Cameo FLAT PRO 7 G2 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D´USO
FLAT PRO 7 / 12 / 18 G2
PROFESSIONAL OUTDOOR FLAT PAR CAN 7 / 12 / 18 X 10 W IP65
CLPFLATPRO7G2, CLPFLATPRO12G2, CLPFLATPRO18G2
RGBWA
FIRMWARE VERSION 1.03 AND LATER

CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO
ENGLISH
INFORMATION ON THIS USER MANUAL 5
INTENDED USE 5
DEFINITIONS AND SYMBOL DECLARATIONS 5
SAFETY INSTRUCTIONS 6
NOTES ON PORTABLE OUTDOOR DEVICES 9
DELIVERY SCOPE 9
INTRODUCTION 9
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS 10
OPERATION 12
SET-UP AND INSTALLATION 24
CARE, MAINTENANCE AND REPAIR 25
OPTIONAL ACCESSORIES 26
DMX TECHNOLOGY 26
TECHNICAL DATA 28
EXPLANATION OF IP PROTECTION CLASS 29
MINIMUM DISTANCE TO ILLUMINATED SURFACE 30
MINIMUM DISTANCE TO NORMALLY FLAMMABLE MATERIALS 30
DISPOSAL 31
MANUFACTURER’S DECLARATIONS 31
DEUTSCH
INFORMATIONEN ZU DIESER BEDIENUNGSANLEITUNG 32
BESTIMMUNGSGEMÄSSER GEBRAUCH 32
BEGRIFFS- UND SYMBOLERKLÄRUNGEN 32
SICHERHEITSHINWEISE 33
HINWEISE FÜR ORTSVERÄNDERLICHE OUTDOOR-GERÄTE 37
LIEFERUMFANG 37
EINFÜHRUNG 38
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 39
BEDIENUNG 41
AUFSTELLUNG UND MONTAGE 54
PFLEGE, WARTUNG UND REPARATUR 55
OPTIONALES ZUBEHÖR 56
DMX TECHNIK 56
TECHNISCHE DATEN 58
ERLÄUTERUNGEN ZUR IP-SCHUTZART 59
ENTSORGUNG 60
MINDESTABSTAND ZUR BELEUCHTETEN FLÄCHE 60
MINDESTABSTAND ZU NORMAL ENTFLAMMBAREN MATERIALIEN 60
HERSTELLERERKLÄRUNGEN 61

FRANÇAIS
INFORMATIONS CONCERNANT LE PRÉSENT MANUEL 62
UTILISATION CONFORME 62
EXPLICATIONS DES TERMES ET DES SYMBOLES 62
CONSIGNES DE SÉCURITÉ 63
REMARQUES CONCERNANT LES APPAREILS D’EXTÉRIEUR MOBILES 67
CONTENU DE LA LIVRAISON 67
INTRODUCTION 68
RACCORDEMENTS, ÉLÉMENTS DE COMMANDE ET D’AFFICHAGE 69
UTILISATION 71
INSTALLATION ET MONTAGE 84
ENTRETIEN, MAINTENANCE ET RÉPARATION 85
ACCESSOIRES DISPONIBLES EN OPTION 86
TECHNIQUE DMX 86
CARACTÉRISTIQUES TECHNIQUES 88
EXPLICATIONS RELATIVES À L’INDICE DE PROTECTIONIP 90
DISTANCE MINIMALE DE LA SURFACE ÉCLAIRÉE 90
DISTANCE MINIMALE AVEC DES MATÉRIAUX NORMALEMENT INFLAMMABLES 90
MISE AU REBUT 91
DÉCLARATIONS DU FABRICANT 91
ESPAÑOL
INFORMACIÓN SOBRE ESTE MANUAL 93
USO PREVISTO 93
TÉRMINOS Y SÍMBOLOS 93
INSTRUCCIONES DE SEGURIDAD 94
INDICACIONES PARA EQUIPOS PORTÁTILES DE EXTERIOR 97
ALCANCE DE LA ENTREGA 98
INTRODUCCIÓN 99
CONEXIONES, ELEMENTOS DE MANEJO Y ELEMENTOS DE VISUALIZACIÓN 100
MANEJO 102
INSTALACIÓN Y MONTAJE 115
CUIDADO, MANTENIMIENTO Y REPARACIÓN 116
ACCESORIOS OPCIONALES 117
TECNOLOGÍA DMX 117
DATOS TÉCNICOS 119
EXPLICACIÓN SOBRE LA CLASE DE PROTECCIÓN IP 120
DISTANCIA MÍNIMA CON RESPECTO A LA SUPERFICIE ILUMINADA 121
DISTANCIA MÍNIMA CON RESPECTO A MATERIALES NORMALMENTE INFLAMABLES 121
ELIMINACIÓN 121
DECLARACIONES DEL FABRICANTE 122
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO

POLSKI
INFORMACJE DOTYCZĄCE NINIEJSZEJ INSTRUKCJI OBSŁUGI 123
UŻYTKOWANIE ZGODNE Z PRZEZNACZENIEM 123
OBJAŚNIENIA TERMINÓW I SYMBOLI 123
ZASADY BEZPIECZEŃSTWA 124
UWAGI DOTYCZĄCE PRZENOŚNEGO SPRZĘTU ZEWNĘTRZNEGO 128
ZAKRES DOSTAWY 128
WPROWADZENIE 129
PRZYŁĄCZA, ELEMENTY OBSŁUGI I WSKAŹNIKI 130
OBSŁUGA 132
USTAWIANIE I MONTAŻ 145
CZYSZCZENIE, KONSERWACJA I NAPRAWY 146
TECHNIKA DMX 148
DANE TECHNICZNE 150
OBJAŚNIENIA DOTYCZĄCE STOPNIA OCHRONY IP 151
UTYLIZACJA 152
MINIMALNA ODLEGŁOŚĆ OD POWIERZCHNI OŚWIETLONEJ 152
MINIMALNA ODLEGŁOŚĆ OD NORMALNIE ŁATWOPALNYCH MATERIAŁÓW 152
DEKLARACJE PRODUCENTA 153
ITALIANO
INFORMAZIONI SUL PRESENTE MANUALE DI ISTRUZIONI 154
UTILIZZO CONFORME 154
SPIEGAZIONE DI CONCETTI E SIMBOLI 154
INDICAZIONI SULLA SICUREZZA 155
AVVERTENZE PER DISPOSITIVI PORTATILI PER ESTERNI 159
INTRODUZIONE 159
CONNESSIONI, ELEMENTI DI COMANDO E DI VISUALIZZAZIONE 160
UTILIZZO 162
INSTALLAZIONE E MONTAGGIO 175
CURA, MANUTENZIONE E RIPARAZIONE 176
TECNOLOGIA DMX 177
DATI TECNICI 179
SPIEGAZIONI SULLA PROTEZIONE IP 180
DISTANZA MINIMA DALLA SUPERFICIE ILLUMINATA 181
DISTANZA MINIMA DAI MATERIALI NORMALMENTE INFIAMMABILI 181
SMALTIMENTO 181
DICHIARAZIONI DEL PRODUTTORE 181
DMX
DMX CONTROL / DMX STEUERUNG / PILOTAGE DMX / CONTROL DMX /
STEROWANIE DMX / CONTROLLO DMX 183
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO

5
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
ENGLISH
YOU HAVE MADE THE RIGHT CHOICE!
This device has been developed and manufactured to the highest quality standards to ensure
many years of problem-free operation. Please read this manual carefully to be able to use your
new Cameo product quickly and optimally. Further information about Cameo Light is available on
our website CAMEOLIGHT.COM.
INFORMATION ON THIS USER MANUAL
•Carefully read the safety instructions and the entire manual before operating the device.
•Observe the warnings on the device and in the user manual.
•Always keep the user manual within reach.
•If you sell or pass on the device, it is important that you also include this user manual, as it is an
integral part of the product.
INTENDED USE
The product is a device for event technology!
This product has been developed for professional use in the field of event technology and is not
suitable for use as domestic lighting!
Furthermore, this product is only intended for qualified users with specialist knowledge of event
technology!
Use of the product outside the specified technical data and operating conditions is considered
inappropriate!
Liability for damage and third-party damage to persons and property due to inappropriate use is
excluded!
The product is not suitable for:
• Use by persons (including children) with limited physical, sensory or mental abilities or lack of
experience and knowledge.
• Children (children must be instructed not to play with the device).
DEFINITIONS AND SYMBOL DECLARATIONS
1. HAZARD: The word HAZARD, possibly in combination with a symbol, is used to indicate imme-
diately dangerous situations or conditions affecting life and limb.
2. WARNING: The word WARNING, possibly in combination with a symbol, indicates potentially
dangerous situations or conditions affecting life and limb.
3. CAUTION: The word CAUTION, possibly in combination with a symbol, indicates situations or
conditions that could lead to injury.
4. ATTENTION: The word ATTENTION, possibly in combination with a symbol, indicates situations
or states that may lead to property damage and/or environmental damage.

6
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
This symbol identifies hazards that can cause electric shock.
This symbol identifies hazardous areas or hazardous situations.
This symbol indicates hazards caused by hot surfaces.
This symbol indicates hazards caused by intense light sources.
This symbol indicates a device in which there are no user-replaceable parts.
This symbol indicates additional information on the operation of the product.
SAFETY INSTRUCTIONS
HAZARD:
1. Do not open the device and do not perform any modifications.
2. If your device no longer functions properly, if liquids or objects get inside it or if it
has been damaged in any other way, switch it off immediately and unplug it from
the power source. The device may be repaired only by authorised repair technici-
ans.
3. For devices of protection class 1, the protective conductor must be connected
correctly. Never disconnect the protective conductor. Devices of protection class 2
do not have a protective conductor.
4. Ensure that live cables are not kinked or otherwise mechanically damaged.
5. Never bypass the device fuse.
WARNING:
1. The device may not be operated if it shows obvious signs of damage.
2. The device may only be installed in a voltage-free state.
3. If the device‘s power cable is damaged, the device may not be used.
4. Permanently connected mains cables may only be replaced by a qualified person.

7
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
CAUTION:
1. Do not switch on the device if it has been exposed to extreme temperature fluctu-
ations (for example, following transport). Moisture and condensation can damage
the device. Switch on the device only when it has reached room temperature.
2. Ensure that the voltage and frequency of the mains supply match the values spe-
cified on the device. If the device has a voltage selector switch, do not connect
the device until it has been set correctly. Use only suitable power cables.
3. To disconnect the device from the mains on all poles, it is not sufficient to press
the on/off switch on the device.
4. Make sure that the fuse used corresponds to the type printed on the device.
5. Ensure that suitable measures have been taken against overvoltage (e.g. lightning
strikes).
6. Observe the specified maximum output current on devices with a Power Out
connection. Ensure that the total current consumption of all connected devices
does not exceed the specified value.
7. Only replace pluggable mains cables with equivalent cables that correspond to
the cable originally supplied. The cross-section must not fall below the cross-sec-
tion of the original cable.
HAZARD:
1. Choking hazard! Plastic bags and small parts must be kept out of reach of per-
sons (including children) with reduced physical, sensory or mental capabilities.
2. Risk of falling! Make sure that the device is securely installed and will not fall
down. Only use suitable stands or mountings (particularly for fixed installations).
Ensure that accessories are properly installed and secured. Ensure that applicable
safety regulations are observed.
WARNING:
1. Use the device in the prescribed manner only.
2. Operate the device using only accessories of the type recommended and supplied
by the manufacturer.
3. Observe safety regulations applicable in your country during installation.
4. After connecting the device, ensure that all cables are routed so as to avoid
damage or accidents, such as from tripping.
5. Always observe the specified minimum distance to normally flammable materials!
Unless explicitly stated, the minimum distance is 0.3m.
6. Always observe the minimum distance to the illuminated surface that can be read
on the device!

8
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CAUTION:
1. Moving components such as mounting brackets or other movable components-
may become jammed.
2. In the case of devices with motor-driven components, there is a risk of injury due
to the movement of the device. Sudden device movement can cause shock-
reactions.
3. The housing surface of the device can become very hot during regular operation.
Ensure that accidental touching of the housing is not possible. Always allow the
lamp to cool sufficiently before removal, maintenance work and charging etc.
CAUTION:
1. Do not install or use the device in the vicinity of radiators, accumulators, stoves,
or other heat sources. Ensure that the device is always installed in such a way
that it is sufficiently cooled and cannot overheat.
2. Do not place any ignition sources, such as burning candles, near the device.
3. Ventilation openings may not be covered and fans may not be blocked.
4. For transport, use the original packaging or packaging provided by the manufac-
turer.
5. Avoid any impacts to or shaking of the device.
6. Observe the IP rating and the ambient conditions such as temperature and humi-
dity according to the specification.
7. Devices can be continuously further developed. In the event of deviating informa-
tion on operating conditions, performance or other device properties between the
user manual and the device labelling, the information on the device always takes
priority.
8. The device is not suitable for tropical climate zones or for operation over 2,000m
above sea level.
9. Unless explicitly stated, the device is not suitable for operation under marine
conditions.
CAUTION! IMPORTANT INFORMATION REGARDING LIGHTING PRODUCTS!
1. Never look directly into the beam of light, not even for a short period of time.
2. Never look into the beam of light using optical devices such as a magnifying
glass.
3. Stroboscopic effects may cause epileptic seizures in susceptible people!

9
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
4. A permanently installed lamp is built into this lighting unit. This may not be repla-
ced by the user. In the event of an error, please contact your salespartner.
NOTES ON PORTABLE OUTDOOR DEVICES
1. Temporary operation! Event equipment is generally only designed for temporary
operation.
2. Continuous operation or permanent structural installation – particularly outdoors
– can impair the function, surfaces and seals and accelerate material fatigue.
3. Damage to the surface coating can impair the device‘s corrosion protection.
Damaged surface coating (e.g. scratches) must be promptly repaired by suitable
measures.
DELIVERY SCOPE
Remove the product from the packaging and remove all packing material.
Please check the completeness and integrity of the delivery and please notify your distributor
immediately after purchase if the delivery is not complete or damaged.
With the package you have purchased you have received:
•Headlamp
•power cord
•Instruction manual
INTRODUCTION
7 X 10 W RGBWA LED OUTDOOR SPOTLIGHT
CLPFLATPRO7G2
12 X 10 W RGBWA LED OUTDOOR SPOTLIGHT
CLPFLATPRO12G2
18 X 10 W RGBWA LED OUTDOOR SPOTLIGHT
CLPFLATPRO18G2
CONTROL FUNCTIONS
XDMX modes without DMX delay channel: 1-channel, 3-channel 1, 3-channel 2, 5-channel 1,
5-channel 2, 10-channel and 13-channel DMX control
XDMX modes with DMX delay channel: 2-channel, 4-channel 1, 4-channel 2, 6-channel 1,
6-channel 2, 11-channel and 14-channel DMX functions
XMaster / slave operation
XStandalone functions
XRDM

10
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
1 : 1
白色
016
DY00
Y37701-016
文件�号
客��号
制�日期
修改内容
�注
制�人�
核�人�
�核批准
版本号
比例
�印�色
蔡杰�
2020-02-28
�品�印�准制�
10
7
6
5
8
1 2 4 3 1111
9
The models CLPFLATPRO7G2, CLPFLATPRO12G2 and CLPFLATPRO18G2 have identical connections,
Operating and display elements, the position of the connections varies slightly.
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
1POWER IN
TRUE 1-compatible power input socket. Operating voltage 100–240 V AC/50–60 Hz. A suitable
mains cable with IP65 plug is included. When not in use, always close with the appropriate rubber
sealing cap.
2POWER OUT
TRUE 1-compatible mains output socket for supplying power to additional Cameo spotlights (for
maximum output current, see label on back of housing). When not in use, always close with the
appropriate rubber sealing cap.
FEATURES
10 W 5-in-1 RGBWA LEDs. Protection class IP65. 3-pin IP65 DMX connections. True 1 compatible
power connections IN and OUT. OLED display. Flicker-free operation through adjustable PWM fre-
quency. Silent due to convection cooling. Operating voltage 100–240 V AC. The spotlights feature
the RDM standard (remote device management). This remote device management allows the user
to view the status and configuration of RDM end devices via an RDM-capable controller.

11
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
3DMX IN
Male IP65 3-pin XLR socket for connection to a DMX control device (e.g. DMX console) When not
in use, always close with the appropriate rubber sealing cap.
4DMX OUT
Female IP65 3-pin XLR socket for sending the DMX control signal. When not in use, always close
with the appropriate rubber sealing cap.
5FUSE
IP65 fuse holder for 5 x 20 mm micro fuses. IMPORTANT: Replace the fuse only with a fuse of the
same type and of the same value (see stamp on back of device). In the event of repeated fuse
failure, please contact an authorised service centre.
6PRESSURE EQUALISATION ELEMENT
The pressure equalisation element serves to prevent condensation inside the housing. In order to
ensure its proper function, the element must be protected from contamination.
7OLED DISPLAY
The OLED display shows the currently activated mode (main display), the menu items in the
selection menu and the numerical value or operating mode in certain menu items. If there is no
input for approx. 30 seconds, the display automatically returns to the main display. Note regar-
ding the main display in operating modes with external control: As soon as the control signal
is interrupted, the characters in the display begin to flash. When there is a control signal again,
the flashing stops. Briefly pressing UP on the control panel when in the main display rotates the
display by 180°.
8ILLUMINATED CONTROL PANELS
Illumination of the control panels is activated as soon as one of the capacitive control panels is
touched; only then is operation via control panels possible. If no input is made within approx. 30
seconds, the control panel illumination goes off.
MENU – Press MENU to access the selection menu. Press repeatedly to return to the main display.
Pressing MENU without confirming a value or status change with ENTER restores the previously
confirmed value or status.
ENTER – Press ENTER to access the menu levels to make value changes and use the ENTER control
field to access the submenus. Confirm value or status changes by pressing ENTER.
UP and DOWN – Select individual menu items in the selection menu (DMX address, operating
mode etc.) and in the submenus.
Allow changes to the value in a menu item, such as the DMX address, as required.

12
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
9STAND AND MOUNTING BRACKET
Four rubber feet on the underside of the stand and/or mounting bracket ensure that it can be se-
curely placed on suitable surfaces while at the same time protecting the surface from scratches.
When installing the traverse mounting, use an optional traverse clamp (Omega bracket and the 16
mm spigot SPIN16® with folding mechanism are available as options).
10 CARRY HANDLE/SECURING POINT
The practical carry handle also serves to secure the spotlight in the event of traverse mounting.
11 GRIP SCREWS
The two grip screws are used for adjusting and fixing the stand and/or mounting bracket.
PLEASE NOTE: To protect the input and output sockets from splash water in accordance with
IP65 protection class, they must be correctly closed using the appropriate IP65 plugs or the rubber
sealing caps must be used to close them.
OPERATION
PLEASE NOTE
XAs soon as the spotlight is correctly connected to the power supply, the following will be
displayed in succession: “Welcome to Cameo”, the model name and the software version. After
this process, the spotlight is ready for operation and the previously activated operating mode is
launched.
XTo return directly from the submenus to the main display, press and hold the MENU control
for around 3 seconds. The main display is activated automatically if no input is made within
approximately 30 seconds. To navigate one level up in the submenus, briefly press MENU.
XTo directly access the previously edited menu item, briefly press MENU and ENTER at the same
time.
XBriefly pressing UP when in the main display rotates the display by 180°.
XTo quickly change a value, such as the DMX start address, press and hold UP or DOWN.
XBefore changing device settings, ensure that the control panel is dry and dust free, in order not
to impair its functionality.
MAIN DISPLAY DMX OPERATING MODE
The display shows the DMX address and current DMX start address (in the example 001). If the
DMX delay is activated, the delay group and delay time are also displayed.

13
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
MAIN DISPLAY STANDALONE MODE
The display shows the currently activated standalone mode
(Mode Auto, Mode Static, Mode CCT, Mode Color Preset, Mode User Color, Mode Loop).
MAIN DISPLAY SLAVE MODE
The display shows Mode Slave. If the slave unit is assigned to a slave group, the slave group and
the delay time set in the master unit under the standalone operating modes Auto and Loop are
also displayed.
CONFIGURE DMX START ADDRESS
Press MENU to access the main menu. Now use UP and DOWN to select the menu item DMX
Mode and confirm with ENTER. Again use UP and DOWN to select the desired DMX mode and
confirm with ENTER (DMX modes with DMX delay channel are identified with ‚D’). Tables with the
channel assignment of the different DMX modes can be found in these instructions under DMX
CONTROL.
CONFIGURE DMX MODE
Press MENU to access the main menu. Now use UP and DOWN to select the menu item DMX
Mode and confirm with ENTER. Again use UP and DOWN to select the desired DMX mode and
confirm with ENTER. Tables with the channel assignment of the different DMX modes can be
found in these instructions under DMX CONTROL.

14
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
DMX DELAY
The DMX Delay function is a simple way to create a running light effect with a large number of
spotlights that are all the same model and that are all running the same software version. This is
otherwise only achievable with a suitable DMX controller and time-consuming programming. All
the spotlights used in this are set to the same DMX operating mode and controlled via the same
DMX start address.
Manually setting the DMX delay for DMX modes without DMX delay channel:
Starting from the main display, press MENU to enter the main menu. Use the buttons and 
to select the menu item DMX Delay and confirm with ENTER. Again use and to select the
desired submenu item, confirm with ENTER and set the value or status accordingly. Confirm all
entries with ENTER. Assign the spotlights to one of up to 47 groups as desired (maximum group
number depends on the activated DMX operating mode). Multiple spotlights may be assigned to
a group. The group number is also the factor by which the set delay time is multiplied. The delay
time (delay time of the DMX signal) can be set manually at each spotlight separately with different
values (0.0 s to 2.0 s in 0.1 s increments).
Setup example:

15
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Setting the DMX delay for DMX modes with DMX delay channel:
Starting from the main display, press MENU to enter the main menu. Use the buttons and to
select the menu item DMX Delay and confirm by pressing ENTER twice. Assign the spotlights to one
of up to 47 groups as desired (maximum group number depends on the activated DMX operating
mode). Multiple spotlights may be assigned to a group. The group number is also the factor by which
the set delay time is multiplied. Confirm each entry by pressing ENTER.
The delay time (delay time of the DMX signal) is set by means of a DMX controller in the separate
DMX delay channel of the corresponding DMX mode (0.0 s to 2.0 s in 0.1 s increments).
Setup example:
AUTO STANDALONE MODE
The 6 available auto-programmes each comprise non-editable color-change sequences; Random
scenes, brightness, speed and delay can be set separately for each programme in some cases.
Starting from the main display, press MENU to enter the main menu. Now use UP and DOWN to select
the Stand Alone menu item and confirm with ENTER. Use UP and DOWN again to select the Auto
standalone mode and confirm with ENTER. Now use UP and DOWN to select the desired programme
and confirm with ENTER.

16
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
This will take you to the submenu for setting the submenu items (see table, select with UP and
DOWN, confirm with ENTER, change value or status with UP and DOWN, confirm with ENTER).
The settings for each programme are made separately and are retained even after restarting the
device.
AUTO STANDALONE MODE
Dimmer Sets brightness 0–100
Speed Sets running speed 0–100
Delay Delay time for slave groups 0.0 s to 2.0 s
STATIC STANDALONE MODE
The Static standalone mode allows the Dimmer, Strobe, R, G, B, W and A values to be set directly
on the device with values in a similar way to with a DMX controller. In this way, an individual
scene can be created without an additional DMX controller.
Starting from the main display, press MENU to enter the main menu. Using UP and DOWN, select
the Standalone menu item and confirm with ENTER. Again use UP and DOWN to select the
Static standalone mode and confirm with ENTER. Using UP and DOWN, now select the menu item
that you wish to edit and confirm with ENTER. You can use UP and DOWN to configure the desired
value between 000 and 255. The strobe effect values correspond to those in channel 2 of the DMX
table 3 CH Mode 1. Confirm all entries with ENTER.
CCT STANDALONE MODE (CORRELATED COLOR TEMPERATURE)
The CCT standalone mode allows the color temperature to be adjusted from 1800 K to 7500 K in
100 K steps, and the tint and brightness (dimmer) can also be adjusted.
Starting from the main display, press MENU to enter the main menu. Using UP and DOWN, select
the Standalone menu item and confirm with ENTER. Using UP and DOWN, select the standalone
mode CCT and confirm with ENTER. Now select the menu item you wish to edit using UP and
DOWN, confirm with ENTER and adjust the desired value using UP and DOWN. Confirm all entries
with ENTER.

17
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
COLOR PRESET STANDALONE MODE
15 different color presets are available. The brightness can be separately set for each preset.
Starting from main display 1, press MENU to enter the main menu. Using UP and DOWN, select
the menu item Standalone and confirm with ENTER. Using UP and DOWN, select the standalone
mode Color Preset and confirm with ENTER. Now use UP and DOWN to select the desired color
as a preset and confirm with ENTER (Color Off = blackout). You can set the desired brightness
from 000 to 100 using UP and DOWN, confirm all entries with ENTER.
USER COLOR STANDALONE MODE
The User Color standalone mode allows you to store four individual color presets for overall bri-
ghtness, strobe and a color blend of R, G, B, W and A directly in the device.
Starting from the main display, press MENU to enter the main menu. Using UP and DOWN, select
the menu item Standalone and confirm with ENTER. Again use UP and DOWN to select the stan-
dalone mode User Color and confirm with ENTER. Using UP and DOWN, now select the desired
preset (Color 1 - Color 4) and confirm with ENTER. Using UP and DOWN, now select the menu
item that you wish to edit and confirm with ENTER. You can use UP and DOWN to configure the
desired value between 000 and 255. The strobe effect values correspond to those in channel 2 of
the DMX table 4 CH Mode 1. Confirm all entries with ENTER.

18
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
LOOP STANDALONE MODE
The Loop standalone mode allows you to individually configure, store and access up to four
different color changing programmes. Brightness, step time, fade time and delay (signal delay) are
also separately configurable.
Starting from the main display, press MENU to enter the main menu. Using UP and DOWN, select
the menu item Standalone and confirm with ENTER. Using the UP and DOWN buttons, select the
standalone mode Loop and confirm with ENTER. Using UP and DOWN, now select the desired
loop (Loop 1 to 4) and confirm with ENTER.
This will take you to the submenu for setting the submenu items (see table, select with UP and
DOWN, confirm with ENTER, change value or status with UP and DOWN, confirm with ENTER). The
settings for each loop are made separately and are retained even after restarting the device.
STANDALONE MODE LOOP (Loop 1 – Loop 4)
Dimmer Sets brightness 0–100
Step
time
Sets step time 0.1 s to 10.0 s
Fade
time
Sets fade time in percent 0% to 100%
Delay Delay time for slave groups 0.0 s to 2.0 s
Step 1 15 colors from Color Preset Red – C White
4 colors from User Color User 1 to User 4
Blackout Blackout
Step 2 „ „
Step 3 15 colors from Color Preset Red – C White
4 colors from User Color User 1 to User 4
Blackout Blackout
--- Skip step
Step 4 „ „

19
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
SLAVE MODE
Standard slave mode: Starting from the main display, press MENU to enter the main menu.
Now use UP and DOWN to select the menu item Slave, confirm with ENTER, select Slave Group
0 and again confirm with ENTER. Connect the slave and the master units (same model, same
software version) using a DMX cable, and enable one of the standalone modes on the master unit
(Auto, Static, Color Preset, User Color, Loop). The slave unit will now follow the master unit.
Main display
Advanced slave mode:If you wish to control the slave units in master/slave mode using one of
the Auto or Loop standalone modes, the control signal can be reproduced with a time delay of
up to 24 steps. The delay is set in the sub-menu item Delay in the relevant standalone mode, the
delay factor is set in the slave menu of the corresponding spotlight. This is a simple way to create
a running light effect with a large number of spotlights that are all the same model and have
the same software version. This is otherwise only possible using a suitable DMX controller and
time-consuming programming.
Main display
with group number
and delay time in master unit
Assign the spotlights to one of up to 24 groups according to preference, whereby several spotli-
ghts can be assigned to one group. The group number is also the factor by which the delay time
set in the master unit is multiplied (see setup example).

20
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
SYSTEM SETTINGS (SETTINGS)
Starting from the main display, press MENU to enter the main menu. Use UP and DOWN to select
the menu item Settings and confirm
with ENTER.
This will take you to the submenu for setting the submenu items (see table, select with UP and
DOWN, confirm with ENTER, change value or status with UP and DOWN, confirm with ENTER).
Settings
Display Reverse = Rotate display Off No display rotation
On Display is rotated by
180° (e.g. for overhead
installation)
Display backlight = Display lighting Off Deactivates after approxi-
mately 30 seconds of
inactivity
On On permanently
Signal Fail = Operating status with
DMX signal fault
Hold Last command is retained
Blackout Activates blackout
Fade slow fade out to blackout
User Color 1 User Color 1 is activated
PWM Frequency = LED PWM frequency 650Hz, 1530Hz,
2000Hz,
3600Hz, 12kHz,
25kHz
Select LED PWM frequ-
ency
Dimmer respon-
se
= Dimmer response LED Lamp responds abruptly to
changes in DMX value
Halogen Spotlight behaves like a
halogen spotlight with soft
brightness changes
