Canon iR2000 Series Reference guide

Aug 23 2004
Installation Procedure
iR2000 Series

Application
This manual has been issued by Canon Inc. for qualified persons to learn technical theory, installation, maintenance, and
repair of products. This manual covers all localities where the products are sold. For this reason, there may be
information in this manual that does not apply to your locality.
Corrections
This manual may contain technical inaccuracies or typographical errors due to improvements or changes in products.
When changes occur in applicable products or in the contents of this manual, Canon will release technical information
as the need arises. In the event of major changes in the contents of this manual over a long or short period, Canon will
issue a new edition of this manual.
The following paragraph does not apply to any countries where such provisions are inconsistent with local law.
Trademarks
The product names and company names used in this manual are the registered trademarks of the individual companies.
Copyright
This manual is copyrighted with all rights reserved. Under the copyright laws, this manual may not be copied,
reproduced or translated into another language, in whole or in part, without the written consent of Canon Inc.
COPYRIGHT © 2001 CANON INC.
Printed in Japan
Caution
Use of this manual should be strictly supervised to avoid disclosure of confidential information.

Introduction
Symbols Used
This documentation uses the following symbols to indicate special information:
Symbol Description
Indicates an item of a non-specific nature, possibly classified as Note, Caution, or Warning.
Indicates an item requiring care to avoid electric shocks.
Indicates an item requiring care to avoid combustion (fire).
Indicates an item prohibiting disassembly to avoid electric shocks or problems.
Indicates an item requiring disconnection of the power plug from the electric outlet.
Indicates an item intended to provide notes assisting the understanding of the topic in question.
Indicates an item of reference assisting the understanding of the topic in question.
Provides a description of a service mode.
Provides a description of the nature of an error indication.
Memo
REF.

Introduction
The following rules apply throughout this Service Manual:
1. Each chapter contains sections explaining the purpose of specific functions and the relationship between electrical
and mechanical systems with reference to the timing of operation.
In the diagrams, represents the path of mechanical drive; where a signal name accompanies the symbol ,
the arrow indicates the direction of the electric signal.
The expression "turn on the power" means flipping on the power switch, closing the front door, and closing the
delivery unit door, which results in supplying the machine with power.
2. In the digital circuits, '1'is used to indicate that the voltage level of a given signal is "High", while '0' is used to
indicate "Low".(The voltage value, however, differs from circuit to circuit.) In addition, the asterisk (*) as in
"DRMD*" indicates that the DRMD signal goes on when '0'.
In practically all cases, the internal mechanisms of a microprocessor cannot be checked in the field. Therefore, the
operations of the microprocessors used in the machines are not discussed: they are explained in terms of from
sensors to the input of the DC controller PCB and from the output of the DC controller PCB to the loads.
The descriptions in this Service Manual are subject to change without notice for product improvement or other
purposes, and major changes will be communicated in the form of Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this Service Manual and all relevant
Service Information bulletins and be able to identify and isolate faults in the machine."

Contents
Contents
第1章 Installation Procedure
1.1 Installing the Card Reader..................................................................................................................................... 2
1.1.1Points to Note .................................................................................................................................................. 2
1.1.2Checking the Contents..................................................................................................................................... 2
1.1.3Installation Procedure...................................................................................................................................... 3
1.1.4Installation in a NetSpot Accountant (NSA) Environment ............................................................................. 7

Contents

Chapter 1 Installation
Procedure

Chapter 1
2
1.1 Installing the Card Reader
1.1.1 Points to Note 0007-2705
The card reader must be used in combination with the Card Reader Mounting Kit-B1.
1.1.2 Checking the Contents 0007-2707
<Card Reader-C1>
T-1-1
F-1-1
<Card Reader Mounting Kit-B1>
[1] Card Reader-C1 1 pc.
[2] RS tightening screw (M4x10) 1 pc.
[3] Toothed washer 1 pc.
C
[1] [2] [3]

Chapter 1
3
T-1-2
F-1-2
1.1.3 Installation Procedure 0007-2709
When you have installed the Card Reader-C1, make the following selections, COPIER> FUNCTION> INSTALL>
CARD, and enter the card number you will be using; otherwise, the card will not be recognized upon insertion.
Be sure to go through the following steps on the host machine before starting the work
1. Hold down the control panel power switch for 3 sec or more.
2. Go through the shutdown sequence as instructed on the screen so that you may turn off the main power switch.
3. Turn off the main power switch.
4. Disconnect the power cable (from the wall outlet).
[1] Card reader base 1 pc.
[2] Relay harness 1 pc.
[3] TP screw (M4x25) 1 pc.
[4] TP screw (M4x8) 1 pc.
[5] Toothed washer 2 pc.

Chapter 1
4
F-1-3
1) Open the pedestal right door [1]. (if equipped with a Cassette Feeding Unit-Y2)
2) Open the lower right cover [2].
3) Remove the 5 screws [3], and detach the right cover (rear) [4].
F-1-4
4) Remove the face plate [2] from the right cover (rear) [1] using nippers.
[4][3][2]
[1]
ON/OFF
[1]
[2]
[3]
[3]
[3]
[4]

Chapter 1
5
F-1-5
5) Connect the relay cable [1] to the connector of the host machine
F-1-6
6) Mount the rear right cover using 4 screws.
7) Mount the card reader [1] and the card reader base [2] using the included TP screw (M4x8) [4]. Be sure to use the
washer [3] when doing so.
F-1-7
8) Route the relay cable [2] through the wire saddle [1].
[1]
[2]

Chapter 1
6
F-1-8
9) Connect the cable [1] of the machine and the relay cable [2] of the card reader.
F-1-9
10) While making sure that the harness swill not be trapped, mount the card reader [1] using a TP screw (4x25) [3]
fitted with a washer [2].
F-1-10
11) Connect the power cable to the wall outlet, and turn on the main power switch. See that the machine is in a
standby state, and start service mode.
12) Make the following selections in the machine's service mode (COPIER>FUNCTION>INSTALL>CARD); then,
[1]
[2]

Chapter 1
7
enter the appropriate card number (1 to 2001).
-Use the number that is the lowest of all the numbers that the user will be using.
-As many as 1000 cards may be used starting with the number entered.
13) Turn off the control panel power switch.
14) Turn off and then on the main power switch.
1.1.4 Installation in a NetSpot Accountant (NSA) Environment 0007-2764
1) Make the following selections in user mode: system control setup>group ID control>count control; then, see that
the following numbers are available: ID00000001 to ID00001000. (If you entered '1' in service mode:
COPIER>FUNCTION>INSTALL>CARD.)
2) Make the following selections in user mode: system setup>network setup>TCP/IP setup>IP address. Set the
following: 'IP address','gateway address','subnet mask'.
Unless you have set'system control group ID'and'system control ID No.', you will not be able to execute 'register card
to device' as part of NSA setup work.
3) In user mode, enter numbers of your choice for 'system control ID'and'system control ID No.'as part of system
administrator information.
4) Turn off the control panel power switch.
5) Turn off and then on the main power switch.
