Campbell Hausfeld PW2120 User manual

BUILT TO LAST
TM
Gasoline Powered
Pressure Washers
Assembly Instructions and PW2120, PW2318,
Replacement Parts Manual PW2408, and PW2418
IN457900AV 4/00
Please record Model No. and Serial No. for use when contacting
the manufacturer:
Model No. ______________ Purchase date ____________________
Serial No. ______________ Purchase place ____________________
For Information About This Product,
call 1-800-330-0712
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or
maintain the product described. Protect yourself and others by observing all safety information. Failure to
comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
For parts, product & service information
visit www.campbellhausfeld.com
Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Replacement Parts Ordering Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Contents Page
Refer to Product Manual for Detailed Safety Instructions
© 2000 Campbell Hausfeld

Gasoline Powered Pressure Washers
This manual contains information that
is very important to know and under-
stand. This information is provided for
SAFETY and to PREVENT EQUIPMENT
PROBLEMS. To help recognize this infor-
mation, observe the following symbols.
Danger indicates
an imminently
hazardous situation which, if not
avoided, WILL result in death or seri-
ous injury.
Warning indicates
a potentially haz-
ardous situation which, if not avoided,
COULD result in death or serious
injury.
Caution indicates
a potentially haz-
ardous situation which, if not avoided,
MAY result in minor or moderate
injury.
Notice
indicates impor-
tant information, that if not followed,
may cause damage to equipment.
Remove the equipment and all parts
from the carton. The carton should
contain the following:
One (1) Pressure washer (pump,
engine, cart base)
One (1) Cart handle Assembly
One (1) Basket (not included with
all models)
One (1) Spray gun
One (1) Lance with nozzle
Five (5) Spray tips (not included
with all models)
One (1) High pressure hose
One (1) Pack of nuts, bolts,
manuals and Chemical Suction
Tube with Filter
If any parts are missing, DO NOT
return unit to the retailer. Know
model number (located on serial num-
ber tag on frame) and call 1-800-330-
0712 for replacement.
After unpacking the product, inspect
carefully for any damage that may
have occurred during transit. Make
!
NOTICE
!
CAUTION
!
WARNING
!
DANGER
sure to tighten fittings, bolts, etc.,
before putting unit into service.
Do not operate
unit if damaged
during shipping, handling or use.
Damage could result in bursting and
cause injury or property damage.
See Product Manual for
General Safety Information
1. Slide handle over legs and secure
with bolts provided.
2. Insert removable spray tips and
rubber grommets into holes pro-
vided on frame (if applicable).
3. Connect the clear plastic chemical
suction tube with filter to chemical
injector hose barb on the pump.
4. Connect the high-pressure hose to
the pump outlet.
5. Connect the high-pressure hose to
the gun.
6. Attach lance with nozzle to the
gun.
!
WARNING
ALWAYS use this start up procedure to
ensure that the unit is started safely
and properly.
If water has
frozen in the pres-
sure washer, thaw in a warm room
before starting. DO NOT pour hot
water on or into the pump; internal
parts will be damaged.
TRIGGER SAFETY LATCH
In the engaged position, the trigger
safety latch prevents the gun from
being triggered accidentally. Push
latch fully down to engage (See Figure
2). Always engage trigger safety latch
when unit is not in use.
1. Check oil levels. Add oil as necessary.
NOTE: Some units are equipped with a
low-oil sensor that shuts engine off if
oil level falls below a certain level. If
unit stops unexpectedly, check both oil
and fuel levels. Check oil level each
time unit is refueled.
2. Check fuel level.
DO NOT refuel a
hot engine.
Refueling a hot engine could cause a
fire. Use only fresh, clean regular or
unleaded gasoline. Close the fuel
shutoff valve during refueling.
3. Attach garden hose to inlet side of
pump and connect to water supply.
Hose should have an I.D. of 5/8” and
not be longer than 50 ft. (15 M).
!
WARNING
!
CAUTION
2
Figure 1 - Pump hook up
Pump inlet
Pump outlet
Chemical
injector
hose barb
Safety Guidelines
Assembly
Start Up
Figure 2 - Trigger Lock
Engaged
Disengaged
www.campbellhausfeld.com
Unpacking

3
www.campbellhausfeld.com
PW2120, PW2318, PW2408 and PW2418
up in the high pressure hose. Go
back to step 7 and repeat until
engine starts.
1. Be sure all detergent is flushed
from system.
2. Turn off engine.
3. Turn off water supply.
4. After engine and water supply are
turned off, trigger the gun to
depressurize the system.
NEVER turn the
water supply off
before turning the engine off. Serious
damage could occur to the pump
and/or engine.
NEVER disconnect
the high pressure
discharge hose from the machine
while the system is pressurized. To
depressurize, turn engine off, turn
water supply off and squeeze gun
trigger 2-3 times.
5. After each use, wipe all surfaces of
the pressure washer with a clean,
damp cloth.
NOTE: A winterizing kit,
(PW104200AJ) is available for long
term storage.
!
WARNING
!
CAUTION
Some local plumb-
ing codes require
backflow prevention when connecting
to a fresh water supply. Install back-
flow preventer upstream from the
pump if necessary.
a. If inlet water pressure is over 100
psi (7 bar) a regulating water
valve must be installed at the gar-
den hose connection.
b. Do not exceed 100¯ F (38¯ C) inlet
water temperature.
NOTE: The inlet water supply must
have a minimum flow rate of 5 gpm
(19 lpm).
4. Turn on the water supply.
Never run the unit
dry. BE SURE water
supply is completely turned on before
operating unit.
5. Trigger gun until water sprays from
tip indicating all air is purged from
system. Set trigger safety latch.
6. Open fuel shutoff valve (if unit is
equipped with valve). Be sure spark
plug ignition cable is pushed firmly
onto spark plug. On units equipped
with an ignition shutoff switch, put
switch in the “ON” position and put
throttle in the “RUN” position.
7. Start engine.
If engine is cold, completely close
engine choke. Grasp starter rope,
brace one foot on chassis then pull
rope rapidly and firmly. Continue
holding rope as it returns. Pull and
return the rope until engine starts.
In cool weather, the choke may have
to be kept closed for 10 to 30 sec-
onds to keep the engine running.
Otherwise, open choke as soon as
engine starts.
If engine is warm, leave choke open
or just partially closed. Start engine
then open choke completely.
Never let starter
rope return by
itself. This could jam the recoil system.
8. If engine does not start after 2-3
pulls, squeeze the gun trigger to
release the pressure that has built
!
NOTICE
!
CAUTION
!
CAUTION
Start Up (Continued)
Shutdown
PRESSURE RELIEF
PROCEDURE
To reduce the risk of bodily injury
or property damage, always fol-
low this procedure whenever
spraying is stopped, when work is
completed and before checking
or repairing any part of the sys-
tem.
1. Engage the trigger safety
latch.
2. Turn unit off.
3. Remove ignition cable from
spark plug.
4. Shut off water supply.
5. Disengage trigger safety latch
and trigger gun to relieve
pressure.
6. Re-engage trigger safety latch.
7. Before overnight or long term
storage or transporting unit,
disconnect water supply and
turn off the fuel supply valve.

Gasoline Powered Pressure Washer
4
www.campbellhausfeld.com
For Replacement Parts, Call 1-800-330-0712
1
2 (2)
3 (2)
4 (4)
5***
20
11 (right side)
12 (left side)
15 (2)
16 (2)
17 (2)
24
25
13
14 (2)
3 (2)
4 (4)
18 (2)
19 (2)
10
2 (1)
3 (1)
4 (2)
21
23
22
*** 6
7 (2)
8 (2)
9 (2)
PW2120, PW2318, PW2408 and PW2418
26 (2)
2 (2)
3 (2)
4 (4)

5
www.campbellhausfeld.com
PW2120, PW2318, PW2408 and PW2418
Ref.
No. Description PW2120 PW2318 PW2408 PW2418 Qty.
1 Handle/placard assembly PM060020SJ PM060020SJ PM060020SJ PM060020SJ 1
2 1/4-20 x 1.75 Hex head bolt * * * * 5
3 1/4-20 Nylock nut * * * * 7
4 Flatwasher, 1/4-20 * * * * 14
5 Hose rack PM223700AV PM223700AV PM223700AV PM223700AV 1
6 Gun rack PM033410AV PM033410AV PM033410AV PM033410AV 1
7 10-24 x 1.75 Socket head cap screw * * * * 2
8 10-24 Nylock nut * * * * 2
9 Flatwasher, 10-24 * * * * 2
10 Baseplate PM223200AV PM223200AV PM223200AV PM223200AV 1
11 Leg, right side PM223610BH PM223610BH PM223610BH PM223610BH 1
12 Leg, left side PM223620BH PM223620BH PM223620BH PM223620BH 1
13 Axle PM224501BH PM224501BH PM224501BH PM224501BH 1
14 1/4-20 x 2.0 Hex head bolt * * * * 2
15 Wheel WA005100AV WA005100AV WA005100AV WA005100AV 2
16 Hub cap PM224400AV PM224400AV PM224400AV PM224400AV 2
17 Push nut MJ104700AV MJ104700AV MJ104700AV MJ104700AV 2
18 Rubber bumper AL062300AV AL062300AV AL062300AV AL062300AV 2
19 1/4-20 x .75 Self tapping screw * * * * 2
20 Engine PM004050AV PM004100AV PM226600AV PM223000AV 1
21 Pump assembly** PM223100SJ PM223100SJ PM223100SJ PM223100SJ 1
22 Gun PM005133AV PM005133AV PM005133AV PM005133AV 1
23 Lance PM035170AV PM035170AV PM035140AV PM035140AV 1
24 Hose PM012904AV PM012904AV PM012904AV PM012904AV 1
25 Detergent tube and filter PM013800AV PM013800AV PM013800AV PM013800AV 1
26 1/4-20 x 1.50 Hex head bolt * * * * 2
*Item available at local hardware store
**See replacement parts list IN458000AV
***Components not included with handle/placard assembly (ref #1)
Replacement Parts List
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
The Campbell Group
Attn: Parts Department
100 Production Drive
Harrison, OH 45030 U.S.A.

Gasoline Powered Pressure Washer
6
www.campbellhausfeld.com
Maintenance
Daily
After first 5 hours of
operation
Every 25 hours of
operation
Each 100 hours of
operation or every 3
months
Each 500 hours of
operation or every 6
months (horizontal shaft
units only)
Check water inlet screen and filter
Check engine and pump oil levels. Fill as necessary
Check gasoline level. Fill as necessary
Change engine break-in oil. Drain oil when warm
Use SAE30 or 10W-30 detergent oil
Clean and remove air cleaner filter (if applicable)
Wash with water and mild detergent. Dry thor-
oughly. Rub with oil and squeeze to distribute oil
Clean or replace paper air cleaner cartridge. Tap
gently to remove dirt
Change engine oil. Use SAE30 detergent oil
Change pump oil. Use SAE30 non-detergent oil
Maintenance Schedule Action needed
Maintenance Schedule
Observe regular maintenance inter-
vals to ensure maximum performance
and life from the pressure washer.
Refer to the schedule for recommend-
ed maintenance. If unit is operated
in dusty conditions, perform mainte-
nance checks more often.
Service Record
Date Maintenance performed Replacement components required

7
www.campbellhausfeld.com
PW2120, PW2318, PW2408 and PW2418
Notes

Gasoline Powered Pressure Washer
www.campbellhausfeld.com
Notes
