Replacement Parts List Model PW1950
CAMPBELL
HAUSFELD
IN199500AV 4/95
Gasoline Powered
Pressure Washers
1
2
3
4
5
6
7
8
910
11
1 Handle PM003100AV 1
2 Wand rack kit [incl. (2) ea. items 3 & 4] PW070300SV 1
3 Washer AL101600AV 2
4 1/4-20 Elastic stop nut ✽ 4
5 Rubber foot PM003000AV 2
6 1/4-20 x 1 1/4” Hex bolt ✽ 2
7 1/4” Black flat washer ✽ 2
8 Wheel PM030300AV 2
9 Base plate PM000100AV 1
10 Hex lock nut ST033500AV 2
11 Axle bolt ST033400AV 2
12 Gun PM021600AV 1
13 Lance/Nozzle PM021500AV 1
14 High pressure hose PM021700AV 1
Ref.
No. Description Part Number Qty.
12
13
12
Cart Assembly for Model PW1950
✽ Indicates Std. hardware

Pump Assembly for
Gasoline Powered
Pressure Washers
1
2
3
4
5
6
7
8
9
11
12
8
*10
13
14
15
14
16
17
18
19
20
21
22
23
24 25 26
27
28
29
30
31 32
37
36
33
34
35
31
32
38 39
40
41
42
*Item 10 not included with item 11
Parts Breakdown Models PW1950 and PW2250
2

For Replacement Parts, call 1-800-330-0712
Please provide following information:
-Model number
-Serial number (if any)
-Part descriptions and number as shown in parts list
Address parts correspondence to:
Campbell Hausfeld
100 Production Drive
Harrison, OH 45030
Ref.
No. Description Part Number Qty
▲Must be replaced only by authorized service center
Replacement Parts List Models PW1950 and PW2250
1Engine connector shaft ▲1
2 Front motor flange ▲1
3 Outer flange o-ring PM011600AV 1
4 Inner flange o-ring PM008600SV 1
5 Seal ring ▲1
6 Oblique ball bearing ▲1
7 Incline plate PM017900AV 1
8 M8 x 25 Screw PM022700AV 5
9 Thrust ball bearing assembly PM025700AV 1
10 Piston PM026000AV 3
11 Piston spring kit (does not include #10) PM027700SV 3
12 Piston guide body PM026300AV 1
13 Vented oil cap PM009900SV 1
14 O-ring PM006900SV 2
15 Head body connective sleeve PM026500AV 1
16 Water seal kit (incl. set of 3) PM029700SV 1
17 3/8” Setscrew PM027400AV 1
18 Oil level sight glass PM029400AV 1
19 O-ring PM029500AV 1
20 Inlet fitting PM029600AV 1
21 Inlet filter PM002500AV 1
22 Pressure regulator knob PM027600AV 1
23 Pressure regulator PM024700AV 1
24 Regulation rod seat PM026900AV 1
25 O-ring PM026800AV 1
26 M6 x 8 Setscrew PM026700AV 2
27 M5 x 5 Setscrew PM026600AV 2
28 Regulation rod PM028600AV 1
29 Brass head PM028500AV 1
30 M8 x 40 screw and lockwasher PM028400AV 4
31 Inlet/Outlet valve kit (incl. set of 6) PM028000SV 1
32 Valve cap PM027300AV 6
33 Bleeder screw PM028300AV 1
34 Chemical suction spring PM024400AV 1
35 Stainless steel ball PM008100SV 1
36 Detergent fitting o-ring PM027500AV 1
37 Detergent hose fitting PM008200SV 1
38 Unloader for Model PW1950 PM028200AV 1
Unloader for Model PW2250 PM028201SV 1
39 O-ring PM028100AV 1
40 O-ring PM007700SV 1
41 Unloader support PM027900AV 1
42 High pressure hose fitting PM027800AV 1
43 Complete pump assembly for Model PW1950 PM021400AV 1
44 Complete pump assembly for Model PW2250 PM021401SV 1
3

1 Cart base PM000100AV 1
2 Iso mount PM003700AV 4
3 5/16-18 Nut ✽ 4
4 Short handle assy. [incl. nuts, bolts, & washers] PW071200SV 1
5 Wheel WA120100AV 2
6 Pal nut kit [incl. (2) pal nuts] PW070000SV 1
7 Axle assy. [incl. (2) pal nuts, bolts & nuts] PW071100SV 1
8 Right leg assy. [incl. nuts, bolts, washers & shock absorber] PW070900SV 1
9 Shock absorber kit [incl. (2) 1/4-20 x 1 1/2” bolts & nuts] PW070100SV 1
10 Left leg assy. [incl. nuts, bolts, washers & shock absorber] PW071000SV 1
11 Hose rack assy. [incl. (4) #10 sheet metal screws] PW070200SV 1
12 Long handle assy. [incl. nuts, bolts & washers] PW070800SV 1
13 Gun PM021600AV 1
14 Lance/nozzle PM021500AV 1
15 High pressure hose PM021700AV 1
16 Hardware kit - Not Shown [ incl. all nuts & bolts] PW070400SV 1
Gasoline Powered
Pressure Washers
1
24
3
5
6
7
8
9
10
11
12
12
13
12
Cart Assembly for Model PW2250
●All nuts are 1/4-20 and all bolts are 1/4-20 x 1 3/4 unless specified otherwise
Replacement Parts List Model PW2250
Ref.
No. Description Part Number Qty.
✽ Indicates Std. hardware
13
14
15
