Foscam X5 User manual

1
User
User Manual Manual
Wireless IP Camera
Model: X5
V3.0

2
Table of Contents
1 Overview............................................................................................................................................................................. 3
1.1 Key Features...........................................................................................................................................................3
1.2 Read before Use.................................................................................................................................................... 3
1.3 Packing Contents................................................................................................................................................... 3
1.4 Physical Description.............................................................................................................................................. 4
1.5 SD Card Management...........................................................................................................................................4
1.6 Add Device: Connection via the Foscam App................................................................................................... 4
1.7 Installation............................................................................................................................................................... 5
2 Default Parameters........................................................................................................................................................... 5
3 Specification....................................................................................................................................................................... 6

3
1 Overview
1.1 Key Features
5.0Megapixels Pan/Tilt Wireless IP Camera
H.264+/H.264 video Compression
Support 2.4GHz WiFi
Supports Human detection, Motion Detection and Sound Detection
Compatible with free Foscam Video Management Software
Compatible with free Foscam iOS and Android APP
Supports Full Duplex two-way Audio
Supports voice prompt
Supports 256GB Micro SD Card storage(External)
IR Range up to 8m(26ft)
P2P Feature for Easy Remote Access
Supports image snapshot
Supports dual-stream
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
Supports Alexa
Supports Google Assistant
1.2 Read before Use
Please first verify that all contents received are complete according to the Package Contents listed below.
Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup
Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly
as intended.
1.3 Packing Contents
● IP Camera × 1
● Mounting Platet × 1
● AC Adapter × 1
● USB Power Cable× 1
● Quick Setup Guide × 1
● Ethernet Cable× 1
● Expansion Screws × 1

4
1.4 Physical Description
Lens: Fixed focus lens
Microphone: Built-in Microphone.
Speaker: Built-in speaker
LAN: 10/100 Mbps RJ-45 port for wired connection
Power : : DC 5V/1A or DC 5V/1.5A Power supply.
Reset: Press and hold on the reset button for 3 seconds. Releasing the reset button, the password will back to
the factory default administrator password.
Micro SD Card slot: Supports up to 256GB SD card for storing the video.
1.5 SD Card Management
This camera supports Micro SD Card.
When you plug in the SD card during the camera work process, please reboot the camera again, or else the
SD card might not work well.
On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.
1.6 Add Device: Connection via the Foscam App
Scan the QR code below to download and install the Foscam APP.
Please refer to the Quick Setup Guide.

5
1.7 Installation
Please refer to the Quick Setup Guide.
Please refer to the Quick Setup Guide.
1.Place the camera directly on a desk.
2.Install the mounting plate on a wall or ceiling with the supplied fixing screws.
Note: Align points a and b to insert the camera base to the mounting plate. Rotate so that points a and b are
aligned, which attaches the camera securely to the base.
2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically

6
3 Specification
ITEMS
X5
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
5.0Megapixels(2560*1920)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f.3.6mm; F2.4
Angle of view
Diagonal: 89°, Horizontal: 71°, Vertical: 52°
Video
Image Compression
H.264+/H.264
Image Frame Rate
Max15fps (5MP), downward adjustable
Resolution
5MP(2560*1920) 15 fps,1080P(1600*1200) 25fps,
720P(1024*768)25fps
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are adjustable
Pan/Tilt Angle
Horizontal:350° & Vertical:70°
Flip Image
Flip and mirror
Infrared Mode
4pcs SMD IR-LEDs
Night Mode
Automatic modes
Night Visibility
8m
Audio
Input/Output
Two-way audio,build-in microphone and speaker
Audio Compression
PCM/ AAC
Network
Ethernet
Yes
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WPA, WPA2
Remote Access
P2P
Wifi Configuration Mode
Support scan QR code
Network Protocol
IP, TCP, UDP, DHCP,RTSP
System
Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android
(Foscam app), iOS (Foscam app)
Other Features
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Sound Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Human Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Privacy Block
Yes
WDR
Improve image clarity in complex scenario
Zoom
6X digital zoom function
Storage
Support max. 256GB Micro SD card, local and FTP storage,Foscam
cloud storage

7
User Accounts
Three levels user role
Power
Power Supply
Micro USB 5V/1.5A or 5V/1A
Power Consumption
7.5Watts (Max.)
Physical
Dimension(LxWxH)
83(L)x76 (W)x114 (H) mm
Net Weight
206g
Environment
Operating Temperature
-10°C~ 50°C (14°F ~ 122°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, RoHS,WEEE
For other parts, please refer to the “FOSCAM Camera User Manual”
