****A CAP**4221A** 315(A,J)AV048090 28,000 13.0 16.0
3632718 116BNA030****A CAP**4221A** 315(A,J)AV060110 28,000 13.0 16.0
3632898 116BNA030****A CAP**4221A** 353(A,B)AV036040 28,400 13.0 16.0
3632915 116BNA030****A CAP**4221A** 353(A,B)AV036060 28,600 13.0 16.0
3663525 116BNA030****A CAP**4221A** 353AAV036040 28,400 13.0 16.0
3632754 116BNA030****A CAP**4221A** 355(A,C)AV042060 28,200 13.0 16.0
3632769 116BNA030****A CAP**4221A** 355(A,C)AV042080 28,000 13.0 16.0
3632781 116BNA030****A CAP**4221A** 355(A,C)AV060080 28,000 13.0 16.0
3632793 116BNA030****A CAP**4221A** 355(A,C)AV060100 27,800 13.0 16.0
3635440 116BNA030****A CAP**4221A** 355BAV042060 28,200 13.0 16.0
3635455 116BNA030****A CAP**4221A** 355BAV042080 28,000 13.0 16.0
3635467 116BNA030****A CAP**4221A** 355BAV060080 28,000 13.0 16.0
3635479 116BNA030****A CAP**4221A** 355BAV060100 27,800 13.0 16.0
3632855 116BNA030****A CAP**4221A**+TDR 28,200 11.5 14.0
3632839 116BNA030****A CAP**4224A** 313*AV048090 28,400 13.0 16.0
3632719 116BNA030****A CAP**4224A** 315(A,J)AV060110 28,200 13.0 16.0
3632729 116BNA030****A CAP**4224A** 315(A,J)AV066135 28,200 13.0 16.0
3632737 116BNA030****A CAP**4224A** 315(A,J)AV066155 28,200 13.0 16.0
3632770 116BNA030****A CAP**4224A** 355(A,C)AV042080 28,000 13.0 16.0
3632782 116BNA030****A CAP**4224A** 355(A,C)AV060080 28,000 13.0 16.0
3632794 116BNA030****A CAP**4224A** 355(A,C)AV060100 27,800 13.0 16.0
See notes on page 37
116B

18
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632804 116BNA030****A CAP**4224A** 355(A,C)AV060120 28,000 13.0 16.0
3632812 116BNA030****A CAP**4224A** 355AAV042040 28,000 13.0 16.0
3635456 116BNA030****A CAP**4224A** 355BAV042080 28,000 13.0 16.0
3635468 116BNA030****A CAP**4224A** 355BAV060080 28,000 13.0 16.0
3635480 116BNA030****A CAP**4224A** 355BAV060100 27,800 13.0 16.0
3635490 116BNA030****A CAP**4224A** 355BAV060120 28,000 13.0 16.0
3632856 116BNA030****A CAP**4224A**+TDR 28,200 11.5 14.0
3632857 116BNA030****A CNPF*3618A**+TDR 28,000 11.5 13.5
3632938 116BNA030****A CNPH*3017A** 353(A,B)AV036080 28,000 13.0 16.0
3632955 116BNA030****A CNPH*3017A** 353(A,B)AV048080 28,200 13.0 15.5
3632824 116BNA030****A CNPH*3017A** 313*AV048070 28,000 12.5 15.0
3632840 116BNA030****A CNPH*3017A** 313*AV048090 28,000 12.5 15.5
3632688 116BNA030****A CNPH*3017A** 315(A,J)AV036070 27,800 12.5 15.5
3632704 116BNA030****A CNPH*3017A** 315(A,J)AV048090 27,800 13.0 15.5
3632720 116BNA030****A CNPH*3017A** 315(A,J)AV060110 27,800 13.0 15.5
3632730 116BNA030****A CNPH*3017A** 315(A,J)AV066135 27,800 13.0 16.0
3632738 116BNA030****A CNPH*3017A** 315(A,J)AV066155 27,800 13.0 16.0
3632904 116BNA030****A CNPH*3017A** 353(A,B)AV036040 28,200 13.0 16.0
3632921 116BNA030****A CNPH*3017A** 353(A,B)AV036060 28,200 13.0 15.5
3663531 116BNA030****A CNPH*3017A** 353AAV036040 28,200 13.0 16.0
3632755 116BNA030****A CNPH*3017A** 355(A,C)AV042060 28,000 13.0 15.5
3632771 116BNA030****A CNPH*3017A** 355(A,C)AV042080 27,600 12.5 15.5
3632783 116BNA030****A CNPH*3017A** 355(A,C)AV060080 27,800 12.5 15.5
3632795 116BNA030****A CNPH*3017A** 355(A,C)AV060100 27,600 12.5 15.5
3632805 116BNA030****A CNPH*3017A** 355(A,C)AV060120 27,800 13.0 16.0
3632813 116BNA030****A CNPH*3017A** 355AAV042040 27,800 12.5 15.5
3635441 116BNA030****A CNPH*3017A** 355BAV042060 28,000 13.0 15.5
3635457 116BNA030****A CNPH*3017A** 355BAV042080 27,600 12.5 15.5
3635469 116BNA030****A CNPH*3017A** 355BAV060080 27,800 12.5 15.5
3635481 116BNA030****A CNPH*3017A** 355BAV060100 27,600 12.5 15.5
3635491 116BNA030****A CNPH*3017A** 355BAV060120 27,800 13.0 16.0
3632858 116BNA030****A CNPH*3017A**+TDR 28,000 12.0 14.0
3632939 116BNA030****A CNPH*3117A** 353(A,B)AV036080 28,800 13.0 16.0
3632956 116BNA030****A CNPH*3117A** 353(A,B)AV048080 29,000 13.0 16.0
3632825 116BNA030****A CNPH*3117A** 313*AV048070 28,600 13.0 16.0
3632841 116BNA030****A CNPH*3117A** 313*AV048090 28,600 13.0 16.0
3632689 116BNA030****A CNPH*3117A** 315(A,J)AV036070 28,400 13.0 16.0
3632705 116BNA030****A CNPH*3117A** 315(A,J)AV048090 28,400 13.0 16.0
3632721 116BNA030****A CNPH*3117A** 315(A,J)AV060110 28,400 13.0 16.0
3632731 116BNA030****A CNPH*3117A** 315(A,J)AV066135 28,400 13.0 16.0
3632739 116BNA030****A CNPH*3117A** 315(A,J)AV066155 28,400 13.0 16.0
3632905 116BNA030****A CNPH*3117A** 353(A,B)AV036040 28,800 13.0 16.0
3632922 116BNA030****A CNPH*3117A** 353(A,B)AV036060 28,800 13.0 16.0
3663532 116BNA030****A CNPH*3117A** 353AAV036040 28,800 13.0 16.0
3632756 116BNA030****A CNPH*3117A** 355(A,C)AV042060 28,600 13.0 16.0
3632772 116BNA030****A CNPH*3117A** 355(A,C)AV042080 28,200 13.0 16.0
3632784 116BNA030****A CNPH*3117A** 355(A,C)AV060080 28,400 13.0 16.0
3632796 116BNA030****A CNPH*3117A** 355(A,C)AV060100 28,200 13.0 16.0
3632806 116BNA030****A CNPH*3117A** 355(A,C)AV060120 28,400 13.0 16.0
3632814 116BNA030****A CNPH*3117A** 355AAV042040 28,400 13.0 16.0
3635442 116BNA030****A CNPH*3117A** 355BAV042060 28,600 13.0 16.0
3635458 116BNA030****A CNPH*3117A** 355BAV042080 28,200 13.0 16.0
3635470 116BNA030****A CNPH*3117A** 355BAV060080 28,400 13.0 16.0
3635482 116BNA030****A CNPH*3117A** 355BAV060100 28,200 13.0 16.0
3635492 116BNA030****A CNPH*3117A** 355BAV060120 28,400 13.0 16.0
3632859 116BNA030****A CNPH*3117A**+TDR 28,600 12.0 14.5
3632940 116BNA030****A CNPH*3617A** 353(A,B)AV036080 28,000 13.0 16.0
3632957 116BNA030****A CNPH*3617A** 353(A,B)AV048080 28,200 13.0 15.5
3632826 116BNA030****A CNPH*3617A** 313*AV048070 28,000 12.5 15.0
3632842 116BNA030****A CNPH*3617A** 313*AV048090 28,000 12.5 15.5
3632690 116BNA030****A CNPH*3617A** 315(A,J)AV036070 27,800 12.5 15.5
3632706 116BNA030****A CNPH*3617A** 315(A,J)AV048090 27,800 13.0 15.5
3632722 116BNA030****A CNPH*3617A** 315(A,J)AV060110 27,800 13.0 15.5
3632732 116BNA030****A CNPH*3617A** 315(A,J)AV066135 27,800 13.0 16.0
3632740 116BNA030****A CNPH*3617A** 315(A,J)AV066155 27,800 13.0 16.0
3632906 116BNA030****A CNPH*3617A** 353(A,B)AV036040 28,200 13.0 16.0
3632923 116BNA030****A CNPH*3617A** 353(A,B)AV036060 28,200 13.0 15.5
3663533 116BNA030****A CNPH*3617A** 353AAV036040 28,200 13.0 16.0
3632757 116BNA030****A CNPH*3617A** 355(A,C)AV042060 28,000 13.0 15.5
3632773 116BNA030****A CNPH*3617A** 355(A,C)AV042080 27,600 12.5 15.5
3632785 116BNA030****A CNPH*3617A** 355(A,C)AV060080 27,800 12.5 15.5
3632797 116BNA030****A CNPH*3617A** 355(A,C)AV060100 27,600 12.5 15.5
3632807 116BNA030****A CNPH*3617A** 355(A,C)AV060120 27,800 13.0 16.0
See notes on page 37
116B

19
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3632815 116BNA030****A CNPH*3617A** 355AAV042040 27,800 12.5 15.5
3635443 116BNA030****A CNPH*3617A** 355BAV042060 28,000 13.0 15.5
3635459 116BNA030****A CNPH*3617A** 355BAV042080 27,600 12.5 15.5
3635471 116BNA030****A CNPH*3617A** 355BAV060080 27,800 12.5 15.5
3635483 116BNA030****A CNPH*3617A** 355BAV060100 27,600 12.5 15.5
3635493 116BNA030****A CNPH*3617A** 355BAV060120 27,800 13.0 16.0
3632860 116BNA030****A CNPH*3617A**+TDR 28,000 12.0 14.0
3632941 116BNA030****A CNPH*4221A** 353(A,B)AV036080 28,400 13.0 16.0
3632958 116BNA030****A CNPH*4221A** 353(A,B)AV048080 28,600 13.0 16.0
3632827 116BNA030****A CNPH*4221A** 313*AV048070 28,200 12.5 15.5
3632843 116BNA030****A CNPH*4221A** 313*AV048090 28,400 13.0 16.0
3632691 116BNA030****A CNPH*4221A** 315(A,J)AV036070 28,000 13.0 15.5
3632707 116BNA030****A CNPH*4221A** 315(A,J)AV048090 28,000 13.0 16.0
3632723 116BNA030****A CNPH*4221A** 315(A,J)AV060110 28,200 13.0 16.0
3632733 116BNA030****A CNPH*4221A** 315(A,J)AV066135 28,200 13.0 16.0
3632741 116BNA030****A CNPH*4221A** 315(A,J)AV066155 28,200 13.0 16.0
3632907 116BNA030****A CNPH*4221A** 353(A,B)AV036040 28,400 13.0 16.0
3632924 116BNA030****A CNPH*4221A** 353(A,B)AV036060 28,400 13.0 16.0
3663534 116BNA030****A CNPH*4221A** 353AAV036040 28,400 13.0 16.0
3632758 116BNA030****A CNPH*4221A** 355(A,C)AV042060 28,200 13.0 16.0
3632774 116BNA030****A CNPH*4221A** 355(A,C)AV042080 28,000 13.0 15.5
3632786 116BNA030****A CNPH*4221A** 355(A,C)AV060080 28,000 13.0 16.0
3632798 116BNA030****A CNPH*4221A** 355(A,C)AV060100 27,800 13.0 15.5
3632808 116BNA030****A CNPH*4221A** 355(A,C)AV060120 28,200 13.0 16.0
3632816 116BNA030****A CNPH*4221A** 355AAV042040 28,000 13.0 15.5
3635444 116BNA030****A CNPH*4221A** 355BAV042060 28,200 13.0 16.0
3635460 116BNA030****A CNPH*4221A** 355BAV042080 28,000 13.0 15.5
3635472 116BNA030****A CNPH*4221A** 355BAV060080 28,000 13.0 16.0
3635484 116BNA030****A CNPH*4221A** 355BAV060100 27,800 13.0 15.5
3635494 116BNA030****A CNPH*4221A** 355BAV060120 28,200 13.0 16.0
3632861 116BNA030****A CNPH*4221A**+TDR 28,200 11.5 14.0
3632692 116BNA030****A CNPV*3014A** 315(A,J)AV036070 27,800 12.5 15.0
3632862 116BNA030****A CNPV*3014A**+TDR 28,000 12.0 14.0
3632933 116BNA030****A CNPV*3017A** 353(A,B)AV036080 28,000 13.0 16.0
3632950 116BNA030****A CNPV*3017A** 353(A,B)AV048080 28,200 13.0 15.5
3632828 116BNA030****A CNPV*3017A** 313*AV048070 28,000 12.5 15.0
3632693 116BNA030****A CNPV*3017A** 315(A,J)AV036070 27,800 12.5 15.5
3632708 116BNA030****A CNPV*3017A** 315(A,J)AV048090 27,800 13.0 15.5
3632899 116BNA030****A CNPV*3017A** 353(A,B)AV036040 28,200 13.0 16.0
3632916 116BNA030****A CNPV*3017A** 353(A,B)AV036060 28,200 13.0 15.5
3663526 116BNA030****A CNPV*3017A** 353AAV036040 28,200 13.0 16.0
3632759 116BNA030****A CNPV*3017A** 355(A,C)AV042060 28,000 13.0 15.5
3635445 116BNA030****A CNPV*3017A** 355BAV042060 28,000 13.0 15.5
3632863 116BNA030****A CNPV*3017A**+TDR 28,000 12.0 14.0
3632928 116BNA030****A CNPV*3117A** 353(A,B)AV036080 28,800 13.0 16.0
3632945 116BNA030****A CNPV*3117A** 353(A,B)AV048080 29,000 13.0 16.0
3632829 116BNA030****A CNPV*3117A** 313*AV048070 28,600 13.0 16.0
3632694 116BNA030****A CNPV*3117A** 315(A,J)AV036070 28,400 13.0 16.0
3632709 116BNA030****A CNPV*3117A** 315(A,J)AV048090 28,400 13.0 16.0
3632894 116BNA030****A CNPV*3117A** 353(A,B)AV036040 28,800 13.0 16.0
3632911 116BNA030****A CNPV*3117A** 353(A,B)AV036060 28,800 13.0 16.0
3663521 116BNA030****A CNPV*3117A** 353AAV036040 28,800 13.0 16.0
3632760 116BNA030****A CNPV*3117A** 355(A,C)AV042060 28,600 13.0 16.0
3635446 116BNA030****A CNPV*3117A** 355BAV042060 28,600 13.0 16.0
3632934 116BNA030****A CNPV*3617A** 353(A,B)AV036080 28,000 13.0 16.0
3632951 116BNA030****A CNPV*3617A** 353(A,B)AV048080 28,200 13.0 15.5
3632830 116BNA030****A CNPV*3617A** 313*AV048070 28,000 12.5 15.0
3632695 116BNA030****A CNPV*3617A** 315(A,J)AV036070 27,800 12.5 15.5
3632710 116BNA030****A CNPV*3617A** 315(A,J)AV048090 27,800 13.0 15.5
3632900 116BNA030****A CNPV*3617A** 353(A,B)AV036040 28,200 13.0 16.0
3632917 116BNA030****A CNPV*3617A** 353(A,B)AV036060 28,200 13.0 15.5
3663527 116BNA030****A CNPV*3617A** 353AAV036040 28,200 13.0 16.0
3632761 116BNA030****A CNPV*3617A** 355(A,C)AV042060 28,000 13.0 15.5
3635447 116BNA030****A CNPV*3617A** 355BAV042060 28,000 13.0 15.5
3632865 116BNA030****A CNPV*3617A**+TDR 28,000 12.0 14.0
3632935 116BNA030****A CNPV*3621A** 353(A,B)AV036080 28,000 13.0 16.0
3632952 116BNA030****A CNPV*3621A** 353(A,B)AV048080 28,200 13.0 15.5
3632831 116BNA030****A CNPV*3621A** 313*AV048070 28,000 12.5 15.0
3632844 116BNA030****A CNPV*3621A** 313*AV048090 28,000 12.5 15.5
3632711 116BNA030****A CNPV*3621A** 315(A,J)AV048090 27,800 13.0 16.0
3632724 116BNA030****A CNPV*3621A** 315(A,J)AV060110 27,800 13.0 15.5
3632901 116BNA030****A CNPV*3621A** 353(A,B)AV036040 28,200 13.0 16.0
3632918 116BNA030****A CNPV*3621A** 353(A,B)AV036060 28,200 13.0 15.5
See notes on page 37
116B

20
COMBINATION RATINGS CONTINUED
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3663528 116BNA030****A CNPV*3621A** 353AAV036040 28,200 13.0 16.0
3632762 116BNA030****A CNPV*3621A** 355(A,C)AV042060 28,000 13.0 15.5
3632775 116BNA030****A CNPV*3621A** 355(A,C)AV042080 27,600 12.5 15.5
3632787 116BNA030****A CNPV*3621A** 355(A,C)AV060080 27,800 12.5 15.5
3632799 116BNA030****A CNPV*3621A** 355(A,C)AV060100 27,600 12.5 15.5
3635448 116BNA030****A CNPV*3621A** 355BAV042060 28,000 13.0 15.5
3635461 116BNA030****A CNPV*3621A** 355BAV042080 27,600 12.5 15.5
3635473 116BNA030****A CNPV*3621A** 355BAV060080 27,800 12.5 15.5
3635485 116BNA030****A CNPV*3621A** 355BAV060100 27,600 12.5 15.5
3632866 116BNA030****A CNPV*3621A**+TDR 28,000 12.0 14.0
3632936 116BNA030****A CNPV*4217A** 353(A,B)AV036080 28,600 13.0 16.0
3632953 116BNA030****A CNPV*4217A** 353(A,B)AV048080 28,800 13.0 16.0
3632832 116BNA030****A CNPV*4217A** 313*AV048070 28,400 13.0 15.5
3632696 116BNA030****A CNPV*4217A** 315(A,J)AV036070 28,200 13.0 16.0
3632712 116BNA030****A CNPV*4217A** 315(A,J)AV048090 28,200 13.0 16.0
3632902 116BNA030****A CNPV*4217A** 353(A,B)AV036040 28,600 13.0 16.0
3632919 116BNA030****A CNPV*4217A** 353(A,B)AV036060 28,600 13.0 16.0
3663529 116BNA030****A CNPV*4217A** 353AAV036040 28,600 13.0 16.0
3632763 116BNA030****A CNPV*4217A** 355(A,C)AV042060 28,400 13.0 16.0
3635449 116BNA030****A CNPV*4217A** 355BAV042060 28,400 13.0 16.0
3632867 116BNA030****A CNPV*4217A**+TDR 28,400 11.5 14.0
3632937 116BNA030****A CNPV*4221A** 353(A,B)AV036080 28,400 13.0 16.0
3632954 116BNA030****A CNPV*4221A** 353(A,B)AV048080 28,600 13.0 16.0
3632833 116BNA030****A CNPV*4221A** 313*AV048070 28,200 12.5 15.5
3632845 116BNA030****A CNPV*4221A** 313*AV048090 28,400 13.0 16.0
3632713 116BNA030****A CNPV*4221A** 315(A,J)AV048090 28,000 13.0 16.0
3632725 116BNA030****A CNPV*4221A** 315(A,J)AV060110 28,200 13.0 16.0
3632903 116BNA030****A CNPV*4221A** 353(A,B)AV036040 28,400 13.0 16.0
3632920 116BNA030****A CNPV*4221A** 353(A,B)AV036060 28,400 13.0 16.0
3663530 116BNA030****A CNPV*4221A** 353AAV036040 28,400 13.0 16.0
3632764 116BNA030****A CNPV*4221A** 355(A,C)AV042060 28,200 13.0 16.0
3632776 116BNA030****A CNPV*4221A** 355(A,C)AV042080 28,000 13.0 15.5
3632788 116BNA030****A CNPV*4221A** 355(A,C)AV060080 28,000 13.0 16.0
3632800 116BNA030****A CNPV*4221A** 355(A,C)AV060100 27,800 13.0 15.5
3635450 116BNA030****A CNPV*4221A** 355BAV042060 28,200 13.0 16.0
3635462 116BNA030****A CNPV*4221A** 355BAV042080 28,000 13.0 15.5
3635474 116BNA030****A CNPV*4221A** 355BAV060080 28,000 13.0 16.0
3635486 116BNA030****A CNPV*4221A** 355BAV060100 27,800 13.0 15.5
3632868 116BNA030****A CNPV*4221A**+TDR 28,200 11.5 14.0
3632942 116BNA030****A CSPH*3012A** 353(A,B)AV036080 28,200 13.0 15.5
3632959 116BNA030****A CSPH*3012A** 353(A,B)AV048080 28,200 13.0 15.5
3632834 116BNA030****A CSPH*3012A** 313*AV048070 28,000 12.5 15.0
3632846 116BNA030****A CSPH*3012A** 313*AV048090 28,000 12.5 15.5
3632697 116BNA030****A CSPH*3012A** 315(A,J)AV036070 27,800 12.5 15.5
3632714 116BNA030****A CSPH*3012A** 315(A,J)AV048090 28,000 13.0 15.5
3632726 116BNA030****A CSPH*3012A** 315(A,J)AV060110 28,000 13.0 15.5
3632734 116BNA030****A CSPH*3012A** 315(A,J)AV066135 28,000 13.0 15.5
3632742 116BNA030****A CSPH*3012A** 315(A,J)AV066155 28,000 13.0 16.0
3632908 116BNA030****A CSPH*3012A** 353(A,B)AV036040 28,200 13.0 16.0
3632925 116BNA030****A CSPH*3012A** 353(A,B)AV036060 28,200 13.0 15.5
3663535 116BNA030****A CSPH*3012A** 353AAV036040 28,200 13.0 16.0
3632765 116BNA030****A CSPH*3012A** 355(A,C)AV042060 28,000 13.0 15.5
3632777 116BNA030****A CSPH*3012A** 355(A,C)AV042080 27,800 12.5 15.5
3632789 116BNA030****A CSPH*3012A** 355(A,C)AV060080 28,000 12.5 15.5
3632801 116BNA030****A CSPH*3012A** 355(A,C)AV060100 27,600 12.5 15.5
3632809 116BNA030****A CSPH*3012A** 355(A,C)AV060120 28,000 13.0 15.5
3632817 116BNA030****A CSPH*3012A** 355AAV042040 27,800 12.5 15.0
3635451 116BNA030****A CSPH*3012A** 355BAV042060 28,000 13.0 15.5
3635463 116BNA030****A CSPH*3012A** 355BAV042080 27,800 12.5 15.5
3635475 116BNA030****A CSPH*3012A** 355BAV060080 28,000 12.5 15.5
3635487 116BNA030****A CSPH*3012A** 355BAV060100 27,600 12.5 15.5
3635495 116BNA030****A CSPH*3012A** 355BAV060120 28,000 13.0 15.5
3632746 116BNA030****A CSPH*3012A** 359BAV036040 27,800 12.5 14.5
3632749 116BNA030****A CSPH*3012A** 359BAV036060 28,000 12.5 15.0
3632869 116BNA030****A CSPH*3012A**+TDR 28,200 11.5 14.0
3632943 116BNA030****A CSPH*3612A** 353(A,B)AV036080 28,600 13.0 16.0
3632960 116BNA030****A CSPH*3612A** 353(A,B)AV048080 28,800 13.0 16.0
3632835 116BNA030****A CSPH*3612A** 313*AV048070 28,600 13.0 15.5
3632847 116BNA030****A CSPH*3612A** 313*AV048090 28,600 13.0 16.0
3632698 116BNA030****A CSPH*3612A** 315(A,J)AV036070 28,200 13.0 16.0
3632715 116BNA030****A CSPH*3612A** 315(A,J)AV048090 28,400 13.0 16.0
3632727 116BNA030****A CSPH*3612A** 315(A,J)AV060110 28,400 13.0 16.0
3632735 116BNA030****A CSPH*3612A** 315(A,J)AV066135 28,400 13.0 16.0
See notes on page 37
116B
