caddytrek R2 S-Series Use and care manual

Tools Needed:
•Phillips screwdriver or
•3 mm hex head wrench
•Rubber mallet
Step 2: Remove the (4) upper screws (circled
in red).
Step 4: Roll handle forward, gently tap outwards
using a rubber mallet then remove top half of
frame..
Step 5: Once top half is off, remove the lower
(4) screws, circledin red.
LOWER JOINTS REPLACEMENT
Step 1: Note the orientation of the unit and
confirm the left and right lower joints.
Step 3: To get screw out, loosen the joint
(red arrow) and squeeze together (red circle).
CAUTION: When removing the top half of
frame, DO NOT over extend sensor wires.
Step 6: Using a rubber mallet, tap upward to
remove lower joints.
Pg. 1 of 2
Right Left

Step 7: Replace the replacement lower joints.
Make sure the lower joints are in a locked
position.
Step 9: Install the top half of the frame to the
lower joints. IMPORTANT: Roll the lower joints
to prevent overextending the sensor wires.
Step 8: Align the screw holes (lower) of the
lowerjoints to the holes on the frame and
install the (4) screws.
Step 10: Align the screw holes (upper) of the
lower joints to the holes on the top half of the
frame and install the (4) screws.
Pg. 2 of 2
