1Carefully remove all items from the box.
2Check the package contents.
• See the flapped lid of the packing box.
3Place the machine on a flat surface.
4Remove all shipping tape and the protective sheet.
5Open the Scanning Unit and remove the protective material (A).
• Be sure to hold the machine by the side. Do not lift the machine by grasping the Paper Support Extension
or the Operation Panel.
1Connect the power cord.
2Press [ON/OFF] to turn
ON the machine.
3Use [ ] or [ ] on the
Operation Panel to select the language on the LCD, then press [OK]. (MP180)
• The language setting is only available for some countries.
• If you have an undesired language selection, refer to the User’s Guide.
1Lift the Scanning Unit and pull the Scanning Unit Support down into place.
IMPORTANT (US only)
• Write down the serial number. You will need this to register the product.
2Prepare the FINE Cartridges.
3Insert the FINE Cartridges.
4Close the Scanning Unit.
• Lift the Scanning Unit to put the Scanning Unit Support back to its original position.
IMPORTANT
Wait until the preparatory operation is complete; this takes about one to two minutes.
1Open the Paper Support (1) and pull up the Paper Support Extension (2) until
it stops.
2Load the paper with the print side face up.
• Ensure the paper stack does not exceed the Load Limit Mark (A).
3Pinch and adjust the Paper Guide (3) to the width of the stack.
4Open the Paper Output Tray.
The hardware setup is complete.
If you are connecting the machine to a computer for use, see the reverse side for instructions on
installing the software.
Thank you for purchasing the Canon PIXMA MP180/MP160. To prepare your machine for use, please follow
these Easy Setup Instructions before referring to any other documentation.
IMPORTANT
Do not connect the USB cable until after the software is installed. See the reverse side of this sheet for
details.
(A)
The cartridge
moves to the left.
Install the FINE
Cartridges here.
Do not touch!
Remove the protective tape.
C
B
(2)
(1)
(3)
(A)
© 2006 Canon Inc.
All products and brand names are registered trademarks or trademarks of their respective owners.
Specifications subject to change without notice.
QT5-0542-V01 xxxxxxx © CANON INC. 2006 PRINTED IN VIETNAM

Select Easy Install in order to install the application software, On-screen Manual and MP drivers.
Select Custom Install in order to choose the options you would like to install.
This sheet explains Easy Install only.
IMPORTANT
• Close any open software applications, including virus checkers, prior to installing the software.
The following software programs are included on the Setup CD-ROM:
IMPORTANT
• Do not connect the USB cable until Step 4, “Connect the USB cable.”
• Before installing the software in Windows XP or Windows 2000, you must log on as Administrator
or a user with Administrator privileges.
Step 1: Prepare the Setup CD-ROM and get ready to install.
1Turn OFF the machine.
2Turn ON your computer, and start Windows.
3Insert the Setup CD-ROM into the CD-ROM drive.
• The setup program should automatically run. If the setup program does not automatically run, click
[My Computer], then double-click the CD-ROM icon.
IMPORTANT
If the following screen appears, the USB cable is
connected.
zPerform the following steps.
1. Turn OFF the machine.
2. Disconnect the USB cable.
3. Click [Cancel].
Step 2: Select the language and place of residence.
• In some countries, the [Select Language] and [Select Your Place of Residence] dialog boxes will not be
displayed. Go to Step 3.
Step 3: Install the software.
• To install Adobe RGB (1998), click Custom Install and follow the instructions on the screen.
• Adobe RGB (1998) cannot be installed in Windows Me and Windows 98
Step 4: Connect the USB cable.
1When the [Printer Connection] appears, connect the machine to the computer
with the USB cable.
2Turn ON the machine.
3Click [Exit].
• If prompted to, restart your computer.
US only
• When the Registration window appears, follow the on-screen instructions to ensure product support.
The serial number is located inside the machine. (See “Install the FINE Cartridge.” on the reverse side of
this sheet)
The following software programs are included on the Setup CD-ROM:
IMPORTANT
• Do not connect the machine to Mac OS 9 or Mac OS X Classic environments since they are not
supported.
Step 1: Turn ON the machine, and connect the USB cable.
Step 2: Prepare the Setup CD-ROM.
1Turn ON your computer, and start Mac OS X.
2Insert the Setup CD-ROM into the CD-ROM drive.
• If the CD-ROM folder does not open automatically, double-click the CD-ROM icon on the desktop.
3Double-click [Setup] on the Setup CD-ROM, or click [Setup] on the Setup CD-
ROM and click [File] menu and then select [Open].
Step 3: Enter the name and password for an Administrator Account.
1Enter the name for the Administrator.
2Enter the password and then click [OK].
Step 4: Select the language and place of residence.
• In some countries, the [Select Language] and [Select Your Place of Residence] dialog boxes will not be
displayed. Go to Step 5.
Step 5: Install the software.
US only
• When the Registration window appears, follow the on-screen instructions to ensure product support.
The serial number is located inside the machine. (See “3 Install the FINE Cartridge.” on the reverse side of
this sheet)
* When connecting from Mac OS X v.10.3.3 or earlier:
Restarting the computer while connected to the machine may cause the machine not to be detected. To
resolve this, either unplug the USB cable then plug it back in again, or turn the machine OFF then back
ON again.
zPerform the following to make sure the driver has been installed correctly.
1. Select [Applications] from the [Go] menu.
2. Double-click the [Printer Setup Utility] ([Print Center] when using Mac OS X v.10.2.8) icon.
If the printer is displayed in the [Printer List], the printer driver is installed.
If the printer is not displayed in the [Printer List], click [Add] in the [Printer List] and select
[USB] from the pop-up menu. Select your machine from the [Product] list and click [Add].
• You can set the scan operation to start with the Operation Panel of the machine. For details, see the User's
Guide.
You now have completed installation of the software.
On-screen Manual MP Drivers MP Navigator
Easy-PhotoPrint Easy-WebPrint ScanSoft OmniPage SE
ArcSoft PhotoStudio My Printer*
* This may not be available depending on the country of purchase.
1Select the language to use with this
CD-ROM and then click [Next].
2Select your place of residence and
then click [Next].
1Click [Easy Install], then click [Install].
• To read descriptions of the software programs, set the mouse on the item.
2Read the License Agreement, then click [Yes].
• Installation begins. Follow the displayed instructions.
Click
Click Click
Click
Click
Click
On-screen Manual MP Drivers MP Navigator
Easy-PhotoPrint ScanSoft OmniPage SE*ArcSoft PhotoStudio
*This may not be available depending on the country of purchase.
1Select the language to use with this
CD-ROM and then click [Next].
2Select your place of residence and
then click [Next].
1Click [Easy Install], then click [Install].
• To read descriptions of the software programs, set the mouse on the item.
2Click [Yes].
• Installation begins. Follow the displayed
instructions.
3Click [Restart] to restart your
computer.
Enter Click
Click
Click
Click
Click
Click
