PlumeSafe®Turbo™
Surgical Smoke Plume Evacuator
BUFFALO FILT ER
Buffalo Filter®is a registered trademark of Buffalo Filter LLC in the United States and other countries. © 2018 Buffalo Filter LLC. All Rights Reserved. 900989 REV J
www.buffalofilter.com +1.716.835.7000 (International) 1.800.343.2324 (United States) [e-mail]
Operator’s Manual
EN

For a period of three (3) years following the date of delivery, BUFFALO FILTER warrants
the Turbo Auto-Sense™ against any defects in material or workmanship. BUFFALO FILTER
will repair or replace (at BUFFALO FILTER’S option) the same without charge, provided that
routine maintenance as specied in this manual has been performed using replacement
parts approved by BUFFALO FILTER. is warranty is void if the product is used
in a manner or for purposes other than intended.
© 2018 BUFFALO FILTER®
Bualo, New York USA 14086
1-716-835-7000
www.bualolter.com
Customer Service: 800-343-2324 (U.S. Only)
1-716-835-7000 (International)
e revision level of this manual is specied by the highest revision letter found
on either the inside front cover or enclosed errata pages (if any).
Manual Number 900989 Rev J
PlumeSafe® TURBO Auto-Sense™
MEDICAL – GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL HAZARDS ONLY
IN ACCORDANCE WITH UL 60601-1, ANSI/AAMI ES60601-1 (2005, 3rd ed.),
CAN/CSA C22.2 NO. 601.1, AND CAN/CSA-C22.2 No. 60601-1 (2008)
9D93
ANSI/AAMI ES60601-1: A1:2012, 1:2009/(R)2012 and A2:2019/(R)2012,
and CSA CAN/CSA-C22.2 NO. 60601-1:14
is device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.
EC REP
EMERGO EUROPE
Prinsessegracht 20
2514 AP The Hague
The Netherlands

Section Title Page
1.0 SYSTEM DESCRIPTION 4
1.1 Introduction
1.2 Inspection
1.3 Operational Information
1.4 Cautions and Warnings
2.0 OPERATING INSTRUCTIONS 11
2.1 System Controls
2.2 ViroSafe® Filter Instructions
2.3 Set-up and Operation
2.4 Specications
3.0 MAINTENANCE 22
3.1 General Maintenance Information
3.2 Cleaning
3.3 Periodic Inspection
3.4 Troubleshooting
4.0 CUSTOMER SERVICE 23
4.1 Equipment Return
4.2 Ordering Information
5.0 TERMS & WARRANTY 24
Figure Title
Page
1 Control Panel
11
Table of Contents
& List of Illustrations

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 4
1.1 Introduction
BUFFALO FILTER® Turbo Auto-Sense™ Smoke Evacuation Systems are intended to evacuate and lter
surgical smoke plume and aerosols created by the interface surgical tools with tissue, examples being
lasers, electrosurgery systems, and ultrasonic devices.
e Turbo Auto-Sense™ Smoke Evacuation Systems have been designed with a high suction, high ow
rate centrifugal action pump. e ultra-quiet motor is used to draw the surgical smoke from the surgical
site through the vacuum tubing and into the ViroSafe® lter where the surgical smoke is processed
by a series of lters. A single disposable lter is used to simplify the installation and removal during
lter changes. e lter is completely enclosed to protect the healthcare personnel from potential
contamination during lter changes. One Bualo Filter ViroSafe® lter contains four dierent stages
within to capture the smoke plume.
e rst stage ltration is a prelter whose function is to trap and remove gross particulate and casual
uid.
e second stage ltration is ULPA grade (Ultra Low Penetration Air) lter whose high-tech patented
(U.S. Patent #5874052) design captures particulates and micro-organisms from .1 to .2 microns at an
eciency of 99.999%.
e third stage ltration uses the highest grade virgin activated carbon, especially designed for Bualo
Filter for the removal and adsorption of odors and toxic gases produced by burning tissues. ese
harmful gases may constitute a health hazard to healthcare professionals who are subjected to prolonged
exposure. e activated carbon used in the Turbo Auto-Sense™ Smoke Evacuation Systems preferentially
removes toxic organic gases rather than water vapor and provides optimal odor removal.
e fourth stage ltration is an expanded foam used to trap activated carbon nes from migrating out of
the lter.
e electronic controls on the face panel of the Turbo Auto-Sense™ Smoke Evacuation System has been
designed “user friendly” and facilitate unit set up and operation. Please refer to Section 2.0 for Operating
Instructions.
1.2 Inspection
e Turbo Auto-Sense™ Smoke Evacuator has been thoroughly tested and inspected before shipment
from the factory. Please check the unit before using it to insure that no damage has occurred in transit.
If damage is evident, please contact BUFFALO FILTER Customer Service
at 1-800-343-2324 (US Only) or [phone] (International)
System Description
Section 1.0

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 5
In addition, please compare the accessories you receive with the standard accessories list below.
If an item is missing, please notify BUFFALO FILTER Customer Service.
Standard Accessories:
• Operator’s Manual
• Power Cord
• Pneumatic Footswitch
Please contact BUFFALO FILTER Customer Service to purchase the following accessories:
• Replacement Filters
• EZ Link® Remote Activator
• Hoses, Tubing, Laparoscopic Kits, Adapters, Wands & Other Accessories
1.3 Operational Information
e operational information contained in this section is intended for the customer review of regulatory
issues. e information pertains to the use of the products both domestically and internationally:
1. e BUFFALO FILTER Turbo Auto-Sense™ Smoke Evacuation System(s) complies with IEC60601.1
electrical specications in the following systems:
100/120 VAC 50/60 Hz, 220/240 VAC 50/60 Hz
2. Type of protection against electrical shock (UL 60601-1, Clause 5.1): Class I
3. Degree of protection against electric shock (UL 60601-1, Clause 5.2); Type CF Applied Part
4. Degree of protection against ingress of water (UL 60601-1, Clause 5.3): IPX1
5. Method of sterilization or disinfection recommended by BUFFALO FILTER (UL 60601-1, Clause 5.4):
Unplug Unit. Wipe unit with a damp cloth containing mild disinfectant solution
or soapy water. Wipe dry with a clean cloth. Do not steam sterilize.
6. Degree of safety of application in the presence of ammable anesthetic mixture with air or
with oxygen or nitrous oxide (UL 60601-1, Clause 5.5): Not Suitable
7. Mode of operation (UL 60601-1, Clause 5.6): Continuous
8. Upon request, BUFFALO FILTER will provide the following:
Service and Repair Instructions, including Circuit Diagrams and Parts List
9. e fuses in the power entry module are to be serviced by an authorized BUFFALO FILTER
technician as follows:
100/120 VAC, 50/60 Hz use 10 Amp 250 Volt Fuse (Slo-Blo)
220/240 VAC, 50/60 Hz use 8 Amp 250 Volt Fuse (Slo-blo)

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 6
10. is equipment needs special precautions regarding Electromagnetic Compatibility and needs to be
installed according to EMC information found in this manual.
11. is equipment utilizes mobile RF communications equipment that can aect medical
electrical equipment.
12. is equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. ese limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. is equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at their expense.
13. is equipment operates in the following radio frequency specications:
RX modulation: Pulse-width coded, AM 100% modulation
TX Frequencies: Manchester encoded,
A = fc =/- 423.75kHz, B = fc +/- 484.29kHz
Low bit: transition A to B
High bit: transition B to A
14. To isolate equipment from supply mains, unplug the power cord from the appliance inlet on
the unit or receptacle in the wall. Position the equipment to allow for ease of unplugging
power cord.
15. Potential Equalization Conductor: Terminal located on back panel for connection of
potential equalization. Conductor complies with requirements per IEC 60601-1 (2005).
e Turbo Auto-Sense™ Smoke Evacuation System(s) and all lters are not intended for
contact with patients.
1.4 Cautions and Warnings
Please note that all Cautions and Warnings
should be read and understood before any
use of this equipment.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 7
1.4.1 WARNINGS:
• Read this manual thoroughly, and be familiar with its contents prior to using this equipment.
• Test this equipment prior to a surgical procedure. is product was thoroughly tested at the factory
before shipment.
• Disconnect the unit from the electrical outlet prior to inspecting system components.
• e Turbo Auto-Sense™ system is only intended and suitable for the applications that are mentioned in
the operating instructions.
• e smoke evacuator produces a strong vacuum. Adjust the airow and the position of the
inlet end of the wand or tubing to prevent patient injury and to prevent suction of surgical
materials and surgical specimens.
• If the smoke evacuator is activated while the airow is set to a high speed, it may produce a
sudden, strong suction action. Check the airow setting before activating the smoke evacuator to
prevent patient injury and to prevent suction of surgical materials and surgical specimens.
• To maximize patient safety, the tubing or wand should not come into direct contact with
tissue. Otherwise, patient injury may result.
• e BUFFALO FILTER ViroSafe® lters and single-use accessories are completely disposable.
Please dispose of according to your local codes or regulations and hospital policy. ese lters
may be disposed of or incinerated, whichever is appropriate for your institution.
• Care should be taken to route the power cord, foot pedal, smoke evacuation tubing, and
EZ Link cable as to not cause a tripping hazard or crimping of cords.
• Do not operate this device in the presence of ammable or explosive gases.
• is equipment is intended for use by healthcare professionals only. is equipment may cause
radio interference or may disrupt the operation of nearby equipment. It may be necessary to
take mitigation measures, such as re-orienting or relocating the Turbo Auto-Sense™ or shielding
the location.
• e use of ACCESSORIES other than those specied by BUFFALO FILTER, or sold by BUFFALO
FILTER as replacement parts for internal components, may result in increased emissions or decreased
immunity of the Turbo Auto-Sense™.
• is equipment should not be used adjacent to or stacked with other equipment and that if
adjacent or stacked use in necessary, the Turbo Auto-Sense™ should be observed to verify normal
operation in the conguration in which it will be used.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 8
• Refer routine servicing to qualied biomedical technical personnel.
• Changes or modications not expressly approved by Bualo Filter could void the manufacturer’s
warranty.
• To avoid risk of Electric Shock, this equipment must only be connected to a supply mains with
protective earth.
e warranty on this product is void if any of these warnings are disregarded.
1.4.2 CAUTIONS:
• Federal law (United States of America) restricts this device to be used by, or on the order of a physician.
• Do not block either the tubing or the lter. If either becomes occluded or signicantly restricted, the
motor/blower may overheat and cause the unit to fail.
• Using any other lter or accessory not supplied by BUFFALO FILTER may cause damage and/
or cause the system to be inoperable and may void the warranty.
• Care must be exercised in the installation of hoses, adapters and suction canisters. Failure to
follow the procedures outlined in this manual may result in overheating of the motor and may
void the unit warranty.
• When using and accessory that will be connected to a surgical cannula, ensure that a mechanical
means of closing the ow to the evacuator is available, such as a stopcock to prevent unwanted loss of
pneumo gasses during the procedure or in case of system failure.
• is device is not intended for evacuation of uid. If uid is expected to be aspirated to the ViroSafe®
Filter, uid collection devices must be installed with the vacuum hose assembly. Failure to install a
uid collection device could cause lter blockage and electrical damage.
• e ViroSafe® Filter should be changed according to the life of the lter. e ViroSafe® Filter, used with
the Turbo Auto-Sense™ Smoke Evacuation System(s), should not be used for more the time specied
for each lter. Failure to change the lter may result in decreased eciency and contamination of the
electric motor, vacuum pump, and sound absorbing media within the unit.
• Do not block either the tubing or the lter during operation. An occlusion or signicant restriction
may cause the motor to overheat and the unit to stop working.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 9
• e installation of this equipment must be performed such that the intake and exhaust vents
located on the bottom of the system are not obstructed. Failure to properly install the unit may
cause reduced performance, damage and/or cause the system to be inoperable and may void the
warranty.
• e ambient temperature during operation must be kept between 50°F to 104°F (10°C to 40°C)
• e relative humidity during operation must be kept between 10% to 75%.
• An atmospheric pressure range of 700 hPA to 1,060 hPa.
• Storage environmental ambient temperature 14°F to140°F (-10°C to 60°C).
• Storage environmental relative humidity 10% to 75%.
ere are no user serviceable components in the Turbo Auto-Sense™ Smoke Evacuation System(s).
Refer service to qualied service personnel.
Use only with the power cord provided and always plug into a grounded outlet.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 10
Symbol Description / Meaning
DANGER HIGH VOLTAGE
CAUTION -
ELECTRICAL SHOCK HAZARD. DO NOT REMOVE COVER.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
TYPE CF APPLIED PART
IPX1 PROTECTION AGAINST INGRESS OF WATER AS DETAILED IN IEC 60529
ALTERNATING CURRENT
PROTECTIVE EARTH, (GROUND)
EQUIPOTENTIALITY
DENOTES THE DATE THE EQUIPMENT WAS MANUFACTURED
DENOTES THE MANUFACTURER OF THE DEVICE
NON-IONIZING RADIATION
CONSULT INSTRUCTIONS

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 11
2.1 System Controls
e Turbo Auto-Sense™ LCD control display is user-friendly and completely interactive, allowing for easy
to understand use (as displayed on the LCD screen).
Key Pad Diagram:
e following items are important for the operation of your system
POWER ON/OFF
e main power switch is located on the rear panel of your smoke evacuator. is switch completely
enables and disables the main power.
When the unit is powered on the
following LCD screen will appear.
Aer inserting a lter a screen will
ash for a few seconds to indicate
lter type and original life.
Next, the standard screen will appear
which displays information regarding
the unit’s current activity.
MOTOR ON/OFF
e Motor ON/OFF button is located on the LCD key pad (Figure 1). is button turns the motor (for
suction) on and o.
SUCTION CONTROL
e amount of suction may be adjusted using the UP or DOWN arrow buttons located on the key
pad (Figure 1). It is recommended that you select the lowest suction setting that eectively clears the
operative eld of surgical smoke.
Operating Instructions
Section 2.0
LCD Panel
Suction Motor
ON/OFF
Increase Suction
TURBO Mode Button
Decrease Suction

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 12
TURBO MODE
e TURBO button is located on the key pad (Figure 1). e amount of suction is signicantly increased
when this button is pressed. To return to NORMAL mode, press the TURBO button again.
FILTER LIFE REMAINING
e exact number of hours and minutes remaining on the ViroSafe® lter (in use) are displayed on the
LCD screen. When the lter’s life is consumed, time remaining will indicate that there are 0 hours and
0 minutes remaining. is line will continually ash. When the lter life reaches this point, a new lter
with time remaining should be inserted; however, the suction will still work. When the unit’s main power
is turned o or the system is le idle for more than 6 hours, a new lter or a lter with remaining lter
life MUST be inserted into the lter basket to allow the unit’s suction to turn back on.
When the lter’s life is exhausted the
LCD screen will ash “REPLACE FILTER.”
FOOTSWITCH
A pneumatic footswitch is provided. To activate the footswitch, simply plug the footswitch tubing into the
jack ( ) on the rear panel. e suction can now be switched ON/OFF by depressing the footswitch.
EZ LINK® REMOTE ACTIVATION DEVICE (EZLINK01)
For directions on using the EZ Link®, see instructions accompanying the EZLINK01.
CIRCUIT FUSES
Two 10 amp circuit fuses (8 amp for International systems) are located on the rear panel within the
power entry module. ese circuit fuses protect both the system and the operator from damage or injury.
SERVICE
When a service message appears, please contact Bualo Filter Customer Service for instructions. Below
are some examples of service screens that may appear.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 13
If this screen appears the system may
be in need of service for the motor.
Call Bualo Filter.
If this screen appears there may be a
problem with your system or lter.
Call Bualo Filter.
SETTING THE DEFAULT LANGUAGE
1. Turn the main power on without lter inserted.
2. Scroll through languages using suction control arrow buttons and select a language by pressing
motor button.
3. Smoke Evacuator will use this language as the default language.
4. To change the default language, remove lter and press motor on and turbo button simultanously.
5. Repeat step 2.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 14
Bualo Filter P/N: PSWTURBO AS & PSWTURBO AS/220
Conguration: Portable or tabletop
ViroSafe® Filters - Multi Port Filter: 4-Stage Filtration In One Casing,
(Pre-Filter, ULPA, Carbon, Post-Filter)
Filter(s): ULPA
Particle Size, µm: 0.1 to 0.2 Microns At 99.999% Eciency
Filter Life: Automatic Factory Set Filter Sensor
Filter Life Indicator: Timed Replacement
ViroSafe® Filter P/N: (Call for selection)
2.2 ViroSafe® Filter Instructions
Note: Before installing or removing any lter, be sure that the system is turned o.
Filter Installation Instructions:
e installation of the ViroSafe® Filter into the BUFFALO FILTER Turbo Auto-Sense™ Smoke Evacuation
System(s) is quick and simple.
1. Remove the ViroSafe® Filter from the shipping box and discard any protective wrapping. Examine all
lters for damage during shipping and storage. Do not install any lter with visible signs of structural
damage.
2. Insert the ViroSafe® Filter into the lter receptacle. Be sure that the lter is seated completely
against the bottom of the lter chamber.
WARNING: is device is not intended for evacuation of uid. If uid is expected to be aspirated
using the ViroSafe® Filter or the BUFFALO FILTER Turbo Auto-Sense™ system, uid collection
devices must be installed with the vacuum hose assembly. Failure to install a uid collection device
may cause lter blockage and/or electrical damage.
Filter Removal Instructions:
1. Aer the ViroSafe® Filter has been exhausted and requires changing, turn the smoke
evacuation system o and disconnect any accessory tubing attached to the lter.
2. Pull the ViroSafe® Filter from the smoke evacuation system and dispose of in accordance with
hospital policy. e ViroSafe® Filter may be disposed of or incinerated.
3. Clean the unit with appropriate germicide prior to re-use. Follow the indicated instructions
for maintenance and installation of a new ViroSafe® Filter.
CAUTION: Using any other lter or accessory not supplied by BUFFALO FILTER may cause
damage to the system and/or cause the system to be inoperable and may void the warranty.
WARNING: e ViroSafe® Filter should be changed when the Filter Life Indicator on the
LCD displays “REPLACE”. Failure to change this lter may result in decreased eciency and
contamination of the electric motor, vacuum pump, and sound absorbing media within the system,
or non-operation of smoke evacuator.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 15
2.3 Set-Up and Operation
e operation of the Turbo Auto-Sense™ Smoke Evacuation System is as follows:
1. Install the ViroSafe® Filter.
2. Attach unit power cord to the receptacle on the rear of the system. Plug the pronged power
cord into an appropriate grounded power outlet. Route power cord in such a way as to minimize
potential trip hazard by users or patients or pinch hazard that could cause electric shock.
3. Optional: Attach either EZ Link® or Footswitch plug into approprate jack on rear or side of
machine. Route footswitch or cord in such a way as to minimize potential trip hazard by users
or patients or pinch hazard that could result in unreliable operation.
4. Ensure that the evacuation tubing is fully seated in the inlet of the lter. Route tubing in such a
way as to minimize potential trip hazard by users or patients.
5. Activate the power unit by:
a. Toggle the rocker switch on the rear of the unit to the ON position, or
b. Depressing and releasing the footswitch (if connected), or
c. Activating either CUT or COAG on the Electrosurgical Pencil (if EZ Link is connected).
6. Adjust the suction level to the desired setting by pressing the UP/DOWN arrow button while
the unit is activated. Noise created by the smoke excavation power unit may be minimized by
selecting the lowest vacuum setting that eectively clears the operative eld of surgical smoke.
7. Deactivate the unit by:
a. Toggle the rocker switch on the rear of the unit to the OFF position, or
b. Depressing and releasing the footswitch (if connected), or
c. Releasing either the CUT or COAG button on the Electrosurgical Pencil (If EZ Link is
connected).
8. Replace the ViroSafe® Filter when the Filter Life Remaining indicator on the LCD Display
ashes REPLACE FILTER. Failure to change the lter will aect the performance of the system.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 16
2.4 Performance References*
PERFORMANCE*
Model Number Turbo Auto-Sense™ 110v
Maximum Flow Setting (CFM-U.S.)
Standard Hose I. D.
1 3/8” 79 CFM
1 1/4” 67.9 CFM
7/8” 44 CFM
1/4” 5.2 CFM
Standard Hose I. D.
35mm 2237 LPM
32mm 1923 LPM
22mm 1257 LPM
6.4mm 147 LPM
Dimensions (H x W x D) inches 13.75 x 8 x 17.23
Dimensions (H x W x D) centimeters 34.93 x 20.32 x 43.76
Weight lbs (kg.) 13.75 (6.24)
Noise Level, dBA MAXIMUM** 58 dB
Footswitch Pneumatic Standard
Remote Control Activation YES (optional)
Safety Features UL Classied
CE Marked
Fuse Protection
Display LCD
Filter Status
Flow Rate
Service Required
Voltage Available 100/120 VAC
Frequency, auto sensed 50/60 Hz
Variable Flow Control Yes
Motor Watts 1000 ±10%
Motor Static Suction 85 inches H O
(6.5 mm orice) (211 mbar)
*For reference purposes only
**using a new 7/8” x 6’ hose

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 17
PERFORMANCE*
Model Number Turbo Auto-Sense™ 220v
Maximum Flow Setting (CFM-U.S.)
Standard Hose I. D.
1 1/4” 43 CFM
7/8” 35 CFM
1/4” 2 CFM
Standard Hose I. D.
35mm 1218 LPM
22mm 991 LPM
6.4mm 56 LPM
Dimensions (H x W x D) inches 6 x 11 x 15.5
Dimensions (H x W x D) centimeters 15.2 x 27.9 x 39.4
Weight lbs (kg.) 4.3
Noise Level, dBA MAXIMUM** 60 dB
Footswitch Pneumatic Standard
Remote Control Activation YES (optional)
Safety Features UL Classied
CE Marked
Fuse Protection
Display LCD
Filter Status
Flow Rate
Service Required
Voltage Available 220/240 VAC
Frequency, auto sensed 50/60 Hz
Variable Flow Control Yes
Motor Watts 1000 ±10%
Motor Static Suction kPa
(6.5 mm orice) (21.1)
*For reference purposes only
**using a new 7/8” x 6’ hose

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 18
Table 1
Guidance and Manufacturer’s Declaration - Electromagnetic Emissions
e Smoke Evacuation System Model Turbo Auto-Sense™is intended for use in the electromagnetic environment specied
below. e customer or user of the Turbo Auto-Sense™ should assure that it is used in such an
environment.
Emissions Test Compliance Electromagnetic Environment - Guidance
RF Emissions
CISPR 11
Group 1 e Turbo Auto-Sense™uses RF energy only for its internal
function. erefore, its RF emissions are very low and are not likely to cause any
interference in nearby electronic
equipment.
RF Emissions
CISPR 11
Class A e Model Turbo Auto-Sense™is suitable for use in all
establishments, other than domestic establishments and those directly connected
to the public low-voltage power supply network that supplies buildings used for
domestic purposes.
Harmonic Emissions
IEC 61000-3-2
Class A Not applicable.
Voltage Fluctuations/
Flicker Emissions
IEC 61000-3-3
Class A Not applicable.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 19
Table 2
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity
e Model Turbo Auto-Sense™is intended for use in the electromagnet environment specied below.
Immunity Test
IEC 60601
Test Level Compliance Level
Electromagnetic Environment -
Guidance
Electromagnetic discharge
(ESD)
IEC 61000-4-2
+6 kV contact
+8 kV air
+6 kV contact
+8 kV air
Floors should be wood, concrete or
ceramic tile. If oors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
+2 kV for power supply
lines
+1 kV for input/output
lines
+2 kV for power
supply lines
+1 kV for input/
output lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
+1 kV dierential mode
+2 kV common mode
+1 kV dierential
mode
+2 kV common
mode
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips, short
interruptions, and voltage
variations on power supply
input lines.
IEC 61000-4-11
<5 % UT
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
<5 % UT
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the Model
Turbo Auto-Sense™ requires continued
operation during power mains
interruptions, it is recommended that
the Model Turbo
Auto-Sense™ be powered by an
uninterruptible power supply or battery.
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec
Power frequency
(50/60 Hz) magnetic eld
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic elds should
be at levels characteristic of a typical
location in a typical commercial or
hospital environment.

Buffalo Filter Turbo Auto-Sense™Operator’s Manual: Page 20
Table 3
Guidance and Manufacturer’s Declaration - Electromagnetic Emissions
e model Turbo Auto-Sense™is intended for use in the electromagnet environment specied below. e
customer or end user of the Turbo Auto-Sense™should assure that it us used in such an environment.
Immunity Test
IEC 60601
Test Level Compliance Level Electromagnetic Environment - Guidance
Portable and mobile RF communications equipment should
be used no closer to any part of the Surgical Smoke Evacuator
including cables, than the recommended separation distance
calculated from the equation applicable to the frequency of
the transmitter.
Radiated RF 3 V/m d = 1.7 √P 80 MHz to 800 MHz
IEC 61000-4-3 80 MHz to 2.5
GHz
3 V/m d = 2.3 √P 800 MHz to 2.5 GHz
3 Vrms d = [3.5/V1} √P
Conducted RF Where P is the maximum output power rating of the
transmitter in Watts (W) according to the transmitter
manufacturer and D is the recommended separation distance
in meters (M).
IEC 61000-4-6
150 kHz to 80
MHz
Field strength from xed RF transmitters, as determined
by an electromagnetic site survey, should be less than the
compliance level in each frequency range.
Interference may occur in the vicinity of equipment marked
with the following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: ese guidelines may not apply in all situations. Electromagnetic propagation is aected by absorption and
reection from structure, objects and people.
aField strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site survey should be
considered. If the measured eld strength in the location in which the Surgical Smoke Evacuator is used exceeds the
applicable RF compliance level above, the Surgical Smoke Evacuator should be observed to verify normal operation.
If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Surgical
Smoke Evacuator.
bOver the frequency range 150 kHz to 80 MHz, eld strengths should be less than 3 V/m.
