BT Versatility Manual

Ofces Worldwide
The telecommunications services described in this publication
are subject to availability and may be modied from time to time.
Services and equipment are provided subject to British
Telecommunications plc’s respective standard conditions of
contract.
Nothing in this publication forms any part of any contract.
© British Telecommunications plc 2003
Registered ofce: 81 Newgate Street, London EC1A 7AJ
Registered in England No. 1800000
Printed in Ireland
PHME 42396/01/04
Part No. 2734.31000-2
Printed on paper which meets international environmental standards
The CE Marking on this equipment indicates
Compliance with the following
This device conforms to Directive 1999/5/EC on
Radio Equipment and Telecommunications
Terminal Equipment as adopted by the
European Parliament And Of The Council
Installation and
Maintenance
Manual
BT Versatility
Communications without
the complications
Installation.indd 3/12/2004, 2:12 PM1

BT Versatility
Installation and maintenance Manual
1
Contents
Introduction 2
General overview 2
Safety Precautions during installation and
system upgrades 3
Electrostatic precaution (ESP) 3
Lightning and surge voltage protection 3
Installation checklist 6
Installing the Central Control Unit 7
CCU Location(CCU) 7
Mounting the CCU 7
CCU Mounting bracket clearances 8
Mounting the CCU 9
Modules located in the CCU 10
Module location 10
System Expansion 11
Installing the Backplane wall bracket 11
Mounting the CCU with two brackets 11
Mounting the Backplane 12
Expansion Modules 13
Installing an Expansion module 14
Analogue line module 15
Installing the Analogue Module in the CCU 15
Basic Rate ISDN expansion module 17
Installing the Basic Rate ISDN Module in
the CCU 17
System ISDN settings 19
T0interface termination 19
S0interface termination 19
Voicemail module 20
Primary Rate Interface (Availability TBC) 21
Connecting the battery backup unit to
the system 22
Connecting the Battery 23
Featurephone V16 24
V16 Featurephone connections
(underside of phone) 24
Featurephone V8 25
V8 Featurephone connections
(underside of phone) 25
Attaching the Featurephone desk plinth
(V8 and V16) 26
V16 expansion console 27
Feature phone with console 27
Clip, Plinth and installation of the V16 expansion console 28
Wall-mounting a Featurephone 29
Door Intercom 30
Cabling the unit 31
Connecting the extensions 31
CCU connections 33
Door Intercom 33
Doorstrike 33
Connecting a MOHI unit 36
Connecting a PA 37
(public Address) amplifier 34
Connecting a PC or
Printer to the Serial Port 34
Ports Module MDF Connections 34
Internet Module MDF Connections 35
Options Module MDF Connections 35
Central Bell 36
External Extension 36
Expanding an Existing system 37
Installing an additional Network
(Analogue or ISDN) module 37
Installing additional modules 37
Maintenance procedures 38
Hot Swapping faulty modules 38
Replacing a faulty Module MDF 39
Replacing Faulty PCBs 40
Replacing the 008 extension board 40
Replacing the CCU Control PCB 41
Power supply unit spare fuse 42
Replacing the Power Supply Unit 43
Replacing the CCU MDF 43
Power fail 44
Analogue 45
ISDN 45
Power up and test 46
Switch on 46
Commissioning 46
Programming 47
Internet Module Programming 49
Installation Wizard 49
ADSL 50
ISDN 51
Recommendations for customer training 52
Troubleshooting 53
Technical specification 54
INDEX 57

BT Versatility
Installation and maintenance Manual
2
Introduction
This document describes the practices to be adopted by field engineers during installation and
maintenance of
the BT Versatility. A more detailed description of the product, along with customer
programmable facilities and features, may be found in the BT Versatility
Owner's Manual, which should
be read in conjunction with this document.
General overview
• The BT Versatility is a new converged PBX and Data product, which can be connected to Analogue ,
ISDN and LAN networks.
• The BT Versatility is a hybrid PABX/key-system, which may be equipped with Featurephones (V8 or
V16) or standard two wire DTMF telephones. Extensions can also be equipped with Fax or Answering
machines.
• The BT Versatility is modular in construction and can be upgraded by adding various system
expansion modules (Ports Modules, Options Module, Music on Hold module and Internet Module).
• The BT Versatility allows Voice connectivity to ISDN and Analogue MF or LD exchange lines.
• The BT Versatility may be configured with up to four internal S-Bus interfaces for connection to
approved ISDN apparatus.
• The BT Versatility is a versatile, easy-to-use system, which is simple to install and maintain.
• The BT Versatility Internet Module. This provides Data connectivity to the Internet via ISDN or ADSL
lines. It also provides an internal LAN.
The CE Marking on this equipment indicates compliance with the
following:
This device conforms to Directive 1999/5/EC on Radio Equipment
and Telecommunications Terminal Equipment as adopted by the
European Parliament And Of The Council.

BT Versatility
Installation and Maintenance Manual
3
Safety Precautions during installation and system upgrades
Always unplug or isolate the mains supply when installing or upgrading the system.
After installing the central control unit (CCU) and all required modules, ensure
that the following points are checked before switching the mains power on:
• The cabled extensions have a DTMF telephone or a (V8/V16) Featurephone
connected.
• The CCU cover is in place and locked.
After switching on the Mains allow approximately 30 seconds for the CCU to go through its power up
routine.
Electrostatic precaution (ESP)
The BT Versatility contains electrostatic components. To ensure long-term reliability of the system,
electrostatic precautions should be taken when handling any of the system PCBs that are not enclosed in
plastic. An ESP pillar is located on the CCU MDF.
Lightning and surge voltage protection
Extension cabling should not be exposed to high voltage surges, (for example,
surges induced by lightning or neighbouring high current-carrying cables). If
this is a possibility, external protection of the Main Equipment and Extensions
using ‘earthed line surge protectors’ is essential.

BT Versatility
Installation and maintenance Manual
4
BT Versatility - Packages, Spares and Maintenance Items
BT Code
BT Versatility Pro. Plus(Includes System, VM, 1M,2V8)
BT Vers Pro Plus 2+8 Digital VDS 007193
BT Vers Pro Plus 4+16 Digital VDS 007194
BT Vers Pro Plus 6+24 Digital VDS 007195
BT Vers Pro Plus 8+32 Digital VDS 007196
BT Versatility Advanced Digital (System, 8 Port VM Pro , 4V8 and V16 with the 12/32 ) N/A
BT Vers Adv 2+8 Dig VDS 017672
BT Vers Adv 6+16 Dig VDS 017673
BT Vers Adv PRI+16 Dig VDS 017674
BT Vers Adv PRI+24 Dig VDS 017675
BT Vers Adv PRI+ 32 Dig VDS 017676
BT Versatility Voice Digital (Includes System, 2V8) N/A
BT Vers Voice 2+8 Dig VDS 017677
BT Vers Voice 6+16 DigVDS 017678
BT Vers Voice PRI+16 Dig VDS 017680
BT Vers Voice PRI 24 Dig VDS 017681
BT Vers Voice PRI+32 Dig VDS 017682
BT Versatility Advanced Analogue (System, 8 Port VM Pro , 4V8 and V16 with the 12/32 ) N/A
BT Vers Adv 2+8 Analog VDS 017683
BT Vers Adv 6+16 Analog VDS 017684
BT Vers Adv 8+24 Analog VDS 017685
BT Vers Adv 12+32 Analog VDS 017686
BT Versatility Voice Analogue (Inculdes System, 2V8) N/A
BT Vers Voice 2+8 Analog VDS 017687
BT Vers Voice 6+16 Analog VDS 017688
BT Vers Voice 8 +24 Analog VDS 017689
BT Vers Voice 12+32 Analog VDS 017690
Versatility Value Add Packs N/A
BT Versatility VM & 4xV8 Phone Pack VDS 007213
BT Versatility Phone Pack 1 - 2 x V8 VDS 007214
BT Versatility Phone Pack 2 - 4 x V8 VDS 007215
BT Versatility Phone Pack 3 - 2 x V16 VDS 007216
BT Versatility Phone Pack 4 - 6 x V VDS 007217
BT Versatility Phone Pack 5 - V16 & V16 Console VDS 007218
Additional items N/A
BT Versatility Digital Line Module ISDN VDS 007219
BT Versatility Analogue Line Module VDS 007220
BT Versatility Voicemail 2P VDS 007221
BT Versatility Voicemail 4P VDS 007222
BT Versatility Internet Module VDS 007223
BT Versatility BBU VDS 007224

BT Versatility
Installation and Maintenance Manual
5
BT Versatility 8 Port Extension Module VDS 007225
BT Versatility Hospitality Application VDS 007226
BT Versatility Options Module VDS 007227
BT Versatility V Telephone VDS 007228
BT Versatility V8 Featurephone 007229
BT Versatility V16 Featurehone VDS 007230
BT Versatility V16 XP Expansion Console VDS 007231
BT Versatility Door Intercom VDS 007232
BT Versatility Expansion Backplane VDS 007233
BT Vers V/email Pro 8P VDS 017691
BT Vers EMOH Module VDS 017693
BT Vers PRI Module VDS 017694
BT Vers M/board (40 Port) VDS 017695
BT Vers PSU (40 P) VDS 017696
BT Vers PRI Module Refurb 767408
BT Vers V/mail Pro 8P Refurb 767409
BT Vers M/board (40 P) Refurb 767410
BT Vers PSU (40 P) Refurb 767411
Maintenance items N/A
BT Versatility V Featurephone MTC 007234
BT Versatility V8 Featurephone MTC 007235
BT Versatility V16 Featurehone MTC 007236
BT Versatility V16 XP Exapansion Console MTC 007237
BT Versatility Main System MDF Top Cover MTC 007238
BT Versatility Main System Front Cover MTC 007239
BT Versatility Module Access Door Cover MTC 007240
BT Versatility Wall Bracket (for CCU or Backplane) MTC 007241
BT Versatility System PSU - PCB Card only MTC 007242
BT Versatility Main CCU Extension Card MTC 007243
BT Versatility Motherboard MTC 010541
BT Versatility CCU MDF Card MTC 007245
BT Versatility V.24 Cable - incl DTYPE MTC 007246
BT Versatility 2m RJ45 Cable ISDN & Interet Mod WAN MTC 007247
BT Versatility CCU Housing screw 1/4 turn 4pk MTC 007248
BT Versatility BBU Blanking Plate MTC 007249
BT Versatility Expansn Backplane Bracket & Screw Pk MTC 007250
BT Versatility 8 Port Extension Module MDF Cover MTC 007253
BT Versatility 8 Port Extension Module (no MDF) MTC 007254
BT Versatility 8 Port Extension Module MDF only MTC 007255
BT Versatility Internet Module MDF Cover MTC 007256
BT Versatility Internet Module (no MDF) MTC 007257
BT Versatility Internet Module MDF MTC 007258
BT Versatility Options Module MDF Cover MTC 007259
BT Versatility Options Module (no MDF) MTC 007260

BT Versatility
Installation and maintenance Manual
6
BT Versatility Options MDF MTC 007261
BT Versatility Mod Retentn Long 1/4 turn Screw MTC 007262
BT Versatility V16 Console to V16 Connection Cable MTC 007263
BT Versatility V16 PSU MTC 007264
BT Versatility PSTN Module MTC 007265
BT Versatility ISDN2 Module MTC 007266
BT Versatility Voice Mail Module 2 Port MTC 007267
BT Versatility Voice Mail Module 4 Port MTC 007268
BT Versatility Battery Backup Module MTC 007269
BT Versatility Door Intercom MTC 007270
Installation checklist
Carry out the following steps to install the system:
FIRST, read the safety and precaution information on page 3 carefully.
SECOND, mount the Main Equipment as detailed in the section on page 7
THIRD, install the Network and Expansion modules as required
At least one Analogue Line Module must be installed to access the Analogue network.
At least one ISDN Basic Rate Module or ISDN Primary Rate Module must be installed to access the
ISDN network.
A Ports module must be installed if the following is required:
• More than 8 Extensions
• More than four Analogue Lines
• More than two ISDN Basic Rate Accesses
• More than one ISDN S-bus
If no options module is installed "External Music on Hold" can be provided through the MOH Module
connected to an extension. See page 33 for details on connection of the unit.
An Internet module must be installed if an internal LAN or connection to an ADSL Line is required
A Voice Module must be installed to provide Voicemail or Auto Attendant functionality.
The Battery Back Up Module and battery must be installed if battery back up is required.
FOURTH, cable the Extensions to the Main Equipment and install the system Featurephones and standard
telephones as detailed in the Cabling Section Page 31 . This section also covers installation the following:
• Long-line Extension,
• Door Intercom,
• Doorstrike,
• Central Bell,
• External Music-on-Hold,
• Public Address
• V24 Interface to provide Call Logging.
FIFTH, cable the Analogue and ISDN Line connections as detailed in the cabling section Page 31.
SIXTH, commission the system and provide customer training as detailed in the Commissioning section
Page 46 and 47.

BT Versatility
Installation and Maintenance Manual
7
Installing the Central Control Unit
CCU Location(CCU)
The CCU is intended for installation in a residential or office-type environment. It needs to be mounted at
a convenient working height on a dry, flat wall. The normal height is 1.5 m from the floor to the bottom of
the CCU case.
Do not site the CCU where it will be subjected to excessive levels of heat, dust,
damp or high humidity. Locating the equipment near sources of electromagnetic
radiation, such as heavy electrical switch gear, lift machinery or electric arc welders,
should be avoided.
Allow at least 150 mm of free space all around the CCU for ventilation.
The CCU needs to be located within two metres of a dedicated mains power supply outlet. The CCU must
not share the same mains supply socket with any other electrical appliance.
Mounting the CCU
When a suitable location has been found, mark the screw locations on the mounting surface, using the
mounting bracket provided.
If the CCU is being mounted on masonry or plasterboard, suitable wall plugs must be used. Drill and plug
four holes in the wall at the marked locations. The holes should be deep enough to accept a 2.5cm screw.
Wall mount bracket

BT Versatility
Installation and maintenance Manual
8
CCU Mounting bracket clearances
The main unit is mounted on a wall using the bracket supplied and should have top and side clearance as
shown below.
CCU Mounting Bracket
If the system is to be equipped with a Ports, Options or Internet module then two mounting brackets need
to be installed.
CCU Bracket + Backplane Bracket
300mm min
300mm
min
300mm

BT Versatility
Installation and Maintenance Manual
9
Mounting the CCU
The CCU is mounted on the bracket by sliding it on from the left hand side. The marks on the side of the
CCU must be lined up with the flanges on the wall bracket as shown below before sliding the CCU into
place. When you slide it fully to the right-hand side of the bracket the CCU is automatically locked in
place.
To remove the CCU depress the lock located on the left-hand side of the wall bracket. Slide the CCU to
the left to remove it from the bracket.
300mm min
Flanges
line marks up
with flanges
