CAME BPT XTS 7 WIFI Series Manual

Wifi touch-screen speaker video-intercom
XTS 7 WH WIFI
XTS 7 BK WIFI
XTS 7 WH WFBF
INSTALLATION AND CONFIGURATION MANUAL
EN
English
FB01262-EN

4
2
1
3
Page 2- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Full-touch speaker video-intercom for the X1 wall-
hung system.
Description of parts
Front view
1Signaling LED
2Speaker
3Touch-screen display
4Microphone.
Rear view
5Housing for the not-included Micro SD card (for
future use).
6Reset button. When pressed it reboots the device;
this operation DOES NOT require any deleting of pro-
gramming.
DESCRIPTION
GENERAL PRECAUTIONS
• Read the instructions carefully before beginning the installation and carry out the actions as specified by the
manufacturer.
• The installation, programming, commissioning and maintenance of the product must only be carried out by
qualified technicians, properly trained in compliance with the regulations in force, including health and safety
measures and the disposal of packaging.
• Before carrying out any cleaning or maintenance operation, disconnect the device from the power supply.
• Use this equipment solely for the its specifically intended purpose.
• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.
Cautionary issues on remotely controlling the device
Some features of the system may be managed by smartphones and tablet PCs, by using the corresponding apps.
For the system to be remotely controlled, the device must be connected to a home WiFi network with internet
access.
This type of system functions properly when:
- the device receives a high-quality WiFi signal
- there is a permanent connection established by your contract with the internet service provider. The connection
must support the data flow generated by the device and support VoIP,
- the smartphone or table PC on which the corresponding app is running does not block any VoIP apps.
remotely controlling the device via app means that the data trac consumption takes place over the
home network of the smartphone or table PC; the ensuing cost of said consumption is borne by the user.

5
6
7
8
ON OFF
Page 3- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
7End-of-line resistor. Set the bridge only on the last of the line's devices.
8 Function of terminals
Local power supply input
BUS-line input
Landing call input
Alarm input
Technical data
Type XTS 7 WIFI
local power supply (V DC) 14 to 18
Maximum draw (mA) 520
Current draw in stand-by mode (mA) 360
Stocking temperature °C -25 to +70
Operating temperature °C 0 to +40
Protection rating (IP) 30
Capacitative TFT Touch-screen Display (pixels) 1024 x 600
Standard wireless (IEEE) 802.11b, 802.11g, 802.11n
Wireless frequency filed (MHz) 2,412 - 2,472
Maximum transmission strength (dBm) 16
Wireless security WPA/WPA2-PSK, WEP

129 mm
24 mm
185 mm
H= 155 -165 cm
H= 125 -135 cm
1
83,5 mm
3
2
4
Page 4- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
INSTALLATION

5
Page 5- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
To make the device's installation more solid, use
the supplied screws and dowels to fasten the frame
to the wall.
Reinforced concrete
Supporting wall
Stone wall
Wooden wall
Plasterboard wall
Light-brick wall
Notes on installing indoor receivers connected to the WiFi network
Install the indoor receiver: away from any metal objects that may interfere with the signal, or from any devices
that generate magnetic fields. Install it in the same room as the router or have the least possible number of walls
separating the router and the indoor receiver.
If the place chosen for installing the indoor receiver is not easily reached by a suciently intense WiFi signal, we
suggest installing a signal regeneration processor which is easily bought on the open market.
Signal quality
Optimal
Good
Sucient
Insucient

La
La
Lb
La
Lc
1
VAS/101
LITHOS MTM VAS/100.30
VAS/101
Page 6- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
VCM/1D VCM/2D UTP/CAT 5 2x1.5mm2
La ≤ 100 m ≤ 100 m ≤ 100 m –
Lb – ≤ 100 m ≤ 50m * –
Lc ≤ 75 m – – ≤ 100 m
* Use a pair of wires for each single power-supply conductor.
Examples of installation
Installing four indoor receivers in one home.
The WiFi connection needs only to be active on one indoor receiver. The Apps are associated to the indoor
receiver that has an active Wifi connection.

Lc
La
L1 L2
Lb
Lb
Ld
LeLf
Lg
Lb
L3
3
1
2
MTM
VA/01
MTM MTM
MTM
VAS/101
VAS/101VAS/101VAS/101VAS/101
VAS/101VAS/101VAS/101
VAS/101
XDV/304
VAS/101 VAS/101
Page 7- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
A maximum of 5 Monitors can be connected enter/exit mode at each output of the XDV/304 distributor
Each single call can activate a maximum number of 8 devices.
Device installed in several homes with dierent types of power-supply units.
In a home where several indoor receivers are installed, the WiFi connection need only be active on one of
the receivers. The Apps are associated to the indoor receiver that has an active Wifi connection.
VCM/1D VCM/2D UTP/CAT 5 2x1.5mm2
La+Lb ≤100 m – ≤100 m –
Lc ≤75 m – – ≤100 m
L1, L2, L3 – ≤100 m – –
La + Lb + L1 (L2, L3) ≤150 m
La + Lb + Lc + Ld + Le + Lf + Lg + (L1, L2, L3)* ≤600 m
*In the count, only consider the longest distance among those measured from the indoor receiver to the power
supply unit.

MAX 4
MODEM
ROUTER
Lb
La
1 2
La
La
Lc
LITHOS VAS/100.30
XDV/304
Page 8- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Greatest number of devices that can be connected to the indoor receiver that has the active WiFi
connection
VCM/1D VCM/2D UTP/CAT 5 2x1.5mm2
La ≤ 100 ≤ m 100 ≤ m 100 –
Lb – ≤ m 100 ≤ m 50* –
Lc ≤ m 75 – – ≤ m 100
* Use a pair of wires for each single power-supply conductor.
Installed at a duplex home, where each home has a device
The Apps are associated to the indoor receiver that has an active Wifi connection.

Page 9- Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Mulmedia
Conguraon X2
CAME Connect
Network
Conguring the user interface
Automac door opener
Credenals
HomeBackInfo
19:02 Thursday
01 Feb 2018
Backdrops
Quick commands
IP video cameras
Video recording
Advanced sengs
Tones
Display
HomeBackInfo
19:02 Thursday
01 Feb 2018
SengsCCTV
HomeBackInfo
19:02 Thursday
01 Feb 2018
Advanced settings
This section requires specific
know-how in operating the vid-
eo-intercom system. Wrong set-
tings may cause partial or even
total malfunctions; that is why
the editing of some parameters
is allowed only after entering the
installer password; the default
password is 112233).
Scroll the list.
Select menu item B.
Select item A.
COMMISSIONING
Once the cables are laid and connected, program the essential function for operating the device.
Scroll the available pages.
B
A

1
Page 10 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
DHCP
YES
Congure WiFi
Save
Stac
NO
Address MAC
DNS
Gateway
Netmask
IP address
Mode
Enabled
WiFi
Type of connecon
HomeBackInfo
19:02 Thursday
01 Feb 2018
Manual programming
Send SN
HomeBackInfo
19:02 Thursday
01 Feb 2018
CThis button is for enabling WiFi
communication.
This icon shows that the WiFi
connection is active, enabling the
network-settings sections below.
DLets you choose the type of ad-
dress from:
DHCP
The device's IP address is as-
signed by the DHCP server; if
there are no special needs, this
mode lets you continue with the
settings without adding any ad-
ditional data.
Static
The device's IP address is manually assigned.
EIf you have chosen a static IP address, enter the device's IP, which must belong to the same subnet as that of
the router and of the other connected devices.
FIf the netmask is dierent from the default one, provide the proper netmask.
GProvide the default gateway for your network.
HEnter a valid DNS address to have the CAMEConnect connection (for example, 8.8.8.8.).
If a DHCP server is also present, the static address selected must not be among those included in the
DHCP pool.
For devices configured as a Master it is advisable to assign a static IP address. Instead if the address is
generated by a DHCP server, check that the IP address is assigned on the basis of the MAC ADDRESS of the
device or that the lease time is very high.
Network
A This button is for sending the
SN (serial number) to the Pcs/Xip
software during the programming
steps.
B This button takes you to manual
programming of the device.
The complete manual pro-
gramming procedure for the call
is printed in the literature that is
issued with the indoor receivers.
Configuration X2
A
B
C
D
E
F
G
H

2
4
3
Page 11 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
None
Hidden network
DHCP
Smith home WiFi
Protected
Public WiFi
Unprotected
Connect
Password
Encrypon
Security
SSID
Save seng
Scan
Add WiFi network
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
YES
Congure WiFi
Save
NO
Netmask
IP address
Mode
Enabled
WiFi
Type of connecon
HomeBackInfo
19:02 Thursday
01 Feb 2018
3The page shows the detected
networks; to manually scan for net-
works, touch the Jbutton.
Select a network to connect to.
If the network is unprotected the
connection will be immediate.
If the network is protected, enter
the password for the WiFi network
to get access.
Press button Lto save the con-
figuration
To connect to a WiFi network with a
hidden SSID, touch this button K.
On the page provided yo can enter
an SSID, that is, network name,
type of security, encryption and
password; when required.
To connect, touch this button M.
Press button Lto save the con-
figuration
IOnce you have chosen the
connection mode, the button is
for selecting and setting up a Wifi
network.
Every 30 seconds the device scans
for available networks.
I
M
J
K
L

Page 12 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Unit - Mobile App 4
00700100003
Unit - Mobile App 3
00700100002
Unit - Mobile App 2
00700100001
Unit - Mobile App 1
00700100000
Save
Video App Bitrate (Kbps)
Video codec
Audio codec
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
Save
YES NO
Status
Internet service provider
Enable connecon
Keycode
HomeBackInfo
19:02 Thursday
01 Feb 2018
The window lets you view the cre-
dentials of the four users enabled
to connect to the device via mobile
devices.
Touch the user you want to access
the screen that lets you assign or
edit an access password.
This window lets you configure the
maximum BITRATE that the device
can handle, while choosing among
the available values.
The greater the BITRATE val-
ues, the better the video quali-
ty, but also the greater the data
bandwidth occupied in UPLINK.
If the video on the App is not fluid
or deteriorated, set the lower BI-
TRATE values.
Multimedia
Credentials
CURL of the service for remote calls (the default one is xip01.cameconnect.net)
DIt shows the state of the connection.
ADevice's univocal code.
BFor enabling or disabling the
VoIP remote control of the video-in-
tercom call.
The factory settings require that the
connection to CAME Connect be
enabled.
The CAME Connect connec-
tion must be active to receive
calls over the App.
CAME Connect
A
B
C
D

1
2
3
Page 13 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Save
Save
Sun
Sun
Sat
Sat
Fri
Fri
Thu
Thu
Wed
Wed
Tue
Tue
Mon
Mon
Days of the week
Days of the week
Stop me
Stop me
13:30
08:30Start me
Start me
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
The list is empty
Delete all
New me-slot
HomeBackInfo
19:02 Thursday
01 Feb 2018
C Touch the days of the week dur-
ing which the time-slot needs to be
active.
D Touch this button to save the
time-slot you have just created.
Create other new time-slots and
touch the Save button to add them
to the list.
B Touch the empty sections and
in the pop-up window set the start
and finish time of the time-slot for
activating the function.
A Touch the button to add a new
time slot.
Automatic door opener
This function, which is especially useful for businesses, lets you automatically open the entrance once the call-but-
ton is pressed on the entry panel. The activation of this function can be programmed to schedule time slots and
days of the week.
A
B
D
C

4
2
1
Page 14 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Customize Homepage funcons
Preset Customized
Homepage acve
HomeBackInfo
19:02 Thursday
01 Feb 2018
Save
Number of frames:
HomeBackInfo
19:02 Thursday
01 Feb 2018
This section is for customizing the
appearance of the homepage.
ASelect the type of homepage
that you wish to see.
BTouch the button to create a
customized homepage.
Configuring the user interface
CFrom the drop down menu se-
lect the total number of frames that
will make up the main page.
Each page contains at most
six frames; the last one is always
the configuration frame.
Delete all
New me-slot
13:30 - 18:30
Mon Tue Wed Thu Fri
Mon Tue Wed Thu Fri
08:30 - 12:30
HomeBackInfo
19:02 Thursday
01 Feb 2018
For editing the selected ele-
ment.
For eliminating the selected
element.
Touch the Back button to return to
the list of configurable parameters.
C
A
B

3
Page 15 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Restore preset sengs
Set slave mode
Restart applicaon
Reboot device
HomeBackInfo
19:02 Thursday
01 Feb 2018
Save
Empty Sengs
EmptyEmpty
Number of frames:
HomeBackInfo
19:02 Thursday
01 Feb 2018
The factory settings require that the indoor receiver operate in "master" mode. If the system features
several indoor receivers, that answer the same call within a home, only one of these must operate in "mas-
ter" mode. The others must operate in "slave" mode.
CTouch the button to set the indoor receiver to "slave" mode.
DTouch the button to return all the local settings to the default factory settings.
(administrator password required;
the default password is 112233).
ATouch the button to reboot the
indoor receiver.
BTouch the button to reboot only
the application that runs the indoor
receiver.
Maintenance
Touch each of the empty sections
and use the drop-down menu to
select the content that you want to
assign to the section.
Save the setting by touching the
Save button.
A
B
C
D

Page 16 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
NODES STATUS
ExitHelp
SIP
RING TIME
PARAMETERS
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Device
Maintenance
Diagnostics
LANGUAGE
English
XTS 7
SETTINGS
Enter
LOG-IN MODE
USER
INSTALLER
PASSWORD
SIP
Characteristics
The ring time is the time after which
the incoming call is interrupted.
AAdd the ring time expressed in
seconds.
Type the address of the device in the browser address bar
(Chrome, Firefox, Safari).
Select the [INSTALLER] access option and enter the password,
which is set to “112233” by default, to access the settings win-
dows.
When accessing with "User" credentials (default password
123456) only lets you browse the pages that follow, except the
user’s sections.
There is no scroll bar on the right on the settings web pag-
es. To scroll through the pages, press and hold down the left-
hand mouse button and drag. On a smartphone or tablet, drag
your finger down the screen.
SETTINGS AVAILABLE ONLY FROM WEB PAGE
The web pages, in addition to allowing the configuration of most of the parameters that can be set by the interface
of the receiver, allow provide some additional functions illustrated in this section.
A

Page 17 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Reload
FILE
No file selected
VERSION
NODES TYPE
All
NODES STATUS
Exit
Exit
Upload
Help
Help
Maintenance
SIP
CHANGE PASS... CONFIGUTION... UPDATE...
PARAMETERS
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Device
Maintenance
Diagnostics
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Device
Maintenance
Diagnostics
Node status
On master receivers, through this
window it is possible to view the
connection status of the SIP nodes.
BChoose the type of SIP nodes for
which you want to view the status.
Red dot = Node not connected or
being connected.
Green dot = Node connected and
working.
CUpdate the node status view.
Maintenance
Update
This window is for updating the
device's firmware, by proceeding
as follows:
APress the button, select the file
containing the firmware update on
your computer, and start the pro-
cess.
A
B
C

Page 18 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Password change
In this window it is possible to
change the password used to ac-
cess.
CONFIRM NEW PASSWORD
NEW PASSWORD
PASSWORD
MODE
Local - RAM
LOG LEVEL
Warning
Exit
Exit
CancelSave
Get
Help
Help
Diagnostics
Maintenance
LOG FILES
CHANGE PASS... CONFIGUTION...
STATISTICS
UPDATE...
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Device
Maintenance
Diagnostics
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Device
Maintenance
Diagnostics
DLets you choose where to save the LOG files from:
Local-RAM: the file is saved in the non-permanent memory of the device
Local-FLASH: the file is saved in the internal memory of the device (attention!, the capacity is limited)
Remote: the file is saved on a remote server where the IP address must be entered.
EIt starts recovery of the log file.
Diagnostics
AThis section brings together
statistical data on the operation of
the device.
BThe section lets you generate
file that contain data useful for
technical servicing aimed at finding
any malfunctions.
CLets you choose the accuracy
and type of LOG files to collect.
A B
C
D
E

Page 19 - Manual FB01262 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions

CAME S.p.A.
Via Martiri Della Libertà, 15
31030 Dosson di Casier - Treviso - Italy
tel. [phone] - fax. [phone]
Page 20 - Manual FB01262-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice.
- Translation of the original instructions
Pertinent Regulations. CAME SpA, the manufacturer, declares that the products described in this manual con-
forms to Directive 2014/53/EU. The complete wording of the EU declaration of conformity is available at the follow-
ing Internet address: www.came.com
Decommissioning and disposal. Dispose of the packaging and the device at the end of its life cycle responsibly,
in compliance with the laws in force in the country where the product is used. The recyclable components are
marked with a symbol and the material's ID marker.
THE DATA AND INFORMATION SHOWN IN THIS MANUAL ARE TO BE CONSIDERED AS SUBJECT TO CHANGE AT ANY
TIME AND WITHOUT THE NEED FOR ANY ADVANCE WARNING. MEASUREMENTS, UNLESS OTHERWISE INDICATED,
ARE IN MILLIMETRES.
