BZB Gear BZ-UHD-1x4HDBT User manual

1×4 HDBaseT Splitter
VER 1.0
Thank you for purchasing this product
For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please
keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
Use of surge protection systems is highly recommended in order to
protect and extend the life of your equipment.
Table of Contents
1. Introduction 2

2. Features 2
3. Package Contents 3
4. Specifications 3
5. Operation Controls and Functions 4
5.1 Transmitter Pa 4
5.2 Receiver Panel 6
6. HDBT Receiver 9
7. Web GUI User Guide 10
8. Application Example 16
1. Introduction
The 1x4 HDBaseT splitter is an advanced signal distribution amplifier
that can distribute one HDMI signal to four HDBaseT outputs each up to
230ft/70m through a single Cat6/6a cable. Max video resolution up to
4K2K@60Hz(4:4:4). A local HDMI loop out can allow two units
cascading to a 1x8 splitter. Two-way IR and RS-232 are supported as
well.
2. Features
☆HDMI 2.0b, HDCP 2.2 compliant.
☆Up to 4K2K@60Hz (4:4:4) 18Gbps.
☆Supports all HDMI audio formats pass-through.
☆HDBaseT up to 230ft/70m through a single Cat6/6a cable
☆RS-232 and two-way IR supported
☆Local HDMI loop out for cascading usage
☆24V POC on all HDBaseT ports
☆Transmission distance: ※Over CAT6 cable
70 meters: 1080P @60Hz36bit;
40 meters: 1080P @60Hz@48bit; 1080P @120Hz@24bit;
4K2K@50/60Hz (YUV420), 4K2K@50/60Hz (YUV444)
☆POC (Power over Cable), either TX or RX is powered by one
[email protected] power supply.
※See the"description 1
☆Bi-directional infrared control signal transmission.
※See the"description 2
☆Bi-directional RS-232 signal transmission.
※See the"description 3

3. Package Contents
①1x 1×4 HDBaseT Splitter
②4x HDBaseT Receivers
③4x Wideband IR Blaster cables
④4x Wideband IR Receiver cables
⑤1x 24V/2.7A Locking Power Adapter
⑥5x Phoenix connectors (5 pins male)
⑦4x Phoenix connectors (3 pins male)
⑧1x User Manual
4. Specifications
Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2
Video Bandwidth 594MHz[18Gbps]
Video Resolutions up to 4K60Hz, 1080P@60Hz
Color Depth 10-bit, 12-bit
Color Space RGB/YCbCr 4:4:4, YCbCr
4:2:2
Transmitter
Input ports: 1x HDMI Type A
[19-pin female]
5x IR INPUT [Phoenix
jack]
Output ports: 1x HDMI Type A
[19-pin female]
5x RS-232 [Phoenix jack]
5x IR OUTPUT [Phoenix
jack]
4x HDBaseT Out [RJ45]
1x LAN [RJ45, Control]
Receiver
Input ports: 1×HDBaseT In
[RJ45]
1×IR In [3.5mm Stereo
Mini-jack]
Output ports: 1×HDMI Type A
[19-pin female]
1×IR Out [3.5mm Stereo
Mini-jack]
1×RS-232 [Phoenix
connector]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions
TX:
210mm(W)×159mm(D)×44mm(
H)
RX:
115mm(W)*65mm(D)*17mm(H)
Weight TX: 1.19kg, RX: 206g
Power Supply
Input: AC100~240V 50/60Hz,
Output: DC24V/2.7A (US/EU
standards，CE/FCC/UL
certified)
Power Consumption 40W
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90%RH (non-condensing)

Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2
Video Bandwidth 594MHz[18Gbps]
Video Resolutions up to 4K60Hz, 1080P@60Hz
Color Depth 10-bit, 12-bit
Color Space RGB/YCbCr 4:4:4, YCbCr
4:2:2
Transmitter
Input ports: 1x HDMI Type A
[19-pin female]
5x IR INPUT [Phoenix
jack]
Output ports: 1x HDMI Type A
[19-pin female]
5x RS-232 [Phoenix jack]
5x IR OUTPUT [Phoenix
jack]
4x HDBaseT Out [RJ45]
1x LAN [RJ45, Control]
Receiver
Input ports: 1×HDBaseT In
[RJ45]
1×IR In [3.5mm Stereo
Mini-jack]
Output ports: 1×HDMI Type A
[19-pin female]
1×IR Out [3.5mm Stereo
Mini-jack]
1×RS-232 [Phoenix
connector]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions
TX:
210mm(W)×159mm(D)×44mm(
H)
RX:
115mm(W)*65mm(D)*17mm(H)
Weight TX: 1.19kg, RX: 206g
Power Supply
Input: AC100~240V 50/60Hz,
Output: DC24V/2.7A (US/EU
standards，CE/FCC/UL
certified)
Power Consumption 40W
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90%RH (non-condensing)
5. Operation Controls and Functions
5.1 Transmitter Pa
Number Name Function
descriptions
1 Power LED
Power indicator
light. When the
power supply is
normal, the indicator
LED is on.
2 HDMI LED
HDMI IN LED:
When the HDMI IN
port has signal input,
the indicator LED is
on.
HDMI OUT LED:
When the HDMI
OUT port has an
active display be
connected, the
indicator LED is on.
3 HDBaseT LED
When the HDBaseT
OUT port connect
Receiver and the
Receiver has signal
output,
corresponding
HDBaseT indicator
LED is on.
4 EDID LED
EDID INT LED:
When have default
EDID output, the
indicator LED is
on.EDID OUT1
LED: The HDBaseT
OUT 1 port has
connected the
receiver and the
receiver has
connected an active
display. When the
display EDID be
copyed, the indicator
LED is on.
5 EDID button
Select default EDID
or copy HDBaseT
OUT 1 EDID.
6 POWER button
Press the button to
open the power of
the unit or set it as a
standby mode.
(Attention: The unit
is power on status
when it is powered
on firstly.)

Number Name Function
descriptions
1 Power LED
Power indicator
light. When the
power supply is
normal, the indicator
LED is on.
2 HDMI LED
HDMI IN LED:
When the HDMI IN
port has signal input,
the indicator LED is
on.
HDMI OUT LED:
When the HDMI
OUT port has an
active display be
connected, the
indicator LED is on.
3 HDBaseT LED
When the HDBaseT
OUT port connect
Receiver and the
Receiver has signal
output,
corresponding
HDBaseT indicator
LED is on.
4 EDID LED
EDID INT LED:
When have default
EDID output, the
indicator LED is
on.EDID OUT1
LED: The HDBaseT
OUT 1 port has
connected the
receiver and the
receiver has
connected an active
display. When the
display EDID be
copyed, the indicator
LED is on.
5 EDID button
Select default EDID
or copy HDBaseT
OUT 1 EDID.
6 POWER button
Press the button to
open the power of
the unit or set it as a
standby mode.
(Attention: The unit
is power on status
when it is powered
on firstly.)

Number Name Function
descriptions
1 Power LED
Power indicator
light. When the
power supply is
normal, the indicator
LED is on.
2 HDMI LED
HDMI IN LED:
When the HDMI IN
port has signal input,
the indicator LED is
on.
HDMI OUT LED:
When the HDMI
OUT port has an
active display be
connected, the
indicator LED is on.
3 HDBaseT LED
When the HDBaseT
OUT port connect
Receiver and the
Receiver has signal
output,
corresponding
HDBaseT indicator
LED is on.
4 EDID LED
EDID INT LED:
When have default
EDID output, the
indicator LED is
on.EDID OUT1
LED: The HDBaseT
OUT 1 port has
connected the
receiver and the
receiver has
connected an active
display. When the
display EDID be
copyed, the indicator
LED is on.
5 EDID button
Select default EDID
or copy HDBaseT
OUT 1 EDID.
6 POWER button
Press the button to
open the power of
the unit or set it as a
standby mode.
(Attention: The unit
is power on status
when it is powered
on firstly.)
5.2 Receiver Panel
Number Name Function
descriptions
1HDMI
HDMI IN: Connect
to the HDMI source
device, such as DVD
player or Set top
box.
HDMI OUT: HDMI
LOOP output port.
Connect to the local
HDMI display
device, such as
HDTV or monitor.
2 HDBaseT OUT
Standard HDBaseT
output port. Connect
to HD-BaseT
Receiver with a UTP
cable.
3 DC 24V
Connect 24V/2.7A
adaptor to AC wall
outlet for power
supply.
4 LAN
Connects to an
active Ethernet link
by an RJ-45 cable.
5 MASTER
RS-232: Phoenix
jack connects control
equipment to
transmit command
from transmitter
RS-232 to every
receiver RS-232 port
or transmit
command from
every receiver
RS-232 port to
MASTER RS-232
port.
IR IN: Phoenix jack
connects control
equipment
totransmission signal
from transmitter IR
IN port to every
receiver IR OUT
port.
IR OUT: Phoenix
jack connects control
equipment to
transmit signal from
every receiver IR IN
port.
6 RS-232/IR
RS-232: Phoenix
jack connects control
equipment to
transmit command
between Transmitter
and Receiver.
(Attention:
Transmitter RS-232
port and
receiver RS-232 port
is one-to-one
transmission.(
IR IN: Phoenix jack
connects control
equipment to
transmission IR
signal between
Transmitter and
Receiver. (Attention:
Transmitter IR IN
port and
receiver IR OUT
port is one-to-one
transmission.(
IR OUT: Phoenix
jack connects control
equipment to
transmission IR
signal between
Transmitter and and
Receiver. (Attention:
Transmitter IR OUT
port
and receiver IR IN
port is one-to-one
transmission.(

Number Name Function
descriptions
1HDMI
HDMI IN: Connect
to the HDMI source
device, such as DVD
player or Set top
box.
HDMI OUT: HDMI
LOOP output port.
Connect to the local
HDMI display
device, such as
HDTV or monitor.
2 HDBaseT OUT
Standard HDBaseT
output port. Connect
to HD-BaseT
Receiver with a UTP
cable.
3 DC 24V
Connect 24V/2.7A
adaptor to AC wall
outlet for power
supply.
4 LAN
Connects to an
active Ethernet link
by an RJ-45 cable.
5 MASTER
RS-232: Phoenix
jack connects control
equipment to
transmit command
from transmitter
RS-232 to every
receiver RS-232 port
or transmit
command from
every receiver
RS-232 port to
MASTER RS-232
port.
IR IN: Phoenix jack
connects control
equipment
totransmission signal
from transmitter IR
IN port to every
receiver IR OUT
port.
IR OUT: Phoenix
jack connects control
equipment to
transmit signal from
every receiver IR IN
port.
6 RS-232/IR
RS-232: Phoenix
jack connects control
equipment to
transmit command
between Transmitter
and Receiver.
(Attention:
Transmitter RS-232
port and
receiver RS-232 port
is one-to-one
transmission.(
IR IN: Phoenix jack
connects control
equipment to
transmission IR
signal between
Transmitter and
Receiver. (Attention:
Transmitter IR IN
port and
receiver IR OUT
port is one-to-one
transmission.(
IR OUT: Phoenix
jack connects control
equipment to
transmission IR
signal between
Transmitter and and
Receiver. (Attention:
Transmitter IR OUT
port
and receiver IR IN
port is one-to-one
transmission.(

Number Name Function
descriptions
1HDMI
HDMI IN: Connect
to the HDMI source
device, such as DVD
player or Set top
box.
HDMI OUT: HDMI
LOOP output port.
Connect to the local
HDMI display
device, such as
HDTV or monitor.
2 HDBaseT OUT
Standard HDBaseT
output port. Connect
to HD-BaseT
Receiver with a UTP
cable.
3 DC 24V
Connect 24V/2.7A
adaptor to AC wall
outlet for power
supply.
4 LAN
Connects to an
active Ethernet link
by an RJ-45 cable.
5 MASTER
RS-232: Phoenix
jack connects control
equipment to
transmit command
from transmitter
RS-232 to every
receiver RS-232 port
or transmit
command from
every receiver
RS-232 port to
MASTER RS-232
port.
IR IN: Phoenix jack
connects control
equipment
totransmission signal
from transmitter IR
IN port to every
receiver IR OUT
port.
IR OUT: Phoenix
jack connects control
equipment to
transmit signal from
every receiver IR IN
port.
6 RS-232/IR
RS-232: Phoenix
jack connects control
equipment to
transmit command
between Transmitter
and Receiver.
(Attention:
Transmitter RS-232
port and
receiver RS-232 port
is one-to-one
transmission.(
IR IN: Phoenix jack
connects control
equipment to
transmission IR
signal between
Transmitter and
Receiver. (Attention:
Transmitter IR IN
port and
receiver IR OUT
port is one-to-one
transmission.(
IR OUT: Phoenix
jack connects control
equipment to
transmission IR
signal between
Transmitter and and
Receiver. (Attention:
Transmitter IR OUT
port
and receiver IR IN
port is one-to-one
transmission.(
※"Description 1

POC (Power over Cable) Application Example
※"Description 2
Bidirectional Infrared control Application Example
※"Description 3
Bidirectional RS232 control Application Example
6. HDBT Receiver
Number Name Function description
1 POWER
This LED
illuminates when the
device is connected
with power supply.
2 DC 24V
Plug the 24V DC
power supply into
the unit.(If the
device connect to the
matrix, the receiver
doesn't need local
power supply due to
POC from the
matrix.)
3 HDBaseT IN
Standard HDBaseT
signal input port.
Connect to splitter
HDBaseT output
with a UTP cable.
4 HDMI OUT
HDMI output port.
This slot is where
you connect the
HDTV or monitor
with HDMI cable.
5 IR IN
Channel 1 IR
Receiver. Connect
with Wideband IR
Rx.
6 IR OUT
Channel 2 IR
Transmitter.
Connect with
Wideband IR Tx.
7 RS-232
Connect to a PC or
control system with
phoenix jack for
transmission of
RS-232 commands.
8Connection Signal
Indicator Lamp
※Illuminate: The
Transmitter and
Receiver are in good
connection status.
※Flashing: The
Transmitter and
Receiver are in poor
connection status.
※Dark: The
Transmitter and
Receiver are not
connected.
9Data Signal
Indicator Lamp
※Illuminate: The
HDMI signal with
HDCP.
※Flashing: The
HDMI signal
without HDCP.
※Dark: No HDMI
signal.

Number Name Function description
1 POWER
This LED
illuminates when the
device is connected
with power supply.
2 DC 24V
Plug the 24V DC
power supply into
the unit.(If the
device connect to the
matrix, the receiver
doesn't need local
power supply due to
POC from the
matrix.)
3 HDBaseT IN
Standard HDBaseT
signal input port.
Connect to splitter
HDBaseT output
with a UTP cable.
4 HDMI OUT
HDMI output port.
This slot is where
you connect the
HDTV or monitor
with HDMI cable.
5 IR IN
Channel 1 IR
Receiver. Connect
with Wideband IR
Rx.
6 IR OUT
Channel 2 IR
Transmitter.
Connect with
Wideband IR Tx.
7 RS-232
Connect to a PC or
control system with
phoenix jack for
transmission of
RS-232 commands.
8Connection Signal
Indicator Lamp
※Illuminate: The
Transmitter and
Receiver are in good
connection status.
※Flashing: The
Transmitter and
Receiver are in poor
connection status.
※Dark: The
Transmitter and
Receiver are not
connected.
9Data Signal
Indicator Lamp
※Illuminate: The
HDMI signal with
HDCP.
※Flashing: The
HDMI signal
without HDCP.
※Dark: No HDMI
signal.

7. Web GUI User Guide
The Splitter can be controlled via Web GUI through LAN port. You must
know current Splitter IP address. The static IP address is 192.168.1.100.
You can connect PC Web GUI through dynamic IP adress. In this unit,
you can get the IP address via PC Controller. Firstly, opening Splitter PC
Controller software, as following page:
Then select the “TCP Control Mode” port, click the “Search” button. At
this moment, you can get current IP address. You can set the IP address to
your PC/laptop/mobile Internet Explorer and click “Search” to enter Web
GUI page.
The Web GUI likes below:
General page
①HDMI Input: Display current the HDMI Input port status. The
“Yes” has connected source device and “No” represent not
connection.
LOOP OUT: Display current the LOOP OUT port status. The “Yes”
has
connected display device and “No” represent not connection.
②This is a drop-down list button:
HDMI CEC/HDBT1 CEC/HDBT2 CEC/HDBT3 CEC/HDBT4 CEC:
If the five
outputs end connect display device that is standbying status, you can
select a drop-down button to open the display device.
ALL: Open all the display device.
(Attention: Supports only the display device with CEC function.)
③Power switch. The Splitter will work when open this switch.
Otherwise, the Splitter will standby. Lock switch. Open this switch,
press the Splitter on-panel button will mute.
Close this switch, it will unmute.
④HDBT Output: Display current the HDBT Output port status.

The “Yes” has connected display device and “No” represent not
connection.
⑤Reboot button: Click this button will reboot device.
Factory Output button: Click this button will set to factory reset.
EDID page
①Set EDID mode to input source, then click the “Set” button.
②Copy EDID from output port to input source, then click “Set”
button.
③Open EDID file to source device, then click “Set” button.
④Click “Refresh” button to refresh currently source device EDID
mode. It will display the latest input EDID mode status.
Status page
①Network Configuration
◆In DHCP open status:
HDCP switch: Obtian the network configuration information,
including IP
address, Subnet, Gateway. Then click “Set” button to save DHCP
status.
◆In DHCP close status:
HDCP switch: If the DHCP switch has been closed, user can set IP,
Subnet
and Gateway address. In this moment, click the “Set ” button to save
current status information. (Attention: If user have set the IP
address, click the “Set” button. In this moment, user need set the IP
address again to your PC/laptop/mobile Internet Explorer and click
“Search” to enter Web GUI page.)
Status button: Click this button will refresh current network
configuration information to display in Status Log. In this unit, Mac
address can check only, you can not set it.
②Display the network configuration information.
Upgrade page
①Open upgrade file to upgrade.

8. Application Example
Mission Statement
BZB Gear manifests from the competitive nature of the audiovisual
industry to innovate while keeping the customer in mind. AV solutions
can cost a pretty penny, and new technology only adds to it. We believe
everyone deserves to see, hear, and feel the advancements made in
today’s AV world without having to break the bank. BZB Gear is the
solution for small to medium-sized applications requiring the latest
professional products in AV.
We live in a DIY era where resources are abundant on the internet. With
that in mind, our team offers system design consultation and expert tech
support seven days a week for the products in our BZB Gear catalog.
You’ll notice comparably lower prices with BZB Gear solutions, but the
quality of the products is on par with the top brands in the industry. The
unparalleled support from our team is our way of showing we care for
every one of our customers. Whether you’re an integrator, home theater
enthusiast, or a do-it-yourselfer, BZB Gear offers the solutions to allow
you to focus on your project and not your budget.
Warranty Information
BZB Gear | Second Year Assurance

BZB Gear wants to assure you peace of mind. We're so confident in the
quality of our products that along with the manufacturer's one-year
limited warranty, we are offering free second-year warranty coverage
upon registration*!
Taking advantage of this program is simple, just follow the steps below:
1. Register your product within 90 days of purchase by visiting
BZBGear.com/warranty.
2. Complete the registration form. Provide all necessary proof of purchase
details, including serial number and a copy of your sales receipt.
For questions, please call 1.888.660.2962 or email
[e-mail].
For complete warranty information, please visit BZBGear.com/warranty
or scan the QR code below.
*Terms and conditions apply. Registration is required.
