CAME BPT XTS 7IP WH WIFI Manual

Handsfree entry phone for IP360 system
XTS 7IP WH WIFI
XTS 7IP BK WIFI
XTS 7IP WH WFBF
INSTALLATION AND CONFIGURATION MANUAL
EN
English
FB01264-EN

4
2
1
3
Page 2- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Description of parts
Front view
1Signaling LED
2Speaker
3Touch-screen display
4Microphone.
Rear view
5Socket for connecting the device to the LAN PoE
network.
Green LED, activity on the network:
permanently lit = active link,
flashing = data activity.
Yellow LED, data transmission speed:
o 10Mbps,
on 100Mbps.
DESCRIPTION
Full-touch speaker video intercom for IP360 system, 7˝ TFT touch screen display, Wi-Fi and Graphical User In-
terface.
GENERAL PRECAUTIONS
• Read the instructions carefully before beginning the installation and carry out the actions as specified by the
manufacturer.
• The installation, programming, commissioning and maintenance of the product must only be carried out by
qualified technicians, properly trained in compliance with the regulations in force, including health and safety
measures and the disposal of packaging.
• Before carrying out any cleaning or maintenance operation, disconnect the device from the power supply.
• Use this equipment solely for the its specifically intended purpose.
• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.
Cautionary issues on remotely controlling the device
Some features of the system may be managed by smartphones and tablet PCs, by using the corresponding apps.
For the system to be remotely controlled, the device must be connected to a home WiFi network with internet
access.
This type of system functions properly when:
- the device receives a high-quality WiFi signal
- there is a permanent connection established by your contract with the internet service provider. The connection
must support the data flow generated by the device and support VoIP,
- the smartphone or table PC on which the corresponding app is running does not block any VoIP apps.
remotely controlling the device via app means that the data trac consumption takes place over the
home network of the smartphone or table PC; the ensuing cost of said consumption is borne by the user.

E F
Page 3- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
The device automatically recognises the local or PoE power supply.
FReset button. When pressed it reboots the device; this operation DOES NOT require any deleting of program-
ming.
Function of terminals
Local power supply input
Landing call input
Alarm input
Technical data
Type XTS 7IP WIFI
local power supply (V DC) 14 to 18
PoE power supply IEEE 802.3af-PD
Maximum draw (mA) 420 series
Current draw in stand-by mode (mA) 340 series
Stocking temperature °C -25 to +70
Operating temperature °C 0 to +40
Protection rating (IP) 30 series
Video codec H.264
Capacitative TFT Touch-screen Display (pixels) 1024 x 600
Standard wireless IEEE 802.11b/g/n
Wireless frequency filed (MHz) 2,412 - 2,472
Maximum transmission strength (dBm) 16 series
Wireless security WPA/WPA2-PSK, WEP

129 mm
24 mm
185 mm
1
83,5 mm
3
2
4
H= 155 -165 cm
H= 125 -135 cm
Page 4- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
INSTALLATION

5
Page 5- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Reinforced concrete
Supporting wall
Stone wall
Wooden wall
Plasterboard wall
Light-brick wall
Notes on installing indoor receivers connected to the WiFi network
Install the indoor receiver: away from any metal objects that may interfere with the signal, or from any devices
that generate magnetic fields. Install it in the same room as the router or have the least possible number of walls
separating the router and the indoor receiver.
If the place chosen for installing the indoor receiver is not easily reached by a suciently intense WiFi signal, we
suggest installing a signal regeneration processor which is easily bought on the open market.
Signal quality
Optimal
Good
Sucient
Insucient
to make the device's installation more solid, use
the supplied screws and dowels to fasten the frame
to the wall.

MTMV/IP
Modem router Wi-Fi
Switch PoE
Master
Slave
MTMV/IP VAS/101
VAS/101
Modem router Wi-Fi
Master
Slave
Page 6- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Single-family system with local power supplies and internal receiver connected in Wi-Fi
Examples of installation
The Master/Slave configuration of the devices is programmed using the PCS/XIP software.
Single-family system with POE power supply

MTMV/IP MTMV/IP
APARTMENT 4 APARTMENT 3
APARTMENT 2 APARTMENT 1
APARTMENT 3
APARTMENT 1
APARTMENT 4
APARTMENT 2
MODEM
ROUTER Wi-Fi
SWITCH PoE
SWITCH PoE
MODEM
ROUTER Wi-Fi
MODEM
ROUTER Wi-Fi
MODEM
ROUTER Wi-Fi
Master
Slave
Page 7- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Multi-family system with an internal receiver for each apartment

MTMV/IP
MODEM
ROUTER Wi-Fi
10.0.X.X
10.0.X.X
10.0.X.X
192.168.X.X
10.0.X.X
SWITCH PoE
SWITCH PoE
Switch PoE
Master
Slave
APARTMENT 1
Page 8- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
A call from the entry panel can ring a maximum of 20 devices (man-
aged by the internal Master receiver of the apartment), whether they
are connected to the LAN line or reachable from a Wi-Fi or mobile
network using CAME Connect.
If a call is made, all the devices programmed to answer the call ring.
The preview of the caller's image can be viewed on up to 5 devices,
one of which is always the master receiver.
The high resolution image is visible only in the internal master receiver.
Other 4 devices, selected using PCS/XIP software, can preview the
caller's image in low resolution.
Any other devices programmed to answer the call ring but can not
display any video preview; only answering the call it is possible to view
the images coming from the entry panel.
Home in which there are several internal receivers, one of which connected to the apartment block
LAN, the others to the home LAN

MTMV/IP
MODEM
ROUTER Wi-Fi
10.0.X.X
10.0.X.X
10.0.X.X
10.0.X.X
10.0.X.X
10.0.X.X
SWITCH PoE
SWITCH PoE
Master
Slave
APARTMENT 1
Page 9- Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
A call from the entry panel can ring a maximum of 20 devices (man-
aged by the internal Master receiver of the apartment), whether they
are connected to the LAN line or reachable from a Wi-Fi or mobile
network using CAME Connect.
If a call is made, all the devices programmed to answer the call ring.
The preview of the caller's image can be viewed on up to 5 devices,
one of which is always the master receiver.
The high resolution image is visible in the internal master receiver
and in a maximum of 4 other internal receivers connected to the LAN.
If only one internal receiver (master) is connected to the LAN, other
4 devices, selected using PCS/XIP software, can display the caller's
image in low resolution.
Any other devices programmed to answer the call ring but can not
display any video preview; only answering the call it is possible to view
the images coming from the entry panel.
Home in which there are several internal receivers, some of which connected to the apartment
block LAN

MTMV/IP
MODEM
ROUTER Wi-Fi
10.0.X.X
10.0.X.X
10.0.X.X
10.0.X.X
SWITCH PoE
SWITCH PoE
ETI/MiniSER
Master
Slave
APARTMENT 1
Switch PoE
192.168.X.X
Page 10 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
A call from the entry panel can ring a maximum of 10 devices, whether they are connected to the LAN line or
reachable from a Wi-Fi or mobile network using CAME Connect.
If a call is made, all the devices programmed to answer the call ring.
The high resolution image is visible from the 10 internal slave devices.
Home in which there are several internal receivers connected to the home network, in which the
local server (ETI/MiniSER) acts as the master receiver of the apartment

Page 11 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
On slave receiverOn master receiver
Automac door opener
SIP Sengs
CAME Connect
NetworkNetwork
Maintenance
Maintenance
Conguring the user interface
Automac door opener Conguring the user interface
Credenals
19:02 Thursday
01 Feb
19:02 Thursday
01 Feb
Backdrops
Quick commands
IP video cameras
Video recording
Advanced sengs
Tones
Display
HomeBackInfo
19:02 Thursday
01 Feb 2018
SengsMessagesCCTV
HomeBackInfo
19:02 Thursday
01 Feb 2018
Advanced settings
This section requires specific
know-how in operating the vid-
eo-intercom system. Wrong set-
tings may cause partial or even
total malfunctions; that is why
the editing of some parameters
is allowed only after entering the
installer password; the default
password is 112233).
Scroll the list.
Select menu item B.
Select item A.
COMMISSIONING
Once the cables are laid and connected, program the essential function for operating the device.
Scroll the available pages.
B
A

1
2
Page 12 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Ethernet connection configuration
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
Enabled
Enabled
Ethernet
DHCP
Save
Save
Congure WiFi
Congure Ethernet
Disabled
Disabled
WiFi
Stac
MAC address
Gateway
Netmask
IP address
Mode
Ethernet
DNS
Default gateway
Wireless
Ethernet
Type of connecon
This section is used to determine
how the device connects to the
network.
AEnable/disable the desired con-
nection types
BIndicate whether the connection
to the gateway take place over the
Ethernet network or through Wi-Fi.
CEnter a valid DNS address to
have the CAMEConnect connection
(for example, 8.8.8.8.).
DLets you choose the type of address from:
DHCP
The device's IP address is assigned by the DHCP server; if there are no special needs, this mode lets you
continue with the settings without adding any additional data.
Static
The device's IP address is manually assigned.
EIf you have chosen a static IP address, enter the device's IP, which must belong to the same subnet as that of
the router and of the other connected devices.
FIf the netmask is dierent from the default one, provide the proper netmask.
GProvide the default gateway for your network.
If a DHCP server is also present, the static address selected must not be among those included in the
DHCP pool.
For devices configured as a Master it is advisable to assign a static IP address. Instead if the address is
generated by a DHCP server, check that the IP address is assigned on the basis of the MAC ADDRESS of the
device or that the lease time is very high.
Network
D
E
F
G
A
B
C

3
5
4
Page 13 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
4The page shows the detected
networks; to manually scan for net-
works, touch the Ibutton.
Select a network to connect to.
If the network is unprotected the
connection will be immediate.
If the network is protected, enter
the password for the WiFi network
to get access.
None
Hidden network
Smith home WiFi
Protected
Public WiFi
Unprotected
Connect
Password
Encrypon
Security
SSID
Save seng
Scan
Add WiFi network
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
HThis button is for selecting and
setting up a Wifi network.
The icon indicates that the Wi-
Fi connection mode is active.
To save the configuration touch the
button K.
To connect to a WiFi network with a
hidden SSID, touch this button J.
On the page provided yo can enter
an SSID, that is, network name,
type of security, encryption and
password; when required.
To connect, touch this button L.
To save the configuration touch the
button K.
Wireless connection configuration
HomeBackInfo
19:02 Thursday
01 Feb 2018
DHCP
Save
Congure WiFi
Stac
Gateway
Netmask
IP address
Mode
WiFi
Type of connecon
D
E
F
G
H
L
I
J
K

Page 14 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Unit - Mobile App 4
00700101268 series
Unit - Mobile App 3
00700101273 series
Unit - Mobile App 2
00700101269 series
Unit - Mobile App 1
00700100267 series
Unit - Receiver 3
Unit - Receiver 2
00700100266 series
Unit - Receiver 1
00700100264 series
HomeBackInfo
19:02 Thursday
01 Feb 2018
Save
YES NO
Status
Internet service provider
Enable connecon
Keycode
HomeBackInfo
19:02 Thursday
01 Feb 2018
The window lets you view the cre-
dentials of the users enabled to
connect to the master devices.
Touch the user you want to access
the screen that lets you assign or
edit an access password.
Credentials (only on master receiver)
CURL of the service for remote calls (the default one is xip01.cameconnect.net)
DIt shows the state of the connection.
ADevice's univocal code.
BFor enabling or disabling the
VoIP remote control of the video-in-
tercom call.
The factory settings require that the
connection to CAME Connect be
disabled.
The CAME Connect connec-
tion must be active to receive
calls over the App.
CAME Connect (only on master receiver)
A
B
C
D

Page 15 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
DIn this space enter the server's IP address.
Default IP addresses of CAME servers (example):
ETI/MiniSER Xip, ETI/DOMO Xip - 192.168.0.3 (port 0) - 192.168.1.3 (port 1)
ETI/SER Xip, 192.168.1.1
Serverless IP entry panel, 192.168.1.5
EChoose the type of server the device is connected.
All CAME servers are of XIP Server type.
Automatic mode
Choosing the automatic SIP setting mode and pressing the [Save] button, a wizard is started through which it is
possible to choose the server or master device, to which the device must be connected. Once the call code (Flat
Id) assigned to your extension has been entered during programming from PCS/Xip, the procedure is completed.
Manual Automac
HomeBackInfo
19:02 Thursday
01 Feb 2018
Save
NoneGenericXIP server
Manual Mode
AIn this space enter the “SIP User
Name” assigned to the device by
PCS Xip.
BIn this space enter the password
assigned in the receiver credentials
in the server set-up window.
CName assigned to the device
(for future use).
SIP settings (only on slave receiver)
Server type
Server address
Display name
Password
Mode
Flat Id
Username A
B
C
D
E

2
3
1
Page 16 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
The list is empty
Delete all
New me-slot
HomeBackInfo
19:02 Thursday
01 Feb 2018
A Touch the button to add a new
time slot.
Automatic door opener
This function, which is especially useful for businesses, lets you automatically open the entrance once the call-but-
ton is pressed on the entry panel. The activation of this function can be programmed to schedule time slots and
days of the week.
Save
Save
Sun
Sun
Sat
Sat
Fri
Fri
Thu
Thu
Wed
Wed
Tue
Tue
Mon
Mon
Days of the week
Days of the week
Stop me
Stop me
13:30
08:30Start me
Start me
Home
Home
Back
Back
Info
Info
19:02 Thursday
01 Feb 2018
19:02 Thursday
01 Feb 2018
C Touch the days of the week dur-
ing which the time-slot needs to be
active.
D Touch this button to save the
time-slot you have just created.
Create other new time-slots and
touch the Save button to add them
to the list.
B Touch the empty sections and
in the pop-up window set the start
and finish time of the time-slot for
activating the function.
B
D
C
A

4
2
1
Page 17 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Custom: to acvate the customized user interface if programmed by tool in the server or if
congured using the buon below
Customize Homepage funcons
Demo: to acvate a demo user interface if programmed by tool in this device
Default: to acvate the factory default user interface, which can not be changed
Preset DemoCustomized
Acve user interface
HomeBackInfo
19:02 Thursday
01 Feb 2018
Save
Number of frames:
HomeBackInfo
19:02 Thursday
01 Feb 2018
BIt is used to display a preview of
the interface (if present) on the de-
vice, during the design phase with
the UI Creator software.
CTouch the button to create a
customized homepage.
Configuring the user interface
Using the PC software [UI Creator], it is possible to design and program a custom graphical interface within the
system master server for the XTS device.
A With the selected button:
- If a custom graphical interface has been programmed, it will be loaded into the device.
- If a custom graphical interface has not been programmed, the configuration of the modified home page is loaded
using the Cbutton.
DFrom the drop down menu se-
lect the total number of sections
that will make up the main page.
Each page contains at most
six frames; the last one is always
the configuration frame.
Delete all
New me-slot
13:30 - 18:30
Mon Tue Wed Thu Fri
Mon Tue Wed Thu Fri
08:30 - 12:30
HomeBackInfo
19:02 Thursday
01 Feb 2018
For editing the selected ele-
ment.
For eliminating the selected
element.
Touch the Back button to return to
the list of configurable parameters.
D
BA
C

3
Page 18 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Save
Empty Sengs
EmptyEmpty
Number of frames:
HomeBackInfo
19:02 Thursday
01 Feb 2018
Touch each of the empty sections
and use the drop-down menu to
select the content that you want to
assign to the section.
Save the setting by touching the
Save button.
Restore preset sengs
Set slave mode
Restart applicaon
Reboot device
HomeBackInfo
19:02 Thursday
01 Feb 2018
The factory settings require that the indoor receiver operate in "slave" mode. The receivers operating in
"master" mode are configured, appropriately to the system structure, by PCS/Xip software.
CTouch the button to set the indoor receiver to "slave" mode.
Setting available only in "master" receivers. Changing the mode requires a reconfiguration of the device.
DTouch the button to return all the local settings to the default factory settings.
(administrator password required;
the default password is 112233).
ATouch the button to reboot the
indoor receiver.
BTouch the button to reboot only
the application that runs the indoor
receiver.
Maintenance
A
B
C
D

Page 19 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
NODES STATUS
ExitHelp
SIP
RING TIME
CHARACTERISTICS
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Maintenance
Diagnostics
LANGUAGE
English
XTS 7 IP
SETTINGS
Enter
LOG-IN MODE
USER
INSTALLER
PASSWORD
SIP
Characteristics
Only for master receivers.
The ring time is the time after which
the incoming call is interrupted or
diverted to devices connected to
the cloud.
AAdd the ring time expressed in
seconds.
Type the address of the device in the browser address bar
(Chrome, Firefox, Safari).
Select the [INSTALLER] access option and enter the password,
which is set to “112233” by default, to access the settings win-
dows.
When accessing with "User" credentials (default password
123456) only lets you browse the pages that follow, except the
user’s sections.
There is no scroll bar on the right on the settings web pag-
es. To scroll through the pages, press and hold down the left-
hand mouse button and drag. On a smartphone or tablet, drag
your finger down the screen.
SETTINGS AVAILABLE ONLY FROM WEB PAGE
The web pages, in addition to allowing the configuration of most of the parameters that can be set by the interface
of the receiver, allow provide some additional functions illustrated in this section.
A

Page 20 - Manual FB01264 -EN - 12/2018 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Reload
FILE
No file selected
VERSION
NODE TYPE
All
NODES STATUS
Exit
Exit
Upload
Help
Help
Maintenance
SIP
CHANGE PASS... CONFIGUTION... UPDATE...
CHARACTERISTICS
System
Date and Time
Network
SIP
IP video cameras
Voicemail
Maintenance
Diagnostics
System
Date and Time
Network
SIP
Credentials
IP video cameras
Voicemail
Maintenance
Diagnostics
Node status
On master receivers, through this
window it is possible to view the
connection status of the SIP nodes.
BChoose the type of SIP nodes for
which you want to view the status.
Red dot = Node not connected or
being connected.
Green dot = Node connected and
working.
CUpdate the node status view.
Maintenance
Update
This window is for updating the
device's firmware, by proceeding
as follows:
APress the button, select the file
containing the firmware update on
your computer, and start the pro-
cess.
A
B
C
