ESCALA Power7
Site and Hardware Planning for the M6-
700, M6-705, M7-700 or M7-705
REFERENCE
86 A1 70FF 04

ESCALA Power7
Site and Hardware Planning for the M6-700, M6-705,
M7-700 or M7-705
The ESCALA Power7 publications concern the following models:
- Bull Escala E5-700 (Power 750 / 8233-E8B)
- Bull Escala M6-700 (Power 770 / 9117-MMB)
- Bull Escala M6-705 (Power 770 / 9117-MMC)
- Bull Escala M7-700 (Power 780 / 9179-MHB)
- Bull Escala M7-705 (Power 780 / 9179-MHC)
- Bull Escala E1-700 (Power 710 / 8231-E2B)
- Bull Escala E1-705 (Power 710 / 8231-E1C)
- Bull Escala E2-700 / E2-700T (Power 720 / 8202-E4B)
- Bull Escala E2-705 / E2-705T (Power 720 / 8202-E4C)
- Bull Escala E3-700 (Power 730 / 8231-E2B)
- Bull Escala E3-705 (Power 730 / 8231-E2C)
- Bull Escala E4-700 / E4-700T (Power 740 / 8205-E6B)
- Bull Escala E4-705 (Power 740 / 8205-E6C)
References to Power 755 / 8236-E8C models are irrelevant.
Hardware
May 2012
BULL CEDOC
357 AVENUE PATTON
B.P.20845
49008 ANGERS CEDEX 01
FRANCE
REFERENCE
86 A1 70FF 04

The following copyright notice protects this book under Copyright laws which prohibit such actions as, but not limited to, copying,
distributing, modifying, and making derivative works.
Bull SAS 2012
Copyright
Printed in France
Suggestions and criticisms concerning the form, content, and presentation of this book are
invited. A form is provided at the end of this book for this purpose.
To order additional copies of this book or other Bull Technical Publications, you are invited
to use the Ordering Form also provided at the end of this book.
Trademarks and Acknowledgements
We acknowledge the right of proprietors of trademarks mentioned in this book.
The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or
r incidental or consequential damages in connection with the use of this material.
fo

Contents
Safety notices .................................v
Site and hardware physical planning overview ...................1
Planning activities ...............................3
Planning task checklist ................................3
General considerations ................................3
Site preparation and physical planning guidelines .......................4
Hardware specification sheets ..........................7
Server specifications .................................7
Model 17M/MB, 17M/MC, 79M/HB, and 79M/HC server specifications ..............7
Plugs and receptacles ..............................10
Connecting your server to a country specific receptacle..................10
Connecting your server to a PDU .........................47
Expansion unit and migration tower specifications ......................52
expansion unit .................................52
expansion unit .................................53
58/02 expansion unit ...............................54
5877 expansion unit ...............................56
58/86 expansion unit ...............................56
58/87 expansion unit ...............................58
58/88 expansion unit ...............................59
Rack specifications .................................60
0551 rack ...................................60
, and 7014 rack configurations ............................62
Model 14S/11 rack ................................68
Model 14S/25 rack ................................71
Planning for the 14T/00 and 14T/42 racks ........................74
Model 14T/00 rack ...............................74
Model 14T/42, 7014-B42, and 0553 rack ........................76
14T/00, 14T/42, and 0553 service clearances and caster location ................78
14T/00, 14T/00, and 0553 racks multiple attachment ...................79
14T/00, 14T/42, and 0553 rack weight distribution and floor loading ..............80
Hardware management console specifications ........................81
7042-C08 Hardware Management Console specifications ...................81
42C/07 desktop Hardware Management Console specifications .................82
Systems Director Management Console specifications .....................83
7042-CR6 rack-mounted Systems Director Management Console specifications ............83
7042-CR7 rack-mounted Systems Director Management Console specifications ............84
Rack installation procedures for racks not purchased from....................85
Planning for power ..............................93
Determining your power requirements ..........................93
Server Information Form 3A.............................94
Workstation Information Form 3B ...........................94
Uninterruptible power supply .............................95
Power distribution unit and power cord options for 7014,, rack ..................99
Power load calculating for 7188 or 9188 power distribution units .................105
Planning for cables ..............................109
Cable management ................................109
Power cord routing and retention...........................110
Serial-attached SCSI cable planning ...........................111
iii

SAS cabling for the 5887 drawer ............................133
Rack installation procedures for racks not purchased from ............147
Notices ...................................155
Trademarks ...................................156
Electronic emission notices ..............................156
Class A Notices.................................156
Class B Notices.................................160
Terms and conditions................................163
iv Site and hardware planning

Safety notices
Safety notices may be printed throughout this guide.
vDANGER notices call attention to a situation that is potentially lethal or extremely hazardous to
people.
vCAUTION notices call attention to a situation that is potentially hazardous to people because of some
existing condition.
vAttention notices call attention to the possibility of damage to a program, device, system, or data.
World Trade safety information
Several countries require the safety information contained in product publications to be presented in their
national languages. If this requirement applies to your country, a safety information booklet is included
in the publications package shipped with the product. The booklet contains the safety information in
your national language with references to the U.S. English source. Before using a U.S. English publication
to install, operate, or service this product, you must first become familiar with the related safety
information in the booklet. You should also refer to the booklet any time you do not clearly understand
any safety information in the U.S. English publications.
Laser safety information
The servers can use I/O cards or features that are fiber-optic based and that utilize lasers or LEDs.
Laser compliance
The servers may be installed inside or outside of an IT equipment rack.
v

DANGER
When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous. To
avoid a shock hazard:
vConnect power to this unit only with the provided power cord. Do not use the provided power
cord for any other product.
vDo not open or service any power supply assembly.
vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
vThe product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
vConnect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet
supplies proper voltage and phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to properly wired outlets.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or structural damage.
vDisconnect the attached power cords, telecommunications systems, networks, and modems before
you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
vConnect and disconnect cables as described in the following procedures when installing, moving,
or opening covers on this product or attached devices.
To Disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices
To Connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
(D005a)
DANGER
vi Site and hardware planning

Observe the following precautions when working on or around your IT rack system:
vHeavy equipment–personal injury or equipment damage might result if mishandled.
vAlways lower the leveling pads on the rack cabinet.
vAlways install stabilizer brackets on the rack cabinet.
vTo avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
vRack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices.
vEach rack cabinet might have more than one power cord. Be sure to disconnect all power cords in
the rack cabinet when directed to disconnect power during servicing.
vConnect all devices installed in a rack cabinet to power devices installed in the same rack
cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power
device installed in a different rack cabinet.
vAn electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
CAUTION
vDo not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer's recommended ambient temperature for all your rack-mounted devices.
vDo not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
vConsideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the
equipment in the rack to determine the total power requirement of the supply circuit.
v(For sliding drawers.) Do not pull out or install any drawer or feature if the rack stabilizer brackets
are not attached to the rack. Do not pull out more than one drawer at a time. The rack might
become unstable if you pull out more than one drawer at a time.
v(For fixed drawers.) This drawer is a fixed drawer and must not be moved for servicing unless
specified by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack.
(R001)
Safety notices vii

CAUTION:
Removing components from the upper positions in the rack cabinet improves rack stability during
relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a
room or building:
vReduce the weight of the rack cabinet by removing equipment starting at the top of the rack
cabinet. When possible, restore the rack cabinet to the configuration of the rack cabinet as you
received it. If this configuration is not known, you must observe the following precautions:
– Remove all devices in the 32U position and above.
– Ensure that the heaviest devices are installed in the bottom of the rack cabinet.
– Ensure that there are no empty U-levels between devices installed in the rack cabinet below the
32U level.
vIf the rack cabinet you are relocating is part of a suite of rack cabinets, detach the rack cabinet from
the suite.
vInspect the route that you plan to take to eliminate potential hazards.
vVerify that the route that you choose can support the weight of the loaded rack cabinet. Refer to the
documentation that comes with your rack cabinet for the weight of a loaded rack cabinet.
vVerify that all door openings are at least 760 x 230 mm (30 x 80 in.).
vEnsure that all devices, shelves, drawers, doors, and cables are secure.
vEnsure that the four leveling pads are raised to their highest position.
vEnsure that there is no stabilizer bracket installed on the rack cabinet during movement.
vDo not use a ramp inclined at more than 10 degrees.
vWhen the rack cabinet is in the new location, complete the following steps:
– Lower the four leveling pads.
– Install stabilizer brackets on the rack cabinet.
– If you removed any devices from the rack cabinet, repopulate the rack cabinet from the lowest
position to the highest position.
vIf a long-distance relocation is required, restore the rack cabinet to the configuration of the rack
cabinet as you received it. Pack the rack cabinet in the original packaging material, or equivalent.
Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the
pallet.
(R002)
(L001)
(L002)
viii Site and hardware planning

(L003)
or
All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class
1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser
product. Consult the label on each part for laser certification numbers and approval information.
CAUTION:
This product might contain one or more of the following devices: CD-ROM drive, DVD-ROM drive,
DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following information:
vDo not remove the covers. Removing the covers of the laser product could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the device.
vUse of the controls or adjustments or performance of procedures other than those specified herein
might result in hazardous radiation exposure.
(C026)
Safety notices ix

CAUTION:
Data processing environments can contain equipment transmitting on system links with laser modules
that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical
fiber cable or open receptacle. (C027)
CAUTION:
This product contains a Class 1M laser. Do not view directly with optical instruments. (C028)
CAUTION:
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the following
information: laser radiation when open. Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam. (C030)
CAUTION:
The battery contains lithium. To avoid possible explosion, do not burn or charge the battery.
Do Not:
v___ Throw or immerse into water
v___ Heat to more than 100°C (212°F)
v___ Repair or disassemble
Exchange only with the approved part. Recycle or discard the battery as instructed by local
regulations. (C003a)
Power and cabling information for NEBS (Network Equipment-Building System)
GR-1089-CORE
The following comments apply to the servers that have been designated as conforming to NEBS
(Network Equipment-Building System) GR-1089-CORE:
The equipment is suitable for installation in the following:
vNetwork telecommunications facilities
vLocations where the NEC (National Electrical Code) applies
The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed
wiring or cabling only. The intrabuilding ports of this equipment must not be metallically connected to the
interfaces that connect to the OSP (outside plant) or its wiring. These interfaces are designed for use as
intrabuilding interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation
from the exposed OSP cabling. The addition of primary protectors is not sufficient protection to connect
these interfaces metallically to OSP wiring.
Note: All Ethernet cables must be shielded and grounded at both ends.
The ac-powered system does not require the use of an external surge protection device (SPD).
The dc-powered system employs an isolated DC return (DC-I) design. The DC battery return terminal
shall not be connected to the chassis or frame ground.
xSite and hardware planning

Site and hardware physical planning overview
Successful installation requires effective planning of your physical and operational environment. You are
the most valuable resource in site planning because you know where and how your system, and devices
attached to it, will be used.
Site preparation for the complete system is the responsibility of the customer. The primary task of your
site planner is to ensure that each system is installed so that it can operate and be serviced efficiently.
This topic collection provides the basic information you need to plan for your system installation. It
provides an overview of each planning task, as well as valuable reference information useful throughout
the performance of these tasks. Depending on the complexity of the system you ordered and your
existing computing resource, you might not need to perform all the steps noted here.
First, with the help of your systems engineer, sales representative, or with the help of those coordinating
your installation, list the hardware for which you need to plan. Use the summary of your order to help
you when making your list. This list is now your “To Do” list. You can use the Planning task checklist to
assist you.
While you are responsible for planning, vendors, contractors, and your sales representative are also
available to help with any aspect of the planning. For some system units, a customer service
representative will install your system unit and verify correct operation. Some system units are
considered customer-installed. If you are not sure, check with your sales representative.
The physical planning section of this topic collection provides the physical characteristics of many system
units, and associated products. For information on products not included in this topic collection, contact
your sales representative or your authorized dealer.
Before proceeding with planning, ensure that the hardware and software you have chosen meets your
needs. Your sales representative is available to answer questions.
While this information is for hardware planning, the system memory and disk storage needed are a
function of the software to be used, therefore some things to consider are listed below. Information on
software products is generally in or with the software Licensed Program Product itself.
In assessing the adequacy of hardware and software, consider the following:
vAvailable disk space and system memory for accommodating software, online documentation, and data
(including future growth needs resulting from additional users, more data, and new applications)
vCompatibility of all devices
vCompatibility of software packages with each other and with the hardware configuration
vAdequate redundancy or backup capabilities in hardware and software
vSoftware portability to the new system, if necessary
vPrerequisites and corequisites of chosen software have been satisfied
vData to be transferred to the new system
1

2Site and hardware planning

Planning activities
You can use this information to help you plan the physical installation for your server.
Proper planning for your system will facilitate a smooth installation and fast system start-up. Sales and
installation planning representatives are also available to help you with installation planning.
As part of your planning activity, you will make decisions about where to locate your server and who
will operate the system
Planning task checklist
Use this checklist to document your planning progress.
Working with your sales representative, establish completion dates for each of the tasks. You might want
to review your planning schedule periodically with your sales representative.
Table 1. Planning task checklist
Planning step Person responsible Target date Completion date
Plan your office or computer
room layout (physical planning)
Prepare for power cords and
electrical needs
Prepare for cables and cabling
Create or modify communications
networks
Perform building alterations, as
needed
Prepare maintenance, recovery,
and security plans
Develop an education plan
Order supplies
Prepare for system delivery
General considerations
Planning your system requires attention to the numerous details.
When determining the placement of your system, consider the following:
vAdequate space for the devices.
vWorking environment of personnel who will be using the devices (their comfort, ability to access the
devices, supplies, and reference materials).
vAdequate space for maintaining and servicing the devices.
vPhysical security requirements necessary for the devices.
vWeight of the devices.
vHeat output of the devices.
vOperating temperature requirements of the devices.
3

vHumidity requirements of the devices.
vAir flow requirements of the devices.
vAir quality of the location where the devices will be used. For example, excess dust could damage
your system.
Note: The system and devices are designed to operate in normal office environments. Dirty or other
poor environments might damage the system or the devices. You are responsible for providing the
proper operating environment.
vAltitude limitations of the devices.
vNoise emission levels of the devices.
vAny vibration of equipment near where the devices will be placed.
vPaths of power cords.
The following pages contain the information you need to evaluate these considerations.
Site preparation and physical planning guidelines
These guidelines help you prepare your site for the delivery and installation of your server.
Information contained in the Site preparation and physical planning might be helpful for preparing your
data center for the arrival of a server.
The Site preparation and physical planning topic covers the following information:
Site selection, building and space considerations
vSite selection
vAccess
vStatic electricity and floor resistance
vSpace requirements
vFloor construction and floor loading
vRaised floors
vConductive contamination
vComputer room layout
Site environment, safety, and security
vVibration and shock
vLighting
vAcoustics
vElectromagnetic compatibility
vComputer room location
vMaterial and data storage protection
vEmergency planning for continuous operations
Electrical power and grounding
vGeneral power information
vPower quality
vVoltage and frequency limits
vPower load
vPower source
4Site and hardware planning

vDual power installations
Air conditioning
vAir conditioning determination
vGeneral guidelines for data centers
vTemperature and humidity design criteria
vTemperature and humidity recording instruments
vRelocation and temporary storage
vAcclimation
vSystem air distribution
Planning for the installation of rear door heat exchangers
vPlanning for the installation of rear door heat exchangers
vHeat exchanger specifications
vWater specifications for the secondary cooling loop
vWater delivery specifications for secondary loops
vLayout and mechanical installation
vSuggested sources for secondary loop components
Communications
vPlanning for communications
Planning activities 5

6Site and hardware planning

Hardware specification sheets
Hardware specification sheets provide detailed information for your hardware, including dimensions,
electrical, power, temperature, environment, and service clearances.
Server specifications
Server specifications provide detailed information for your server, including dimensions, electrical, power,
temperature, environment, and service clearances.
Select the appropriate models to view the specifications for your server.
Model 17M/MB, 17M/MC, 79M/HB, and 79M/HC server specifications
Server specifications provide detailed information for and servers including dimensions, electrical data,
power, temperature, environment requirements, and service clearances.
Dimensions
Table 2. Dimensions
Width Depth Height EIA units Weight
483 mm (19.0 in.) 863 mm (34.0 in.) 174 mm (6.9 in.) 4 EIA units 70.3 kg (155 lb)
Electrical
Table 3. Electrical
Electrical characteristics Properties
Maximum kVA 1.649 kVA
Voltage 200 - 240 V ac
Frequency 50/60 Hz (Plus or minus 3Hz)
Maximum thermal output 5461 BTU/hr per enclosure with 16 cores active (Model
17M/MB, 17M/MC, and 79M/HB)
6485 BTU/hr per enclosure with 24 cores active (Model
79M/HC)
Maximum power consumption 1600 watts per enclosure with 16 cores active (Model
17M/MB, 17M/MC, and 79M/HB)
1900 watts per enclosure with 24 cores active (Model
79M/HC)
Power factor .97
Maximum inrush current 95 amps
Phase Single
Power source loading 1.649 kVA per enclosure with 16 cores active (Model
17M/MB, 17M/MC, and 79M/HB)
1.959 kVA per enclosure with 24 cores active (Model
79M/HC)
7

Table 3. Electrical (continued)
Electrical characteristics Properties
Notes:
1. The power supplies automatically accept any voltage with the published, rated-voltage range. If dual power
supplies are installed and operating, the power supplies draw approximately equal current from the utility
(mains) and provide approximately equal current to the load.
2. Maximum power consumption is specified for each 17M/MB 16-core drawer. The 32-core, 48-core, and 64-core
configurations are based on the use of multiple 16-core drawers (for example, a 32-core configuration consists of
two 16-core drawers, and so on).
3. Power draw and heat load vary greatly by configuration. When planning for an electrical system, it is important
to use maximum values. However, when planning for heat load, you can use the IBM®Systems Energy
Estimator to obtain a heat output estimate based on a specific configuration. See The IBM Systems Energy
Estimator Web site for more information.
4. Measured according to IEC 60950.
5. To calculate the amperage, multiply the kVA by 1000 and divide that number by the operating voltage.
Environment requirements
Table 4. Environment requirements
Environment Recommended operating Allowable operating Nonoperating
Temperature 118°C - 27°C (64°F - 80° F) 5°C - 35°C (41°F - 95° F) 5°C - 45°C (41°F - 113° F)
Relative humidity (RH) 5.5°C (42°F) dew point to
60% RH and 15°C (59°F)
dew point
20% - 80% 8% - 80%
Maximum operating
altitude
3048 m (10 000 ft)
Shipping temperature -40°C - 60°C (-40°F - 140°F)
Shipping relative humidity 5% - 100%
Dew point 29°C (84°F) 28°C (82°F)
1Derate maximum dry-bulb temperature 1°C/300 m above 900 m.
Table 5. Noise emissions
Product description Declared A-weighted sound power level, LwAqd (B) Declared A-weighted sound pressure level, LpAm (dB)
Operating Idle Operating Idle
Model 17M/MB and
79M/HB single drawer (16
way) (2 socket- 8
core/socket)
6.8 6.8 51 51
Model17M/MB and
79M/HB single drawer (16
way) (2 socket- 8
core/socket) with
acoustical rack doors
feature code 6248 or 6249
6.3 6.3 46 46
Model 17M/MB and
79M/HB four drawer (64
way) (8 socket- 8
core/socket)
7.3 7.3 54 54
Model 17M/MB and
79M/HB four drawer (64
way) (8 socket- 8
core/socket) with
acoustical rack doors
feature code 6248 or 6249
6.8 6.8 49 49
8Site and hardware planning
