Buckingham 21402 User manual

BUCKINGHAM MFG.
PN 21402 –HOOK & LOOP FASTENER FOOT STRAPS WITH QC BUCKLE
ATTACHMENT INSTRUCTIONS
(USE WITH RING TYPE CLIMBERS ONLY)
Note: hardware, materials and colors may vary from that shown.
Attach the foot strap to the climber by separating the split ring
and inserting it thru the climber ring as shown in Fig. 1. Rotate
the split ring until it is completely inside the climber ring.
Ensure the female half of the QC Buckle is towards the front
of your foot and the strap end tab is facing down when the strap
is lying flat as shown in Fig. 2.
Step into the climber (Fig. 2).
Wrap the footstrap around the back of your ankle and over the top of
your foot (Fig. 3).
PN 21402.doc (02/5/19)
PN 230443 1 of 2
Fig. 1
Fig. 2
Fig. 3
Strap End Tab
Facing Down
Female Half of QC Buckle
Facing Front of Foot

Insert the male half of the QC buckle into the female half of the
QC buckle (Fig. 4).
To tighten the foot strap, grasp the strap end tab and pull
the tail of the foot strap towards the QC buckle separating
the loop fastener from the hook fastener (Fig. 5). Once
released, pull the tail away from the QC buckle and through
the slot of the male half of the buckle, tightening the strap
until snug on your foot. Finally, fold the strap over and attach
the strap loop fastener to the strap hook fastener. To ensure a
proper wrap, always ensure that as a minimum the minimum
wrap label, has been pulled through the slot of the male half
of the QC buckle (Fig. 6), before aligning and attaching the
hook fastener to the loop fastener. Failure to do so, may cause
release, resulting in serious injury or death.
Note: If the minimum wrap label will not pull through the slot of the m
ale half of the QC buckle (Fig. 7) do not use the strap. Replace the strap
with a longer one to ensure proper bonding of the hook and loop
fastener.
BUCKINGHAM MFG. CO.
BINGHAMTON, NY
1-800-937-2825
www.buckinghammfg.com
Information contained in these written instructions supersedes all other information (written, audio, video etc.) produced by Buckingham Mfg. prior to the revision date of this document.
PN 21402.doc (02/5/19)
PN 230443 2 of 2
Fig. 4
Fig. 6
Fig. 5
Fig. 7
Hook
Fastener
Loop
Fastener
Strap
End Tab
Minimum
Wrap Label
