BT Baby Monitor 100
User Guide

Section
•Digital sound quality with high definition sound (Hi-dSTM)
lets you hear your baby breathe, gurgle, snuffle or cry
with complete clarity.
•Wireless range of up to 300m outdoors and up to 50m
indoors(in ideal conditions) - giving you the freedom to
move around with clear reception and no interference from
other baby monitors.
•Out of range warning.
•Link light provides continuous confidence that the Parent unit
is receiving a signal from the Baby unit and will alert
you if the link is lost.
•3lullabies.
•Talk Back feature lets you instantly reassure and calm
your baby.
•Adjustable nightlight brightness on Baby unit.
•Mains or battery operation.
•Rechargeable batteries in Parent unit.
Welcome…
to your BT Baby Monitor 100

Section
This User Guide provides you with all the
information you need to get the most
from your BT Baby Monitor 100.
Please read this guide carefully and keep
it for future reference.
Need help?
If you have any problems setting up or using your BT Baby
Monitor 100 (or would like additional or replacement
batteries), call the BT Baby Monitor Helpline 0808 100 6554*.
Alternatively, you may also find the answer in ‘Help’
at the back of this guide.
Got everything?
• Baby unit
• Parent unit
• 2 x AA rechargeable
batteries for Parent unit
• Parent unit charger
• 2 x mains power adapters
(item code 045327)
• Travel bag
• Wall mounting bracket for
the Baby unit
*Calls made from within the UK mainland network are free.
Mobile and international call costs may vary.

5
If you experience any problems, please call the Helpline on 0808 100 6554*
In this guide
Setting up
Important safety information . . . . . . . . . . . . 6
Parent unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Baby unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Check the connection . . . . . . . . . . . . . . . . . . 9
Getting to know your Baby Monitor
Parent unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Parent unit charger . . . . . . . . . . . . . . . . . . . . 11
Baby unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Back of Baby unit. . . . . . . . . . . . . . . . . . . . . . 13
Using your BT Baby Monitor 100
Switching on/off . . . . . . . . . . . . . . . . . . . . . . 14
Changing Baby unit from
battery tomains power .................14
Adjust speaker volume at the Parent unit . . 15
Talk Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjust Talk Back volume ................15
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Nightlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Select a sensitivity level .................18
Sound level visual indicator. . . . . . . . . . . . . . 18
Mute(loudspeaker off) .................18
Alert tone when the loudspeaker is off . . . . 18
Lullaby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Playing a lullaby .......................19
Help ................................20
General information
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Product disposal instructions . . . . . . . . . . . . 23
R&TTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Declaration of Conformance . . . . . . . . . . . . . 23
User Guide formats ....................23

6
If you experience any problems, please call the Helpline on 0808 100 6554*
Setting up
Important safety information
Your BT Baby Monitor 100 is designed to be an aid and should
not be used as a substitute for responsible and proper adult
supervision.
Make sure the Baby unit, Parent unit and mains adapter cable
are kept out of reach of your baby – at least one metre away.
Never place the Baby unit inside your baby’s cot, bed
or playpen.
Never cover your Parent or Baby units (e.g. with clothes,
towels or blankets).
Never use or place your Parent or Baby units in moist places or
near water.
If travelling abroad, make sure that the voltage shown on the
mains power adapter corresponds to the local mains power
beforeconnecting tothe power supply.
Thereis a risk of explosion if the batteries are replaced by an
incorrect type.
Dispose of used batteries according to the instructions.
Always dispose of batteries in accordance with applicable
wastedisposal regulations, never in your household rubbish.

7
If you experience any problems, please call the Helpline on 0808 100 6554*
Battery performance - Parent unit
Rechargeable batteries in the Parent unit
give up to 14 hours continuous performance.
Please note however, that new batteries do
not reach full capacity until they have been
in normal use for several days.
Running rechargeable batteries right down
at least once a week will help them last as
long as possible. The charge capacity of
rechargeable batteries will reduce with time
as they wear out, so reducing the
performance time of the Parent unit.
Eventually they will need to be replaced.
New batteries can be obtained from the BT
Baby Monitor Helpline 0808 100 6554*.
The Parent unit rechargeable batteries will
lose charge over a period of time, even if
switched off.
Batterylow warning – Parent unit
When the batteries arelow – approximately
within 1 hour and 30 minutes of running
out – the Parent unit light will come on.
If the batteries are completely flat the
Parent unit will switch off.
Place the Parent unit back on the charger
to charge the batteries. It is advisable to
keep the Parent unit on the charger as
much as possible or ideally all the time.
To speed up the charging process turn the
Parent unit off when charging if it’snot
being used.
WARNING
The re-chargeable battery icon in
the battery compartment means that only
re-chargeable batteries can be used.
Never use non-rechargeable batteries in
your Parent unit. Use only the
recommended type – 2 x AA rechargeable
(1300mAh NiMH) batteries – using other
types could permanently damage your unit.
Charge the batteries in accordance with the
instructions given in this user guide.
The Parent unit can still be used when it is
in the charger.
Parent unit
1. Plug the mains power cable into the socket marked
on the back of the Parent unit charger.
Connect the other end to the mains power and switch on.
2. Remove the battery compartment cover and insert the 2 x AA
rechargeable batteries into the battery compartment on the
Parent unit and replace the battery compartment cover as
shown. You should always ensure you have inserted batteries
in the Parent unit.
3. Slot the Parent unit into the charger, the red charging light
comes on. Charge the batteries for 16 hours before switching
on the Parent unit.
Note: if you ever need to remove the batteries, remove the
battery compartment cover and tip the parent unit until they
slide out.
Setting up

8
If you experience any problems, please call the Helpline on 0808 100 6554*
Baby unit
Once your Parent unit has been fully charged:
1. Plug the power cable into the socket marked
on the back of the Baby unit.
Connect the other end to the mains power and switch on.
Using batteries
Your Baby unit also works on battery power, so that you can
use it even when you are not near to a mains power socket or
during a power cut.
1. Using your finger or a coin, turn the battery lock on the back
of the Baby unit anticlockwise so the groove is vertical then
lift off the cover.
2. Insert 4 x AA alkaline batteries (not supplied) as shown.
Setting up
Battery performance – Baby unit
The recommended batteries are 4 x AA
alkaline. Not included.
With new batteries, your Baby unit will
give up to 14 hours continuous
performance with the night lights
switched off. This will be less if the
lights are switched on.
When the Baby unit is not being used
and is disconnected from the mains
power, you should ensure you remove
the batteries. This will prevent the
batteries discharging.
It is recommended that the same
batteries should not be used for more
than 48 hours continuously. Use of old
batteries may result in the unit not
functioning correctly and could
damage the Baby unit.
Batterylow warning – Baby unit
When the batteries arelow –
approximately within 30 minutes of
running out – the Baby unit light
will come on. However, this
will depend on the type of
batteries used.
Temperaturerange
The features on your BT Baby Monitor
100 have been designed towork
normally at any temperature between
0°C and 40°C. Battery lock
Child tamper proof lock for
the battery compartment.

9
If you experience any problems, please call the Helpline on 0808 100 6554*
WARNING!
Use only the mains power adapter
supplied. Using an incorrect adapter
may permanently damage your BT
Baby Monitor 100.
The Baby unit will only work from the
batteries if the mains power is off or
disconnected.
3. Replace the battery cover, turning the battery lock into the
vertical position again to lock it.
Check the connection
When both Units are switched on, the green link lights on both
Units will come on.
If the link between the Units is broken at any time, the link
lights will turn red and flash slowly.
At the Parent unit, you will also hear an alert signal (3 beeps
every 30 seconds) to warn you that there is no communication
between the Units. If this happens, check that the mains
power is plugged in and switched on at the Baby Unit.
Also check that the units are within range of one another.
During continual use the Baby unit and Parent unit charger
power adapters may become warm to the touch. This is
normal and not something tobe concerned about.
In the event of power failure, when the power is restored all
your settings will remain unchanged.
Setting up

Getting to know your Baby Monitor 10
Parent unit
From the Parent unit you can listen to your baby and operate the Baby unit by remote control.
If you experience any problems, please call the Helpline on 0808 100 6554*
Talk (on side of unit)
Press to talk to your baby.
Lullaby LEDs
Green on – When the selected
lullably is being played.
Up
Increase speaker volume.
Increase sensitivity when reviewing
the setting.
Change lullaby when playing.
Mute LED
Green on – When speaker is muted.
Mute
Press to switch the speaker off, press
again to switch it back on.
Sensitivity
Press to review and change
the sensitivity setting.
Down
Decrease speaker volume.
Decrease sensitivity when
reviewing the setting.
Change lullaby when playing.
LED Link indicator
Green On – Linked to Baby unit
Green flashing – Not linked to Baby unit
–first 30 seconds
Red Flashing – Not linked to Baby unit
–for longer than 30 seconds.
Sensitivity / Volume level LEDs
During use, lights indicate:
–Sensitivity level
–Parent unit volume level
–How loudly baby is crying
Battery status LED
–Red flashing when batteries are low.
Lullaby
Press to start playing a lullaby,
press again to stop.
Power on/off
Press and hold to switch the power
on or off.
Microphone

Parent unit charger
11Getting to know your Baby Monitor
If you experience any problems, please call the Helpline on 0808 100 6554*
Power socket
For connection to
mains power.
Charging light
Indicates Parent
unit is charging.
Front
Back

Baby unit
12 Getting to know your Baby Monitor
If you experience any problems, please call the Helpline on 0808 100 6554*
Link light
Green when linked to
Parent unit.
Flashes if not linked -
first 30 seconds.
Flashes when Talk is
pressed on Parent unit.
Red flashing if not linked
longer than 30 seconds.
Page
Press to page the
Parent unit – useful
for finding when it
is misplaced.
Brightness
Press to adjust the
nightlight brightness
(once nightlight is
switched on).
There are three levels.
Nightlight
Press to switch
nightlight on or off.
Up/Down/Volume
Increase or decrease
speaker volume
for playback of
lullabies and talk
back volume only.
Play/Stop
Press to play lullaby,
press again to stop.
Power on/off
Press to switch
on or off.
Lullaby
Press to select
lullaby 1, 2, 3
or Play All.
Batterylight
Red when battery
is low.
Lullaby lights
Indicates which
lullaby is playing.
Microphone
Nightlight illuminates

Back of Baby unit
13Getting to know your Baby Monitor
If you experience any problems, please call the Helpline on 0808 100 6554*
Batterylock
Child tamper proof lock for the
battery compartment.
Power socket
For connection
to mains power.
Underside

14
Helpline
If you have any problems using
your BT Baby Monitor 100,
call 0808 100 6554*.
If you experience any problems, please call the Helpline on 0808 100 6554*
Using your BT Baby Monitor 100
Switching on/off
Switch on the Parent unit
1. Press and hold until all LEDs briefly illuminate. The
Parent unit is now switched on and will search for and link
itself to the Baby unit.
Switch on the Baby unit
1. To switch on, press . All LEDs and the nightlight briefly
illuminate. When the green link LED stops flashing and
remains a steady green, the unit is within range of the Parent
unit and is ready to use.
Switching off both units
1. Toswitch Off,press until the link light goes off.
Changing Baby unit from battery to mains power
Toconserve battery power on the Baby unit or when the
batteries are low or flat, plug the Baby unit into the mains.
If currently running on batteries and switched on, changing
from battery to mains power will be instant and not affect
any of the settings.
You can use the Parent unit to monitor baby while it is charging.
If you place the Parent and Baby units
too close together you will hear a high
pitched noise, this is normal. The units
are designed to be located at a
distance from one another, e.g. in
separate rooms.
Do not press the Talk button when
the Baby unit and Parent unit are
positioned in the same room. High-
pitch noise will be generated if the Talk
button is pressed when Baby unit and
Parent unit are close to each other or
within 3 metres distance.
Put down / mutethe Parent unit
before you go into the nursery in order
toprevent any high-pitched whistle /
feedback.

15
If you experience any problems, please call the Helpline on 0808 100 6554*
Whilstusing Talk Back you will not be
able to hear your baby until you
release the button.
Adjust speaker volume at the Parent unit
There are 5 volume levels (and off) on the Parent unit.
The LEDs indicate the level. The first 4 levels are shown as
green and the 5th level as red. Red is the highest level.
1. Press or to select the required level.
Talk Back
You can use the Talk Back feature to comfort and reassure
your baby.
1. Press and hold on the Parent unit to speak to baby.
The green link lights on both units flash.
2. Release to hear your baby again.
Adjust Talk Back volume
The Baby unit has 5 volume levels.
1. Press or on the Baby unit to increase or decrease
the volume. This also affects the lullaby volumes.
Using your BT Baby Monitor 100
The LEDs that indicate the volume
level of the Parent unit are actually the
second to sixth LEDs, since the first
LED is the link status indicator.
If is used on the Parent unit when
the volume is set to level 1 it will
activate the Mute function.
If the Parent unit has its volume
muted, pressing the button will
un-mute the Parent unit and set the
volume to level 3 automatically.

16
If you experience any problems, please call the Helpline on 0808 100 6554*
Paging
You can use the button on the Baby unit to find the
Parent unit. This will also reset the speaker volume level, in
case it has been switched off (muted).
1. Press on the Baby unit. If the Parent unit volume was set
to off (muted), this will automatically reset the volume to the
default volume. The paging alertwill sound.
2. To stop the Page alert, press any button on the Parent unit, or
press again on the Baby unit. If no button is pressed, the
paging tone will stop after 2 minutes.
Nightlight
Set a comforting nightlight with a choice of three
brightness levels.
1. On the Baby unit, press to switch the nightlight On or Off.
2. Press repeatedly to select the brightness settings.
Using your BT Baby Monitor 100

17
If you experience any problems, please call the Helpline on 0808 100 6554*
Sensitivity
You can change the sensitivity of your BT Baby Monitor 100
to determine how much noise your baby must make before
the sound is heard at the Parent unit.
There are 5 different levels.
Level 1 is the least sensitive setting (shown by two green
LEDs) and will require your baby to make a loud noise before
the sound is heard at the Parent unit.
Level 2 to 4 correspond to progressively quieter baby noises
that are required before the sound is heard at the Parent unit.
Level 5 is the most sensitive setting (shown by five green and
one red LED), and any noise made by your baby (no matter
how quiet) will be heardat the Parent unit.
Sensitivity levels 1-5 are indicated by the number of LEDs
illuminated after pressing .
Using your BT Baby Monitor 100
If you set the sensitivity level too low,
only louder sounds in the baby’s room
will be picked up and communicated
back to you via the Parent unit.
The Unit will not pick up quieter
background noises.
The 5 sensitivity level LED indicators
startat the second LED on the
Parent unit. The first LED is the link
status indicator.
LED Link indicator = Green or red LED
Level 1
Level 2
Level 3
Level 4
Level 5 = Red LED
Red LEDs
Green LEDs

18
If you experience any problems, please call the Helpline on 0808 100 6554*
Select sensitivity level
1. Press to view the current sensitivity setting (as shown by
the LEDs).
2. Press or to change the sensitivity setting.
Sound level visual indicator
The noise level from baby’sroom is indicated by the LEDS on
the Parent unit. So even if the loudspeaker is turned down or
off (muted), you can be alerted visually.
There are 7 LED noise indicators - 4 green and 3 red -
covering a range of noise levels from 0dB up to 40dB.
Mute(loudspeaker off) – Parent unit only
You can prevent sounds from coming out of the Parent
unit loudspeaker by pressing . The mute active
LED illuminates.
To restore sounds press again.
The volume or buttons can also be used to
activate and deactivate mute.
Alert tone when the loudspeaker is off
If the Parent unit loudspeaker is turned off, and the noise level
from baby’s room reaches the 2nd red LED level, the unit will
beep toalert you. This is independent of any sensitivity setting
you may have set.
Using your BT Baby Monitor 100
The sound level visual indicator LEDs
start at the second LED. The first LED
is the link status indicator.

Lullaby
The Baby unit plays lullabies to gently soothe your baby back to
sleep. Each lullaby is played repeatedly for 15 minutes. Select
one of the three melodies or select Play All for a medley of all 3
lullabies for 15 minutes. The Lullaby LEDs indicate which lullaby
is playing or if all 3 are being played.
Playing a lullaby
At the Baby unit:
1. Press . The Lullaby 1 LED is switched on. Press again
to select Lullaby 2, Lullaby 3 or all three lullabies.
2. Press to start playing the Lullabies.
3. Press at the Baby unit OR at the Parent unit to stop.
At the Parent unit:
1. Press . Lullabies at the Baby unit will start to play.
2. Press or to select between lullabies, or all 3
lullabies. Lullaby selection is indicated on the Parent unit
lullaby selection LEDs.
3. To stop the lullaby, press .
19Using your BT Baby Monitor 100
While a lullaby is playing you can still
access any of the other functions.
The lullaby may stop part way through
playback. This is normal because
playback stops after 15 minutes.
The volume of the lullaby can only
be controlled by the Baby unit volume
and buttons.
If you experience any problems, please call the Helpline on 0808 100 6554*

20
If you experience any problems, please call the Helpline on 0808 100 6554*
Help
Helpline
If you have any problems using your BT Baby Monitor 100, call 0808 100 6554*.
Power lights do not come on
• If using the mains power adapters make sure they are plugged in and switched on.
• If using batteries, check they are correctly installed and not drained.
Link light does not come on
• Check that both the Baby and Parent units are switched on.
• If using batteries check that they are correctly installed and that they are not drained.
Link light is flashing green
• If you have pressed to use the Talk Back feature, the link light will flash to indicate one-way
communication between the units.
• The Units are searching for a communication link. Check they are within range of one another and
that the mains power (or batteries) are properly connected.
