Buffalo WCR-HP-GN User manual

User Manual
WCR-HP-GN
AirStation N Technology HighPower
Wireless N150 Router,
Access Point, & Bridge
www.bualotech.com
35011715 ver.01

WCR-HP-GN User Manual 1
Contents
Chapter 1 - Product Overview .........................................5
Features .................................................................................. 5
Air Navigator CD Requirements .............................................. 6
150 Mbps High Speed Mode ................................................... 6
Package Contents ................................................................... 6
Hardware Overview ................................................................. 7
Front Panel LED's .......................................................................... 7
Back Panel ..................................................................................... 9
Bottom ............................................................................................ 10
Right Side ...................................................................................... 10
Chapter 2 - Placing Your AirStation ................................11
Antenna Placement ................................................................. 11
Vertical Placement .................................................................. 11
Horizontal Placement .............................................................. 12
Chapter 3 - Installation .....................................................13
Manual Setup .......................................................................... 13
WDS Setup ............................................................................. 15
Automatic Setup ............................................................................. 16
WDS Setup (Manual) ..................................................................... 18
Chapter 4 - Conguration ................................................21
Accessing the Web-based Conguration Interface ................. 21
Conguration Menu (Router Mode) ......................................... 23
Conguration Menu (Bridge Mode) ......................................... 25
Setup ....................................................................................... 27

WCR-HP-GN User Manual 2
Internet/LAN (LAN Cong) ...................................................... 29
Internet (Router Mode only) ........................................................... 29
PPPoE (Router Mode only) ............................................................ 30
DDNS (Router Mode only) ............................................................. 32
LAN ................................................................................................ 34
DHCP Lease (Router Mode only) .................................................. 36
NAT (Router Mode only) ................................................................ 37
Route ............................................................................................. 38
Wireless Cong ....................................................................... 39
WPS ............................................................................................... 39
AOSS ............................................................................................. 40
Basic .............................................................................................. 42
Advanced ....................................................................................... 46
WMM .............................................................................................. 47
MAC Filter ...................................................................................... 49
WDS (Bridge Mode only) ............................................................... 50
Security (Router Mode only) ................................................... 52
Firewall (Router Mode only) ........................................................... 52
IP Filter (Router Mode only) ........................................................... 54
VPN Pass-Through (Router Mode only) ........................................ 55
LAN Cong (Router Mode only) .............................................. 56
Port Forwarding (Router Mode only) .............................................. 56
DMZ (Router Mode only) ............................................................... 57
UPnP (Router Mode only) .............................................................. 58
QoS (Router Mode only) ................................................................ 59
Admin Cong ........................................................................... 60
Name ............................................................................................. 60
Password ....................................................................................... 61
Time/Date ...................................................................................... 62
NTP ................................................................................................ 63
Access ........................................................................................... 64
Log ................................................................................................. 65
Save/Restore ................................................................................. 66
Initialize/Restart ............................................................................. 67

WCR-HP-GN User Manual 3
Update ........................................................................................... 68
Diagnostic ............................................................................... 69
System Info .................................................................................... 69
Logs ............................................................................................... 71
Packet Info ..................................................................................... 72
Client Monitor ................................................................................. 73
Ping ................................................................................................ 74
Chapter 5 - Connect to a Wireless Network ...................75
Automatic Secure Setup (AOSS/WPS) ................................... 75
Windows 7 or Vista (Client Manager V) ......................................... 76
Windows XP (Client Manager 3) .................................................... 77
Other Devices (e.g. Game Consoles) ............................................ 77
Chapter 6 - Troubleshooting ............................................84
Cannot connect to the Internet over wired connection. ........... 84
Cannot access the web-based conguration interface. .......... 84
Cannot connect to the network wirelessly. .............................. 84
You forgot AirStation's SSID, Encryption Key, or Password. ... 85
The link speed is slower than 150 Mbps (Maximum link speed is
only 72Mbps). .......................................................................... 85
Other Tips ................................................................................ 86
Appendix A - Specications ............................................89
Appendix B - Default Conguration Settings ................90
Appendix C - TCP/IP Settings ..........................................95

WCR-HP-GN User Manual 4
Windows 7 ............................................................................... 95
Windows Vista ......................................................................... 96
Windows XP ............................................................................ 97
Mac OS X ................................................................................ 98
Appendix D - Restoring the Default Conguration ....... 99
Appendix E - Regulatory Compliance Information ........100
Appendix F - Environmental Information .......................105
Appendix G - GPL Information ........................................106
Appendix H - Warranty Information ................................107

WCR-HP-GN User Manual 5
Chapter 1 - Product Overview
Features
Supports IEEE802.11n and IEEE802.11b/g
With support for Wireless-N, Wireless-G, and Wireless-B standards, the AirStation can transfer data to
and from all standard 2.4 GHz wireless clients.
Supports WDS
WDS bridging allows multiple units to operate in a bridged network for extended coverage.
Dual speed mode
Dual speed mode makes wireless transmission faster by using 2 channels, allowing 150 Mbps data
transmission.
Support AOSS and WPS
Both AOSS (AirStation One-touch Secure System) and WPS (Wi-Fi Protected Setup) are supported.
These automatic connection standards make connection with compatible wireless devices easier.
Security Features
The AirStation is equipped with the following security features:
• AOSS
• WPS
• WPA-PSK (TKIP/AES)
• WPA2-PSK(TKIP/AES)
• WPA/WPA2 mixed PSK
• WEP(128/64 bit)
• Privacy Separator
• MAC address access restriction
• Deny Any Connection/SSID stealth
• Web conguration interface with password
• Firewall with easy rules
Automatic Channel Selection
Monitors wireless interference and automatically assigns the clearest, best channel.

WCR-HP-GN User Manual 6
Chapter 1 Product Overview
Initialization
To restore settings back to the factory defaults, hold down the Reset button on the bottom of the
unit.
Browser Based Administration
This unit can be easily congured from a web browser on your computer.
Air Navigator CD Requirements
The AirStation wireless router and access point works with most wired and wireless devices. The
automatic installation program on the CD requires Windows 7, Vista or XP to run. Client Manager
software is included for Windows 7, Vista and XP. The use of other operating systems may require
that the AirStation be manually congured from a browser window.
150 Mbps High Speed Mode
150 Mbps is the link speed of WCR-GN when using Wireless-N mode. It represents actual wireless
data speeds, including overhead. Because the overhead is not available for user data transfer, usable
wireless throughput will be substantially slower.
Package Contents
Following items are included in your AirStation. If any of the items are missing, please contact your
vender.
• Main unit ..............................................................................................1
• Detachable antenna ........................................................................1
• Stand .....................................................................................................1
• AC adapter ...........................................................................................1
• LAN cable .............................................................................................1
• AirNavigator CD .................................................................................1
• Quick Setup Guide............................................................................1

1
2
3
4
5
6
Chapter 1 Product Overview
WCR-HP-GN User Manual 7
Hardware Overview
Front Panel LED's
1 Antenna connector
Screw on the antenna here.
2 Power LED (Green)
On: The AC adapter is connected
O: The AC adapter is not connected
3 Security LED (Amber)
Indicates security status.
O: Encryption is not set
On: Encryption has been set
Double blink: The unit is waiting for an AOSS or WPS
security key
Blinking: AOSS/WPS error; failed to exchange security keys
Note: When the Security LED is lit, an encryption key has
been set. Wireless clients will need the same key to
connect.
4 Wireless LED (Green)
Indicates wireless LAN status.
Blinking: Wireless LAN is transmitting
On: Wireless LAN is connected but not active
5 Router LED (Green) On: Router functionality is enabled
O: Router functionality is disabled
6 Diag LED (Red) This indicates the status of the unit depending on the number of
blinks per cycle.
Note: When the unit is rst turned on or restarted, the Diag LED will
blink for almost a minute during boot. This is normal.

WCR-HP-GN User Manual 8
Chapter 1 Product Overview
Diag LED
status
Meaning Status
2 blinks *1Flash ROM error Cannot read or write to the ash memory.
3 blinks *1Ethernet (wired) LAN
error
Ethernet LAN controller is malfunctioning.
4 blinks *1Wireless LAN error Wireless LAN controller is malfunctioning.
5 blinks IP address setting error Because the network addresses of both the Internet port (INTERNET
port) and the LAN port are the same, it is not possible to establish
communication. Change the LAN side IP address of this unit.
Continuously
blinking *2
Updating the rmware
Saving settings
Initializing settings
Updating the rmware.
Saving the settings.
Initializing the settings.
*1 Unplug the AC adapter from the wall socket, wait for a few seconds, and then plug it again. If the
light still ashes, please contact technical support.
*2 Never unplug the AC adapter while the Diag LED is blinking continuously.

ADSS
LAN
1
2
3
4
INTERNET
POWER
7
8
9
10
Chapter 1 Product Overview
WCR-HP-GN User Manual 9
Back Panel
7 AOSS Button
Hold down this button until the Security LED ashes (about
3 seconds), while the unit’s power is on, initiates AOSS/WPS
mode, allowing the unit to exchange security keys with AOSS
or WPS compatible devices.
8 LAN Port
Connect your computer, hub, or other Ethernet devices
to these ports. This switching hub supports 10 Mbps and
100 Mbp s connections.
9 Internet (WAN) Port
10 Mbps and 100 Mbps connections are supported.
Note: In bridge/AP mode, the Internet port becomes a
regular LAN port, for a total of 5 usable LAN ports.
10 Power Connector
Connect the included AC adapter.

RESET
11
12
WCR-HP-GN User Manual 10
Chapter 1 Product Overview
Bottom
11 Reset Button With the power on, hold down this button until the Diag LED comes on to
initialize the AirStation’s settings to their default values.
Right Side
12 Factory Default Settings This sticker shows the AirStation’s SSID, default encryption key,
and WPS PIN code. By default, encryption key is disabled for
Asia Pacic.

1
WCR-HP-GN User Manual 11
Chapter 2 - Placing Your AirStation
Vertical Placement
To place unit vertically, attach the stand as shown below.
Antenna Placement
The antenna is included in the package. Screw the antenna clockwise to install.

WCR-HP-GN User Manual 12
Chapter 2 Placing Your AirStation
Horizontal Placement
For horizontal placement, the stand is not used.

modem
1) connect
LAN cable
2) connect
INTERNET port
AirStation wireless
router (rear side)
ÐÏ×ÅÒ
ÉÎÔÅÒÎÅÔ
ÌÁÎ
ᴮ
ᴯ
ᴰ
ᴱ
computer
modem
2) disconnect
2) disconnect
ÏÆÆ
1) turn o the computer
WCR-HP-GN User Manual 13
Chapter 3 - Installation
Manual Setup
To congure your AirStation manually, follow the procedure below.
1Turn o your computer and modem. If the modem doesn’t have an o switch, unplug its
power connector.
2Find the LAN cable that connects your
computer and modem. Unplug it
from the computer.
3Plug the LAN cable from the modem into the Internet (WAN) port of your AirStation. Turn on
the modem.
Automatic Setup
The AirNavigator CD can step you through installing your AirStation. To step through the setup pro-
gram, insert the CD into your Windows 7/Vista/XP PC and follow the instructions on the screen.
If your computer uses a dierent operating system, use manual setup instead.

ÐÏ×ÅÒ
ÉÎÔÅÒÎÅÔ
ÌÁÎ
ᴮ
ᴯ
ᴰ
ᴱ
power outlet
AirStation wireless router
(rear side)
PC
1) connect
1) connect
Ethernet cable
2) connect the power supply
ADSS
LAN
1
2
3
4
POWER
INTERNET
ON
modem
power outlet
computer
WCR-HP-GN User Manual 14
Chapter 3 Installation
4Connect your computer to one of the AirStation’s LAN ports with the Ethernet cable.
Turn on the AirStation, wait one minute, and then turn on your computer.
5Conrm the devices are connected correctly as the below diagram shows.
6Wait for a minute or so, until the AirStation’s LEDs are lit as described below:
Power Green light is on
Wireless Green light is on
Router Green light is on
Diag O
LAN Green light is on or blinking
Internet Green light is on or blinking
※ Refer to page 7 for LED locations and other details.
7Launch a web browser. If the [home] setup screen is displayed, setup is complete.
If a user name and password screen are displayed, enter [root] (in lower case) for the user
name, leave the password blank, and click [OK]. Follow the instructions on the screen to
complete setup.
You’ve completed initial setup of your AirStation. Refer to Chapter 4 for advanced settings.

POWER
SECURITY
WEIRELESS
ROUTER
DIAG
Extend the
wireless coverage
wireless connection
blocked
Internet modem wireless AP
WCR-HP-GN
(WDS enabled)
computer computer
computer
Chapter 3 Installation
WCR-HP-GN User Manual 15
WDS Setup
The AirNavigator CD can step you through installing multiple AirStations in a WDS bridge. Insert
it into your Windows 7, Vista, or Windows XP PC and follow the instructions on the screen. If your
computer uses a dierent operating system, use manual setup instead.

WCR-HP-GN User Manual 16
Chapter 3 Installation
Automatic Setup
1Insert the AirNavigator CD into your PC.
2When the screen below screen appears, click [Start], then [Next].
3Choose [WDS Setup].

Chapter 3 Installation
WCR-HP-GN User Manual 17
4When the below screen appears, select [AOSS conguration] or [Manual Conguration] from
[Select WDS Setup method].
AirStation will attempt to connect to other wireless APs to set up WDS.
If the target wireless AP that supports WDS is a Bualo AirStation, select [AOSS
conguration] , then push the AOSS button on the target AP.
If the target AP is not a Bualo AirStation, select [Manual Conguration]. Click [Scan for
SSID]. A list of available wireless AP will be generated. Select the target AP’s SSID from the
list and click [Next] to continue.
5Step through the wizard to complete the setup.
After conguring the WDS bridge with AOSS, any preexisting AOSS wireless clients will be
disconnected. Turn to page 75 to reconnect wireless clients with AOSS.

ÐÏ×ÅÒ
ÉÎÔÅÒÎÅÔ
ÌÁÎ
ᴮ
ᴯ
ᴰ
ᴱ
power outlet
AirStation wireless router
(rear side)
PC
1) connect
1) connect
Ethernet cable
2) connect the power supply
WCR-HP-GN User Manual 18
Chapter 3 Installation
WDS Setup (Manual)
To congure the WDS manually, follow the procedure below.
1Change your computer’s IP to a xed address. For details, please refer to Appendix C (page 95).
ex) IP address 192.168.11.80
Subnet mask 255.255.255.0
Default gateway blank
Preferred DNS server blank
Alternate DNS server blank
2Turn o your computer.
3Connect your computer to one of the AirStation’s LAN ports with the Ethenet cable.
Turn on the AirStation, wait one minute, and then turn on your computer.
4Wait for about a minute, until the AirStation’s LEDs are lit as described below:
Power Green light is on
Wireless Green light is on
Router Green light is on
Diag O
※ Refer to page 7 for LED locations and other details.

Chapter 3 Installation
WCR-HP-GN User Manual 19
5Open the web conguration interface (page 21).
6In the [Mode information] menu, select [Bridge Mode], then click [Apply].
7When this below screen appears, re-enter
the web conguration interface username
"root" and password. Click [OK].
8The web conguration interface will open. Click [Wireless Cong] , then [WDS].
10 Follow the directions below.
AOSS Settings
Select [AOSS] from [Connection type] and click the AOSS button. Also push the AOSS button
on the unit intended to connect. Automatic conguration will take about a minute. To return
the unit to its original IP address settings, refer to Appendix C.
9Check [Use].
