1. 1 Important Safety Instruction
• Read these instructions.
• Pay attention on all the warnings.
• Follow all instructions.
• Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
• Do not dissemble or insert foreign objects.
• Do not install near any heat sources such as radiation, beat registers, stoves, or other apparatus.
(Including amplifiers) that produce heat.
• Do not aim the camera at the sun or any other strong light source.
• Do not install the camera in intermittent lighting environments.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Installation should be done only by qualified personnel and conform to all local codes.
• Installation should be done in a place strong enough to hold it.
• Use only installation methods and materials capable of supporting four times the maximum specified load.
• It is designed for indoor use only and it must not be installed where exposed to rain and moisture
without additional outdoor housing and bracket.
• To prevent damage from water leakage when installing a mount outdoors on a roof or wall,
apply sealant around the bolt holes between the mount and mounting surface.
• These instructions are for use by qualified service personnel only. To reduce the risk of electric shock
do not perform any servicing other that contained in the operating instructions unless you are qualified
to do so.
• Only use replacement parts recommended by manufacturer. ad these instructions.
1. PRECAUTIONSTABLE OF CONTENTS
3p.
4p.
4p.
5p.
6p.
7p.
9p.
26p.
33p.
33p.
33p.
34p.
35p.
36p.
1. PRECAUTIONS
1. 1 Important Safety Instruction ...................................................................................
2. GETTING STARTED
2. 1 Unpacking ..............................................................................................................
2. 2 Part name ...............................................................................................................
2. 3 DIP Switch Setting .................................................................................................
2. 4 Cable Connection ...................................................................................................
3. INSTALLATION
3. 1 Installation .............................................................................................................
4. ON-SCREEN DISPLAY PROGRAM MENU
4. 1 Motion Setting .......................................................................................................
4. 2 Dome Setting .........................................................................................................
4. 3 Clear Setting ..........................................................................................................
4. 4 PTZ Reset ..............................................................................................................
4. 5 Other Quick Opercating Guide .................................................................................
5. SPECIFICATION
5. 1 Mechanism Specification .......................................................................................
6. DIMENSION
6. 1 DIMENSION ..........................................................................................................
7. CONFIGURATION
7. 1 Connecting to Keyboard with DVR ..........................................................................

04 05
2. 1 Unpacking
The following parts are supplied with the outdoor speed PTZ dome system.
2. GETTING STARTED
<Figure 1. package Components>
2. 3 DIP Switch Setting
Before start up the dome camera, set the protocol and camera address and termination
set with dip-switches and click-switches as shown in the below diagram.
1.Set the camera address (ID)
2. Protocol, Baudrate, Camera setting
3.Set the termination On/Off
Address switch
Open the top cover of the product to set camera address.
* ID setting is 1~255 available
S1 S3 S4
S1 : 1-digit number of address
S3 : 10-digit number of address
S4 : 100-digit number of address
Ex) S4 = 1
S3 = 2
S1 = 8
The ID number is 128.
123456789101112
ON DIP
123
OFF OFF OFF
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
PELCO-D
PELCO-P
WTX
EZP
NC
NC
NC
NC
PROTOCOL 456
OFF OFF OFF
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
2400
4800
9600
19200
38400
57600
115200
NC
BAUDRATE
7
OFF
ON
RS-422
RS-485
RSMODE 9
OFF
ON
OFF
ON
RS LOOP 11
OFF
ON
IP OFF
IP ON
IP SELECT
8
OFF
ON
NTSC
PAL
NTSC/PAL 10
OFF
ON
NC
NC
NC 12
OFF
ON
OFF
PROGRAM MODE
BOOTO
The device which is connected at the end of the line must have the
cable communication terminated. Without proper termination,
there is potential for control signal errors.
The product have the cable communication terminated by setting
the appropriate dip switch.
9
ON : Terminated
OFF : Not terminated
2. 2 Part name
Front Back Bottom
Safety loop
ID setting
Commnucation
setting
2
3
1
Analogue video cable
Manual
Ceiling bracket
Wall bracket
SCREW(M4*8 SUS)
Screw
Tape seal
Body
Mount joint
Mount
Ceiling bracket
Pipe socket
SCREW
(SET ANCHOR 1/4")
Screw
HD-SDI Cable connector
(HD-SDI only)
Power adaptor(Option)
<Wall type> <Ceiling type>

06 07
2. 4 Cable connection
2. 4. 2 RS-485/RS-422 Connection
2. 4. 1 Power/Data communication cable connection
RS-422/485 connection
The PTZ can be remotely controlled by an external device or control system, such as a control
keyboard or DVR, using RS-485 half-duplex, RS-422 duplex or simplex serial communication signals.
Connect marked RX+, RX- to TX+ and TX- of the RS-485 control system.
If control system is RS-422, connect TX+,TX- of controller to RX+ and RX- of the PTZ Camera series.
And also connect the TX+, TX- to RX+, RX- of the control device respectively. Total length
of the cable for communication should not exceed 1.2Km.
2. 4. 3 HD-SDI Output connection
Connect the HD-SDI out (BNC) connector to the monitor or video input of DVR. Video cable and
RS-485/422 communication cable are not provided in this product's package.
3.Installation
- The following steps of installation and connection work should be done by qualified service personnel
or system installers and should conform to all local codes.
- Be sure to switch the camera off before installation is completed.
- Do not install the camera near the air outlet of an air conditioner.
- Before installation, set the dome system with Dip switch on the back side of the mechanism part, and
assemble the mechanism and housing according to the below instruction
3. 1 Installation
Set the mount to the wall bracket by trun it to clockwise.
Push the knob of mount and pull down.
Connect the cable. (See the page6)
To insert or remove the SD card, open the protective cap
and put up the slot cover of SD card.
Cover the protective cap after insert the SD card to prevent
foreign substance damage.
Set the mount to the ceiling bracket by trun it to clockwise.
Knob
Knob
Pipe Socket
Ceiling Pipe
* Fix the socket into the ceiling pipe when install the ceiling
bracket. The socket is included in the accessory package.
Tx-
Tx+
Rx-
Rx+
HD-SDI POWER AC 24V
Tx + / Tx -
CVBS
FG
AC24
AC24
NETWORK
Coaxial cable
AUX
)%4%*
DBCMFDPOOFDUPS
6TFUIF)%4%*DBCMFDPOOFDUPSXIFOVTFDPBYJBMDBCMF
ALARM INPUT(I/O 1)
ALARM INPUT(I/O 2)
Do not connect the AC24V power terminal to
the communication terminal.
- Power Terminal: 2PIN
- Com Terminal: 4PIN
Caution

08 09
4. ON-SCREEN DISPLAY PROGRAM MENU
4. 1 Motion Setting
The initialize screen is shown up to check address, version,
protocol and video when the power on.
MAIN MENU
< NEAR / RIGHT →PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
The preset function is that the camera memorizes
positions of the pan/tilt and zoom. This function is
a representative function of the speed dome which
can find memorized preset positions just by selecting
the preset No. A Maximum of 255 Preset positions
are toured in order.
4. 1. 1 Preset
Preset Quick Operating Guide
Set Preset : 1~255 +
Go to Preset : 1~255 +
PRESET
PRESET
PRESET MENU
< NEAR / RIGHT →PRESET NO >
PRESET NO : 01 DEFINE
LABEL :
POSITION : XXX . X, XXX. X
FOCUS : AUTO
SAVE CLR BACK EXIT
PRESET SELECT 1
(1) Select the Preset number
P01 : Defined Preset number / 01 : Undefined Preset number
Move : Select : NEAR
001 002 003 004 005 006
007 008 009 010 011 012
013 014 015 016 017 018
019 020 021 022 023 024
025 026 027 028 029 030
031 032 033 034 035 036
037 038 039 040 041 042
043 044 045 046 047 048
049 050 051 052 053 054
<SEL
ઔ
NEAR /MOVE & JOYSTICK>
INITIALIZE
PTZID
FIRMWARE
V-FORMAT
CVBS
PROTOCOL
BUADRATE
CAMERA
>>PAN OFFSET. . . . . PASS
>>TILT OFFSET. . . . . PASS
NORMAL SETTING . . . . . . WAIT
: 001
: X.XX
: 1080p30
: NTSC
: PELCO D V1.0
: 2400 ,N.1
: MMC
MOTION MENU
< NEAR / RIGHT
ઔ
PRESET >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
3sec.
※You can not go into the menu in the IP mode.
After connecting the cable, set the mount in the proper position and fix the 2 screws (M4*8)
1. Connect the safety loop on the body and mount back side.
2. Align the arrow mark in the body and mount.
3. Fix the body by turn it to clockwise.
* Please check the direction of connector in the camera body and mount.
Fix the screws with camera body and mount as the left picture.
CLOSE
(Turn the body to clockwise)
OPEN
safety loop
Front
Front

10 11
PRESET MENU
< NEAR / RIGHT
ઔ
PRESET NO >
PRESET NO : 01 DEFINE
LABEL :
POSITION : XXX . X, XXX. X
FOCUS : AUTO
SAVE CLR BACK EXIT
PRESET MENU
< NEAR / RIGHT
ઔ
PRESET NO >
PRESET NO : 01 DEFINE
LABEL :
POSITION : XXX .X , XXX. X
FOCUS : AUTO
SAVE CLR BACK EXIT
PRESET MENU
< NEAR / RIGHT
ઔ
PRESET NO >
PRESET NO : 01 DEFINE
LABEL :
POSITION : 000. 0 ,000. 0
FOCUS : AUTO
SAVE CLR BACK EXIT
(4) Select the focus mode for Preset
PRESET POSITION
(3) Define the Preset position
① Select the Position menu
or
NEAR
② Move and set the position ③ Set & Back
NEAR
PRESET LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : PRESET 01
(2) Set the Preset Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Preset.
After the label is set, push the NEAR button to exit.
On focus menu, there are 3 modes : Auto, Manual,
Onepush. It allows detailed settings for the preset.
① Select the Focus menu
or
NEAR
② Move and set the Focus Menu
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
POSITION : 000. 0 , 000. 0
<EXIT FOCUS NEAR >
PRESET MENU
< NEAR / RIGHT
ઔ
PRESET NO >
PRESET NO : 01 DEFINE
LABEL :
POSITION : 000. 0 ,000. 0
FOCUS : AUTO
SAVE CLR BACK EXIT
EXTEND SET ▶
(5) “Save” above setting Pattern data to the memory.
(6) “CLR” means above setting Pattern data will not be
saved and be cleared.
(7) “BACK” means it goes back to the previous
menu :Motion.
(8) “EXIT” means it goes out of MENU.
MAIN MENU
< NEAR / RIGHT →PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
The Tour function consists of several presets run by turn. It is also adjusts the moving speed
(0~63 step) and dwell time (1~99secs). Maximum of 8 Tour functions are toured in order.
4. 1. 2 Tour
Tour Quick Operating Guide
( 1 Tour can be set for 15 presets. )
※
MOTION MENU
< NEAR / RIGHT
ઔ
GROUP >
PRESET
ઔ
GROUP ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
Set Tour : 71~78 + 3sec.
Go to Tour : 71~78 +
PRESET
Set Tour : 1~8 + 3sec.
TOUR
PRESET
Go to Tour : 1~8 + TOUR

12 13
TOUR MENU
< NEAR / RIGHT
ઔ
TOUR NO >
TOUR NO : 01 UNDEFINE
LABEL :
TOUR EDIT :
SAVE CLR BACK EXIT
TOUR SELECT
< SEL →NEAR / MOVE
ઔ
JOYSTICK >
01 02 03 04 05 06
07 08
(1) Select the Tour number
T01 : Defined Tour number / 01 : Undefined Tour number
Move : Select : NEAR
TOUR MENU
< NEAR / RIGHT →TOUR NO >
TOUR NO : 01 DEFINE
LABEL : TOUR 01
TOUR EDIT :
SAVE CLR BACK EXIT
(3) Define the Preset position
① Move to the set-up window
or
NEAR
② Move and set the position ③ Set & Back
NEAR
TOUR EDIT (01)
NO PRESET SPEED DWELL
01 ◀01 63 01
02 ◁ 02 63 01
03 ◁ XX XX XX
04 ◁ XX XX XX
05 ◁ XX XX XX
06 ◁ XX XX XX
07 ◁ XX XX XX
08 ◁ XX XX XX
< SEL & NEAR PRESET & LEFT >
(2) Set the Tour Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Tour.
After the label is set, push the NEAR button to exit.
PRESET SELECT 1
001 002 003 004 005 006
007 008 009 010 011 012
013 014 015 016 017 018
019 020 021 022 023 024
025 026 027 028 029 030
031 032 033 034 035 036
037 038 039 040 041 042
043 044 045 046 047 048
049 050 051 052 053 054
<SEL
ઔ
NEAR /MOVE & JOYSTICK>
TOUR LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : TOUR 01
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
TOUR MENU
< NEAR / RIGHT
ઔ
TOUR NO >
TOUR NO : 01 DEFINE
LABEL :
TOUR EDIT :
SAVE CLR BACK EXIT
TOUR MENU
< NEAR / RIGHT →DATA SAVE >
TOUR NO : 01 DEFINE
LABEL : TOUR 01
TOUR EDIT :
SAVE CLR BACK EXIT
(4) “Save” above setting Pattern data to the memory.
(5) “CLR” means above setting Pattern data will not be
saved and be cleared.
(6) “BACK” means it goes back to the previous
menu :Motion.
(7) “EXIT” means it goes out of MENU.
4. 1. 3 GROUP
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
GROUP : You can make Max. 6 groups and call the saved tour by turn.
- GROUP NO : Set from 1to 6 groups.
- LABEL : Set the lable of each group
- GROUP EDIT : Set the tour from 1 to 6 of group.
▷GROUP NO
LABEL
GROUP EDIT
: 01 DEFINE
:
▷
GROUP MENU
< NEAR / RIGHT
ઔ
GROUP NO >
SAVE CLR BACK EXIT
MOTION MENU
< NEAR / RIGHT
ઔ
GROUP >
PRESET
ઔ
GROUP ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
Set Group : 101~106+
Go to Group : 101~106+
PRESET
PRESET
Group Quick Operating Guide
3sec.

14 15
SCAN SELECT
< SEL
ઔ
NEAR / MOVE

JOYSTICK >
01 02 03 04 05 06
07 08
SCAN MENU
< NEAR / RIGHT
ઔ
SCAN NO >
SCAN NO : 01 UNDEFINE
LABEL :
START POS : XXX . X, XXX . X
END POS : XXX . X, ---
SPEED : XX
DWELL : XX
FOCUS : NONE
SAVE CLR BACK EXIT
(1) Select the Scan number
S01 : Defined Scan number / 01 : Undefined Scan number
Move : Select : NEAR
The Scan function means that the camera keeps panning between two programmed pan positions.
It is also adjusts the moving speed(1~63 step). Maximum 8 Scan functions are toured in order.
4. 1. 4 Scan
Scan Quick Operating Guide
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
SCAN NO >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : XXX . X, XXX . X
END POS : XXX . X, ---
SPEED : XX
DWELL : XX
FOCUS : NONE
SAVE CLR BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
START POS >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
END POS >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
STRAT POSITION
< EXIT →FOCUS NEAR >
POSITION : 000.0, 000.0
(3) Define the Start pan position
① Select Start Pos menu
or
NEAR
② Move and set the position ③ Go back
NEAR
(2) Set the Scan Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
(4) Define the End pan position
① Select End Pos menu
or
NEAR
② Move and set the position ③ Go back
NEAR
POSITION : 000.0, 000.0
END POSITION
< EXIT →FOCUS NEAR >
It’s available to set the desired label, displayed on the executing screen of Scan.
After the label is set, push NEAR button to go out.
SCAN LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : SCAN 01
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
MOTION MENU
< NEAR / RIGHT
ઔ
SCAN >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
Set Scan : 81~88 +
Go to Scan : 81~88 +
PRESET
Set Scan : 1~8 + Scan
PRESET
Go to Scan : 1~8 + Scan
3sec.
3sec.
※Save the zoom, Tilt and position.

16 17
(8) Save above Scan data setting to the memory.
(9) “CLR” means above setting Scan data will not be
saved and be cleared.
(10) “BACK” means it goes back to the previous
menu :Motion.
(11) “EXIT” means it goes out to MENU
(7) Set the Focus
(5) Set the Scan speed
Increase : or
Decrease : or
TELE
JOYSTICK
WIDE
JOYSTICK
SCAN MENU
< NEAR / RIGHT
ઔ
MOVE SPEED >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
DWELL >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
DWELL >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
SCAN MENU
< NEAR / RIGHT
ઔ
DWELL >
SCAN NO : 01 DEFINE
LABEL : SCAN 01
START POS : 000 . 0 , 000 . 0
END POS : 000 . 0 , ---
SPEED : 60
DWELL : 02
FOCUS : AUTO
SAVE CLR BACK EXIT
It adjusts the moving speed from 1~63 steps.
Focus can be set Auto or Manual.
(6) Set the Dwell Time
Increase : or
Decrease : or
TELE
JOYSTICK
WIDE
JOYSTICK
Dwell time means the time that the camera stay at
the start & end pan positions.
It’s adjustable from 00~59seconds.
PATTERN MENU
< NEAR / RIGHT
ઔ
PATTERN NO >
PATTERN NO : 01 UNDEFINE
LABEL :
RECORD :
PLAY :
SAVE CLR BACK EXIT
PATTERN SELECT
< SEL
ઔ
NEAR / MOVE & JOYSTICK >
01 02 03 04
(1) Select the Pattern number
PAT01 : Defined Pattern number / 01 : Undefined Pattern number
Move : Select : NEAR
The Pattern function memorizes User’s random moving path and zoom ratio. Total recording time
limit is 90secs and maximum 4 Pattern functions are toured in order.
4. 1. 5 Pattern
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
MOTION MENU
< NEAR / RIGHT
ઔ
PATTERN >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
Set Pattern : 91~94 +
Go to Pattern : 91~94 +
PRESET
Set Pattern : 1~4 + Pattern
PRESET
Go to Pattern : 1~4 + Pattern
Pattern Quick Operating Guide
3sec.
3sec.

18 19
PATTERN MENU
< NEAR / RIGHT
ઔ
EDIT LABEL >
PATTERN NO : 01 DEFINE
LABEL :
RECORD
ઔ
PLAY
ઔ
SAVE CLR BACK EXIT
PATTERN MENU
< NEAR / RIGHT
ઔ
RECORD >
PATTERN NO : 01 DEFINE
LABEL :
RECORD ▶
PLAY
ઔ
SAVE CLR BACK EXIT
PATTERN MENU
< NEAR / RIGHT
ઔ
PLAY >
PATTERN NO : 01 DEFINE
LABEL :
RECORD
ઔ
<08SEC>
PLAY
ઔ
SAVE CLR BACK EXIT
(4) Play back the recorded Pattern data
(3) Record and Save the User’s random Pattern data
① Select the “Record” Menu
or
NEAR
② Move and record the pattern ③ Set & Back
NEAR
000.0, 000.0
EXIT
ઔ
NEAR 06/60
PATTERN RECORD
(2) Set the Pattern Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Pattern.
After the label set, push NEAR button to go out.
PATTERN LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : PATTERN
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
PATTERN MENU
< NEAR / RIGHT
ઔ
PLAY >
PATTERN NO : 01 DEFINE
LABEL :
RECORD
ઔ
<08SEC>
PLAY
ઔ
SAVE CLR BACK EXIT
(5) “Save” above setting Pattern data to the memory.
(6) “CLR” means above setting Pattern data will not be
saved and be cleared.
(7) “BACK” means it goes back to the previous
menu :Motion.
(8) “EXIT” means it goes out of MENU.

20 21
AREA MENU
< NEAR / RIGHT
ઔ
AREA NO > <SEL & MEAR / MOVE & JOYSTICK>
AREA NO : 01 UNDEFINE
LABEL :
START PAN POS.: XXX . X
STOP PAN POS.: XXX . X
SAVE CLR BACK EXIT
AREA MENU
< NEAR / RIGHT
ઔ
AREA NO >
AREA NO : 01 DEFINE
LABEL :
START PAN POS.: XXX . X
STOP PAN POS.: XXX . X
SAVE CLR BACK EXIT
The Area function means that it displays the Area name between two programmed pan positions.
Maximun 16 Area functions are toured in order.
4. 1. 6 Area
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
AREA SELECT
01 02 03 04 05
06 07 08 09 10
11 12 13 14 15
16
(1) Select the Area number
AR 01 : Defined Area number / 01 : Undefined Area number
Move : Select : NEAR
(2) Set the Area Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Area.
After the label set, push NEAR button to go out.
AREA LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : AREA
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
AREA MENU
< MOVE & NEAR / JOYSTICK >
AREA NO : 01 DEFINE
LABEL :
START PAN POS.: 000 . 0
STOP PAN POS.: 000 . 0
SAVE CLR BACK EXIT
AREA MENU
< MOVE & NEAR / JOYSTICK >
AREA NO : 01 DEFINE
LABEL :
START PAN POS.: 000 . 0
STOP PAN POS.: 000 . 0
SAVE CLR BACK EXIT
AREA MENU
< NEAR / RIGHT
ઔ
AREA >
AREA NO : 01 DEFINE
LABEL : AREA 01
START POS : 000 . 0 .
STOP POS : 000 . 0 .
SAVE CLR BACK EXIT
AREA START PAN POSITION
< EXIT →FOCUS NEAR >
POSITION : 000.0
AREA STOP PAN POSITION
< EXIT →FOCUS NEAR >
POSITION : 000.0
(3) Define the Start pan position
① Select the “Start Pan Pos” menu
or
NEAR
② Move and set the position ③ Set & Back
NEAR
(4) Define the Stop pan position
① Select the “Start Pan Pos” Menu
or
NEAR
② Move and set the position ③ Set & Back
NEAR
** Only pan position is adjustable, becaue tilt position is fixed when “Start Pan Position” is set.
(5) “Save” above setting Area data to the memory.
(6) “CLR” means above setting Area data will not be
saved and be cleared.
(7) “BACK” means it goes back to the previous
menu :Motion.
(8) “EXIT” means it goes out of MENU
※ Camera will move to clockwise direction only when START setting.
MOTION MENU
< NEAR / RIGHT
ઔ
AREA >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT

22 23
ALARM MENU
< NEAR / RIGHT

ALARM NO >
ALARM NO : 01 UNDEFINE
LABEL :
PRESET NO. : XX
SAVE CLR BACK EXIT
ALARM MENU
< NEAR / RIGHT

ALARM LABEL >
ALARM NO : 01 DEFINE
LABEL :
PRESET NO. : XX
SAVE CLR BACK EXIT
The Alarm function means that the camera moves to the programmed Preset position by the Alarm trigger.
Maximum 8 Alarm functions are toured in order.
4. 1. 7 Alarm
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
(1) Select the Alarm number
Alarm 01 : Defined Alarm number / 01 : Undefined Alarm number
Move : Select : NEAR
(2) Set the Alarm Label
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Alarm.
After the label is set, push the NEAR button to exit.
ALARM LABEL EDIT ( 01 )
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL : ALARM 01
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
ALARM SELECT
< SEL →NEAR / MOVE  JOYSTICK >
01 02
07 08
03 04 05 06
ALARM MENU
< NEAR / RIGHT

SELECT PRESET >
ALARM NO : 01 DEFINE
LABEL :
PRESET NO. : 01
SAVE CLR BACK EXIT
(3) Define the Preset position with Alarm trigger
① Select the “Preset No”
or
NEAR
② Move and set the position ③ Set & Back
NEAR
(4) “Save” above setting Alarm data to the memory.
(5) “CLR” means above setting Alarm data will not be
saved and be cleared.
(6) “BACK” means it goes back to the previous
menu :Motion.
(7) “EXIT” means it goes out of MENU
PRESET SELECT
001 002 003 004 005 006
007 008 009 010 011 012
013 014 015 016 017 018
019 020 021 022 023 024
025 026 027 028 029 030
031 032 033 034 035 036
037 038 039 040 041 042
043 044 045 046 047 048
049 050 051 052 053 054
<SEL
ઔ
NEAR /MOVE & JOYSTICK>
ALARM MENU
< NEAR / RIGHT

SELECT PRESET >
ALARM NO : 01 DEFINE
LABEL :
PRESET NO. : 01
SAVE CLR BACK EXIT
MOTION MENU
< NEAR / RIGHT
ઔ
ALARM >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT

24 25
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
The Privacy Zone Masking function means that it sets the blocking territories to prevent camera functions
for the privacy of personal reasons. Maximum of 8 Privacy Zone Masking functions are toured in order.
4. 1. 8 Privacy Zone Masking
PRIVACY MENU
< NEAR / RIGHT
ઔ
PRIVACY NO >
PRIVACY NO : 01 UNDEFINE
POSITION : XXX . X , XXX . X
SAVE CLR BACK EXIT
PRIVACY MENU
< NEAR / RIGHT
ઔ
PRIVACY NO >
PRIVACY NO : 01 UNDEFINE
POSITION : XXX . X , XXX . X
SAVE CLR BACK EXIT
PRIVACY SELECT
< SEL →NEAR / MOVE
ઔ
JOYSTICK >
01 02 03 04 05
06 07 08
(1) Select the Privacy Zone number
Privacy 01 : Defined Alarm number / 01 : Undefined Alarm number
Move : Select : NEAR
(2) Set the Privacy Zone Position
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired position and size of the blocking territories freely.
After the Privacy Zone is set, push the NEAR button to go out.
PRIVACY POSITION
< EXIT
ઔ
FOCUS NEAR >
POSITION : 000. 0 , 000 .
MASK SIZE : <OPEN / CLOSE >
PRIVACY MENU
< NEAR / RIGHT
ઔ
AREA >
SAVE CLR BACK EXIT
PRIVACY NO : 01 UNDEFINE
POSITION : XXX . X , XXX . X
(3) “Save” above settings of Privacy Zone data to the memory.
(4) “CLR” means above setting of Privacy Zone data will not
be saved and be cleared.
(5) “BACK” means it goes back to the previous
menu :Motion.
(6) “EXIT” means it goes out of MENU.
MOTION MENU
< NEAR / RIGHT
ઔ
PRIVACY >
PRESET
ઔ
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
ALARM
ઔ
AREA
ઔ
PRIVACY
ઔ
BACK EXIT
Adjust the MASK SIZE : OPEN (Lager), CLOSE (smaller)

26 27
NEAR
MAIN MENU
< NEAR / RIGHT
ઔ
PRESET >
MOTION
ઔ
DOME ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
BACK EXIT
4. 2 Dome Setting 4. 2. 3 Set the Power Up Action
When this function is ON, the camera memorizes the latest action and restores, it from sudden power
failure.
Select : or Set ON : Set OFF :
NEAR
4. 2. 1 Set the Dome camera title
Move : Select : or or Delete : or
TELE
JOYSTICK
WIDE
JOYSTICK
It’s available to set the desired camera title.
After the label is set, push NEAR button to exit.
Pan, Tilt, Zoom motion is adjustable in the “Dome Setting” Menu.
TITLE SET
< DELETE
ઔ
WIDE
< STORE
ઔ
TELE
BACK
ઔ
NEAR >
MOVE
ઔ
JOYSTICK >
LABEL :
0 1 2 3 4 5 6 7 8 9 (
) A B C D E F G H I J K
L M N O P Q R S T U V W
X Y Z . / , + - = < >
PARK MENU
<NEAR / RIGHT & PARK TIME>
TIME <MIN> : OFF
FUNCTION : NONE
NUMBER : XX
BACK
PARK MENU
<NEAR / RIGHT & PARK TIME>
TIME <MIN> : OFF
FUNCTION : NONE
NUMBER : XX
BACK
PARK MENU
<NEAR / RIGHT & PARK TIME>
TIME <MIN> : OFF
FUNCTION : NONE
NUMBER : XX
BACK EXIT
(1) Set the park Time (OFF, 10sec~10 min)
(2) Select the function which will be back
after the above set time.
(3) Select the appointed function’s Number
4. 2. 4 PARK ACTION
or NEAR
This function enables to locate the camera to specific
position automatically if operator doesn’t operate the
controller for a while.
4. 2. 2 VIDEO FORMAT
PAL : (1080P25) / (720P50) , NTSC : (1080P30) / (720P60)
DOME MENU
TITLE :
TEMP. SET
POWER UP ACTION : ON
VIDEO FORMAT
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
FACTORY SET
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
DOME MENU
TITLE
:
TEMP. SET
POWER UP ACTION : ON
VIDEO FORMAT
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
FACTORY SET
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
DOME MENU
TITLE :
VIDEO FORMAT
TEMP. SET
POWER UP ACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
FACTORY SET
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
DOME MENU
TITLE :
VIDEO FORMAT
TEMP. SET
FACTORY SET
POWER UP ACTION : ON
PARK ACTION
ઔ
DISPLAY ON/OFF
DOME SUB MENU
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ

28 29
< NEAR / RIGHT
ઔ
DWELL >
BACK
(4) “Save” above setting data to the memory.
(5) “CLR” means above setting Pattern data will
not be saved and be cleared.
(6) “BACK” means it goes back to the previous
menu.
(7) “EXIT” means it goes out of the MENU
PARK MENU
TIME <MIN> : OFF
FUNCTION : NONE
NUMBER : XX
4. 2. 5 Display ON/OFF Set
You can select the OSD ON to shown on the screen or clear by selecting OFF in this function.
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or NEAR
4. 2. 6 DOME SUB MENU
DOME MENU
TITLE :
VIDEO FORMAT
TEMP SET
FACTORY SET
POWER UP ACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
DOME MENU
TITLE :
VIDEO FORMAT
TEMP SET
FACTORY SET
POWER UP ACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
DISPLAY ON/OFF MENU
TITLE :
ZOOM :
PRESET :
TOUR :
AREA :
ALARM :
PATTERN :
PRIVACY :
SCAN :
POSITION :
GROUP :
ACTION :
(0)
(0)
(0)
(0)
(0)
(0)
(0)
(0)
(0)
(0)
(0)
<ON
ઔ
TETLE MOVE
ઔ
JOY >
<OFF
ઔ
WIDE BACK
ઔ
NEAR>
(1) DATA BACK/LOAD
Backup or load the Motion, Camera and PTZ Setting Data
(2) SPEED BY ZOOM
Pan and Tilt speed can be changed depending on
zoom magnification.
(3) IR SYNC MODE
ALS SYNC : Synchronized in visible light.
ALL ON : IR always on.
ALL OFF : IR always off.
(4) IR ILLUMINATE
HIGHEST : Output the Max.IR light
HIGH : Output the hight level of IR light
LOWEST : Out put the Min. IR light
LOW : Output the low level of IR light
MOTION SAVE
CAM DATA SAVE
DOME DATA SAVE
ALL DATA SAVE
MOTION LOAD
CAM DATA LOAD
DOME DATA LOAD
ALL DATA LOAD
: Save the current Motion Data
: Save the current Camera Data
: Save the current PTZ Data
: Save above all 3 Datas.
: Apply the saved Motion Data
: Apply the saved Camera Data
: Apply the saved PTZ Set Data
: Apply the saved above all 3 Datas.
- DATA BACK/LOAD Sub Menu Tree
※Factory default is ALS SYNC .
※Factory default is HIGHEST.
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< NEAR / RIGHT
ઔ
SUB MENU >
DOME MENU
MOTION SAVE
CAM DATA SAVE
DOME DATA SAVE
ALL DATA SAVE
MOTION LOAD
CAM DATA LOAD
DOME DATA LOAD
ALL DATA LOAD
▷
▷
▷
▷
▷
▷
▷
▷
BACK
< NEAR / RIGHT
ઔ
DATA SAVE >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >

30 31
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
4. 2. 7 TEMP. SET
< NEAR / RIGHT ON TIME >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 15 C
: 50 C
: 40 C
CURRENT TEMPER 50.40C
It shows you the current temperature and you can also set
the value manually. The compulsory Fan & Heater operation
is a useful function to remove humidity.
Set the operating temperature of the heater.(0~70℃)
(1) HEATER ON TEMP
Set the operating time of the heater.
- By 10min. (10~60 min.)
< NEAR / RIGHT ON TEMP >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 15C
: 50 C
: 40 C
CURRENT TEMPER 50,40C
DOME MENU
TITLE :
VIDEO FORMAT
TEMP. SET
POWER UP ACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
FACTORY SET
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
Tx communication line to transfer the unique value of
protocal response.
(Use this function when the protocol is pelco-D 5.0)
(9) RESPONSE TXD
Set the Day / Night ICR illumination. (0.5~10)
(5) ICR CHG LUX
(8) WIPER MODE
※Factory default is 2 LUX.
※factory default is OFF.
Select : or Set ON :
Set OFF :
NEAR
NEAR
(6) IR CONT. TYPE
※Factory default is OFF.
(2) HEATER ON TIME
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
DOME MENU
DATA BACK/LOAD
SPEED BY ZOOM
IR SYNC MODE
IR ILLUMINATE
ICR CHG LUX
IR CONT. TYPE
IR OFFSET
WIPER MODE
RESPONSE TXD
▷
: ON
: ALS SYNC
: HIGHEST
: 2 LUX
: AUTO
: 0
: OFF
: OFF
BACK
< CHANGE
ઔ
UP/DN SEL
ઔ
NEAR >
Set the IR sensitivity. (-4~4)
※Factory default is 0
(7) IR OFFSET
Select ON/OFF to use the wiper function.
Select AUTO or MANUAL mode in IR Zoom function.
※factory default is AUTO.

32 33
4. 3 Clear Setting
MAIN MENU
< NEAR / RIGHT
ઔ
CLEAR >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR ▶
PTZ RESET
EXIT
Select : or Set ON : Set OFF :
NEAR NEAR
4. 4 PTZ Reset
MAIN MENU
< NEAR / RIGHT
ઔ
RESET >
MOTION
ઔ
DOME
ઔ
CAMERA
ઔ
CLEAR
ઔ
PTZ RESET
EXIT
It is a reset function
Clears the PTZ position and function value.
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Select : or Set ON :
Set OFF :
NEAR
NEAR
Restore setting values to the factory default.
(Includeing MOTION DATA and CAMERA DATA )
All existing setting value will be erased.
4. 2. 8 FACTORY SET
< NEAR / RIGHT OFF TEMP >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 15 C
: 50 C
: 40 C
CURRENT TEMPER 50.40C
< NEAR / RIGHT FAN ON >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 15 C
: 50 C
: 40 C
CURRENT TEMPER 50.40C
< NEAR / RIGHT FAN OFF >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 15 C
: 50 C
: 40 C
CURRENT TEMPER 50.40C
Set the temerature of heater OFF. (0~70℃)
Set the operating temperature of the Fan. (0~70℃)
Set the temperature of Fan OFF. (0~70℃)
DOME MENU
TITLE :
VIDEO FORMAT
TEMP. SET
POWER UP ACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
FACTORY SET
SAVE BACK EXIT
< NEAR / RIGHT
ઔ
TITLE SET >
ઔ
ઔ
ઔ
ઔ
CLEAR MENU
< SEL
ઔ
NEAR LEFT /RIGHT>
PRESET ▶YES NO
GROUP
ઔ
TOUR
ઔ
SCAN
ઔ
PATTERN
ઔ
AREA
ઔ
PRIVACY
ઔ
ALARM
ઔ
ઔ
PRESET CLEAR:
4. 5 Other Quick Opercating Guide
LIGHT
WIPER
HEATER
ICR AUTO
ICR DAY
ICR NIGHT
INFO
IR ZOOM
( ON / OFF ) = 252 + F1 Long Preset
( ON / OFF ) = 244 + F1 Long Preset
( ON / OFF ) = 245 + F1 Long Preset
( ON ) = 240 + F1 Long Preset
( ON ) = 241 + F1 Long Preset
( ON ) = 242 + F1 Long Preset
( ON / OFF) = 255 + F1 Long Preset
( AUTO / MANUAL) = 248 + F1 Long Preset
(3) HEATER OFF TEMP
(4) FAN ON TEMP
(5) FAN OFF TEMP
* The keyboard shortcut of IR ZOOM is available only when the IR CONT.TYPE is in manual mode.
(DOME SUB MENU -> IR CONT. TYPE->MANUAL)
Select :
TELE WIDE

34 35
6. DIMENSION
6. 1 DIMENSION
5. 1 Mechanism Specification
5. SPECIFICATION
5. 1. 1 MECHANICAL
5. 1. 2 ENVIRONMENTAL
5. 1. 3 FUNCTIONS
5. 1. 4 ELECTRICAL
5. 1. 5 USER CONNECTIONS
157,9
Ø231
R82,5
160,6 206 18
384,6
1-1/2inch
PF TAP
Ø231
- Pan : 360°Continuous Pan, 0.1° to 120°/sec (proportional to zoom)
- Pan Preset Speed : 250°/sec, ± 0.1° Accuracy
- Tilt : -8°(352°) to 188° movement, 0.8°~80°/sec (proportional to zoom)
- Tilt Preset Speed : 250°/sec, ± 0.05° Accuracy
- Weight : 6.4 Kg(MECHANICAL)
- Dimensions Set : 231(Ø) x 385(mm)
- Construction : Aluminum
- Ingress Protection : IP66 (Outdoor Housing)
- Color : Cool gray
- Operating Temp : Outdoor : -50°C to 70°C (-58° F to 158° F)/ with 30W Heater
- Humidity : 0% to 90% (non-condensing)
- Fan operate : 50°C on , 40°C off
- Heater operate : 5°C on , 15°C off
- Preset : 255 points, less than 0.1° accuracy
- Tour : 8 programmable
- Pattern : 4 patterns for 60 second.
- Group : 6 group(Max.6 Tours are programmable in each Group)
- Scan : 8 (programmable speed and diagonal scan)
- Privacy Zone : 8 block with title (Mask)
- ID Address : Up to 255 selectable ID (Rotary switch)
- Data Communication Control : RS-485 / RS-422
- Protocol : Multiple protocol (PELCO D/P, WTX)
- Baud rate : 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps selectable
- Alarm : 8 alarm
- Display : 16 Area title
- Power : AC21~26V 60Hz / 50Hz(Power adaptor not included)
- Consumption : Operation(5A) / MAX 6A
- Fan & Heater : 10 W / 45 W
- Data communication connection : RS-422, 485 + / - Optional Control Data
- HD-SDI connection : BNC
- Alarm Inputs : 8 Programmable
- Relay : 2 Dry Contact Output Rating: 2A @30VAC

36 37
7. CONFIGURATION
7. 1 Connecting to Keyboard with DVR
......
......
