Bticino D45 User manual

1
323018
72 mm
59,5 mm
33 mm
105 mm
94 mm
POWE R
+
-
1 2
POWE R
+
-
5678
4
3
D45 System
Description
Entrance panel/Switchboard shunt
D45 System interface device used to connect the entrance panel and the switchboard
to the system. This device automatically switches over the video channels. Must be
configured. DIN RAIL installation.
Technical data
Power supply: 30 Vdc
Stand by current absorption: ≤ 70 mA @ 30 V
Max. operating current absorption: ≤ 70 mA @ 30 V
Stand by power consumption: 2.1 W
Operating power consumption: 2.1 W
Operating temperature: (-10)-(+40)°C
Dimensional data Legend
1. Configurators housing
2. Serial port interface for configuration download and firmware update
3. S1 - S2 keys for pushbuttons device configuration (NOT USED)
4. LED indicator for configuration status
5. RJ45 connector for digital entrance panel or switchboard connection
6. B2 RJ45 connector for main system BUS connection
7. B1 RJ45 connector for main system BUS connection
8. Auxiliary power supply input connector (30 V)
Front view
Lower view
BT00463-b-EN 13/05/2013

2
323018
CF1 CF2 CF3 CF4 CF5 CF6
MC
min
MC
min
MC
max
MC
mac DEV DIR
CF1 CF2 CF3 CF4 CF5 CF6
MC
min
MC
min
MC
max
MC
mac DEV DIR
123456
CF1 CF2 CF3 CF4 CF5 CF6
MIN MIN MAX MAX DEV DIR
0 4 0 4 0 1
CF1 CF2 CF3 CF4 CF5 CF6
MIN MIN MAX MAX DEV DIR
0 4 0 5 1 0
CF1 CF2 CF3 CF4 CF5 CF6
MIN MIN MAX MAX DEV DIR
0 4 0 5 1 1
Entrance panel/Switchboard shunt
Configuration
Two different device configuration ways available:
WAY 1) Configuration settings by inserting phisical configurators
WAY 2) Configuration by using SF2 Software and PC connection
Configuration by inserting phisical configurators - WAY 1:
Meaning of the configuration places:
*Min: the minimal number connected to the Backbone/main EP or to the switchboard
at main EP/Switchboard of interface.
**Max: the maximal number connected to the Backbone/main EP or to the switchboard
at main EP/Switchboard of interface.
CONFIGURATION PLACE MODE 1 MODE 2
CF1 Min*
Same as Mode 1
CF2
CF3 Max**
CF4
CF5 DEV
CF6 DIR
DEV = options of main EP/Switchboard types:
DEV
0Switchboard
1Backbone/main EP
DIR: options of main EP/Switchboard wiring directions:
DIR
0The Switchboard is connected to the B1 interface and backbone/main EP to the B2 interface
1The backbone/main EP is connected to B1 and the Switchboard to B2
The DIR configuration for the device wiring direction must satisfy the following rules or
they will lead to irregular working of the system :
1. Riser shunt must be connected at the B1 connector interface of all interface in the
relevant zone.
2. The wiring direction of the switchboard and the main EP can be set through the
DIR configuration place, but all of interfaces wiring directions must be identically
configured in the project.
3. Pushbutton-configuration operation (it will be invalid when the configurator is
inserted).
Value of the configuration place (from 0 – 9)
Code of the configuration place (1 to 6)
Configuration examples:
Example (A):
Item 323018 is used to extend one switchboard.The switchboard address range is 4; all
main EP are installed in the B1 port of 323018, configuration as follows:
Configuration examples:
Example (C):
Item 323018 is used to extend one Switchboard, Switchboard address range is 4; all
main EP are installed in the B1 port of 323018, configuration as follows:
POSITION MODE 1 VALUE FOR CONFIG. REMARKS
CF1 MIN 0 x
CF2 MIN 4 x
CF3 MAX 0 x
CF4 MAX 4 x
CF5 DEV 0 x
CF6 DIR 1 x
Configuration examples:
Example (B):
Item 323018 used to extend the main EP.The main EP address range is 4 to 5; all switch-
boards are installed in the B1 port of 323018, configuration as follows:
POSITION MODE 1 VALUE FOR CONFIG. REMARKS
CF1 MIN 0 x
CF2 MIN 4 x
CF3 MAX 0 x
CF4 MAX 5 x
CF5 DEV 1 x
CF6 DIR 0 x
POSITION MODE 1 VALUE FOR CONFIG. REMARKS
CF1 MIN 0 x
CF2 MIN 4 x
CF3 MAX 0 x
CF4 MAX 5 x
CF5 DEV 1 x
CF6 DIR 1 x
BT00463-b-EN 13/05/2013

3
323018
POW E R
+
-
X X X X 1 1 X X X X 1 1 X X X X 0 1 X X X X 0 1
X X X X 0 1X X X X 0 1
323003
323005
323018
323001 323001
323018
323004
323004 323007
323001 323001
323018 323018 323018 323018
Entrance panel/Switchboard shunt
Wiring diagram
Configuration by using SF2 software and PC connection - WAY 2:
This is the enhanced way to download the device configuration to interface device previously created by using SF2 configuration software and a personal computer. To transfer file use
the configurator hardware tool 323020 serial interface.
WARNING: in order for the communication to take
place, floor shunt device must be powered and not
physically configured.
Connect the EP
Backbone
main EP
Backbone
main EP
Backbone
main EP
Backbone
main EP
Backbone
main EP
323020
configuration
tool
Connect Floor shunt
