Fractal Flex 2 User manual

Flex 2
PCIe 4.0 Vertical Riser Bracket
1
1
2
2
3
3
4
4
5
5
6
6
7
7
Contents
PCI Slot Cover Bracket
GPU Support Bracket
Flexible PCIe 4.0 Riser Cable
2 x 6-32 Thumbscrew for PCI Cover
2 x 6-32 Captive Thumbscrew
2 x 6-32 Screw for Riser Cable
2 x 6-32 Screw for Bracket

+
38W+Max 38W
!
Fractal Gaming AB,
Victor Hasselblads Gata 16A,
S–421 31, Västra Frölunda, Sweden
Designed in Sweden
fractal-design.com
Represented by:
Authorised Rep Compliance Ltd.
ARC House
Thurnham
Lancaster
LA2 0DT
UK
Flex 2
Installation manual
Insert GPU Support Bracket in PCI Slot Cover Bracket
Add PCIe Riser Cable
Install the Graphics Card
Mount Flex 2 Bracket in the Case
1.
3.
5.
7.
2.
4.
6.
8.
Insert 2 x Screw (6-32) and 2 x Captive Thumbscrew
Insert 2 x Screw (6-32) for Riser Cable
Insert 2 x Thumbscrew in
PCI Slot Cover Bracket
Connect PCIe 16x Riser Cable to Motherboard
2x
2x
2x
2x
PH2
PH2
PH2
