METIS INSTALLATION GUIDE
PRODUCT FEATURES:
Flat is a functional LED lighting solution for exterior lighting applications.
By using the same lighting platform and incorporating a new and unique
BSISQ® LED Module; the luminaire achieves the required illumination
levels and distribution in pedestrian, site, roadway environments.
Designed to last in extremely harsh environments.
RECOMMENDATIONS FOR THE USER:
1)Before the nstallaton, make sure that there s no voltage.
2)Do not touch the fittng when t s workng on / swtched on
3)Do not look at the fittng drectly or from a short dstance.
4)Dsconnect / swtch off the fittng before changng the lamps
NOTES:
-Techncal amendments are reserved.
-CE – Conformty mark
-The manufacturer s then dscharged from lablty when damage s caused by mproper
use or nstallaton.
-Clean lumnare regularly wth solvent-free cleansers from drt and deposts. Do not use
hgh pressure cleaners.

2
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
METIS INSTALLATION GUIDE
1) - The gjoons are screwed nto the anchor.
- The prepared anchorage s embedded n the concrete.
Gjon
Anchor
Mn 30mm
Incomng
energy
hose
Outgong
energy
hose
H
AA
Pole Heght A H
3mt - 4mt 35cm 50cm
4mt - 5mt 40cm 50cm
6mt - 7mt 50cm 80cm
8mt - 9mt 60cm 90cm
10mt - 12mt 70cm 120cm
Concrete Dmensons
Concrete
Gjons should be mn
30mm above the anchorage
2) After the concrete has been dred, the electrcal cables are pulled and the nuts are removed.
Concrete
Concrete
Incomng
energy
cable
Outgong
energy
cable

3
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
METIS INSTALLATION GUIDE
3) - The jont s screwed nto the pole and fuse cover s removed from the pole.
- Pass the power cable through the cable hole of the pole and remove t from the fuse cover.
- Tghten the lumnare to the jont wth screws.
- The lumnare s brought to the desred angle and the screws of the jont are tghtened.
Screw
Fuse Cover
Jont
Screw
Energy Cable
Angle adjustment bolt

4
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
METIS INSTALLATION GUIDE
4) - The pole s fixed on the anchor and the washer-nuts are tghtened.
- Fuse box is removed.
- Electrical connection is done.
- The fusebox and the fuse cover is re-mounted.
Lumnare
Cable
Output
Energy
Input
Energy
(L) Brown
( ) Green-Yellow
(N) Blue
Fuse Box Connecton
*Please contact us for cables f n dfferent colors.
Lumnare Cable
1
2
unscrew
Fuse box removal from pole
