Product Data
ERVBBLHA
ENERGY RECOVERY VENTILATORS
A07619
The Energy Recovery Ventilation (ERV) system offered by Bryant
is the finest on the market today. The ERV provides efficient and
cost effective heat recovery during the heating season when needed
most.
As temperatures drop below 23_F(--5_C), indoor air is recirculated
periodically through the heat exchanger core to prevent frost from
forming. Competitors’ methods of supplementary electric defrost
waste energy. Unlike rotary wheel heat exchangers which mix air
streams, these cross--flow or counterflow heat exchangers ensure
that there is no mixing of the stale air stream with the fresh outdoor
air stream.
A filter installed on the incoming outdoor air stream removes large
airborne particles from the intake air stream before they enter the
heat exchanger and reduces the maintenance required. (A filter is
also installed on the outgoing air stream, up stream of the heat
exchanger core.) The units’ acoustically engineered design makes
the Bryant ERV the quietest on the market and ensures that comfort
is felt, not heard.
Unlatching two (2) suitcase style latches allows easy removal of the
filters and core for cleaning.
STANDARD FEATURES
SDrainless design
SIntegrated airflow balancing points
SIntegrated furnace interlock
SAcoustical design
SOnboard control for continuous high/low ventilator operation
SEnergy saving defrost cycle
SCross--flow, counterflow heat exchangers
SOne filter on incoming air; one filter on outgoing air to protect
core
SNo--tools maintenance
SEnthalpic heat exchanger core

2
MODEL NUMBER NOMENCLATURE
ERV BB LHA 1 150
Product Type Brand Model Type Electrical Supply Maximum Capacity
Energy Recovery Ventilator Bryant LHA --- Large Horizontal 1 --- 115 Volts 150 CFM
200 CFM
A
16.75
″
(425.5)
B
12"
(381.0)
G
4
1
⁄ 2 ″
(114.3)
D
C
34"
(864)
NOTES:
1. FRESH AIR FROM ERV TO HOUSE
2. FRESH AIR FROM OUTSIDE TO ERV
3. STALE AIR FROM HOUSE TO ERV
4. STALE AIR FROM ERV TO OUTSIDE
4
3
1
2
E
F
5
7
⁄ 8 ″DIA
(149.2)
4 PLCS
2
3
⁄ 16 ″
(56.2)
4 PLCS
1 ″
(25.4)
2 PLCS
A07638
DIMENSIONS
MODEL
A B C D E F G
in. mm in. mm in. mm in. mm in. mm in. mm in. mm
ERVBBLHA 17--- 1/4 438.2 10 254 4 --- 1 / 2 114.3 11 279.4 7 --- 3 / 4 196.9 4 --- 1 / 4 108 9 --- 1 / 2 241.3
ERVBBLHA

3
Climate Map for Energy and Heat Recovery Ventilators
ERV Recommended w/HRV or ERV Wall Control
ERV Recommended
HRV Recommended
Honolulu
Sacramento Salt Lake
City
Boise
Salem
Vancouver
Helena
Edmonton
Calgary Regina Winnipeg
Bismark
Topeka
Denver
Oklahoma City
Austin
Baton Rouge
Orlando
Atlanta Columbia
Raleigh
Washington D.C.
Nashville
Indianapolis
Springfield
Chicago
Des Moines
Minneapolis
Green Bay
Milwaukee
Detroit
Madison
Harrisburg
Hartford
Boston
Syracuse
Montreal
Ottawa
Timmins
PHYSICAL DATA
MODEL ERVBBLHA1150 ERVBBLHA1200
Port Locations Sides Sides
Core Type Enthalpic transfer media, cross flow Enthalpic transfer media, cross flow
Weight — lb (kg) 74 (33.6) 76 (34.5)
Shipping Weight — lb (kg) 78 (35.4) 80 (36.3)
Shipping Dimensions in. (mm)
Height
Width
Length
19.75 (502)
20.5 (521)
40.5 (1029)
19.75 (502)
20.5 (521)
40.5 (1029)
MODEL ERVBBLHA1150 ERVBBLHA1200
Capacity—CFM @
0.5-0.3ESP (in. wc) 60--- 148 60--- 183
Efficiency (Sensible)—Percent
32_F(0_C)
--- 1 3 _F ( --- 2 5 _C)
60
49
58
41
Efficiency (Latent)—Percent
@ all temperatures 58 53
Cooling Season Total Recovery Efficiency 95_F
(35_C) 56 52
MODEL ERVBBLHA1150 ERVBBLHA1200
Voltage 120 120
Max Power — watts 150 240
Max Amps 1.3 2.1
METHODS TO SIZE ERVs
METHOD 1
1. Calculate cu ft of occupied space.
2. Multiply by recommended air changes per hr (AC/h).
3. Divide by 60 minutes per hr to convert to CFM.
Example:
2000 sq ft with 8 ft ceiling, 0.35 air changes per hr (AC/h)
(2000 sq ft x 8 ft ceiling x 0.35 AC/h) / 60 min/h = 93.3 CFM
METHOD 2
1. Multiply number of people times 15 CFM/person.
2. Multiply number of bath rooms 20 CFM/each.
3. Add 25 CFM for kitchen.
Example:
2 people, 2 baths, 1 kitchen
(2 x 15) + (2 x 20) + 25 = 95 CFM
ERVBBLHA

4
HEATING AND COOLING LOAD CHARTS
Although the ventilators process the outside air before it enters the home, additional heating and cooling loads need to be considered.
HEATING LOAD BTUH
Outside
Tem p °F
Heating Load (Btuh) @
Inside Design Temp 72°F
ERV150 ERV200 HRV150 HRV250
–25 5186 8143 6636 10603
–20 4919 7723 6294 10057
–15 5075 7967 5952 9510
–10 4783 7509 5610 8964
–5 4491 7051 5268 8417
04200 6594 4925 7871
54234 6647 4583 7324
10 3918 6151 4241 6777
15 3958 6214 3899 6231
20 3611 5669 3557 5684
25 3264 5124 3215 5138
30 2916 4579 2873 4591
35 2569 4034 2531 4045
40 2222 3489 2189 3498
The heating load chart shows the heating loads in Btuh for a range
of winter design temperatures for each model of ventilator.
EXAMPLE: The heating design temperature for Little Rock, AR is
20_F. The additional heating load of the ERVBBLHA1200 at
20_F is 559 Btuh. This additional load should be taken into
consideration when sizing the heating equipment.
COOLING LOAD BTUH
Outside
Enthalpy
Cooling Load (Btuh) @ Inside Design Temp
72°F and 50% Relative Humidity
Btu/lb ERV150 ERV200 HRV150 HRV250
30 380 640 670 1071
31 618 1040 1090 1741
32 855 1441 1509 2411
33 1093 1841 1928 3080
34 1331 2241 2347 3750
35 1568 2641 2766 4419
36 1806 3041 3185 5089
37 2043 3441 3604 5759
38 2281 3842 4023 6428
39 2519 4242 4442 7098
40 2756 4642 4861 7767
41 2994 5042 5280 8437
42 3231 5442 5699 9107
The cooling load chart shows loads in Btuh as well. To use the
cooling load chart, first find the design enthalpy from a
psychrometric chart using the design dry bulb and wet bulb
temperatures. (See pg. 7.) The cooling load can then be found for a
range of enthalpies for each ventilator.
EXAMPLE: The design dry bulb temperature for Miami is 90_F
and the average wet bulb at that temperature is 77_F. Using the
psychrometric chart, the enthalpy is about 40.5 Btu per pound
(Btu/lb) of dry air, which would round up to 41 Btu/lb dry air. In
the left column, at 41 Btu/lb dry air, the ERVBBLHA1200 has an
additional cooling load of 5042 Btuh, while the HRV150CFM unit
has an additional cooling load of 8437 Btuh.
ERVBBLHA

5
PSYCHROMETRIC CHART
.025 .024 .023
.022
.021 .020 .019
.018
.017
.016
.015 .014
.013
.012
.95
.90
.85
.80
.75
.70
.65
.60
.55
.50
.45
.40
.35
.011 .010
.009
.008
.007
.006
.005
.004
.003
.002
.001
0
Sensible
heat
factor
Pounds of moisture
per pound of dry air
789
10 11
12
32 33
34 35
36
37 38
39 40
41
42 43
44 45
47
48 49
46
27 28
29 30
31
19 20
21 22
23
24 25
26
12 13
14 15
16
17
18
Wet Bulb, Dewpoint or Saturation Temperature F
Dry Bulb Temperature F 20
Below 32ûF, properties and enthalpy deviation lines are for ice.
25
25 30 35
40
45 50 55
60
65
70 75
80
30 35 40
85 90 95 100 105
180
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
45 50 55 60 65 70 75 80 85 90 95 100 105 110
Enthalpy at saturation, Btu per pound of dry air
Grains of moisture
per pound of dry air
14.0 cu ft
14.5 cu ft per pound of dry air
13.5 cu ft
13.0 cu ft
12.5 cu ft
90% Relative Humidity
80%
70%
60%
50%
40%
30%
20%
10%
-.02 BTU
-.01 BTU
-.02 Btu
-.04 Btu
-.06 Btu
-.08 Btu
+0.1 Btu
+0.2 Btu
+0.3 Btu
+0.4 Btu
+0.5 Btu
80% 60% 40% 20%
Btu per
pound of dry air -0.3 Btu
Enthalpy deviation
A98394
ERVBBLHA

6
ACCESSORIES
ITEM ACCESSORY PART NO. ERVBBLHA SIZE USED WITH
Bryant OneTouch Control KVBCN0101BLT All
Bryant Basic Wall Control KVBCN0101BBS All
Bryant Latent Wall Control KVACN0101BLC All
6 0 --- M i n u t e T i m e r K i t KVATM010160M All
Bryant 20---Minute Push Button KVATM010120B All
Airflow Measuring Kit KVBAC0101KIT All
Hood (2 required) KVAAC0101HOD All
ACCESSORY DESCRIPTION, SUGGESTED AND REQUIRED USE
Bryant OneTouch Control
Control option choice. Used with all ERVs as a main wall control.
Bryant Basic Wall Control
Control option choice. Can be used with all ERVs.
Bryant Latent Wall Control
Control option choice. Can be used with all ERVs.
60--Minute Timer Kit
Used with all ERVs, time is adjustable between 10 and 60 minutes.
Bryant 20--Minute Push Button
Used with all ERVs when 20 minute manual operation is required
Airflow Measuring Kit
Start up Balancing Kit, includes Magnehelic Gauge
Hood (2 required)
Used with all ERVs. Exterior intake and exhaust hoods.
Control Description Fan Speed Control Humidistat Control Continuous Mode Intermittent Mode
OneTouch Yes No Yes Yes
Latent Yes Yes Yes Yes
Control features
OneTouch Control:
Allows control of ventilator with the touch of a button. This
control will operate as a main wall control. The OneTouch will
operate the unit in Intermittent Mode (20 minutes per hour),
continuous low speed, continuous high speed, and off.
Latent Control:
Low Exchange Mode—If the relative humidity inside the building
is lower than selected, air exchange would occur with the outside at
high speed. If the relative humidity inside the building is higher
than selected, air exchange would occur with the outside at low
speed. This ensures continuous air exchange for constant air
quality.
Intermittent Mode—If the relative humidity inside the building is
higher than selected, no air exchange would occur and the system
would turn off. If the relative humidity inside the building is lower
than selected, air exchange would occur with outside at high speed.
this mode is ideal for maintaining the proper humidity level when
the continuous mode cannot.
Automatic Defrost Cycle Features
All models offer a non--electric defrost cycle feature which
prevents frost and ice buildup within the heat recovery core. When
the outside air temperature falls below 23_F(--5_C) it is
electronically sensed and the dampers close the outside air ports.
This allows warm indoor air to recirculate within the heat recovery
core. The frequency of this cycle increases as the outside air
temperature decreases.
Model
25_F
( --- 5 _C)
4_F T O --- 1 7 _F
( --- 1 5 . 6 _C T O --- 2 7 . 3 _C)
B E L O W --- 1 8 _F
( --- 2 7 . 8 _C)
DEFROST* EXCHANGE{DEFROST* EXCHANGE{DEFROST* EXCHANGE{
ERVBBLHA 10 Minutes 60 Minutes 10 Minutes 30 Minutes 10 Minutes 20 Minutes
* All defrost times are in the standard mode (as shipped)
{Time between defrost when within specified temperature range
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
E2007 Bryant Heating & Cooling Systems 7310 W. Morris St. Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 07/07
Replaces: NEW
Catalog No: PDSER
V
LH
A
--- 0 1
