Bticino Classe100 X16E Operating manual

User and installation manual
www.bticino.com
Classe100 X16E

Classe100 X16E
User and installation manual

3
Contents
Classe100 X16E
User and installation manual
Quick guide 4
Answer a call 4
Auto-switching on and camera scrolling 6
Call another room or apartment (intercom) 8
Dissociate a smartphone 10
Dissociate an user 11
Customise the home page of the Door entry Classe100X App 13
General information 15
Warnings and recommendations 15
Avvertenze normative 16
Front view 17
Function keys and status LEDs 17
Rear view 19
Installation 20
Dimensional data and recommended installation heights 20
Wall-mounted installation 20
Installation on the tabletop bases 344692 (optional) 21
Configuration 23
Programming of the programmable keys 24
Use from the device 31
Functions 31
Answer a call 31
Call another room or apartment (intercom) 32
PE or cameras direct auto-switching on 34
Door lock release 36
Paging 37
Services 38
Inductive loop 38
Door status 39
Professional Studio (Office) 40
Safe door lock 41
Device adjustments and settings 42
Use of the joystick 42
Wi-Fi adjustments and settings 43
Settings 54
Use with the Door entry Classe100X App 57
Introduction 57
Account registration 58
Authentication 60
Forgotten password 61
Help 62
FAQ 63
Sending log 63
Association of the device 64
Home page 73
Display the cameras or Entrance Panels 74
Open door locks 76
Staircase Lights 76
To receive a video door entry call 77
Call home: Call your Classe100 X16E 78
Menu 80
Users 81
Settings 85
Account 98

Quick guide
4
Classe100 X16E
User and installation manual
2
3
1
Quick guide
Answer a call
1. Touch to answer the call.
2. If necessary, during the call press the joystick to display the audio/video parameter adjustment
icons.
3. Move the joystick up/down to select the type of parameter for which you want to modify the
value (see the following table) among:
– Speaker volume (Parameter that can be adjusted only with active audio);
– Image brightness;
– Image contrast;
– Image colour.

Quick guide
54
Classe100 X16E
User and installation manual
4
5
5. Touch to end the call.
4. Touch to open the main Entrance Panel door lock

Quick guide
6
Classe100 X16E
User and installation manual
3
1
2
Auto-switching on and camera scrolling
Note: switching from one camera to another is also possible without enabling the audio.
2. If necessary, touch to activate the audio communication
3. Touch to display another Entrance Panel or camera (using the scrolling service). When
switching from one camera to the next the key lights up.
1. Touch to display the Entrance Panels or the cameras in your system.

Quick guide
76
Classe100 X16E
User and installation manual
4
4. Touch to end camera display mode, or wait for the automatic switch off time to elapse.

Quick guide
8
Classe100 X16E
User and installation manual
Call another room or apartment (intercom)
1
A
#2
Key (A) lights up to indicate that the call is active.
1. For example, touch programmable key to activate the communication with the Internal Unit
(e.g. configured as 2)
Note: the programmable key to use for calling a certain Internal Unit is set by the installer (see
Programming of the programmable keys).

Quick guide
98
Classe100 X16E
User and installation manual
#2
When the Internal Unit answers, the key starts flashing. Touch it to end the call or establish
communication with the Internal Unit.
Note: if during the conversation a call is received from the Entrance Panel, the conversation is
interrupted in order to answer the Entrance Panel call.

Quick guide
10
Classe100 X16E
User and installation manual
1
2
3
4
5
Dissociate a smartphone
4. Touch to continue.
5. Touch to confirm
The user will no longer be able to manage the system using that smartphone.
To re-associate the smartphone simply repeat the authentication process.
1. Touch to open the pull-down menu.
2. Touch to open the user section.
3. Scroll to dissociate a smartphone.

Quick guide
1110
Classe100 X16E
User and installation manual
1
2
3
4
5
Warning: if the user to associate is the only one left, the system will suggest a tutorial to reset the device
1. Touch to open the pull-down menu.
2. Touch to open the user section.
3. Scroll to dissociate a user, and therefore all the devices associated with the same.
Dissociate an user
4. Touch to continue.
5. Touch to confirm

Quick guide
12
Classe100 X16E
User and installation manual
7
6
If the user is the main user, it will be necessary to indicate a replacement as main user.
The main user has been dissociated. To return to manage the system through the App you will
have to:
– reset Classe100 X16E using the specific procedure;
– complete the authentication;
– repeat the association with Classe100 X16E.
6. Touch to indicate the new main user.
7. Touch to confirm. You will be redirected to the Home page

Quick guide
1312
Classe100 X16E
User and installation manual
2
3
1
4
Customise the home page of the Door entry Classe100X App
1. Touch to open the pull-down menu.
2. Touch to open the setting section.
3. Touch to customise the Home page
4. Touch to modify the description of the main EP door lock
5. Enter the new description
6. Touch to display the Staircase Light key on the home page
5
Door lock 2
Door lock 2
6

14
Quick guide
14
Classe100 X16E
User and installation manual
Door lock 2
7
8
D
C
A
B
Door lock 2
Door lock 2
Note: the number and types of objects available for customisation depend on the way your installer has
configured Classe100 X16E (see Programming of the programmable keys).
In addition to the Staircase Light key, it is also possible to show on the homepage the Entrance Panels/
Cameras (A) and Door Locks (B)corresponding to the programmable keys of your Classe100 X16E.
The Cameras/Entrance Panels will be available in the appropriate area (C), while for the Door Locks
there is a dedicated key (D).
7. Touch to confirm the modifications.
8. Touch to return to the home page.
9. Now the staircase light key is available.
Door lock 2
9

1514
Classe100 X16E
User and installation manual
14
General information
Warnings and recommendations
The Classe100 X16E video internal unit must be connected to a Wi-Fi network with the following
features:
– IEEE 802.11 b/g/n (2,4 GHz) 13 channels
– Encrypting and authentication methods supported:
– OPEN WPA-PSK networks
– TKIP WPA2-PSK included
– included AES WEP 64 bits (ASCII 5 figure or hexadecimal 10 figure codes)
– WEP 128 bits (ASCII 13 figure or hexadecimal 26 figure codes)
– WPS authentication (supported for WPA2-PSK)
It is important to read this manual carefully before proceeding with the installation.
The warranty becomes automatically void in case of negligence, improper use, tampering by
unauthorised personnel.
The Classe100 X16E video internal unit must only be installed indoors; it must not be exposed to
water drops or splashes; it must be used only on BTicino 2 WIRES digital systems.
Note: a domestic Wi-Fi with internet access is needed for the connection between the Classe100 X16E
video internal unit and the smartphone.
To use the service, the Customer must acquire the technical equipment which allows access to the
Internet, on the basis of an agreement made by the Customer himself with an ISP (Internet Service
Provider). BTicino plays no part in this.
The customer must install the Door Entry CLASSE100X app on his smartphone so that he can use some
services which BTicino supplies as extras to the normal basic functions of the Classe100 X16E.
The services offered by means of the app require being able to interact with Classe100 X16E remotely
and through the Internet.
In these cases the integration and good working between Classe100 X16E and app may depend on:
– a) quality of the Wi-Fi signal;
– b) type of access contract to the home internet;
– c) type of data contract on the smartphone;
– d) configuration of the router.
When one of these 4 elements does not conform with the specifications required for product operation,
BTicino accepts no responsibility for any faults.
The Door Entry CLASSE100X app operation with screen off (background) may be compromised by the
applications installed on the smartphone that:
– optimise the use of the battery and the energy saving;
– protect the device (antivirus or similar programs)
The product in fact supports a VoIP streaming system. You must therefore check with your smartphone
data network contract that it does not block it.
We would like to inform you that the service provided by BTicino by means of remote use via the app
involves the use of data. The cost linked to data usage depends on the type of contract which the
customer has with his ISP (Internet Service Provider) and is solely the customer’s responsibility.

16
Classe100 X16E
User and installation manual
Regulatory warnings
Read carefully before use and keep for future reference
Touching the units with wet hands is forbidden
Using liquid cleaners or aerosols is forbidden
Blocking the ventilation openings is forbidden
Modifying the devices is forbidden
Removing protective parts from the devices is forbidden
Installing the units near liquids and powders is forbidden
Installing the units near heat sources is forbidden
Installing the units near harmful gases, metal dusts or similar is forbidden
Fastening the units on unsuitable surfaces is forbidden
Danger of electrical shock
Risk of devices falling because the surface on which they are installed collapses
or inappropriate installation
Switch the power supply OFF before any work on the system
Caution: Installation, configuration, starting-up and maintenance must be
performed exclusively by qualified personnel.
Check that the wall installation has been carried out correctly
Lay out the wires respecting the standards in force
Connect the power supply wires as indicated
Use only the items indicated in the technical specifications for any system
expansions

1716
Classe100 X16E
User and installation manual
1
2
3
4
1. 5” (16:9) display
2. Speaker
3. Tactile guides for the blinds
4. Microphone
Front view
Function keys and status LEDs
Note: when pressed, the keys light up and emit a “beep” (that can be deactivated using the procedure).
Note: the device initialisation procedure can last up to 2 minutes.
Icon Meaning
Wi-Fi signal notification LED:
When it is OFF, the Wi-Fi is disabled or works correctly.
When it flashes red it indicates that the Wi-Fi is active but not connected to a
network.
When green and on steady, Classe100 X16E is exchanging data with the Door Entry
CLASSE 100 APP (Entrance Panel call/Automatic Switching On/Call Home)
Bell exclusion notification LED:
When on red flashing, it means that the call ringtone is disabled,
Programmable touch keys *
Use these keys for intercom calls, activate Entrance Panels and Door Locks. The
functions that can be completed depend on the configuration set by the installer
(see Programming of the programmable keys).
Door lock release touch key *
During the connection with an Entrance Panel, use this key to release the door
lock of that Entrance Panel, when idle, the same key releases the door lock of the
associated Entrance Panel. When on white flashing, it means that the Professional
Studio function is active.
Entrance panel/scrolling activation touch key
This key has two functions: It can be used to switch on the camera of the
associated Entrance Panel, and to scroll through the connected cameras and/or
entrance panels.

18
Classe100 X16E
User and installation manual
Communication disabling key
Use this key to answer a call: when a call is answered, it switches on red; when the
call is terminated it switches off.
Staircase light touch key
Use this key to switch the Staircase Light on
Communication enabling key
Use this key to answer a call: when a call is received, the key starts flashing, once
the call is answered the light switches off.
* If the LEDs flash white when pressed, the “safe door lock” service is active and the key is deactivated.

1918
Classe100 X16E
User and installation manual
45
PM
N
BTICINO
V.le Borri, 231
21100 (VA) ITALY
Made in Italy
2 1 5M 1 BUS
2-1
ON OFF
1
2
3
678910
Rear view
1. Mini USB socket for device Firmware update
2. OFF / ON micro-switch for“safe door lock” service
ON=
Note: to activate the service with device not powered
3. Configurator socket
4. Line termination ON/OFF micro-switch
5. ON / OFF micro switch to enable the additional power supply
6. 2 WIRES SCS/BUS connection clamps
7. Clamps for the connection of an external call to the floor pushbutton
PM
N
BTICINO
V.le Borri, 231
21100 (VA) ITALY
Made in Italy
2 1 5M 1 BUS
2-1
ON OFF
MasterSlave
ON CTS
12
8. Additional bell connection clamps (5M – 1). The connection must be point - point on the
clamps of the additional bells
9. Additional power supply clamps (2– 1)
10. Joystick for adjustments ans programming
Caution: Installation, configuration, starting-up and maintenance must be performed
exclusively by qualified personnel.

20
Classe100 X16E
User and installation manual
160 – 165 cm
135 – 140 cm
164 mm
165 mm
20,5 mm
1
Box
502E - 503E
1
Ø max 5 mm
2
Installation
Dimensional data and recommended installation heights
Wall-mounted installation
Recommended height, unless different regulations are specified.
Caution: Installation, configuration, starting-up and maintenance must be performed
exclusively by qualified personnel.
