GRAPHIC ARTS
LARGE-FORMAT PRINTING
imagePROGRAF

SPECIFICATIONS
imagePROGRAF
Print-Heads
PF-05 (2)
Technology
FINE (Full-photolithography Inkjet Nozzle Engineering)
Configuration
Two Print-Heads (Total 12 Colors)
6 Colors per Print-Head
Print-Head (L) Y/PC/C/PGY/GY/MBK
Print-Head (R) PM/M/BK/R/G/B
Number of Nozzles
2,560 per Color (30,720 Total)
Droplet Size
Uniform 4 Picoliter for all colors
Nozzle Pitch (Head Resolution)
1200 dpi
Print Head Swath
1.07 inch
Print Resolution (Max.)
2400 x 1200 dpi
Ink Type
LUCIA EX Ink (Pigment-based)
Ink Tank
PFI-105 (130ml): (BK, MBK, C, M, Y, PC, PM, GY,
PGY, R, G, B)
Colors
Cyan, Photo Cyan, Magenta, Photo Magenta,
Yellow, Black, Matte Black, Gray, Photo Gray, Red,
Green, Blue
Ink Tank Shipped with Printer
12 Colors (90ml Starter Tank Each Color)
Ink Supply Method
Tubing System
Nozzle Recovery System
Non-firing Nozzle Detection and Compensation
Printer Controller
L-COA Controller
Printer Memory
384MB
Hard Disk Capacity
160GB (iPF6350 only)
Media Feed
Roll Feed
One Roll, Front Output
Top-Loading Manual Feed
One Sheet, Front Output
Front-Loading Manual Feed
One Sheet, Front Output
Media Width
8”–24” (Cut Sheet and Roll)
Minimum Media Length
Top-Loading Manual Feed
11.0” (279mm)
Front-Loading Manual Feed
13.8” (350mm)
Roll Feed
8” (203mm)
Maximum Print Length
Manual Feed (Top)
63” (1.6m)
Manual Feed (Front)
36” (914mm)
Roll Feed
59 Feet (18m)*
* The maximum printable length varies depending on the
application, OS, and RIP used. The maximum printable
length from Canon Printer Driver is 50 feet.
** For Adobe®Photoshop 6, 7, CS, CS2, CS3, CS4 running
on Windows 2000/XP/Windows Vista (32 bit)/Windows 7
or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
*** For Digital Photo Professional version 2.1 or later running
on Windows 2000/XP/Windows Vista (32 bit)/Windows 7
or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
**** Not compatible with Windows 64-bit OS.
  For Canon Printer Driver. For printing from PostScript®
applications such as Adobe Illustrator®or QuarkXPress,®
please use a PostScript compatible RIP package. For
a list of Canon recommended RIP packages, please
consult with Canon Alliance and Industry Market
program list of RIP vendors.
Borderless Printing Width (Roll Media Only)
10” (254mm), B4 (257mm), A3+ (329mm),
14” (356mm), 16” (407mm), A2 (420mm), A2+/17”
(432mm), B2 (515mm), A1 (594mm), 24” (610mm)
Media Cutter
Built-in Durable Rotary Blade
Printer Stand
Standard
Media Thickness
Top-Loading Manual Feed
0.07mm-0.8mm (2.8mil-31.4mil)
Front-Loading Manual Feed
0.5mm-1.5mm (19.6mil-59.0mil)
Roll Feed
0.07mm-0.8mm (2.8-31.4mil)
Media Core Sizes
2” or 3” Core (with Supplied Adapter)
Printable Margins
Manual Feed (Top/Front)
Leading and Left/Right Edges: 0.12” (3mm)
Trailing Edge, Front Feed: 0.90” (23mm)
Trailing Edge, Top Feed: 0.12” (3mm) Except Art Paper
Top Feed (Art Paper): 0.90” (23mm)
Roll Feed
All Sides: 0.12” (3mm) or 0” for Borderless
Maximum Media Roll Outer Diameter
5.9” (150mm)
Bundled Software
Printing Software
Canon Printer Driver, Print Plug-in for Photoshop®,**
Print Plug-in for Digital Photo Professional,***
Printer Driver Extra Kit**** (Free Layout,
imageRUNNER®Linking Function), Print Plug-in for
Microsoft®Office
Applications
PosterArtist Lite
Digital Photo Front-Access
Utilities
imagePROGRAF®Status Monitor (Windows®), Print
Monitor (Macintosh®), Media Configuration Tool,
Remote UI, Accounting Manager
Printer Language
GARO (Canon Proprietary)
Operating Systemu
Windows 2000 (32 bit), XP (32/64 bit), Server 2003
(32/64 bit), Server 2008 (32/64 bit), Windows Vista®
(32/64 bit), Windows 7 (32/64 bit) Macintosh OS X®
10.3.9-10.6 (32 bit), OS X 10.5-10.6 (64bit)
Interface
Standard
USB 2.0 High-Speed
10/100/1000Base-T/TX
Acoustic Noise
Operation
47dB or Less
Power Supply
AC 100-120V (50-60Hz)
Power Consumption
Maximum
100W or Less
Standby
6W or Less
Power Off
Less than 1W (compliant with executive order)
Certifications
UL, FCC Class B, ENERGY STAR®
Operational Environment
Temperature
59–86 F° (15–30 C°)
Relative Humidity
10–80% (No Condensation)
Dimensions with Stand (H x W x D)
39.1” x 46.4” x 34.3”
Weight
Approx. 146 lb. with Stand
(Excludes Ink Tank and Print-Heads)
Package Dimensions (H x W x D)/ Weight
25.4” x 52.0” x 36.0”/236 lb.
User-Replaceable Items
Print-Head (PF-05)
Maintenance Cartridge (MC-16)
Options
Roll Holder Set (RH-25)
PosterArtist
