BSi iBAROS User manual

1
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
BAROS INSTALLATION GUIDE
PRODUCT FEATURES:
Baros s a classc-look decoratve outdoor fittng, deal for the
efficent lghtng of hstorcal downtown areas and other tradtonal areas.
Desgned to last n extremely harsh envronments.
RECOMMENDATIONS FOR THE USER:
1)Before the nstallaton, make sure that there s no voltage.
2)Do not touch the fittng when t s workng on / swtched on
3)Do not look at the fittng drectly or from a short dstance.
4)Dsconnect / swtch off the fittng before changng the lamps
NOTES:
-Techncal amendments are reserved.
-CE – Conformty mark
-The manufacturer s then dscharged from lablty when damage s
caused by mproper use or nstallaton.
-Clean lumnare regularly wth solvent-free cleansers from drt and
deposts. Do not use hgh pressure cleaners.

2
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
BAROS INSTALLATION GUIDE
1) - The gjons are screwed nto the anchor.
- The prepared anchorage s embedded n the concrete.
Gjon
Anchor
Mn 30mm
Incomng
energy
hose
Outgong
energy
hose
H
AA
Pole Heght A H
3mt - 4mt 35cm 50cm
4mt - 5mt 40cm 50cm
6mt - 7mt 50cm 80cm
8mt - 9mt 60cm 90cm
10mt - 12mt 70cm 120cm
Concrete Dmensons
Concrete
Gjons should be mn
30mm above the anchorage
2) After the concrete has been dred, the electrcal cables are pulled and the nuts are removed.
Concrete
Concrete
Incomng
energy
cable
Outgong
energy
cable

3
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
BAROS INSTALLATION GUIDE
3) - The lumnares cable s passed through the poles top tube.
- The lumnare s screwed onto the poles top tube.
Energy
Cable
Energy
Cable
Setscrew
4) - The setscrew on the lower ornament s loosened and the ornament s pulled up.
- The fuse cover on the pole s removed.
- The cable s passed through the pole and removed from the fuse cover hole.
- The lumnare s placed on the pole.
- Tghten the setscrews on the lumnare.
Fuse Cover
Energy
Cable
Energy
Cable
Energy
Cable
Setscrews
Pole Mounted
Lumnare Installaton

4
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
BAROS INSTALLATION GUIDE
5) - The pole is placed on the anchor andthe washer - nut are tghtened.
- Electrical connection is done.
- The fuse cover is re-mounted.
- The ornament s pulled down and the setscrew on the lower ornament s tghtened .
Inox
Nut-Washer
Lumnare
Cable
Output
Energy
Input
Energy
(L) Brown
( ) Green-Yellow
(N) Blue
Energy
Connecton
*Please contact us for cables f n dfferent colors.
Lumnare Cable
