BSi RANO User manual

1
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
RANO INSTALLATION GUIDE
PRODUCT FEATURES:
Mnmal desgn bollard, Rano s deal for dscrete llumnaton of walkways
and resdental areas.
Offers glare-free llumnaton and vsual comfort, creatng a welcomng atmosphere.
Desgned to last n extremely harsh envronments.
RECOMMENDATIONS FOR THE USER:
1)Before the nstallaton, make sure that there s no voltage.
2)Do not touch the fittng when t s workng on / swtched on
3)Do not look at the fittng drectly or from a short dstance.
4)Dsconnect / swtch off the fittng before changng the lamps
NOTES:
-Techncal amendments are reserved.
-CE – Conformty mark
-The manufacturer s then dscharged from lablty when damage s caused by mproper
use or nstallaton.
-Clean lumnare regularly wth solvent-free cleansers from drt and deposts. Do not use
hgh pressure cleaners.

2
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
RANO INSTALLATION GUIDE
1) - The gjons are screwed nto the anchor.
- The prepared anchorage s embedded n the concrete.
Gjon
Anchor
Mn 30mm
Incomng
energy
hose
Outgong
energy
hose
30cm
25cm 25cm
Concrete
Gjons should be mn
30mm above the anchorage
2) After the concrete has been dred, the electrcal cables are pulled.
Incomng
energy
cable
Outgong
energy
cable
Concrete
Concrete

3
Headquarters : Konutkent Mah. 3029 Cad. No:3/91 06810 Çankaya Ankara/TURKEY Phone : [phone] Fax : [phone] Email : [email protected]
RANO INSTALLATION GUIDE
5) Luminaire is fixed to the flange with
fastening the setscrews below
4) Electrical connection is done and luminaire is
placed on the flange.
Lumnare
Cable
Output
Energy
Input
Energy
(+) Brown
( ) Green-Yellow
(-) Blue
Fuse Box Connecton
*Please contact us for cables f n dfferent colors.
Lumnare Cable
3) -Loosen the setscrews at the bottom of the lumnare
and remove the flange from the lumnare.
-The flange s seated on the anchor and the
new nox washer s tghtened to the threads.
Inox Nut and
Washer
Fuse Box
Setscrews
