580J
SINGLE PACKAGE ROOFTOP
GAS HEATING/ELECTRIC COOLING UNIT
SIZES 04 -- 07 with PURONr(R--410A) REFRIGERANT
Submittal Data
Certified to ISO
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
9001
—or—
DESCRIPTION
580J units are single--packaged electric cooling, gas heating
units that are pre--wired and pre--charged with PuronR
(R--410A) HFC refrigerant. The units are factory tested in
both heating and cooling modes. These units meet the
ASHRAE 90.1--2007 efficiency levels.
STANDARD FEATURES
Base Unit
SPuron (R--410A) HFC refrigerant
SSEER’s up to 13.0 (04--06 sizes)
SEER’s up to 11.0
SIEER 11.2 (07 size only)
SRated in accordance with AHRI Standards 210/240
(04--06 sizes) and 340/360 (07size)
SDesigned in accordance with Underwriters’
Laboratories Std 1995
SListed by UL & CUL--Canada or ETL & ETL--Canada
SSingle--stage cooling capacity control
SNon--corrosive composite sloping design; side or center
drain condensate pan. Meets ASHRAE Standard 62
SStandard cooling operating range from 40_Fupto
115_F(4_Cupto46_C). Field installable accessory
extends the minimum down to --20_F(--29_C)
SField convertible from vertical to horizontal airflow for
slab mounting — No special kits required
STwo--inch disposable return air filters
SThru--the--bottom power and gas entry capability
SSingle point gas and electric connections
S24--volt control circuit protected with resettable circuit
breaker
SBelt drive, constant torque, permanently lubricated
evaporator--fan motor
STotally enclosed condenser motors with permanently
lubricated bearings
SLow--pressure and high--pressure switches
SFull perimeter base rail with built--in rigging adapters
and fork truck slots
SCentral Terminal Board facilitating simple safety circuit
troubleshooting and simplified control box arrangement
Cabinet
SAccess panels with easy grip handles
SInnovative, easy starting, no--strip screw feature on unit
access panels
SPre--painted exterior panels and primer--coated interior
panels tested to 500 hours salt spray protection
SFully insulated cabinet
STool--less filter access door
Refrigerant System
SAcutroltrefrigerant metering system
SLiquid line filter drier
SScroll compressors with internal line--break overload
protection
SCopper tube, aluminum fin coils with optional corrosion
resistant coils. Corrosion resistant coils are not available
for single phase (--J voltage) models.
SRemovable gauge line plugs for reading refrigerant
pressure with unit panels in place

2
STANDARD FEATURES (cont.)
Gas Heat
SIGC solid--state gas heat exchanger control for on--board
diagnostics, anti--cycle protection, LED error code
designation, burner control logic and energy saving
indoor fan motor delay
SDedicated 3--5 ton “Low NOx” models available that
meet California Air Quality Management NOx
requirement of 40 nangrams/joule or less. Low NOx
models include stainless steel heat exchangers
SGas efficiencies up to 82%
SInducted draft combustion
SRedundant gas valve, with 2 states of heating
SFlame roll--out safety protector
SSolid--state electronic direct spark ignition system
Standard Parts Warranty
S15--year gas heat exchanger parts -- Stainless Steel
S10--year gas heat exchanger parts -- Aluminized
S5--year compressor parts
S1--year parts
PERFORMANCE DATA
Unit Operating Weight lb
Cooling
Gross Total Capacity: Btuh
at Condenser Air Temperature _F
Gross Sensible Capacity: Btuh
Compressor Power Input: kW
Indoor Entering db _Fwb _F
Airflow CFM External Static Pressure in.wg
Indoor Fan Motor Size Hp
Exhaust Fan Motor Size Hp
Curb Weight lb
Heating
Heating Capacity:
Stage 1 Btuh
Stage 2 Btuh
Heating Capacity Total Btuh
Stage 1 kW
Stage 2 kW
Heating Capacity Total kW
ELECTRICAL DATA
Power Supply to Unit Volts Phase Hz
Minimum Circuit Amps Maximum Overcurrent Protection
SUBMITTAL DATA
Job Name
Architect
Engineer
Contractor
Unit Designation
580J

3
FACTORY--INSTALLED OPTIONS (FIOPs)
jEconomizer with DRY BULB sensing and barometric
relief*
Standard Air Leak Dampers —
fModels with W7212 controller provides standard
non--diagnostic control. EconoMi$er IV.
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er 2.
jEconomizer with ENTHALPY sensing and barometric
relief*
Standard Air Leak Dampers —
fModels with W7212 controller provides standard
non--diagnostic control. EconoMi$er IV.
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er 2.
jEconomizer with DRY BULB sensing and barometric
relief*
ULTRA LOW LEAK Air Dampers —
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements --
plus 5 year limited parts warranty. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements --
plus 5 year limited parts warranty. EconoMi$er 2.
jEconomizer with ENTHALPY sensing and barometric
relief*
ULTRA LOW LEAK Air Dampers —
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements --
plus 5 year limited parts warranty. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements --
plus 5 year limited parts warranty. EconoMi$er 2.
jRTU Open multi--protocol controller communicates to
LON, MODBUS, BACNET and Johnson N2 protocols.
jThrough the base connectors for gas and electric
conduit/piping
jStainless steel gas heat exchanger (includes tubes,
vestibule plate and collector box)
jPerfect Humiditytdehumidification system*
j2 position motorized outdoor air damper*
jNon--fused disconnect
jPowered 115--volt convenience outlet*
jNon--powered 115--volt convenience outlet
jHigh static evaporator fan motor
jReturn Air smoke detector
jSupply Air smoke detector
jCO2sensor
jCondenser hail guard -- louvered style*
jSpecial coating protection for evaporator
and condenser coils*
* Not available for single phase (--J voltage) models.
OPTIONAL WARRANTIES
jComplete Unit Parts only up to 5 years
jComplete Unit Parts and Labor up to 5 years
Many other optional warranties are available.
See the Commercial Start--Up and Optional Extended
Warranty Price price pages for further information.
580J

4
FIELD INSTALLED ACCESSORIES
jEconomizer with DRY BULB sensing and barometric
relief
Standard Air Leak Dampers —
fModels with W7212 controller provides standard
non--diagnostic control. EconoMi$er IV.
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er 2.
jEconomizer with ENTHALPY sensing and barometric
relief
Standard Air Leak Dampers —
fModels with W7212 controller provides standard
non--diagnostic control. EconoMi$er IV.
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements. EconoMi$er 2.
jEconomizer with DRY BULB sensing and barometric
relief
ULTRA LOW LEAK Air Dampers —
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements.
EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements.
EconoMi$er 2.
jEconomizer with ENTHALPY sensing and barometric
relief
ULTRA LOW LEAK Air Dampers —
fModels with W7220 controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements.
EconoMi$er X.
fModels with RTU Open controller meets California
Title 24 (section 120.2) Fault Detection and
Diagnostic (FDD) requirements, has return, outside
air and relief damper leakage that meets Title 24
(section 140.4 and ASHRAE 90.1) requirements.
EconoMi$er 2.
jPower exhaust -- prop fan design
jTwo--position motorized outdoor air damper
jManual outside air damper 25%
jManual outside air damper 50%
jRoofcurb -- 14 inch (356mm) tall
jRoofcurb -- 24 inch (610mm) tall
jThru--the--bottom connections--electrical only
jThru--the--bottom connections--electrical and gas
jCondenser hail guard -- louvered style
jFlue shield
jFlue discharge deflector
jLiquid propane (LP) conversion kit
jHigh altitude conversion kit
jPhase monitor (loss of phase/phase reversal)
jWinter start kit, down to 25_F(--4_C)
jFan/Filter status switch
jLow ambient head pressure controller,
downto0_F(--18_C)
jLow ambient head pressure controller,
down to --20_F(--29_C)
jTime Guard II compressor anti--cycle protection
jReturn Air smoke detector
jSupply Air smoke detector
jThermostats and Sensors
Economizer Sensors
jSingle Dry bulb control
jDifferential Dry bulb control
jSingle enthalpy control
jDifferential enthalpy control
jCO2-- wall mounted
jCO2-- duct mounted
jCO2-- unit mounted
580J

5
CERTIFIED DIMENSION 580J*04--07
C08039
580J

6
CERTIFIED DIMENSION 580J*04--07
C08040
580J

7
ROOF CURB DETAILS
EE
7/16" [11]
4 9/16"
[115.5]
1/4"
[7.0]
5' 7-3/8"
[1711.3]
1' 4-13/16" [427] INSIDE
1-3/4" [44.4]
2-3/8" [61]
1-3/4" [44.5]
1.00" [25.4]
"A"
1-3/4" [44.4]
21.74"
[552.2]
5.42"
[137.7]
11.96"
[303.8]
4.96"
[126.0] 70.87"
[1800.2]
40.69"
[1033.5]
21.84"
[554.7]
16.03"
[407.2]
1.75"
[44.5] 20.41"
[518.3]
3.00" [76.2]
13.78"
[350.0]
14.00"
[355.6]
3.00" [76.2]
15.19"
[385.8]
32.19"
[817.6]
3'-1 3/16"
[944.6]
"A"
1-3/4" [44.5]
CRBTMPWR001A01 3/4" [19] NPT
3/4" [19] NPT
1/2" [12.7] NPTCRRFCURB002A01
CONNECTOR PKG. ACC. GAS CONNECTION TYPE GAS FITTING POWER WIRING
FITTING
CONTROL WIRING
FITTING
ACCESSORY CONVENIENCE
OUTLET WIRING CONNECTOR
THRU THE CURB
1/2" [12.7] NPT 1/2" [12.7] NPT
CRBTMPWR003A01 THRU THE BOTTOM
ROOF CURB
ACCESSORY # A
CRRFCURB001A01 14"
[356]
24"
[610]
ECN NO.APP'DCHK'DBYDATEREVISION RECORDREV
1067898--MMC04/22/13
OVERALL DIM. 5'-7 3/8" WAS 5'-7 7/8; 18GA MATERIAL WA 16 GA.; NAIL FIELD SUPPLIED WAS WITH CURB
A
DRAWING RELEASE LEVEL:
PRODUCTION
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ON:
THIS DOCUMENT AND THE INFORMATION CONTAINED THEREIN IS PROPRIETARY TO CARRIER CORPORATION AND SHALL NOT BE USED OR DISCLOSED TO OTHERS, IN WHOLE OR IN PART, WITHOUT THE WRITTEN AUTHORIZATION OF CARRIER CORPORATION.
1 DEC 2 DEC 3 DEC ANG
MATERIAL
----
- - -
AUTHORIZATION NUMBER TITLE
1041738
CURB ASY, ROOF
ENGINEERING MANUFACTURING
(004-007)
ENGINEERING REQUIREMENTS
----
SIZE DRAWING NUMBER REV
T-005, Y-002
DRAFTER CHECKER
D48TC400427 B
WEIGHT:
-MMC 06/17/11 - -
SHEET 5 OF 5
SURFACE FINISH MFG/PURCH MODEL (INTERNAL USE ONLY) NEXT DRAWING SCALE DISTRIBUTION
- PURCH - N/A MMC
NOTES: 1. ROOFCURB ACCESSORY IS SHIPPED DISASSEMBLED. 2. INSULATED PANELS: 25.4 [1"] THK. POLYURETHANE FOAM, 44.5 [1-3/4] # DENSITY. 3. DIMENSIONS IN [ ] ARE IN MILLIMETERS. 4. ROOFCURB: 18 GAGE STEEL. 5. ATTACH DUCTWORK TO CURB. (FLANGES OF DUCT REST ON CURB). 6. SERVICE CLEARANCE 4 FEET ON EACH SIDE. 7. DIRECTION OF AIR FLOW. 8. CONNECTOR PACKAGE CRBTMPWR001A01 IS FOR THRU-THE-CURB GAS TYPE PACKAGE CRBTMPWR003A01 IS FOR THRU-THE-BOTTOM TYPE GAS CONNECTIONS.
TYPICAL (4) SIDES
SUPPLY AIR RETURN AIR
ROOFING MATERIAL (FIELD SUPPLIED)
CANT STRIP (FIELD SUPPLIED)
ROOFING FELT (FIELD SUPPLIED)
COUNTER FLASHING (FIELD SUPPLIED)
UNIT
GASKET
(SUPPLIED WITH CURB)
RIGID INSULATION (FIELD SUPPLIED)
DUCT
(FIELD SUPPLIED)
NAIL (FIELD SUPPLIED)
CERTIFIED DRAWING
VIEW "B"
CORNER DETAIL
SEE VIEW "B"
RETURN AIR
SUPPLY AIR
SUPPLY AIR OPENING
RETURN AIR OPENING
GAS SERVICE PLATE THRU THE CURB DRILL HOLE
2" [50.8] @ ASSEMBLY (IF REQUIRED) (SEE NOTE #8)
SEE NOTE #2
11 3/4"[298.5] WIDE INSULATED DECK PANELS
8 9/16"[217.5] WIDE INSULATED DECK PANEL
1/3/4"[44.5]
SCALE 0.250
E-ESECTION
C13310
580J

8
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
E2014 Bryant Heating & Cooling Systems D7310 W. Morris St. DIndianapolis, IN 46231 Edition Date: 06/14
Replaces: SUB580J--- 13
Catalog No. SUB580J---4---7---01
580J
