Product Data
582J
LEGACY LINE™
SINGLE PACKAGED ROOFTOP 14 SEER
GAS HEAT/ELECTRIC COOLING
3 to 5 NOMINAL TONS

2
TABLE OF CONTENTS
PAGE
FEATURES/BENEFITS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
MODEL NUMBER NOMENCLATURE . . . . . . . . . . . . . . . 4
AHRI CAPACITY RATINGS . . . . . . . . . . . . . . . . . . . . . . . . 5
PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPTIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . 11
BASE UNIT DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . 15
PAGE
APPLICATION DATA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PERFORMANCE DATA. . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . .44
GUIDE SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . .47
The Bryant rooftop unit (RTU) was designed by customers for customers. With “no-strip screw” collars, handled access panels, and
more, we’ve made your unit easy to install, easy to maintain and easy to use.
Easy to install:
All Legacy Line™ units are field-convertible to horizontal air flow, which makes it easy to adjust to unexpected job site complica-
tions. Lighter units make easy replacement. Bryant 582J rooftops fit on existing Bryant curbs dating back to 1989. Also, our large
control box gives you room to work and room to mount Bryant accessory controls.
Easy to maintain:
Easy access handles by Bryant provide quick and easy access to all normally serviced components. Our “no-strip” screw system has
superior holding power and guides screws into position while preventing the screw from stripping the unit’s metal. Take accurate
pressure readings by reading condenser pressure with panels on. Simply remove the black, composite plug, route your gage line(s)
through the hole, and connect them to the refrigeration service valve(s).
Easy to use:
The newly designed central terminal board by Bryant puts all your connections and troubleshooting points in one convenient place,
standard. Most low voltage connections are made to the same board, which makes it easy to find what you’re looking for and easy
to access it. Bryant rooftops have high and low pressure switches, a filter drier, and 2-in. (51mm) filters standard.

3
Key features
• Single cooling stage models are available from 3-5 tons.
• SEERs up to 14.1.
• EERs up to 12.0.
• Up to 28% lighter than similar industry units. Lighter rooftop units make for easier replacement jobs.
• Utility connections are the same because 3-5 ton units fit on existing Bryant rooftop curbs. This saves time and money on replace-
ment jobs.
• Standardized components and layout. Standardized components and controls make service and stocking parts easier.
• Scroll compressors on all units. This makes service, stocking parts, replacement, and troubleshooting easier.
• Field-convertible airflow. Being able to convert a unit from vertical airflow to horizontal makes it easy to overcome job site com-
plications.
• Standard Direct Drive - ECM indoor motor with optional belt drive system to meet nearly all applications.
• Provisions for bottom or side condensate drain.
• Capable of thru-the-base or thru-the-curb gas line routing.
• Single-point gas/electrical connection.
• Sloped, composite drain pan sheds water and won’t rust.
• Standardized controls and control box layout. Standardized components and controls make stocking parts and service easier.
• Tool-less filter access door.
• Clean, large, easy to use control box.
• Color-coded wiring.
• Large, laminated wiring and power wiring drawings are affixed to unit, making troubleshooting easy.
• Single, central terminal board for test and wiring connections.
• Fast-access, handled, panels for easy access on normally accessed service panels.
• “No-strip” screw system guides screws into the panel and captures them tightly without stripping the screw, the panel, or the unit.
• Mechanical cooling (115°F to 40°F or 46°C to 4°C) standard on all models. Winter Start Kit allows cooling operation down to
25°F (–4°C) and Motormaster®to –20°F (–29°C).
• High efficiency gas heat with induced-draft flue exhaust design.
• Induced draft motor ensures no flue gas can escape into the indoor air stream.
• Bryant-designed naturally draining heat exchanger, unlike positive pressure heat exchangers, do not need to be periodically, man-
ually drained. This saves labor and maintenance expense.
• 2-in. (51mm) disposable filters on all units.
• Refrigerant filter-drier on each circuit.
• Each circuit is protected with a high pressure and low pressure switch.
• Many factory-installed options ranging from air management economizers, 2 position dampers, plus convenience outlets, discon-
nect switches and smoke detectors.
• Standard (parts only) Warranty: 15 yr. Stainless steel, 10 yr. aluminized heat exchanger, 5 yr. compressor, 1 yr. parts.
• Factory-installed Perfect Humidity™dehumidification system on all sizes with round tube/plate fin condenser coils, includes
Motormaster®I controller.
FEATURES/BENEFITS

4
\
Model
J - Puron®(R-410A) Refrigerant
Unit Type
582 - Gas Heat RTU, Legacy Series
Packaging and Control
A = Standard Packaging, electro-mechanical
controls that require W7212 EconoMi$er
®
IV
B = LTL Packaging , electro-mechanical
controls that require W7212 EconoMi$er IV
C = Standard Packaging, electro-mechanical
controls that require W7220 EconoMi$er X
F = LTL Packaging, electro-mechanical
controls that require W7220 EconoMi$er X
Cooling Tons
04 - 3 tons
05 - 4 tons
06 - 5 tons
Heat Level Input
Standard / Stainless Steel
072 = 72,000
115 = 115,000
150 = 150,000
Low NOx
060 = 60,000
090 = 90,000
120 = 120,000
Indoor Fan Options
0 = Direct Drive ECM
2 = Medium Static Option
3 = High Static Option
Refrig. System/Gas Heat Options
A = Standard One Stage cooling models/Nat. Gas Heat
B = Standard One Stage cooling models/Low NOxHeat
C = Standard One Stage cooling models/SS HX Heat
G = One-Stage cooling models/Alum Heat Exchanger
with Perfect Humidity™
H = One-Stage cooling models/Low NOxHeat
with Perfect Humidity
J = One-Stage cooling models/Stainless Steel Exchanger
with Perfect Humidity
Coil Options (RTPF) (Outdoor - Indoor - Hail Guard)
A = Al/Cu - Al/Cu
B = Precoat Al/Cu - Al/Cu
C = E-coat Al/Cu - Al/Cu
D = E-coat Al/Cu - E-coat Al/Cu
E = Cu/Cu - Al/Cu
F = Cu/Cu - Cu/Cu
M = Al/Cu -Al/Cu — Louvered Hail Guard
N = Precoat Al/Cu - Al/Cu — Louvered Hail Guard
P = E-coat Al/Cu - Al/Cu — Louvered Hail Guard
Q = E-coat Al/Cu - E-coat Al/Cu — Louvered Hail Guard
R = Cu/Cu - Al/Cu — Louvered Hail Guard
S = Cu/Cu - Cu/Cu — Louvered Hail Guard
Voltage
E = 460-3-60
J = 208/230-1-60
P = 208/230-3-60
T = 575-3-60
Outdoor Air Options
A = None
B = Temperature Economizer, Barometric Relief,
Standard Leak (W7212 or W7220)
E = Temperature Economizer, Barometric Relief,
Standard Leak w/CO2 (W7212 or W7220)
H =
Enthalpy Economizer, Barometric Relief,
Standard Leak (W7212 or W7220)
L =
Enthalpy Economizer, Barometric Relief,
Standard Leak w/CO2 (W7212 or W7220)
Q = Motorized 2 Position Damper
U = Temperature
Economizer, Barometric Relief,
Ultra Low Leak (W7220)
W= Enthalpy Economizer, Barometric Relief, Ultra Low Leak
(W7220)
Example:
Position:
582JE06A072A0B0A A
123456789
10 11 12 13 14 15 16
17
Factory Installed Options
0A = None
NOTE: See the 582J 3 to 5 ton Price Pages
for a complete list of factory installed
options.
Note: On single phase(-J) voltage code) models, the
following are not available as a factory installed option:
- Perfect Humidity
- Coated Coils or Cu Fin Coils
- Louvered Hail Guards
- Economizer or 2 Position Damper
- Powered 115 Volt Convenience Outlet
For California Residents:
For installation in SCAQMD only: This furnace does not meet the SCAQMD Rule 1111 14 ng/J
NOx emission limit, and thus is subject to a mitigation fee of up to $450. This furnace is not
eligible for the Clean Air Furnace Rebate Program: www.CleanAirFurnaceRebate.com.
MODEL NUMBER NOMENCLATURE

5
LEGEND NOTES:
1. Rated in accordance with AHRI Standard 210/240.
2. Ratings are based on:
Cooling Standard: 80°F (27°C) db, 67°F (19°C) wb indoor air tempera-
ture and 95°F (35°C) db outdoor air temperature.
3. All 582J units comply with ASHRAE 90.1 and Department of Energy
(DOE) Energy Standard for minimum SEER and EER requirements.
4. All 582J units comply with US Energy Policy Act (2005). To evaluate
code compliance requirements, refer to state and local codes.
NOTES:
1. Heat ratings are for natural gas heat exchangers operated at or below
2000 ft (610 m). For information on propane or altitudes above 2000 ft
(610 m), see the Application Data section of this book. Accessory Pro-
pane/High Altitude kits are also available.
2. In the USA, the input rating for altitudes above 2000 ft (610 m) must be
de-rated by 4% for each 1000 ft (305 m) above sea level. In Canada, the
input rating must be de-rated by 10% for altitudes of 2000 ft (610) to
4500 ft (1372 m) above sea level.
AHRI COOLING RATING TABLE
UNIT COOLING STAGES NOM. CAPACITY
(TONS)
NET COOLING
CAPACITY (MHBH)
TOTAL POWER
(kW) SEER EER
582J*04 1 3 35.4 3.0 14.0 12.00
582J*05 1 4 47.5 4.0 14.0 12.00
582J*06 1 5 58.5 4.9 14.1 12.00
AHRI — Air-Conditioning, Heating, and Refrigeration Institute Test
Standard
ASHRAE — American Society of Heating, Refrigerating, and Air-Condition-
ing Engineers
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
®
CS
HEATING RATING TABLE - NATURAL GAS AND PROPANE
582J UNITS GAS HEAT
AL/SS HEAT EXCHANGER TEMP RISE
(DEG F) THERMAL EFFICIENCY (%) AFUE (%)
INPUT/OUTPUT
STAGE 1 (MBH)
INPUT/OUTPUT
STAGE 2 (MBH)
SINGLE
PHASE
04
LOW – 65/53 25-55 82.0% 81.0%
MED – 90/73.5 45-85 82.0% 81.2%
HIGH – – – – –
05
LOW – 65/53 20-55 82.0% 81.0%
MED – 90/73.5 30-65 82.0% 81.2%
HIGH – 130/106 45-80 82.0% 81.0%
06
LOW – 65/53 15-55 82.0% 81.0%
MED – 90/73.5 25-65 82.0% 81.2%
HIGH – 130/106 35-80 82.0% 81.0%
THREE
PHASE
04
LOW – 72/59 25-55 82.0% N/A
MED 82/66 115/93 55-85 81.0% N/A
HIGH – – – – –
05
LOW – 72/59 25-55 82.0% N/A
MED – 115/93 35-65 81.0% N/A
HIGH 120/96 150/120 50-80 80.0% N/A
06
LOW – 72/59 20-55 82.0% N/A
MED – 115/93 30-65 81.0% N/A
HIGH 120/96 150/120 40-80 80.0% N/A
AHRI CAPACITY RATINGS

6
— – Not applicable. NOTE: Units meet California’s South Coast Air Quality Management District
(SCQAQMD) Low - NOXemissions requirement of 40 nanograms per joule or
less.
LEGEND
dB – Decibel
NOTES:
1. Outdoor sound data is measured in accordance with AHRI standard 270.
2. Measurements are expressed in terms of sound power. Do not compare these
values to sound pressure values because sound pressure depends on specific
environmental factors which normally do match individual applications. Sound
power values are independent of the environment and therefore more accurate.
3. A-weighted sound ratings filter out very high and very low frequencies, to
better approximate the response of the “average” human ear. A-weighted mea-
surement for Bryant units are taken in accordance with AHRI standard 270.
HEATING RATING TABLE – LOW NOX(see note)
582J UNIT GAS HEAT
LOW NOXHEAT EXCHANGER TEMP RISE
(DEG F)
THERMAL
EFFICIENCY (%) AFUE (%)
INPUT/OUTPUT
STAGE 1 (MBH)
INPUT/OUTPUT
STAGE 2 (MBH)
SINGLE/THREE PHASE
04
LOW — 60/49 20–50 82.0% 81.3%
MED — 90/73.5 30–60 82.0% 81.5%
HIGH — — — — —
05
LOW — 60/49 20–50 82.0% 81.3%
MED — 90/73.5 30–60 82.0% 81.5%
HIGH — 120/98 40–70 82.0% 81.3%
06
LOW — 60/49 15–50 82.0% 81.3%
MED — 90/73.5 25–60 82.0% 81.5%
HIGH — 120/98 35–70 82.0% 81.3%
SOUND PERFORMANCE TABLE
582J UNIT COOLING
STAGES
OUTDOOR SOUND (dB) AT 60 Hz
A–WEIGHTED 63 125 250 500 1000 2000 4000 8000
04 A 1 76 78.2 78.0 74.2 73.3 70.6 66.0 62.4 56.9
05 A 1 81 90.9 84.6 79.5 77.9 76.5 71.1 66.9 62.5
06 A 1 77 87.5 82.5 76.1 73.6 71.3 67.1 64.1 60.0
MINIMUM - MAXIMUM AIRFLOW RATINGS–NATURAL GAS AND PROPANE
VOLTAGE UNIT HEAT LEVEL COOLING AL HX HEATING SS HX HEATING
MINIMUM MAXIMUM MINIMUM MAXIMUM MINIMUM MAXIMUM
SINGLE
PHASE
582J*04
LOW
900 1500
900 1970 900 1970
MED 800 1520 800 1520
HIGH ————
582J*05
LOW
1200 2000
900 2470 900 2470
MED 1050 2280 1050 2280
HIGH 1230 2190 1230 2190
582J*06
LOW
1500 2500
900 3290 900 3290
MED 1050 2730 1050 2730
HIGH 1230 2820 1230 2820
THREE
PHASE
582J*04
LOW
900 1500
990 2190 990 2190
MED 1010 1570 1010 1570
HIGH ————
582J*05
LOW
1200 2000
990 2190 990 2190
MED 1330 2460 1330 2460
HIGH 1390 2220 1390 2220
582J*06
LOW
1500 2500
990 2730 990 2730
MED 1330 2880 1330 2880
HIGH 1390 2780 1390 2780
AHRI CAPACITY RATINGS (cont)

7
PHYSICAL DATA (COOLING) 3-5 TONS
582J*04A/B 582J*05A/B 582J*06A/B
REFERIGERATION SYSTEM
# Circuits / # Comp. / Type 1 / 1 / Scroll 1 / 1 / Scroll 1 / 1 / Scroll
Puron®refrig. (R-410A) A 1 phase (lbs-oz) 7-2 10-8 16-0
Puron®refrig. (R-410A) A 3 phase (lbs-oz) 7-2 10-8 14-8
Perfect Humidity™ Puron®refrig. (R-410A) charge A (lbs-oz) 10-6 15-5 26-0
oil A/B (oz) 25 42 42
Metering Device Acutrol Acutrol Acutrol
Perfect Humidity Metering Device Acutrol + TXV Acutrol + TXV Acutrol + TXV
High-press. Trip / Reset (psig) 630/505 630/505 630/505
Low-press. Trip / Reset (psig) 54/117 54/117 54/117
Loss of charge Trip/Reset (psig) N/A N/A N/A
EVAPORATION COIL
Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type 3/8-in. RTPF 3/8-in. RTPF 3/8-in. RTPF
Rows / FPI 3 / 15 3 / 15 4 / 15
Total Face Area (ft2) 5.5 5.5 7.3
Condensate Drain Conn. Size 3/4-in. 3/4-in. 3/4-in.
PERFECT HUMIDITY COIL
Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type 3/8-in. RTPF 3/8-in. RTPF 3/8-in. RTPF
Rows / FPI 1 / 17 2 / 17 2 / 17
Total Face Area (ft2) 3.9 3.9 5.2
EVAP. FAN AND MOTOR
STANDARD STATIC
1 PHASE
Motor Qty / Drive Type 1 / Direct 1 / Direct 1 / Direct
MaxBHP111
RPM Range 600-1200 600-1200 600-1200
Motor Frame Size 48 48 48
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
MEDIUM STATIC
1 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 1.2 1.2 1.5
RPM Range 770-1175 770-1175 1035-1466
Motor Frame Size 48 48 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
HIGH STATIC
1 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt N/A
Max BHP 1.5 1.5 N/A
RPM Range 1035-1466 1035-1466 N/A
Motor Frame Size 56 56 N/A
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal N/A
Fan Diameter (in.) 10 x 10 10 x 10 N/A
STANDARD STATIC
3 PHASE
Motor Qty / Drive Type 1 / Direct 1 / Direct 1 / Direct
MaxBHP111
RPM Range 600-1200 600-1200 600-1200
Motor Frame Size 48 48 48
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 11 x 10
MEDIUM STATIC
3 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 1.7 1.7 2.9
RPM Range 770-1175 920-1303 1035-1466
Motor Frame Size 48 56 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
HIGH STATIC
3 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 2.9 2.9 2.9
RPM Range 1035-1466 1208-1550 1303-1550
Motor Frame Size 56 56 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
PHYSICAL DATA

8
N/A – Not applicable
COND. COIL
1 phase Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type 3/8-in. RTPF 3/8-in. RTPF 3/8-in. RTPF
Rows / FPI 1 / 17 2 / 17 2 / 17
Total Face Area (ft2) 16.5 16.5 21.3
3 phase Material (Tube/Fin)
Coil Type 3/8-in. RTPF 3/8-in. RTPF 3/8-in. RTPF
Rows / FPI 1/17 2/17 2/17
Total Face Area (ft2) 16.5 14.6 18.8
COND. FAN / MOTOR
Qty / Motor Drive Type 1 / Direct 1 / Direct 1 / Direct
Motor HP / RPM 1 / 8 / 825 1 / 4 / 1100 1 / 4 / 1100
Fan diameter (in.) 22 22 22
FILTERS
RA Filter # / Size (in.) 2 / 16 x 25 x 2 2 / 16 x 25 x 2 4 / 16 x 16 x 2
OA inlet screen # / Size (in.) 1 / 20 x 24 x 1 1 / 20 x 24 x 1 1 / 20 x 24 x 1
PHYSICAL DATA (COOLING) 3-5 TONS (cont)
582J*04A/B 582J*05A/B 582J*06A/B
PHYSICAL DATA (CONT)

9
LEGEND
LP – Liquid propane
—– Not applicable
PHYSICAL DATA (HEATING - SINGLE PHASE UNITS) 3-5 TONS
582J*04 582J*05 582J*06
ELECTRICAL
Single Phase Single Phase Single Phase
GAS CONNECTION
# of Gas valves 1 1 1
Nat. gas supply line pressure (in. wg) / (PSIG) 4-13 / 0.18-0.47 4-13 / 0.18-0.47 4-13 / 0.18-0.47
LP gas supply line pressure (in. wg) / (PSIG) 11-13 / 0.40-0.47 11-13 / 0.40-0.47 11-13 / 0.40-0.47
HEAT ANTICIPATOR SETTING (AMPS)
First stage 0.14 0.14 0.14
Second stage 0.14 0.14 0.14
NATURAL GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 20-55 15-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 45-85 30-65 25-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 45-80 35-80
LIQUID PROPANE HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 20-55 15-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection Size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature Rise (°F) 45-85 30-65 25-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 45-80 35-80
LOW NOX GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 20-50 20-50 15-50
MED
# of stages / # of burners (total) 1 / 3 1 / 3 1 / 3
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 30-60 30-60 25-60
HIGH
# of stages / # of burners (total) — 1 / 3 1 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 40-70 35-70

10
LEGEND
LP – Liquid propane
—– Not applicable
PHYSICAL DATA (HEATING - THREE PHASE UNITS) 3-5 TONS
582J*04 582J*05 582J*06
ELECTRICAL
Three Phase Three Phase Three Phase
GAS CONNECTION
# of Gas valves 1 1 1
Nat. gas supply line pressure (in. wg.) / (PSIG) 4-13 / 0.18-0.47 4-13 / 0.18-0.47 4-13 / 0.18-0.47
LP gas supply line pressure (in. wg.) / (PSIG) 11-13 / 0.40-0.47 11-13 / 0.40-0.47 11-13 / 0.40-0.47
HEAT ANTICIPATOR SETTING (AMPS)
First stage 0.14 0.14 0.14
Second stage 0.14 0.14 0.14
NATURAL GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 25-55 20-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 55-85 35-65 30-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 50-80 40-80
LIQUID PROPANE HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 25-55 20-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 55-85 35-65 30-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 50-80 40-80
LOW NOX GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 20-50 20-50 15-50
MED
# of stages / # of burners (total) 1 / 3 1 / 3 1 / 3
Connection size 1/2-in. NPT 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 30-60 30-60 25-60
HIGH
# of stages / # of burners (total) — 1 / 3 1 / 3
Connection size — 1/2-in. NPT 1/2-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 40-70 35-70
PHYSICAL DATA (CONT)
