User Manual
BSL-POE-G2105U
Package Contents
The package contains the items shown below. If any items are missing,
please contact the dealer where you purchased the BSL-POE-G2105U.
The appearance of the BSL-POE-G2105U may vary from the illustration.
• Switch (main unit) ...................................................................................................... 1
• Power cable (AC 100-240 V) .................................................................................... 1
• Rubber feet .................................................................................................................. 4
• Serial number stickers ............................................................................................. 2
• User manual (this document) ................................................................................. 1
• Warranty ........................................................................................................................ 1
Layout
1.Indicators
Indicators are located on the front panel of the product. The functions of
each indicator are shown below.
LOOP (Red)
Blinking : Loop detected (blinks at 1 second intervals)
O : Nomal
POWER (Green)
On : Power on
O : Power o
PoE (Green or Orange)
On (Green) : PoE power is available
On (Orange) : Overcurrent or excessive power draw
O : PoE power is disabled
1000M (Green)
On (Green) : 1000M Link
O : 100M or 10M Link, No Link
LINK/ACT (Green)
On : Link established
Blinking : Data transfer
O : Link not established
2.Loop detection switch
This switches loop detection on and off. After ipping the switch,
disconnect and reconnect the power cable.
3.PoE ports
These ports support PoE. Connect devices that need Ethernet power
to these ports. Each port can supply up to 15.4 Watts with a maximum
total of 40 Watts for all 4 ports.
All ports support autonegotiation. The optimal duplex mode (full
duplex or half duplex) and transfer speed (1000, 100, or 10 Mbps) are
selected automatically.
4.Uplink port
Connect other hubs or switches to this port. This port doesn't support
PoE.
5.Power connector
Connect the included power cable to this connector.
Installation
Precautions for Installation
• Do not install the device in an unstable location such as on an unsteady
table or an inclined surface.
• Do not place another hub or object that generates heat on this unit.
• Please route LAN cables properly to prevent people from tripping over
them.
• Ensure the air vents on the product are not blocked by other equipment
or walls.
• Only use the power cable included with the product. Using other power
cables may result in damage or re.
Floor or Shelf Mounting
Attach the supplied rubber feet to the bottom corners of the unit before
use.
Mounting to a Metal Surface
To mount to a metal surface, such as the side of a steel desk, use the
"BS-MGK-A Magnet Kit" (sold separately).
Caution: Do not put oppy discs, magnetic cards, or other magnetic storage
media near magnets. Doing so may delete or corrupt data.
Wall Mounting
To mount the unit to a wall, use 2 screws (not included) with the dimensions
shown below. Install the screws 113 mm apart and slide the mounting holes
in the base of the BSL-POE-G2105U over them.
3
2
φ6
Use screws where this section
is 2 mm or less.
1. Indicators 3. PoE ports
2. Loop detection switch
5. Power connector
4. Uplink port
Bottom
Mounting
holes
Magnet mounting
holes
Loop Detection
This unit can detect network loops that can cause interference in the
network.
What is a Loop?
If both ends of an Ethernet LAN cable are connected to the same hub, or
when multiple connections exist between two hubs, data may be sent in a
loop around the network, wasting network capacity and never getting to its
destination. This continuously circulating data may interfere with other
network communication.
Loop Detection
･Off:Loops are not detected.
･On: If a network loop is detected, the loop LED on the front of the
BSL-POE-G2105U will ash red once per second.
Turning Loop Detection On and Off
1. Use the switch on the front of the BSL-POE-G2105U to turn loop detection
on or o.
2. After changing the switch position, disconnect and reconnect the power
cable. The change will take eect when the BSL-POE-G2105U has rebooted.
Notes:
・While loop detection is enabled, the BSL-POE-G2105U will send a loop
detection packet through the network every two seconds. If these
packets disrupt your network in any way, disable loop detection.
・Loop detection cannot detect all types of loops.
When a Loop is Detected
Reconnect the wiring, making sure that no wires are connected in a
loop.

2014 - 4
Specifications
Troubleshooting
If you are unable to connect to a network, check the following.
• Is the power cable connected correctly? Also, is the power cable plugged
into an outlet or surge protector?
• Is the LAN cable connected correctly? Are any cables disconnected or
broken?
• Is the LINK/ACT LED on*?
*If the LINK/ACT LED is off, manually set the communication mode of the
connected hub or LAN adapter to 100M half-duplex or 10M half-duplex.
Check Buffalo’s website (www.buffalotech.com) or the product catalog for
information about the latest products or compatible models.
Standards
Operating
Environment
Weight
External Dimensions
Power Consumption
Power
Connector
Compatible Cables
(*) (**)
Ports
IEEE 802.3ab (1000 BASE-T)
IEEE 802.3u (100 BASE-TX)
IEEE 802.3 (10 BASE-T)
IEEE 802.3af (PoE)
PoE ports : 4
Uplink ports: 1
RJ-45 8-pin connector (shielded)
AC 100-240 V 50/60 Hz
Max. 55 W
200 x 161 x 41 mm
1.2 kg (main unit only)
Operating temperature: 0–45℃
Operating humidity: 10–85% (no condensation)
Acquired Standards VCCI Class B, FCC Class B, Canada IC Class B, UL
Transmission
Speeds
1000 Mbps (1000 BASE-T)
100 Mbps (100 BASE-TX)
10 Mbps (10 BASE-T)
Switching Method Store & Forward
Jumbo Frame 9,216 Bytes
(Header 14 Bytes + FCS 4 Bytes inclusive)
Access Method CSMA/CD
Data Transfer Speed
(Throughput)
1,488,095 packets/second (1000 BASE-T)
148,810 packets/second (100 BASE-TX)
14,881 packets/second (10 BASE-T)
MAC Address Table 2,048 (Self learning)
Buer Memory 128 KBytes
Aging Time Approx. 300 seconds
Other Loop detection
Power saving (***)
* : This unit automatically detects and adjusts for straight or crossover
Ethernet cables, so either type of cable may be used.
** : Site-terminated Ethernet cables may prevent correct connections to the
network. Always use preassembled cables.
***: This function detects unused ports and reduces the amount of
electricity they use.
1000 BASE-T: Enhanced category 5 or higher UTP
cables
100 BASE-TX: Category 5 or higher UTP cables
10 BASE-T : Category 3 or higher UTP cables
PoE : Category 5 or higher UTP cables
All ports support Auto-MDIX.
IEEE802.3x (when operating at full duplex)
Back pressure (when operating at half duplex)
Flow Control
Transfer Encryption
Method
8B1Q4/4D-PAM5（1000 BASE-T）
4B5B/MLT-3（100 BASE-TX）
Manchester encoding（10 BASE-T）
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
